Black & Decker Spatula Smart M175 Installation instructions

1-800-231-9786
QUESTIONS? Please call us TOLL FREE
?
MODELS M175/M175W
SAVE THIS USE AND CARE BOOK
Spatula Smart® Mixer
With Power Boost
M175W Shown

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
■Read all instructions.
■To protect against a risk of electric shock, do not immerse mixer,
cord, plug, or base unit in water or other liquid.
■Close supervision is necessary when any appliance is used by or
near children.
■Unplug from outlet when not in use, before putting on or taking
off parts, and before cleaning.
■Avoid contacting moving parts. Keep hands, hair, clothing, and
handheld spatulas and other utensils away from beaters/whisks
during operation to prevent injury and/or damage to the mixer.
■Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions or has been damaged in any
manner. Return the appliance to an authorized service center
for examination, repair, or adjustment.
■The use of attachments not recommended by the appliance
manufacturer may cause injuries.
■Do not use outdoors.
■Do not let cord hang over the edge of table or counter or touch
hot surfaces.
■Remove beaters/whisks and spatula attachment from mixer
before washing.
■Do not use appliance for other than intended use.
■Mixing flammable non-food substances may be hazardous.
2

■Do not operate in the presence of explosive and/or flammable
fumes.
■This product is intended for household use only and not for com-
mercial or industrial use.
■Do not abuse the cord. Never carry the mixer by the cord or
yank the cord to disconnect it from an outlet; instead, grasp the
plug and pull to disconnect.
■Do not attempt to repair the mixer yourself; instead take it to a
Black & Decker (U.S.) Inc. Household Appliance Company-
Owned or Authorized Service Center for repair. Call the toll-free
“800” number listed on the cover of this book for the location of
the Service Center nearest you.
POLARIZED PLUG This appliance has a polarized plug—
one blade is wider than the other. To
reduce the risk of electric shock, this
plug will fit into a polarized outlet only
one way. If the plug does not fit fully
into the outlet, reverse it. If it still does
not fit, contact a qualified electrician.
Do not attempt to defeat this safety
feature by modifying the plug in any
way.
SAVE THESE INSTRUCTIONS
3

POWER BOOST
The Power Boost feature works
great on tough mixing tasks and
has easy-access thumb control.
(Figure A)
The Power Boost feature lets you
increase the mixing speed to the
maximum power level from any
speed setting by depressing the
Power Boost Button. When you
feel the Mixer slowing down or
straining in tough mixing tasks
Power Boost Button
Speed Control
Switch
Beaters
Spatula
Attachment
Beater Eject
Lever
Heel Rest
Convenience Features
4
Figure A
Bonus Whisks
(M175W Only)

Figure B
5
(such as mixing cookie dough), just
press the Power Boost Button to get
the maximum mixing performance.
As soon as the Power Boost Button
is released, the Mixer will return to
the speed setting you were previ-
ously using.
BEATER EJECT LEVER
The Spatula Smart® Mixer fea-
tures a convenient Beater Eject
Lever which is located below the
handle. It allows for easy release
of the Beaters/Whisks using the
index finger. (Figure B)
LARGE BEATERS
The large Beaters help you get
fast, thorough mixing results. The
Beaters are dishwasher-safe for
easy cleanup.
BONUS WHISKS (MODEL M175W ONLY)
The Whisks are perfect for whip-
ping cream or eggs. They are
especially useful when making
meringue, omelets, fluffy angel
food cake, or mousse. Like the
Beaters, the Whisks are
dishwasher-safe.
SPATULA ATTACHMENT
The Spatula Attachment is used with
the Beaters and allows you to scrape
dry ingredients and batter from the
bowl sides continuously while mix-
ing. It snaps off for easy dishwasher
or soap and water cleaning.

6
1. Before using the Beaters, be
sure the Mixer is unplugged and
the Speed Control Switch is in the
OFF position. To insert a Beater,
grasp the Mixer with one hand and
the Beater stem with the other.
Insert the Beater into the opening;
you may have to rotate it slightly
until it locks into place. Use the
same method when inserting the
Whisks (Model M175W only).
Repeat for the other Beater/Whisk.
2. Plug the Cord into an outlet.
3. Place the ingredients into a
bowl, grip the Mixer handle, and
position the Beaters/Whisks in the
center of the food to be mixed.
4. Select the appropriate speed
setting for the task. See the
“Mixing Guide” on page 9.
5. Guide the Beaters/Whisks con-
tinuously through the mixture for
uniform mixing. Whenever you
wish to scrape the sides and bot-
tom of the bowl using a handheld
utensil, be sure to turn the Speed
How To Use

7
Control Switch OFF. Place the
Mixer on the Heel Rest so that
batter can drain into the bowl.
(Figure C)
6. To remove the Beaters/Whisk,
push the Beater Eject Lever up
with your index finger of one hand,
then pull the Beater/Whisk out of
the Mixer with the other hand.
Use the Spatula Attachment during
mixing to scrape dry ingredients or
batter from the bowl as you mix. It
is designed for use when mixing
thin (pudding, pancake batter) to
medium batters (cake mixes,
muffins, frosting) and for whipping
mashed potatoes. It is not recom-
mended when beating egg whites,
whipping cream, or when mixing
thick cookie dough. Do NOT use
the Spatula Attachment with the
Whisks (Model M175W only).
1. Insert the Beaters into the
Mixer. Be sure the Mixer is
unplugged and the speed control
Switch is in the OFF position.
USING THE SPATULA
ATTACHMENT
Figure C

2. Hold the Mixer by the handle
with the Beaters facing forward.
The Spatula attachment should be
positioned so that the Spatula is to
the right of the Beaters.
3. Weave the top of the Spatula
Attachment under the left Beater
shaft and over the right Beater
shaft. The word “Front” on the
Attachment should face out from
the front of the Mixer. Snap the
Attachment onto the Beater shafts.
(Figure D)
4. As you mix, place the front edge
of the Spatula Attachment against
the side of the bowl and move it
forward slowly along the side of
bowl to scrape away buildup and
blend ingredients or batter back
into the Beaters. (Figure E)
NOTE: If the Spatula Attachment
detaches during use, be sure to
turn OFF the Mixer before attempt-
ing to reattach the Spatula to the
Beaters.
Figure D
8
Figure E

SPEED FUNCTION USE
1 Blend To combine liquids, fold in
dry ingredients, egg whites, and
whipped cream.
2 Stir To prepare sauces, puddings,
muffins, and quick breads.
3 Mix To prepare batters and mixes.
4 Beat To cream butter or sugar, make
cookie dough, cake mixes, and
frostings.
5 Whip To whip fluffy mixtures, whipped
cream, eggs, and mashed
potatoes.
Power Use at any Maximum power for tough tasks.
Boost speed setting
No other maintenance is required other than the care
mentioned here. Repairs, if necessary, must be per-
formed by a Black & Decker (U.S.) Inc. Household
Appliance Company-Owned or Authorized Service
Center. For the Service Center nearest you, call the
toll-free “800” number on the cover of this book.
9
Mixing Guide
Care and Cleaning

1. Be sure the Speed Control Switch is in the OFF
position before cleaning any part of the Mixer.
Unplug the cord and eject the Beaters/Whisks.
Remove the Spatula Attachment, if used.
2. The Beaters, Whisks (Model M175W only), and
Spatula Attachment may be washed in hot, sudsy
water or in a dishwasher. Be sure to dry all parts
thoroughly before storing.
3. Clean the Mixer or cord with a damp cloth. To
remove stubborn spots, wipe surfaces with a cloth
dampened in sudsy water or a mild, non-abrasive
cleaner. Follow with a clean, damp cloth. Do not
use abrasive cleaners on any part of the Mixer as
they can damage the finish.
1. For longer life, avoid jerking the Power Cord or
straining it at the plug connection. To store, coil the
Cord in loops and secure it with a twist tie. Do not
wrap the cord around the Mixer.
2. Store the Beaters, Whisks (Model M175W only),
and Spatula Attachment in a drawer or in the origi-
nal packaging.
HOW TO BEAT EGG WHITES
• Beaters/Whisks and bowl must be clean.
• Be sure there is no egg yolk in the egg whites.
• For maximum volume, egg whites should be at
room temperature.
CLEANING
10
STORING
THE MIXER
Mixing Tips

• Beat at the highest speed (Whip #5) until egg
whites are the desired consistency.
• Beating time varies with the freshness of eggs.
NOTE: For best results when beating egg whites,
do not use an aluminum or plastic bowl. Use a
stainless steel, copper, or glass bowl.
HOW TO WHIP CREAM
• Chill the cream, Beaters, and bowl.
• Start with the lowest setting (to minimize splatter)
as the cream begins to thicken, gradually
increase to WHIP (Setting #5).
• Whipping time varies with fat content, age,
and temperature of cream.
NOTE: The Spatula Attachment is NOT recom-
mended for use when whipping cream as volume
may be reduced.
11

12
Service, if necessary, must be performed by a
Black & Decker (U.S.) Inc., Household Appliance
Company-Owned or Authorized Service Center. The
Service Center nearest you can be found in the yel-
low pages of your phone book under “Appliances-
Small-Repairing.” For your convenience a listing of
our Company-Owned Service Centers can be found
on pages 12-15.
If shipping or mailing your Mixer, pack the unit
carefully in a sturdy carton with enough packing
material to prevent damage. The original carton is
not suitable for mailing. Include a note describing
the problem to our Service Center and be sure to
give your return address. We also suggest that you
insure the package for your protection.
Consumer replaceable parts and accessories are
also available at Black & Decker (U.S.) Inc.,
Household Appliance Company-Owned or
Authorized Service Centers.
SERVICE
OR REPAIR
ALABAMA
BIRMINGHAM — 2412 Green Springs, Hwy., 35209
205-942-0538
MOBILE — 3831 Airport Blvd., 36608 205-343-6624
ALASKA
ANCHORAGE — 910 West International Airport Rd., 99518
907-563-4664
ARIZONA
MESA — 535 South Dobson Rd., Suite 7, 85202
602-461-1074
PHOENIX — 4501 N. 7th Ave., 85013 602-279-6414
TUCSON — 4845 E. Speedway Blvd., 85712
602-323-3388
ARKANSAS
LITTLE ROCK — 519 W. Seventh St., 72201
501-372-3040
CALIFORNIA
ANAHEIM — 540 South State College Blvd., 92806
714-772-4050
CHULA VISTA — 309 Broadway, 91911 619-420-6350
CONCORD — 1500 Monument Blvd., #C2, 94520
510-682-4880
FRESNO — 5412 North Blackstone Ave., 93710
209-435-0810
BLACK AND DECKER COMPANY-OWNED SERVICE CENTERS

LONG BEACH — 2011 South St., 90805 310-422-5825
LOS ANGELES — 4820 South Eastern Ave., Suite “L” 90040
213-720-1834
RIVERSIDE — 6215 Magnolia Ave., Suite B, 92506
714-787-9700
SACRAMENTO — 2033 Fulton Ave., 95825 916-972-9090
SAN DIEGO — 9270 Clairmont Mesa Blvd., 92123
619-279-2011
SAN JOSE — 1185 South Bascom Ave., 95128
408-293-7350
SAN LEANDRO — 15206 East 14th St., 94578
510-276-1610
VAN NUYS — 14920 Victory Blvd., 91411 818-787-5531
COLORADO
DENVER — 1171 South Federal Blvd., Box 19220, 80219
303-922-8325
CONNECTICUT
HARTFORD — 662 Silas Deane Hwy., 06109
203-563-5800
ORANGE — 481 Boston Post Rd., 06477 203-795-3583
DISTRICT OF COLUMBIA
COLMAR MANOR, MD — 4153 Bladensburg Rd., 20710
301-779-3808
FALLS CHURCH, VA — 344 W. Broad St., 22046
703-533-7313
FLORIDA
FT. LAUDERDALE — 799 East Oakland Pk. Blvd., 33334
305-566-5102
FT. MYERS — 5224 Bank St., 33907 813-278-1188
JACKSONVILLE — 920 Cassat Ave., 32205
904-781-2253
MIAMI — 13345 North West Seventh Ave., 33168
305-681-6658
MIAMI — 12233 South Dixie Hwy., 33156 305-232-9497
ORLANDO — 3807 East Colonial Dr., 32803
407-894-7011
ST. PETERSBURG — 5635 49th St. North, 33709
813-525-0273
TAMPA — 3432 West Kennedy Blvd., 33609
813-872-8317
WEST PALM BEACH — 310 South Military Trail, 33415
407-689-3247
GEORGIA
ATLANTA (South) — 5330 Old National Hwy., 30349 404-
762-8844
SMYRNA — 2550 Cobb Parkway South, 30080
404-956-0869
STONE MOUNTAIN — 5723 Memorial Dr., 30083
404-292-4714
HAWAII
HONOLULU — Unit No. 106, Sand Island Access Rd., 96819
808-847-7447
ILLINOIS
CHICAGO (Lincolnwood) — 6710 North Crawford Ave.,
60646 708-673-0923
DES PLAINES — 1277 South Elmhurst Rd., 60018
708-364-5220
LISLE — 2950 Ogden Ave., Unit H, 60532 708-717-1075
MOLINE — 4433 23rd Ave., 61265 309-762-3000
OAK LAWN — 6343 W. 95th St., 60453 708-423-7212
WAUKEGAN — 31 S. Greenbay Rd., 60085
703-249-4390
INDIANA
EVANSVILLE — 307 First Ave., Crescent Ctr., 47710
812-425-4269
HAMMOND — 7103 Kennedy Ave., 46323 219-845-5100
INDIANAPOLIS (Speedway) — 5999 Crawfordsville Rd.,
46224 317-243-8308
IOWA
DES MOINES — 3427 Merle Hay Rd., 50310
515-270-1340
KANSAS
WICHITA — 155 South West St., 67213 316-943-1271
KENTUCKY
LOUISVILLE — 5211 Preston Hwy., 40213 502-968-7100
LOUISIANA
BATON ROUGE — 11859 Florida Blvd., 70815
504-272-8111
HARVEY — 2500 Lapalco Blvd., 70058 504-366-8676
METAIRIE (New Orleans) — 3504 North Causeway Blvd.,
70002 504-837-2550
SHREVEPORT — 7710-7714 Jewella Rd., 71108
318-688-1553
13

MARYLAND
BALTIMORE — 4712 Erdman Ave., 21205 410-485-5550
BALTIMORE — 29-31 Cranbrook Rd., Cockeysville, 21030
410-666-5966
COLMAR MANOR (Wash. D.C.) — 4153 Bladensburg Rd.,
20722 , 301-779-3808
PASADENA — 8220 Ritchie Hwy., 21122 410-647-8456
MASSACHUSETTS
BRIGHTON (Boston) — 12 Market St., 02135
617-782-6264
SEEKONK — 120 Highland Ave., 02771 508-336-6510
MICHIGAN
GRAND RAPIDS — 3040 28th St.,SE, 49512
616-949-8331
LANSING — 3205 W. Saginaw Hwy., 48917
517-323-4181
WARREN — 27035 Van Dyke Blvd., 48093 313-756-6711
WESTLAND — 8067 N. Wayne Rd., 48185 313-427-1520
MINNESOTA
BLOOMINGTON — 9517 Lyndale Ave., South, 55420 612-
884-9191
MISSOURI
KANSAS CITY — 4324 Main St., 64111 816-531-0629
ST. ANN — 3637 North Lindbergh Blvd., 63074
314-739-4661
ST. LOUIS — 12852 Manchester Rd., 63131
314-821-8740
NEBRASKA
OMAHA — 4225 South 84th St., 68127 402-592-5666
NEVADA
LAS VEGAS — 3411 East Charleston Blvd., 89104
702-641-6555
NEW JERSEY
CHERRY HILL — 1444 East Marlton Pike (Rt. 70), 08034
609-429-2822
LITTLE FALLS — 1189 U.S. Hwy. 46, 07424
201-256-9373
SCOTCH PLAINS — 2520 Route #22 East, 07076
908-233-5665
NEW MEXICO
ALBUQUERQUE — 5617 Menaul Blvd., N.E., 87110
505-884-1002
NEW YORK
ALBANY (Latham) — 836 Troy-Schenectady Rd., 12110
518-785-1867
BUFFALO — 881 West Delavan Ave., 14209
716-884-6220
CENTEREACH L.I. — 2061-63 Middle Country Rd., 11720
516-737-4706
NEW YORK (Elmhurst) — 77-20 Queens Blvd., 11373
718-335-1042
NEW YORK (Manhattan) — 50 West 23rd St., 10010
212-929-6450
NEW YORK (Westbury, L.I.) — 1061 Old Country Rd., 11590
516-997-6140
ROCHESTER — 2969 W. Henrietta Rd., 14623
716-424-1310
SYRACUSE — 3485 Erie Blvd., East, 13214 315-446-3086
NORTH CAROLINA
CHARLOTTE — 3007 East Independence Blvd., 28205
704-374-1779
GREENSBORO — 3716 High Point Rd., 27407
919-852-1300
RALEIGH — 2930 Capital Blvd., 27604 919-878-0357
OHIO
CINCINNATI — 2310 East Sharon Rd., 45241
513-772-3111
COLUMBUS — 3975 East Livingston Ave., 43227
614-237-0461
DAYTON — 2898 South Dixie Drive, 45409 513-298-1951
MAYFIELD HEIGHTS — 5881 Mayfield Rd., 44124
216-449-2770
PARMA HEIGHTS (Cleveland) — 6483 Pearl Rd., 44130
216-842-9100
TOLEDO — 3231 Dorr St., 43607 419-531-8921
OKLAHOMA
OKLAHOMA CITY — 1318 Linwood Blvd., 73106
405-232-7515
TULSA — 3120 S. Sheridan Rd, 74145 918-622-5666
OREGON
PORTLAND — 1640 NW Johnson St., 97209
503-228-8631
14

PENNSYLVANIA
ALLENTOWN (Whitehall) — 2242 MacArthur Rd., 18052
215-435-9544
EVANS CITY — Cranberry Town Center Plaza, 20808 Rt. 19
N., 16033 412-779-9600
HARRISBURG — 6080 Allentown Blvd., 17112
717-545-0651
LANCASTER — 118 Keller Ave., 17601 717-393-5251
PHILADELPHIA — 9977-81 Bustleton Ave., 19115
215-464-7771
PHILADELPHIA — 333 North 20th St., 19103
215-564-5520
PITTSBURGH — 5437 Baum Blvd., 15232 412-362-2700
WILKES-BARRE — 759 Kidder St., 18702 717-824-5704
PUERTO RICO
GUAYNABO — “C” Street # 14, Rexco Industrial Park,
00922-1924 809-783-3535
RHODE ISLAND
SEEKONK, MA — 120 Highland Ave., 02771
508-336-6510
SOUTH CAROLINA
GREENVILLE — 1557 Laurens Rd., 29607 803-232-3038
TENNESSEE
CHATTANOOGA — Perimeter Place Shopping Ctr., Sp. E,
6231 Perimeter Dr., 37421 615-894-5957
KNOXVILLE — 4118 North Broadway, 37917
615-688-0921
MEMPHIS — 1085 East Brooks Rd., 38116 901-332-3444
NASHVILLE — 4811 Nolensville Rd., 37211 615-833-8277
TEXAS
AMARILLO — 3008 West 6th Ave., 79106 806-373-1531
AUSTIN — 6549 Burnet Rd., 78757 512-459-1133
DALLAS — 2257 Royal Lane, 75229 214-620-8655
EL PASO — 6822 Gateway East, 79915 915-778-9769
FORT WORTH — 721 North Beach St., 76111
817-831-3828
GARLAND — 78 West Centerville Rd., 75043
214-686-9302
HOUSTON — 536 East Tidwell Rd., 77022 713-692-7111
SAN ANTONIO — 500 Culebra Ave., 78201 210-732-1221
WEBSTER — 100 East Nasa Road One, Ste. 75, 77598 713-
338-4556
UTAH
SALT LAKE CITY — 1541 S. Third West St., 84115
801-486-5828
VIRGINIA
FALLS CHURCH — 344 W. Broad St., 22046 703-533-7313
HAMPTON — 3416 W. Mercury Blvd., 23666
804-826-9382
NORFOLK — 7631 Sewells Point Rd., 23513
804-480-3333
RICHMOND — 1424 Chamberlayne Ave., 23222
804-649-9245
WASHINGTON
SEATTLE — 421 S. Michigan, 98108 206-763-2010
SPOKANE — N. 7011 Division St., 99208 509-467-8190
TACOMA — 2602 S. 38th St., 98409 206-473-6040
WEST VIRGINIA
CHARLESTON — 1638 Sixth Ave., 25312 304-343-0289
WISCONSIN
MILWAUKEE (Wauwatosa) — 10424 W. Bluemound Rd.,
53226, 414-453-4240
REV: 9/94
15

Black & Decker (U.S.) Inc. warrants this product
against any defects that are due to faulty material
or workmanship for a two-year period after the
original date of consumer purchase or receipt as a
gift. This warranty does not include damage to the
product resulting from accident or misuse.
If the product should become defective within the
warranty period, we will repair it or elect to
replace it free of charge. We will return your prod-
uct, transportation charges prepaid, provided it is
delivered prepaid to any Black & Decker (U.S.)
Inc., Household Appliance Company-Owned or
Authorized Service Center.
This warranty gives you specific legal rights and
you may also have other rights which vary from
state to state.
Answers to any questions regarding warranty or
service locations may be obtained by calling toll
free, 1-800-231-9786, or by writing:
Consumer Assistance and Information
Black & Decker (U.S.) Inc.
626 Hanover Pike
Hampstead, MD 21074-0618
16
Listed by Underwriters Laboratories Inc.
Copyright © 1991 - 1995 Black & Decker
Pub. No. 168633-06-RV01
Printed in Hong Kong
FULL
TWO-YEAR
WARRANTY
