Black & Decker REVCOM12C User manual

final page size: 8.5 x 5.5 in
Please read before returning this product for anyreason.
Àlire avant de retourner ce produit pour quelque raison que cesoit.
Lea el manual antes de devolver este producto por cualquiermotivo.
INSTRUCTION MANUAL
MODE D’EMPLOI
MANUAL DE INSTRUCCIONES
REVCOM12C
OSCILLATING MULTI‑TOOL
OUTIL MULTIPLE OSCILLANT
MULTI‑HERRAMIENTA OSCILATORIA

English (original instructions) 3
Français (traduction de la notice d’instructions originale) 10
Español (traducido de las instrucciones originales) 18

1
Fig. A REVCOM12C
Components
1 Main handle
2 On/Off button
3 Tool‑free accessory clamping lever
4 Charger jack port
5 Charging LED
6 Charger
7 Charger jack plug
8 Diamond shaped sanding platen
9 Sand paper
10 Wood/Metal blade
11 Scraper blade
25
7
6
1
4
310
9
8
11
Componentes
1 Manija principal
2 Botón de encendido/apagado
3 Palanca de sujeción de accesorio
sin herramientas
4 Puerto de conector de cargador
5 LED de carga
6 Cargador
7 Enchufe de conector de cargador
8 Plato de lijado en forma de diamante
9 Papel lija
10 Cuchilla para madera/metal
11 Cuchilla raspadora
Composants
1 Poignée principale
2 Bouton Marche/Arrêt
3 Levier d’attache d’accessoires sans outil
4 Port de la prise du chargeur
5 Voyant DEL de chargement
6 Chargeur
7 Connecteur mâle du chargeur
8 Plateau de ponçage en forme de
diamant
9 Papier de verre
10 Lame pour bois/métal
11 Lame de raclage

2
Fig.B Fig.C
Fig.D Fig.E
Fig.G
Fig.F
8
10
15
4
10
13
12
14
16
7
4
5
8
91

3
ENGLISH
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electricshock.
f ) If operating a power tool in a damp location
is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of a GFCI
reduces the risk of electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personalinjury.
b ) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non‑skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off‑position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energizing power tools that have the switch
on invitesaccidents.
d ) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personalinjury.
e ) Do not overreach. Keep proper footing and
balance at all times. This enables better control of the
power tool in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair
can be caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust‑relatedhazards.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with
this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or
seriousinjury.
SAVE ALL WARNINGS
AND INSTRUCTIONS FOR
FUTUREREFERENCE.
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated
(cordless) powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust orfumes.
c ) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to losecontrol.
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert
symbols and words to alert you to hazardous situations and
your risk of personal injury or propertydamage.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
(Used without word) Indicates a safety relatedmessage.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Intended Use
This oscillating tool is designed for residential detail sanding,
plunge cutting, flush cutting, removal of excess materials,
and surface preparationapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
English (original instructions)
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.

ENGLISH
4
Additional Safety Rules for Oscillating
Multi-Tools
• Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electricshock.
• Use clamps or another practical way to secure and
support the work piece to a stable platform. Holding
the workpiece by hand or against your body leaves it
unstable and may lead to loss ofcontrol.
• Air vents often cover moving parts and should be
avoided. Loose clothes, jewelry or long hair can be caught
in movingparts.
• Disconnect power before using tool near live wires or
where there may be hidden wiring. Cutting accessory
contacting a “live” wire may make exposed metal parts of
the power tool “live” and could give the operator an electric
shock.” Always check for hidden wiring, gas lines, or other
utilities before performing any material cutting or removal
operations with thetool.
• Wait for the cutter to stop before setting the tool
down. An exposed cutter may engage the surface leading
to possible loss of control and seriousinjury.
• Do not operate this tool for long periods of time.
Vibration caused by the operating action of this tool may
cause permanent injury to fingers, hands, and arms. Use
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
orburns.
e ) Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may
exhibit unpredictable behavior resulting in fire,
explosion or risk ofinjury.
f ) Do not expose a battery pack or tool to
fire or excessive temperature. Exposure to
fire or temperature above 265°F (130°C) may
causeexplosion.
g ) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside the
specified range may damage the battery and increase
the risk offire.
6) Service
a ) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power tool
ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized serviceproviders.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of
untrainedusers.
e ) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking
into account the working conditions and the
work to be performed. Use of the power tool for
operations different from those intended could result in
a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury andfire.
c ) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or afire.

5
ENGLISH
Additional Safety Information
WARNING: Never modify the power tool or any part of
it. Damage or personal injury couldresult.
WARNING: ALWAYS use safety glasses. Everyday
eyeglasses are NOT safety glasses. Also use face or
dust mask if cutting operation is dusty. ALWAYS WEAR
CERTIFIED SAFETYEQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratoryprotection.
WARNING:
Some dust created by power sanding,
sawing, grinding, drilling, and other construction activities
contains chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm.
Some examples of these chemicalsare:
• lead from lead‑based paints,
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from
chemically‑treatedlumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter
out microscopicparticles.
• Wear protective clothing and wash exposed areas
with soap and water. Allowing dust to get into your
mouth, eyes, or lay on the skin may promote absorption of
harmfulchemicals. Direct particles away from face andbody.
• Use the appropriate dust extractor vacuum to remove
the vast majority of static and airborne dust. Failure
to remove static and airborne dust could contaminate the
particles. Workers should wash and clean up BEFORE
eating, drinking or smoking. Articles of food, drink, or
smoking should not be left in the work area where dust
would settle onthem.
Environmental Safety
• Paint should be removed in such a manner as to
minimize the amount of dustgenerated.
• Areas where paint removal is occurring should be sealed
with plastic sheeting of 4milsthickness.
• Sanding should be done in a manner to reduce tracking
of paint dust outside the workarea.
Cleaning and Disposal
• All surfaces in the work area should be vacuumed and
thoroughly cleaned daily for the duration of the sanding
project. Vacuum filter bags should be changedfrequently.
• Plastic drop cloths should be gathered up and disposed
of along with any dust chips or other removal debris
They should be placed in sealed refuse receptacles and
disposed of through regular trash pick‑up procedures
During clean up, children and pregnant women should
be kept away from the immediate workarea.
• All toys, washable furniture and utensils used by children
should be washed thoroughly before being usedagain.
Specific Safety Warnings and
Instructions:Sanders
Sanding Lead Based Paint
Sanding of lead based paint is NOT RECOMMENDED due
to the difficulty of controlling the contaminated dust.
The greatest danger of lead poisoning is to children and
pregnantwomen.
Since it is difficult to identify whether or not a paint contains
lead without a chemical analysis, we recommend the
following precautions when sanding any paint:
Personal Safety
• No children or pregnant women should enter the work
area where the paint sanding is being done until all clean
up iscompleted.
• A dust mask or respirator should be worn by all persons
entering the work area. The filter should be replaced daily
or whenever the wearer has difficultybreathing.
NOTE: Only those dust masks suitable for working with lead
paint dust and fumes should be used. Ordinary painting
masks do not offer this protection. See your local hardware
dealer for the proper (NIOSH approved)mask.
• NO EATING, DRINKING or SMOKING should be done in
the work area to prevent ingesting contaminated paint
gloves to provide extra cushion, take frequent rest periods,
and limit daily time ofuse.
• Do not restart the cutting operation in the work
piece. Let the tool reach full speed and carefully re‑enter
thecut.
• Do not “jam” the saw blade or apply excessive
pressure. Do not attempt to make an excessive depth
ofcut.
• Keep your hands away from cutting area. Do not reach
under the material beingcut.
• Do not use dull or damaged blades. Bent blade can
break easily or cause kickback. Exercise extreme caution
when handling the accessories. The accessories are very
sharp. Wear protective gloves when changing cutting
accessories. Accessories become hot after prolongedusage.
• Before scraping, check work piece for nails. If there are
nails, either remove them or set them well below intended
finished surface. Striking a nail with accessory edge could
cause the tool tojump.
• Do not wet sand with this tool. Liquids entering the
motor housing are an electrical shockhazard.
• Never work in area which is soaked with a liquid, such
as a solvent or water, or dampened such as newly
applied wallpaper. There is an electrical shock hazard
when working in such conditions with a power tool and
heating of the liquid caused by scraping action may cause
harmful vapors to be emitted from workpiece.
• Do not use sandpaper intended for larger sanding
pads. Larger sandpaper will extend beyond the sanding
pad causing snagging, tearing of the paper or kick‑back.
Extra paper extending beyond the sanding pad can also
cause seriouslacerations.

ENGLISH
6
READ ALL INSTRUCTIONS
Important Safety Instructions for All
Integral Battery Tools
WARNING: Read all safety warnings, instructions,
and cautionary markings for the battery, charger
and product. Failure to follow the warnings and
instructions may result in electric shock, fire and/
or seriousinjury.
• NEVER force a charger plug into thetool.
• DO NOT
modify the charger plug of a non‑compatible
charger in any way to fit into the tool as the battery
may rupture causing serious personalinjury.
• DO NOT charge or use the battery in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Inserting or removing the charger
plug from the tool may ignite the dust orfumes.
• Only charge the battery with the providedcharger.
• DO NOT splash or immerse in water or otherliquids.
• DO NOT allow water or any liquid to entertool.
• DO NOT store or use the tool in locations where the
temperature may reach or exceed 104°F (40°C) (such
as outside sheds or metal buildings in summer). For
best life store tools in a cool, drylocation.
NOTE: Do not store the tool with the switch locked on.
Never tape the switch in the ONposition.
• DO NOT incinerate the tool even if it is severely
damaged or is completely worn out. The battery can
explode in a fire. Toxic fumes and materials are created
when lithium‑ion batteries areburned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open
eye for 15minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte is composed of a
mixture of liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause
respiratory irritation. Provide fresh air. If symptoms
persist, seek medicalattention.
• Battery liquid may be flammable if exposed to spark
orflame.
• Never attempt to open the tool for any reason. If the
tool case is cracked or damaged, do not charge. Do
not crush, drop or damage the tool. Do not use a tool or
charger that has received a sharp blow, been dropped, run
over or damaged in any way (e.g., pierced with a nail, hit
with a hammer, stepped on). Damaged tools should be
returned to the service center forrecycling.
Storage Recommendations
The best storage place is one that is cool and dry, away
from direct sunlight and excess heat or cold. Store the fully
charged tool disconnected from thecharger.
Transportation
NOTE: Integral Li‑ion tools should not be put in checked
baggage on airplanes.
Only for use with S010QU1400040chargers.
BATTERY AND CHARGER
The battery is not fully charged out of the carton. Before using
the charger to charge the battery, read the safety instructions
below and then follow charging proceduresoutlined.
The RBRC® Seal
Please take your spent battery packs to
an authorized BLACK+DECKER service
center or to your local retailer for recycling.
In some areas, it is illegal to place spent
battery packs in the trash. You may also contact your local
recycling center for information on where to drop off the
spent battery pack. Do not place in curbside recycling. For
more information visit www.call2recycle.org. or call the toll
free number in the RBRC®Seal.
RBRC® is a registered trademark of Call 2Recycle,Inc.
The label on your tool may include the following symbols. The
symbols and their definitions are asfollows:
V.........................volts
Hz .......................hertz
min..................... minutes
or DC......direct current
......................Class I Construction
(grounded)
…/min.............. per minute
BPM....................beats per minute
IPM..................... impacts per minute
OPM.................... oscillations per
minute
RPM....................revolutions per
minute
sfpm ...................surface feet per
minute
SPM.................... strokes per minute
A.........................amperes
W........................watts
Wh...................... watt hours
Ah.......................amp hours
or AC........... alternating current
or AC/DC.... alternating or direct
current
......................Class II Construction
(double insulated)
no.......................no load speed
n.........................rated speed
PSI.......................pounds per square
inch
......................earthing terminal
..................... safety alert symbol
..................... visible radiation
do not stare into
the light
..................... wear respiratory
protection
..................... wear eye protection
..................... wear hearing
protection
..................... r ead all documentation
..................... do not expose to rain
WARNING: Always wear proper personal hearing
protection that conforms to ANSI S12.6 (S3.19)
during use. Under some conditions and duration
of use, noise from this product may contribute to
hearingloss.
working environment or pose an increased health risk to
the operator and those in closeproximity.
CAUTION: When not in use, place tool on its
side on a stable surface where it will not cause
a tripping or falling hazard. Some tools with large
battery packs will stand upright on the battery pack
but may be easily knockedover.

7
ENGLISH
Attaching Accessories Using the
Universal Adapter (Fig.E)
CAUTION: To avoid injury, do not use any accessory
for an application where the adaptor may fail to hold
theaccessory.
CAUTION: Read and follow all manufacturers' safety
warnings for any accessories used with thistool.
CAUTION: To avoid injury, ensure adaptor and
accessory are securelytightened.
Non‑BLACK+DECKER accessories can be attached using the
universaladaptor.
1. Place the washer12 on thetool.
2. Place accessory10 on towasher.
3. Tighten and secure adaptor nut13 using hex
wrench14.
To purchase any of the following accessories, please contact
your local service center.
Part Part Number
Outer flange 90583886
Screw 90583887
Ring 90583888
Flange N440293
Installing/Removing Accessories (Fig.C, D)
The tool features an exclusive tool‑free system for faster
accessory changes and adjustments without the need for
wrenches or hex keys like other oscillating toolsystems.
1. Grasp the tool and squeeze the tool‑free accessory
clamp lever4.
2. Clean any residual debris from the tool shaft8 and
the tool‑free accessory clamp holder.
3. Slide the accessory10 between the shaft and the
accessory holder15 making sure the accessory
engages all of the pins16 on the holder and is flush
with the shaft.
4. Release the tool‑free accessory clamp lever.
5. Some accessories, such as scrapers and blades can
be mounted at an angle if required as shown in
Fig.D.
WARNING: Risk of lacerations or burns. Do not touch
the sharp edges of accessories at any time. Do not
touch workpiece or blade immediately after operating
the tool. They can become very hot. Handle carefully.
Always allow accessories and work piece to cool
beforehandling.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious
personal injury, turn unit off before making any
adjustments or removing/installing attachments
or accessories. An accidental start‑up can
causeinjury.
3. You may charge a partially used battery whenever you
desire with no adverse effect on thetool.
Charging the Battery (Fig.A, B)
WARNING: Do not use tool while it is connected to
the charger. The integral battery needs to be charged
before first use and whenever it fails to produce
sufficient power on jobs that were easily done before.
The battery may become warm while charging; this is
normal and does not indicate aproblem.
WARNING:
For use only with the suppliedcharger.
WARNING: Do not charge the battery at ambient
temperatures below 39°F (4°C) or above 104°F (40°C).
NOTE: The charger will not charge a battery if the cell
temperature is below approximately 39°F (4 °C) or above
104°F (40 °C).
From new, the rechargeable cells of the product need a
minimum charge time of 3 to 4hours to ensure fullpower.
1. The switch must be in the OFF position, the tool will not
charge if it is in any other position.
2. Fig. B‑ Plug the jack plug7 of the charger into the
charging socket4 of thetool.
3. Plug the charger 6 into any standard 120Volt 60Hz
electricaloutlet.
4. The charge indicator LED5 on the center of the main
housing1 will illuminate whilecharging.
5. The charge indicator LED5 will turn off upon
completion ofcharging.
NOTE: While charging, the charger may get warm,
this is perfectly normal and safe. It is safe to leave the
appliance connected to the charger indefinitely. The
charger automatically reduces power consumption when
charging iscomplete.
Electronic Protection System
Li‑Ion tools are designed with an Electronic Protection
System that will protect the battery against overloading,
overheating or deep discharge. The tool will automatically
turn off and the battery will need to berecharged.
Important Charging Notes
1. The tool may become warm to the touch while charging.
This is a normal condition, and does not indicate a
problem. To facilitate the cooling of the tool after use,
avoid placing the tool in a warm environment such as in
a metal shed or an uninsulatedtrailer.
2. If the tool does not charge properly, take the tool and
charger to your local servicecenter.
Tool Disposal
This product uses a lithium‑ion rechargeable and recyclable
battery. When the battery no longer holds a charge, the tool
should be recycled. The tool should not be incinerated or
placed in thetrash.
The tool can be taken for disposal to an Authorized Service
Center. Some local retailers are also participating in a national
recycling program (refer to RBRC®). Call your local retailer for
details. If you bring the tool to an Authorized Service Center,
the Center will arrange to recycle the tool and its battery.
Or, contact your local municipality for proper disposal
instructions in your city/town.

ENGLISH
8
Maintenance
WARNING: To reduce the risk of serious
personal injury, turn unit off before making any
adjustments or removing/installing attachments
or accessories. An accidental start‑up can
causeinjury.
Your BLACK+DECKER product has been designed to operate
over a long period of time with a minimum of maintenance.
Helpful Hints
• Always ensure the workpiece is firmly held or clamped to
prevent movement. Any movement of the material may
affect the quality of the cutting or sandingfinish.
• Do not start sanding without having the sandpaper
attached to sandingplaten.
• Use coarse grit paper to sand rough surfaces,
medium grit for smooth surfaces and fine grit for the
finishing surfaces. If necessary, first make a test run on
scrapmaterial.
• Excessive force will reduce the working efficiency and
cause motor overload. Replacing the accessory regularly
will maintain optimum workingefficiency.
• Do not allow the sandpaper to wear away, it will damage
the sanding pad.
• If the tool overheats, run it with no load for 2–3 minutes
to cool the motor. Always keep the bladesharp.
Sanding
WARNING: Fire hazard. When working on metal
surfaces, do not use a vacuum cleaner because sparks
are generated. Wear safety glasses and a dust mask.
Due to the danger of fire, do not use your sander to
sand magnesium surfaces. Do not use for wetsanding.
NOTE: Do not rest fingers on platen during use. Move it in
long sweeping strokes across the surface, letting it do the
work. Light pressure is all that is required forsanding.
dust mask if cutting operation is dusty. ALWAYS WEAR
CERTIFIED SAFETYEQUIPMENT.
WARNING: CUT HAZARD. Before cutting any type of
material, be sure it is firmly anchored or clamped to
preventslipping.
WARNING: CUT HAZARD. Let the tool work at its own
pace. Do not overload, blade breakage mayoccur.
1. Clearly mark the desired cutting area.
2. Switch the tool on before applying pressure and
slowly feed the blade into the workpiece at the
marked location.
WARNING: CUT HAZARD. Ensure the blade is not in
contact with cutting surface before startingsaw.
3. Advance the blade along the cutting line until cut is
completed. Don’t force the tool; let the blade cut at its
ownspeed.
4. Switch the tooloff.
NOTE:
Always use the appropriate type of saw blade for
the workpiece material and type of cut. Cut only with sharp
blades; they cut cleaner, faster and put less strain on the motor
while cutting.
To Make a Cut
NOTICE: The cutting capacity of the tool is limited by
the type and size of accessory used. Always make sure
to use the correct accessory for your application
Plunge Cutting
WARNING: Hold saw firmly with both hands for all
cuttingoperations.
WARNING: Inspect work area for hidden electrical
wiring, gas pipes or water pipes before making blind
or plunge cuts. Failure to do so may result in electrical
shock, fire, explosion, or propertydamage.
WARNING: ALWAYS use safety glasses. Everyday
eyeglasses are NOT safety glasses. Also use face or
On/Off Button (Fig. A)
CAUTION: The tool will start at full speed.ALWAYS
hold securely in anticipation of a suddenreaction.
1. To turn the tool ON, press the On/Off button to the
ON " l" position.
2. To turn the tool OFF, press the On/Off button to the
OFF " O" position.
Proper Hand Position (Fig.G)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the
mainhandle1.
OPERATION
WARNING: To reduce the risk of serious
personal injury, turn unit off before making any
adjustments or removing/installing attachments
or accessories. An accidental start‑up can
causeinjury.
Installing/Removing Sanding Sheets (Fig.F)
Optional Accessory
A diamond shaped platen uses a hook and loop adhesion
system to attach the sanding sheets.The platen allows you to
use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen accesory as described under
Installing/RemovingAccessories.
2. Align the edges on the sanding sheet with the edge
of the sanding platen and press the sanding sheet
onto the platen.
3. Firmly press the base with the sanding sheet
attached against a flat surface and briefly switch the
tool on. This provides for good adhesion between
the platen and the sanding sheet and also helps to
prevent premature wear.
NOTE: When the tip of the sanding sheet becomes
worn, detach the sheet from the platen, rotate
and reapply.
