Black Box LR1530A-EU-R3 Instruction Manual

Series 500
Frame Relay/Leased Line
Bridge/Router
User and System Administration Guide
LR1530A-R3, LR1530A-EU-R3, LR1531A-R2, LR1535A-R2
5500099-10 equivalent to
5500086-12
© copyright 2002 by Black Box Corporation.

Federal Communications Commission (FCC)
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
Warning: The user is cautioned that modifications to this equipment can void the
authority granted by the FCC to operate the equipment.
Canadian Emissions Standard ICES-003
This digital apparatus does not exceed the Class A limits for radio noise emissions
from digital apparatus as set out in the interference-causing equipment standard
entitled “Digital Apparatus”, ICES-003 of the Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques”, NMB-003 édictée par le ministre des Communications.
Specifications
Speed — Ethernet: LAN 10 Mbps, WAN up to 2.048 Mbps
Protocol — IP & IPX Multi-Protocol router capabilities; Protocol-
independent MAC-layer bridging; SNMP terminal access
Indicators — (4) LEDs: Power, LAN, Tx, Rx
Connectors — DB25 female (model 1530A-R2 Universal or model
1530A V.35 WAN); RJ45 female (model 1531A 56/64K CSU/DSU
WAN and model 1535A T1/E1 CSU/DSU WAN); RJ45 female
10BaseT (LAN); RJ45 female console port
Power — 12VDC 1A (external) – center positive
Size — 1.6"H x 6.1"W x 4.3"D (4 x 15.5 x 11 cm)
Weight — 15 oz. (500 g);

INSTRUCCIONES DE SEGURIDAD
(Normas Oficiales Mexicanas Electrical Safety Statement)
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el
aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia
futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación
deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la
tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean
recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo
descrito en las instrucciones de operación. Todo otro servicio deberá ser referido
a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su
uso. La colocación del aparato eléctrico sobre una cama, sofá, alfombra o
superficie similar puede bloquea la ventilación, no se debe colocar en libreros o
gabinetes que impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como
radiadores, registros de calor, estufas u otros aparatos (incluyendo amplificadores)
que producen calor.
11. El aparato electico deberá ser connectado a una fuente de poder sólo del tipo
descrito en el instructivo de operación, o como se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del
equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean
pisados ni pellizcados por objectos colocados sobre o contra ellos, poniendo
particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de
energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado
por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados
sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado devera ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
El aparato ha sido tirado o su cubierta ha sido dañada.

Using This Manual
This Installation and Applications Guide provides the basic information
required to initially set up and configure the router. This guide is organized
into the following sections:
“Installation” provides instructions for installing the router.
“Typical Applications & How to Configure Them” provides
simple configuration examples for typical applications in which the
router might be used. The applications described in this document are
for example only and provide a method of quick configuration of the
router. For more complete information on all of the configuration
parameters available, please refer to the PPP Menu Reference Manual
on the accompanying CD-ROM.
“Introduction to Filtering” provides an introduction to the pattern
filtering options of the router. Several examples of typical pattern
filters are also provided.
”Menu Trees” provides a graphical tree type overview of the
structure of the built-in menu system of the router. All of the
configuration is performed using the options provided in the menu
system. The Menu Tree is like an index to the menu options.
“Configuration Pages” provides a place to note the current
configuration of the router for future reference. If a replacement unit
is required, the configuration may be quickly modified to be the same
as the existing unit.
“Octet Locations on Ethernet Frames” provides a graphical
representation of the various common Ethernet frames that the router
will bridge or route. When defining a pattern filter, these frame
displays indicate the offset values to use in order to define the pattern
filter correctly.
“Servicing Information” provides information on opening the case
and changing the straps.

Using the Electronic Reference Manual
The router Reference Manuals are provided as Adobe Acrobat PDF
files on the accompanying CD-ROM. The PPP Menus Reference File
is provided individually for ease of configuration reference.
The Adobe Acrobat Reader program is included on the CD-ROM. It is
also available for most computer operating platforms from Adobe on
the Internet at: www.adobe.com.
The Reference Manual provides the following information:
•Introduction to bridging, routing, and router features
•Pin out references for the link modules
•List of event and alarm logs
•Expanded description of programmable filtering
The router PPP Menus Reference Manual provides the following
information:
•Complete description of the options for the built-in menu
system.

Contents
1 - INSTALLATION 5
Unpack the router 5
Select a Site 5
Identify the Connectors 6
Connect to the Console 7
Make the LAN Connections 7
Make the WAN Link Connection 7
Power Up the router 9
Login and Enter the Required Configuration 9
Mandatory Configuration 10
Setting the Link Interface Type (Universal WAN only) 11
Setting the T1/E1Parameters (T1/E1 WAN only) 12
Identify the Status LEDs 15
2 - TYPICAL APPLICATIONS & HOW TO CONFIGURE
THEM 17
Managing the router Using Menus 18
Conventions 19
Basic Frame Relay Configuration 20
Auto Learning the Frame Relay Configuration 22
Manual Configuration - LMI Type 23
“Quick Start” Frame Relay 24
Basic Leased Line Configuration 26
“Quick Start” PPP Leased Line Connections 26
Should You Bridge or Route? 29
Configure as an Ethernet Bridge 30
Configure as an Ethernet IP router 33
Define an IP Default Gateway 35
Define an IP Static Route 36
Define an IP Subnet Mask 37
Configure as an Ethernet IPX router 40
Novell Servers in Both Locations 40
Novell Servers in One Location Only 42
PPP Link Configuration Overview 44
Numbered Links 44
Unnumbered Links 45
Configure Dynamic Host Configuration Protocol 46
Configure Network Address Translation (NAT) 48
Configure PPP Security 50
Configure Firewall 52

3 - INTRODUCTION TO FILTERING 57
MAC Address Filtering 57
Pattern Filtering 58
Popular Filters 61
Bridge 61
IP & Related Traffic 61
Novell IPX Frames 61
NetBIOS &NetBEUI (Microsoft Windows) 61
Banyan 62
IP router 62
NetBIOS over TCP 62
Other interesting TCP Ports 62
APPENDIX A MENU TREES 63
APPENDIX B OCTET LOCATIONS ON ETHERNET
FRAMES 67
Octet Locations on a Bridged TCP/IP Frame 68
Octet Locations on a Bridged Novell Netware Frame 68
ETHERNET Type Codes 69
Octet Locations on an IP Routed TCP/IP Frame 70
Octet Locations on an IPX Routed Novell Netware Frame 70
Octet Locations on a Bridged XNS Frame 71
APPENDIX C SERVICING INFORMATION 73
Opening the case 73
Identifying the Internal Components 74
Sanity Timer 76
Force ZMODEM Software Load 76
To Clear a “Lost” Password 76
Connecting to the Console Connector 77
WAN Interface Connection 78
Pinout Information 78
V.35 Module: 78
CSU/DSU Module: 78
T1/E1 Module: 79
UNIVERSAL WAN Module: 80
V.35 Link Pinouts 81
RS232C / V.24 Link Pinouts 83
RS530 / RS422 Link Pinouts 84
V.11 / X.21 Link Pinouts 85

Contents
V.11 / X.21 DB25 to DB15 Connector Cable 86
V.35 Null-Modem Cable Configuration 87
The link speed must be defined for each of the two units. 87
RS232 / V.24 Null-Modem Cable 88
RS530 / RS422 Null-Modem Cable 89
APPENDIX D SOFTWARE UPGRADES 91

* * * *

5
1 - INSTALLATION
The router is an Ethernet Bridge/Router that provides bridging,
IP/IPX routing, and compression over a frame relay permanent virtual
circuit or a PPP leased line circuit..
The following instructions provide a quick set-up guide for installation
of the router
Unpack the unit
Rough handling during shipment can damage electronic equipment. As
you unpack the router, carefully check for signs of damage. If damage
is suspected, contact the shipper. Save the box and all packing material
to protect the router should it ever need to be moved or returned for
service.
Check the packing slip that identifies the components and the LAN
connector. The connectors on the rear of the router provide all
external connections to the router.
Select a Site
Place the router in a well-ventilated area. The site should maintain
normal office temperature and humidity levels. Air vents located on
the rear of the router must have an inch or so of clearance from any
object. Units should not be stacked.

Installation
6
Identify the Connectors
Each unit is configured with both straight (MDI) and crossed over
(MDI-X) 10BaseT LAN connectors; the router will auto-sense
between the two. Only one connector may be used at a time.
The router is produced with four different WAN interface modules:
V.35, CSU-DSU, Universal WAN or T1/E1. The type of module in a
unit may be determined by looking at the label over the WAN
connector on the back panel.
Figure 1 - 1Rear View of the CSU-DSU router
Figure 1 - 2 Rear View of the Universal WAN router
Figure 1 - 3 Rear View of the V.35 router
Figure 1 - 4 Rear View of the T1/E1 router
V.35
UNIVERSAL WAN
CSU-DSU
T1/E1

Installation
7
Connect to the Console
Connection to the router operator’s console is made through the RJ-45
connector labeled CONSOLE on the back of the router. A RJ-45
cable and RJ-45 to DB9 (female) converter are provided for connection
to a DB9 (male) connector.
Connect the console port of the router to a computer running an
asynchronous communication package or a standard asynchronous
terminal. The router supports autobaud rates at 1200, 2400, 9600 or
19,200 bps. The router is managed through the use of “hotkey” Menus.
Appendix C provides the pinout information for the console connector
and the DB9 to RJ45 converter.
Make the LAN Connections
Connect the router to the LAN with the available LAN interface cable.
The router may be connected directly to a wiring hub or Ethernet
switch by using the MDI LAN port and a standard 10BaseT cable.
The router may be connected directly to a computer network card by
using the MDI-X LAN port and a standard 10BaseT cable.
Make the WAN Link Connection
The Universal WAN module may be selected to operate as a V.11,
V.35, RS232, or EIA530 interface. The Universal WAN interface
module uses a DB25 connector. Be sure to secure the cable connector
to the router and the communications equipment with connector
screws to prevent accidental disconnection.
WARNING: ensure that the connector cable used with the Universal
interface module has the correct pinouts for the operational mode
selected for the interface (V.11, V.35, RS232, or EIA530). Using the
incorrect cable connector for the operational mode selected may cause
permanent damage to the interface module. Please see Appendix D for
pinout assignments.
Note: When the router is initially powered up, the Universal WAN
will have the default type of “none”. Before the link can be used, it

Installation
8
must be configured to the type of connection service that will be used;
please see the following section for this procedure.
The V.35 module and Universal WAN module in V.35 mode require
interface converters that convert from a DB25 connector to a male 34
pin (V.35) connector used for the V.35 service interface. Be sure to
secure the cable connector to the router and the communications
equipment with connector screws to prevent accidental disconnection.
The T1/E1 and LX411 CSU-DSU interfaces connect with a standard
RJ-45 (RJ-48C specification for T1/E1, RJ-48S specification for
CSU/DSU) connector
After the router is powered up and the router has established
communications with its partner across the WAN, the “Tx” LED will
turn green.

Installation
9
Power Up the router
Once the LAN and Link connections are made and the console is
connected to a terminal, you are ready to power-up the router.
Connect the DC power cord from the supplied power supply to the
back of the router and plug the power supply into the AC wall outlet.
Observe the LEDs as the router powers up. The LEDs will go
through a flashing pattern as the power-up diagnostics are performed.
After the power-up diagnostics are finished, the Power LED will go
from red to green.
The console will also display testing and initialization messages as it
performs these tasks (if this is the first time the router has been
powered up on this console, the display may be unreadable until the
next step is performed).
Enter at least one [RETURN] (up to three if necessary) in order for the
router to determine the baud rate of the terminal used for the console
(i.e., autobaud). The following information will now be seen on the
console connected to the router :
Terminals supported:
ansi, avt, ibm3101, qvt109, qvt102, qvt119,
tvi925, tvi950, vt52, vt100, wyse-50, wyse-vp,
teletype
Enter terminal type:
Select the terminal type being used if listed and enter its name (in lower
case) at the prompt, or choose the terminal type teletype if your
terminal is not listed. This terminal type operates in scroll mode and
may be used successfully until a custom terminal definition is created.
Login and Enter the Required Configuration
At the login screen type a 1 and the default password to enter the menu
system of the router. The default password is BRIDGE (case
sensitive) and should be changed if security is desired.
With the options of the built-in menu system, the router may be
configured to operate within your environment.
Refer to the router PPP Menus Reference Manual file on the
accompanying CD-ROM for a complete description of all the Menu
Options.

Installation
10
Mandatory Configuration
The router requires a minimum amount of mandatory configuration in
order to operate. The following table identifies the configuration
parameters that must be defined for proper operation under the
operational states shown in the table.
Mandatory Configuration
Bridge IP Router IPX Router
None IP Address none
IP Routing
IP Forwarding
Frame Relay PPP Leased Line
None Frame Relay
Disabled
Remote Site Profile
The configuration options required for proper initial operation are
described in Section 2: Typical Applications and How to Configure
Them.
Refer to Section 2 for details on configuring the router. Also refer to
the Menu Reference Manual file on the accompanying CD-ROM for a
complete description of all the Menu Options.
Other options may be changed depending upon specific installation
configurations. Refer to the menu tree in Appendix A for a reference
of the menu structure and options.

Installation
11
Setting the Link Interface Type
(Universal WAN only)
The Universal WAN Interface must be configured to match the service
to which it will be connected.
WARNING: ensure that the connector cable used with the Universal
interface module has the correct pinouts for the operational mode
selected for the interface (V.11/X.21, V.35, RS232/V.24, or
RS530/RS422). Using the incorrect cable connector for the operational
mode selected may cause permanent damage to the interface module.
Please see Appendix D for pinout assignments.
Set Link Interface Type:
Location: Main
ÄConfiguration
ÄWAN Set Up
ÄLink Set Up
ÄLink Interface Type
Select the Service type to which this router will be
connected.
Note: If the module is being changed from one type of service to
another, you must first select “none” before a new selection
may be chosen. Also the link must be toggled through a
disable/enable cycle before the change is brought into effect.
7

Installation
12
Setting the T1/E1Parameters
(T1/E1 WAN only)
The parameters requred for a T1 or E1 connection may be obtained
from your service provider. These may then be entered via the T1/E1
set-up menu to configure the router for that service.
T1/E1 Selection:
Location: Main
ÄConfiguration
ÄWAN Set Up
ÄLink Set Up
ÄT1/E1 Set Up
ÄLink mode
T1 or E1
Set the service mode to which this router will be connected.
Service parameters:
Location: Main
ÄConfiguration
ÄWAN Set Up
ÄLink Set Up
ÄT1/E1 Set Up
ÄSpeed/Channel rate
56/64 kbps
ÄT1/E1framing
framed/unframed/SF/ESF
ÄLine encoding
AMI/INV_AMI/
B8ZS/HDB3
Select the service channel speed, framing format, and encoding
as designated by the service provider.
T1 service requires the specification of a Line Build Out factor. This
parameter modifies the transmitted signal to compensate for
degradation due to line losses between the transmitter and receiver. A
number of different options are available to meet standards for T1 long
haul (direct connection to service providers central office facility), T1
short haul (connection through a local PBX), AT&T TR64211
specification long haul and AT&T TR64211 short haul. Your service
provider will tell you which specification their service requires. Short
7
7

Installation
13
haul LBOs are listed as the length of the cable run (in feet) between the
router and the local exchange.
E1 service does not require line build out selection.
Set Link Interface Type:
Location: Main
ÄConfiguration
ÄWAN Set Up
ÄLink Set Up
ÄT1/E1 Set Up
ÄLBO
as specifed
T1 long-haul LBOs: L0db, L7.5db, L15db, L22.5db
Short haul LBOs: S0to110ft, S110to220ft, S220to330ft,
S330to440ft, S440to550ft, S550to660ft
AT&T standard TR64211long-haul connection: TL0db
AT&T standard TR64211 short-haul connection: TS0to110ft,
TS110to220ft, TS220to330ft, TS330to440ft, TS440to550ft,
TS550to660ft
If fractional T1/E1 service is being provided, you will need to specify
the channels/timeslots to be used.
Set Link Interface Type:
Location: Main
ÄConfiguration
ÄWAN Set Up
ÄLink Set Up
ÄT1/E1 Set Up
ÄSlot/Channel Set Up
ÄStart
first channel
ÄNumber
number of channels
7
7

Installation
14
Some E1 service providers reserve timeslot 16 for network
management use. If your service specifies that timeslot 16 is for their
use, toggle this option to reserved
Set Link Interface Type:
Location: Main
ÄConfiguration
ÄWAN Set Up
ÄLink Set Up
ÄT1/E1 Set Up
ÄSlot/Channel Set Up
ÄE1 Timeslot 16
reserved
7
