FEBRUARY 2000
IC904C
Relay/Digital I/O PCI Card
8 Inputs/8 Outputs
CUSTOMER SUPPORT INFORMATION
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1
8 INPUT/8 OUTPUT PCI CARD
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if
not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication. It
has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart J of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference
when the equipment is operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference, in which case
the user at his own expense will be required to take whatever measures may be
necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
8 INPUT/8 OUTPUT PCI CARD
EMC Directive Statement
Products bearing the CE Label fulfill the requirements of the EMC directive
(89/336/EEC) and of the low-voltage directive (73/23/EEC) issued by the
European Commission.
To obey these directives, the following European standards must be met:
• EN55022 Class A - “Limits and methods of measurement of radio
interference characteristics of information technology equipment”
• EN50082-1 - “Electromagnetic compatibility - Generic immunity
standard” Part 1 : Residential, commercial and light industry
• EN60950 (IEC950) - “Safety of information technology equipment,
including electrical business equipment”
WARNING
This is a Class A Product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
Always use cabling provided with this product if possible. If no cable is provided
or if an alternate cable is required, use high-quality shielded cabling to maintain
compliance with FCC/EMC directives.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
8 INPUT/8 OUTPUT PCI CARD
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama,
sofá, alfombra o superficie similar puede bloquea la ventilación, no se
debe colocar en libreros o gabinetes que impidan el flujo de aire por los
orificios de ventilación.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
8 INPUT/8 OUTPUT PCI CARD
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del
aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en
su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
8 INPUT/8 OUTPUT PCI CARD
TRADEMARKS USED IN THIS MANUAL
Windows®is a registered trademark of Microsoft
Corporation.
Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark
owners.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
8 INPUT/8 OUTPUT PCI CARD
CONTENTS
1. Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 Environmental Specifications. . . . . . . . . . . . . 8
1.2 Power Consumption . . . . . . . . . . . . . . . . . . . . 8
1.3 Mean Time Between Failures (MTBF) . . . . . 8
1.4 Physical Dimensions . . . . . . . . . . . . . . . . . . . . 8
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 What’s Included. . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Technical Description. . . . . . . . . . . . . . . . . . . 10
2.3.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3.2 Input Port . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 Card Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Operating System Installation . . . . . . . . . . . . 14
3.3 System Installation. . . . . . . . . . . . . . . . . . . . . . 14
4. Additional Information . . . . . . . . . . . . . . . . . . . . 16
4.1 Sensor Input Port Pin Assignments
(P3 DB37 Male). . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Output Port (Reed Relay) . . . . . . . . . . . . . . . 16
4.3 Reed Relay Specifications . . . . . . . . . . . . . . . . 16
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
8 INPUT/8 OUTPUT PCI CARD
4.4 Output Port (Reed Relay) Pin Assignments
(P3 DB37 Male). . . . . . . . . . . . . . . . . . . . . . . . 17
4.5 Power and Ground Pin Assignments
(P3 DB37 Male). . . . . . . . . . . . . . . . . . . . . . . . 18
4.6 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.7 Register Description . . . . . . . . . . . . . . . . . . . . 19
Appendix A: Troubleshooting . . . . . . . . . . . . . . . . . 20
A.1 Read this First . . . . . . . . . . . . . . . . . . . . . . . . . 20
A.2 Calling for Technical Support . . . . . . . . . . . . 21
Appendix B: Block Diagram. . . . . . . . . . . . . . . . . . . 22
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
8 INPUT/8 OUTPUT PCI CARD
1. Specifications
Temperature Tolerance—Operating: 32 to 122°F
(0 to 50°C); Storage: -4 to +158°F (-20 to +70°C)
Humidity —10 to 90%, noncondensing
Supply line—+5 VDC
MTBF—Greater than 150,000 hours (calculated)
Connectors—(1) DB37 male
Power—10 to 29 mA (19 mA factory default),
+5 VDC
Size—3.9"H x 5"L (9.9 x 12.7 cm) including
goldfingers; 3.6"H x 5"L (9.1 x 12.7 cm) without
goldfingers
Weight—3.2 oz. (90.7 g)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
8 INPUT/8 OUTPUT PCI CARD
2. Introduction
2.1 Overview
The 8 Input/8 Output PCI Card provides 8 reed relays
that can latch power, data and other electronic signals
for control applications. The Card also has 8 optically
isolated inputs to allow monitoring of off-board switch
closures or relays, or for any other general purpose
monitoring needs. The Card conforms to the PCI 2.1
specification.
2.2 What’s Included
The 8 Input/8 Output PCI Card comes with the
following items. If anything is missing or damaged,
please contact Black Box at 724-746-5500.
• (1) 8 Input/8 Output PCI Card
• (1) 3.5" diskette containing DIO Software
• This users’ manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10
8 INPUT/8 OUTPUT PCI CARD
2.3 Technical Description
The 8 Input/8 Output PCI Card provides two parallel
input/output (I/O) ports. The ports are organized as
ports A, B, C, and D. Port A is an input port interfaced
to optically isolated inputs, while port C is the reed-relay
output port.
2.3.1 F EATURES
• 8 SPST relays
• One eight-bit optically isolated input port.
• DB37 male connector.
• Highly reliable 10-VA DIP reed relays used.
• Multiple adapters can reside in same computer.
• PCI 2.1 Bus compliant.
2.3.2 I NPUT P ORT
Port A is an 8-bit input port connected to optically
isolated input sensors. Each sensor can be used to
interface a voltage input and then sense whether the
voltage is on or off. Each sensor is isolated (with respect
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

11
8 INPUT/8 OUTPUT PCI CARD
to a common ground) from every other sensor, and also
isolated with respect to the host PC ground. This means
that signals such as low-voltage AC, motor-servo voltage,
and control-relay signals can be “sensed,” (or read) by
the PC without risking damage caused by ground loops
or ground faults.
Each sensor input pair has a current-limiting resistor
that is used to limit the input current to the opto-
isolator. The opto-isolator has two internal“back-to-back”
diodes. This allows AC or DC signals to be sensed,
regardless of polarity. When the applied voltage is high
enough to cause the LED in the opto-isolator to turn-on,
the output of the opto-isolator goes low (0 volts) and the
signal is read as a low logic level (binary 0) by the PC.
When the input signal is too low to turn on the opto-
isolator, the output goes high and the port bit is read by
the PC as a high logic level (binary 1).
The input impedance of each isolated input is
approximately 560 ohms (factory default). The opto-
isolator requires approximately 3 mA to turn on. The
maximum input current is 60 mA.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12
8 INPUT/8 OUTPUT PCI CARD
When selecting the input resistor, consider:
1. Power-on voltage for the circuit to sense.
2. The maximum input voltage. Maximum input
voltage must not overload the input resistor, and
must not overdrive the opto-isolator input-current
specification. The following formulas apply:
• Power-on current: 3 mA
• Isolator diode drop: 1.1 V
• Resistor power max: 0.25 W
Power-on voltage = diode drop + power-on current x
resistance
Or:
1.1 + (.003 A) x R
Maximum voltage = square root of (0.25 [resistor
value])
The table on the next page shows four common input
resistors and the ranges associated with each.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13
8 INPUT/8 OUTPUT PCI CARD
Input Resistor Value Power-On Max. Input Range Max. Current
(Ohms) (Volts) (Volts) (mA)
220 1.76 to 7.4 2 to 6 29
560* 2.8 to 11.8 3 to 12 19
1K 4.1 to 15 4 to 16 15
2.2K 7.7 to 23.4 8 to 24 10
*Factory default
Increasing the input resistor can increase the maximum
input voltage. Because the PCI Card uses socketed DIP
resistor networks, they can easily be replaced (at the
factory) with a different value. The input circuits are not
intended for monitoring 120-volt AC circuits.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14
8 INPUT/8 OUTPUT PCI CARD
3. Installation
3.1 Card Setup
The 8 Input/8 Output PCI Card is a fully compliant PCI
“plug-and-play” adapter. All card resources (such as I/O
address and IRQ selection) are auto-assigned by either
your system BIOS or your plug-and-play operating
system.
3.2 Operating System Installation
Please install the proper software for your adapter
before installing the hardware. Refer to the supplied
software for the correct operating system installation
procedure.
3.3 System Installation
You can install the 8 Input/8 Output PCI Card in any of
the PCI expansion slots. To install the Card:
1. Turn off the PC’s power. Disconnect the power
cord.
2. Remove the PC case cover.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

15
8 INPUT/8 OUTPUT PCI CARD
3. Locate an available PCI slot and remove the screw
that secures the blank metal slot cover. Remove
the cover.
4. Gently insert the PCI Card into the slot. Make sure
that the Card is seated properly.
5. Replace the screw.
6. Replace the cover.
7. Connect the power cord. Installation is complete.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16
8 INPUT/8 OUTPUT PCI CARD
4. Additional Information
4.1 Sensor Input Port Pin Assignments (P3 DB37 Male)
Port A Bit P1
0 2,20
1 3,21
2 4,22
3 5,23
4 6,24
5 7,25
6 8,26
7 9,27
4.2 Output Port (Reed Relay)
Reed relays provide very high quality, long life, low
current (0.5 amps max.), dry-contact switch closures.
Reed relays are not suited for high-current applications,
and can be destroyed by inductive load switching where
a spark occurs across the contacts internally. The relays
are normally open; then close when energized. Writing a
“1” to the proper port bit can individually energize each
relay.
4.3 Relay Specifications
• Contact Power Ratings: 10 watts maximum
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

17
8 INPUT/8 OUTPUT PCI CARD
• Contact Voltage Maximum: 100 Volts DC or
AC maximum
• Contact Current Maximum: 0.5 Amps DC or AC
RMS
• Contact Resistance, Initial: 0.15 Ohms
• Rated Life: Low Load: 200 million closures;
Maximum Load: 100 million closures
• Contact Speed: 0.5 mSec each for Operate,
Bounce, and Release
• Maximum Operating Speed: 600 Hz
4.4 Output Port (Reed Relay) Pin Assignments (P3 DB37 Male)
Port C Bit Relay P2 Pin
0 K1 10,28
1 K2 11,29
2 K3 12,30
3 K4 13,31
4 K5 14,32
5 K6 15,33
6 K7 16,34
7 K8 17,35
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18
8 INPUT/8 OUTPUT PCI CARD
4.5 Power and Ground Pin Assignments (P3 DB37 Male)
Ground 18,36,37
+ 5 Volts 19
+ 12 Volts 1
4.6 Software
The 8 Input/8 Output PCI Card ships with an I/O suite
of Windows®95, 98, and NT drivers. The software
provides a consistent and straightforward API, so the
developer can concentrate on the details of the
application instead of low-level driver development.
Popular development environments, including Visual
C++, Visual Basic, and Delphi, are supported for
application development. The software includes a utility
for configuring the driver parameters under Windows
NT. Configuration is automatic with Windows 95 or 98.
For DOS, and other operating systems, please refer to
the software included with your card.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
