Black Ridge BR70i User manual

1
03597 03/18
For service, spare parts or product information,
please contact Smart Marketing Group Pty. Ltd.
AUST. 1300 660 457 N.Z. 0800 474 876
Recyclable
Cardboard
INFLATOR MANUAL
Portable Inflator for
general light duty tasks
around the home
MODEL NO.
BR70i

2
3
SUGGESTED APPLICATIONS
You may use most light duty air tools with this inflator. Some
examples of light duty tools are:
• Ball Inflator
• Toy Inflator
• Tyre Inflator
• Airbrush
• Stapler
• Combo Nailer
This inflator is NOT recommended for use with a spray gun
or medium duty air tools. Always check the air requirement
of the tool wishing to be used to ensure that it is within this
inflators air output. Attaching air tools that draw more than
70 litres per minute, free air delivery, to this inflator, may
cause them not to operate to the tools’ full potential. The
listed air tools and accessories above are not included with
this inflator.
Section Page
Contents 2
Suggested Applications 2
Introduction 3
Guarantee 3 – 4
General Safety Instructions 5 – 7
Electrical Information 8
Components and Controls 9
Operating Instructions 10 – 14
Maintenance 14
Trouble Shooting 15
Technical Information 15
Parts Diagram 16
Contact Information 16
CONTENTS
Specifications
Inflator BR70i
Voltage 240V AC ~ 50Hz
Motor 1 HP
Wattage 750W
Oil Free
No Load Speed 2800 RPM
FAD (Free Air Delivery) 70L per minute
Tank Size 8L
Duty Cycle 50%
Max Tank Pressure 115PSI (8BAR)
Outlet Pressure 115PSI - No Regulator
Lubrication Oil Free
Minimum Generator Size Pure Sine Wave 1500W
Noise Rating 77dB@3m
Motor/Pump Kicks In 85PSI
Pressure Cycle Stops 115PSI
Number Of Outlets 1 - No regulator

2
3
INTRODUCTION
Dear Customer,
Thank you for purchasing this inflator which has passed
through our extensive quality assurance processes. Every
care has been taken to ensure that it reaches you in perfect
condition. However, in the unlikely event that you should
experience a problem, or if you require any assistance
please do not hesitate to contact us;
If you have a problem, call customer service do not return this
inflator to the place of purchase.
Note: For convenience we suggest taking a photocopy of
your purchase receipt as the original may fade.
CUSTOMER SERVICE
Australia: 1300 660 457
New Zealand: 0800 474 876
Operating times: Monday – Friday
8.00am - 5.00 pm
Australian Eastern Standard Time (AEST)
EXPRESS WARRANTY STATEMENT
INFLATOR
You are not required to do anything to register your inflator
purchase. Please attach the purchase receipt to this manual
and ensure both are kept safe. We hope you enjoy your new
inflator, and if you have any problems call customer service
on the above phone numbers. Do not return to place of
purchase.
Smart Marketing Group Pty Ltd (SMG) warrants that this
inflator will be free from manufacturing faults or defects
for 12 months from the date of purchase, providing original
purchase receipt is kept and shown when needed and is
subject to the terms and conditions below.
If a warranty fault appears within the warranty period,
SMG reserves the right to replace or repair the product. In
the event that SMG chooses to replace the product, this
original warranty will expire at the original date. If the
product includes various accessories or components, only
the defective accessory or component will be replaced or
repaired.
SMG reserves the right to replace defective parts of the
product with parts and components of similar quality, grade
and composition where an identical part or component is not
available.
Products presented for repair may be replaced by
refurbished products of the same type rather than being
repaired. Refurbished parts may be used to repair the
products.
What is covered.
• Manufacturing fault or defect.
How to claim under this warranty.
• Call customer service, phone number to the left.
• Ensure you have the following: Original purchase receipt,
Model of inflator, Serial number of inflator.
• Discuss the issue.
• Customer service will advise which authorised service
agent to take the inflator to provided the issue is a
warranty one.
• Take inflator to authorised service agent for repair.
What is not covered.
• Commercial use of inflator.
• Use of inflator in a commercial premises.
• Damage caused by incorrect fuel or incorrectly mixed 2
stroke fuel.
• Damage or deterioration due to transport.
• Damage caused by negligence, misuse, abuse or
accident or incorrect voltage and wattage.
• Any corrosion or rusting.
• Damage caused by incorrect set up and start up.
• Replacement parts due to general wear and tear.
• Inflators with serial number defacement, modification or
removal.
• Inflators which have been serviced by other than an
authorised SMG service agent.
• Inflators with no original purchase receipt.
• Inflators which have been on sold, not original purchaser.
• Damage due non-servicing of inflator as is required by
this manual.
• Blockages / damage caused by dust, dirt, spiders webs
or insects.
• Damage caused by the incorrect fitting of accessories.
• Damage caused by overloading, overworking the inflator.
• Damage to attached equipment or third party
accessories.
• Damage caused by attached equipment or third party
accessories.
CONTACT DETAILS
Smart Marketing Group Pty Ltd
33-35 Lionel Road, Mt. Waverley
Victoria 3149, Australia.
Tel [phone]
Fax [phone]
[email protected]

4
5
As soon as you have purchased the inflator, we recommend
that you check to make sure it is intact and that you read
the operating instructions carefully before using it. The
purchase receipt for this product is to be retained and must
be presented if making a claim under the terms of the Smart
Marketing Group (SMG) warranty. Bank account statements
are not acceptable for proof of purchase.
This warranty does not cover inflators intended for hire or
use in commercial applications or in commercial premises.
The warranty will under no circumstances extend to
reimbursement or payment of damages, whether direct,
indirect or consequential. The warranty is void if there is
evidence the inflators has been modified or tampered with
in any way or used with unauthorised accessories without
our consent.
SMG declines any responsibility or liability whatsoever
arising from misuse or abuse, negligent handling of the
inflators or if the product has not been installed or failure
to comply with the relevant safety, operating, setting and
maintenance instructions (see further in this manual).
The warranty does not extend to installation or disconnection
costs.
Any item sent freight forward/collect for repair will be
refused. Warranty repairs are free of charge, provided
the appliance is delivered to our service department or
authorised service agent. The inflator will need to be
returned, adequately protected in a box. SMG will not be
responsible for any in-transit loss or damage. Assistance
under the warranty will only be made available if the request
is made to our customer service team on the contact
numbers listed below and proof of purchase is provided.
This is a repair only warranty you will need to take the
inflator to the authorised service agent after contacting our
customer service centre.
If the product includes various accessories or components,
only the defective accessory or component will be replaced
or repaired.
SMG reserves the right to replace defective parts of the
product with parts and components of similar quality, grade
and composition where an identical part or component is not
available.
Products presented for repair may be replaced by
refurbished products of the same type rather than being
repaired. Refurbished parts may be used to repair the
products.
Damage caused by third party accessories is not covered
under this warranty.
Damage caused to attached equipment or third party
accessories will not be covered under this warranty.
Rust and corrosion are not covered under this warranty.
If a warranty fault is found the freight cost will be credited to
the owner. If no fault is found the product will be returned
and any costs associated with the service will be charged to
the owner.
Blockages caused by spider webs, insects, dirt, accumulated
dust, incorrect fuel or incorrectly mixed 2-stroke fuel are
not covered by warranty. SMG reserves the right to replace
or repair the appliance within the warranty period. Parts
found to be defective due to a manufacturing default will be
replaced free of charge.
In the event of SMG choosing to replace the appliance, the
warranty will expire at the original date of purchase. If no
warranty fault is found the owner will be advised and the
product will be returned and any costs associated with the
service will be charged to the owner.
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure. The benefits
of this warranty are in addition to any rights and remedies
imposed by Australian State and Federal legislation that
cannot be excluded.
In New Zealand, this SMG warranty is in addition to the
conditions and guarantees which are mandatory as implied
by the New Zealand Consumer Guarantee Act 1993.For
service, spare parts or product information please contact
customer service:
Australia: 1300 660 457
New Zealand: 0800 474 876
CONTACT DETAILS
Smart Marketing Group Pty Ltd
33-35 Lionel Road, Mt. Waverley
Victoria 3149, Australia.
Tel [phone]
Fax [phone]
[email protected]
COMPLETE WARRANTY STATEMENT – INFLATOR

4
5
LUBRICATION OF INFLATOR
This inflator is OIL FREE. Therefore there is NO oil used for
lubrication.
ASSEMBLY
This inflator MUST be fully assembled by you prior to use.
Failure to do so will result in the warranty being VOID.
Failure to fully assemble this inflator may also result in
personal injury.
MANOEUVRING
When moving this inflator always use the handle to lift it and
be aware of this inflators weight. Failure to lift correctly may
result in personal injury.
SAFETY
Before attempting to operate this inflator the following basic
safety precautions should be taken to reduce the risk of
fire, electric shock and personal injury. It is important to
read the instruction manual and to understand applications,
limitations and potential hazards associated with the
inflator. This inflator is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their
safety.
BEWARE OF CHILDREN
AND PETS
Children and pets should be kept out of the work area.
Children should not be allowed to touch or operate the
inflator, tools or extension cords. This inflator is not
designed for use by young children or infirm persons without
supervision. The inflator and tools should be kept out of
reach of children, preferably stored or locked in a secure
cabinet or room when not in use.
WORK AREA
Work areas and benches should be kept tidy. Cluttered
benches and work areas can cause accidents. Floors should
be kept clean and free from rubbish. Special care should
be taken when the floor is slippery due to sawdust or wax.
Always leave sufficient distance, at least 5 metres between
the inflator and the work area, especially when using tools
designed for sanding or spraying liquids.
WORK ENVIRONMENT
Do not expose your inflator to rain or use in damp or wet
conditions. Keep the work area well lit.
GUARD AGAINST ELECTRIC SHOCK
Avoid body contact with earthed or grounded surfaces (e.g.
pipes and refrigerators).
DO NOT OVERLOAD INFLATORS
The inflator will do a better, safer job and give you much
better service if it’s used at the duty cycle for which it was
designed. The duty cycle will only take effect after the initial
(1st) tank fill for the day. This inflators duty cycle is 50%.
Duty cycle is the proportion of time during which the inflator
is operating compared with not operating. For example a
50% duty cycle could mean after 30 seconds of operation,
motor pumping, the inflator must be left for 30 seconds
resting, motor not pumping. When the motor is pumping
the attached air tool can not be used. Only use the attached
air tool while the inflator is not pumping. Stop using the
attached tool as soon as the inflator starts pumping.
USE THE RIGHT TOOL
Select the right tool for the job. Do not use a tool for a job
for which it was not designed. Do not force a small inflator
to do the job of a heavy–duty inflator. Do not use the inflator
for purposes not intended.

6
7
DO NOT ABUSE THE POWER CORD
Never yank or pull on the power cord to disconnect it from
the mains supply socket. Never carry or pull your inflator
by its power cord. Keep the power cord away from heat,
oil, solvents and sharp edges. Regularly check the plug
and cord and if damaged have it replaced by an authorised
service facility.
EXTENSION CORDS AND REELS
This inflator MUST be plugged directly into a 240V AC wall
socket.
This inflator is NOT designed to be run off an extension cord/
lead. If you need extra distance do NOT use an extension
cord, USE A LONGER AIR HOSE.
The use of extension cords may cause power voltage loss
and will result in damage to the motor. This will NOT be
covered under warranty.
SECURE THE WORK PIECE
Whenever possible secure the work piece using clamps or
a vice. It is safer than using your hands or feet and leaves
both hands free to control the tool.
HOT COMPONENTS
Beware many of the components will get hot during use.
Never touch any of the metal pipes, pump or motor as these
may burn.
MAINTAIN YOUR INFLATOR WITH CARE
Follow the instructions for use and changing accessories.
Check the inflator power cord periodically and if damaged
have it replaced by an authorised service facility. Keep
handles clean, dry and free from oil and grease. Ensure
that ventilation slots are kept clean and free from dust at
all times. Blocked ventilation slots or air filter can cause
overheating and damage to the motor and this will not be
covered under warranty.
DISCONNECT INFLATOR
Ensure that the inflator is disconnected from the mains
supply when not in use, before servicing, making
adjustments or when changing any accessories.
REMOVE ADJUSTING KEYS
AND WRENCHES
Form the habit of always checking to see that any adjusting
keys or wrenches have been removed from the inflator or
attached air tools before operating.
AVOID UNINTENTIONAL STARTING
Ensure that the switch is in the ‘OFF’ position before
plugging the inflator into the mains supply.
PROTECT FURNISHINGS
If using the inflator inside your house, protect furnishings
and floors with a suitable dust sheet.
FIRE PRECAUTIONS
When using the inflator inside your house or workshop
general fire precautions should be observed. This means
never leaving your inflator turned on while not in attendance,
never cover the inflator while being used or while still hot
from use, never use in areas where a spark may cause
a fire, always use in clean areas. As a precaution it is
recommended that an expert is consulted on obtaining and
using a suitable fire extinguisher.
CLEANING YOUR INFLATOR
When using the inflator inside your house or workshop
general fire precautions should be observed. This means
never leaving your inflator turned on while not in attendance,
never cover the inflator while being used or while still hot
from use, never use in areas where a spark may cause
a fire, always use in clean areas. As a precaution it is
recommended that an expert is consulted on obtaining and
using a suitable fire extinguisher.

6
7
WARNING
Only use inflator when fully assembled.
Do not attempt to modify the inflator in any way; this will VOID your warranty.
The use of any attachment or accessory other than those recommended in this instruction manual could result in
damage to the inflator and could cause injuries to the operator.
This electric inflator complies with Australian / New Zealand and International standards and safety requirements.
Repairs should only be carried out by qualified persons using original spare parts. Failure to do so may result in
considerable danger to the operator.
PERSONAL SAFETY
Clothing
Do not wear loose clothing, jewellery or anything that could
get caught in moving machinery.
Hair
Long hair should be tied back or contained in a protective
covering.
Eye Protection
The use of safety goggles is highly recommended (normal
glasses are not sufficient for eye protection) when using
inflator. Prescription glasses do not have safety lenses.
Footwear
Where there is the risk of heavy objects or if there is a risk
of slipping on wet or slippery floors, suitable non–slip safety
footwear should be worn. Protect your feet from dropping
accidents.
Ear Protection
The use of ear protection is highly recommended when
using inflators. The continual noise may damage your ears.
Respiratory Protection
When operating any machinery that creates dust or when
spray painting, an approved dust / filter mask must be worn.
When machining concrete, man made fibres, especially
MDF (Medium Density Fibre board), the resin used in these
materials can be hazardous to your health. Use an approved
face mask with replaceable filter.
Do Not Over Reach
Do not over reach. Keep a proper footing and maintain your
balance at all times. Avoid using abnormal stances and
awkward body positions.
Stay Alert
Watch what you are doing, use common sense, and never
operate a inflator when you are tired, drinking alcohol, taking
drugs or if taking medication that causes drowsiness.
CHECK DAMAGED PARTS
Before using the inflator it should be carefully checked
to determine that it will operate properly and perform its
intended function.
Check for the correct alignment of moving parts ensuring
that they do not bind. Check for broken or missing parts
and have them replaced or repaired at an authorised
service facility. Check any other condition that may affect
the operation of the inflator. A guard or any other part of
the inflator that is damaged should be properly repaired or
replaced by an authorised service facility unless otherwise
indicated in this instruction manual.
Any switch that does not operate correctly must be replaced
by an authorised service facility.
DO NOT use the inflator if the ‘ON / OFF’ button does not
turn the inflator ‘ON’ and ‘OFF’.
DO NOT use the power point switch to operate the inflator as
this will cause damage and injury may occur. Any damage
will not be covered under warranty.
For assistance, product information, spare parts or service
please contact Smart Marketing Group Pty. Ltd.
AUST. 1300 660 457
N.Z. 0800 474 876

8
9
SPECIFIC SAFETY INSTRUCTIONS
Warning! Do not use the inflator in areas where there is a
risk of explosion or fire from combustible materials. The
sparks generated from certain tools attached to inflator can
ignite combustible materials as well as flammable liquids,
paint, varnish, petrol, flammable gases and dust of an
explosive nature. As a precaution it is recommended that
you consult an expert on a suitable fire extinguisher and its
use.
• Do not attempt to modify the inflator, guards or the
supplied accessories in any way.
• Domestic inflators are designed for intermittent
operation. Ideally a 50% duty cycle. (Meaning. 30
seconds ON motor pumping and 30 seconds OFF,
motor not pumping). When the motor is pumping
the attached air tool can not be used. Only use the
attached air tool while the inflator is not pumping.
• Stop using the attached tool as soon as the inflator
starts pumping.
• Fully assemble inflator before use.
• Always ensure your inflator is level and stable.
• Never use an extension cord with this inflator always
use a longer air hose.
• Never connect to a generator which does not produce
sufficient power, at least 1500W and has pure sine
wave power output.
• Domestic inflators are not designed for
industrial / commercial applications.
• Domestic inflators are not designed for continuous
running. Always follow duty cycle - 50%.
• Avoid touching the pump area as it can become very hot
and may burn.
• Ensure that the inflator is disconnected from the mains
supply when not in use, before servicing, making
changes and when changing attachments such as air
hoses / tools.
• Always use the correct type of tool for the operation to be
carried out.
• Never use the inflator if any part of the unit is damaged.
Always have the inflator serviced by an authorised
service agent.
• Always wear safety eye, ear and respiratory protection
when operating the inflator.
• Allow the tank to completely fill before using the inflator.
• If the inflator makes an unfamiliar sound or vibrates
excessively, switch the inflator ‘OFF’ immediately and
disconnect from the mains power supply. Investigate the
possible cause or consult your authorised service facility.
• Always move the inflator using the handle and wheels.
• Always use the inflator on stable ground.
• This inflator is designed to compress normal air. Never
use to compress any other type (s) of gases.
• Never direct the jet of air or other liquids / gases towards
your body, other persons or animals.
• Never direct the jet of air or other liquids / gases towards
this inflator.
• This inflator is not suitable for pharmaceutical, food or
sanitary purposes.
• This inflator is not to be used to for filling scuba or
oxygen air bottles or tanks.
• Always follow the instructions relating to the tools
attached to this inflator.
IMPORTANT
ELECTRICAL DATA
This inflator is fitted with a sealed electrical connection plug that is compatible with the mains power supply for Australia
/ New Zealand and meets the requirements of Australian Standards. This inflator must be connected to a supply voltage
that is equal to that stated on the rating label. If the mains power connection plug or power cord becomes damaged it
must be replaced with a complete assembly that is identical to the original, and this must be replaced by an authorised
service centre. Always follow the Australian / New Zealand requirements for connection to the mains supply. If in doubt
always consult a qualified electrician.

8
9
COMPONENTS AND CONTROLS
Pic. 1
1. Pressure switch
2. On / Off button - red colour
3. Handle
4. Motor cover
5. Pump
6. Tank
7. Rubber feet
8. Tank drain tap
9. Tank pressure gauge
10. Air filter - plastic
11. ‘Nitto style’ outlet socket fitting
12. Safety valve
PIC. 1
8
6
7
5
43
21
9
12
10
2
11
12
1

10
11
OPERATING INSTRUCTIONS
Unpacking
Carefully unpack your inflator. Dispose of all packing
material in an environmentally responsible manner.
When unpacking this inflator always use the handle to lift it
and be aware of this inflators weight. Failure to lift correctly
may result in personal injury. Dispose of all packing material
in an environmentally responsible manner.
Assembly
Your inflator requires minor assembly before initial operation.
Check that you have all required components required for
assembly and initial use.
Air Filter
The supplied air filter must be used.
Failure to do so may result in irreparable damage and will
void the warranty, Pic. 2
To install;
1. Carefully screw supplied air filter into the threaded hole
on the top of the pump head. This only needs to be done
up by hand. Do not use tools to tighten air filter.
NOTE: Do not OVER TIGHTEN as this may damage the air
filter or cylinder head which will NOT be covered under
warranty.
PIC. 2
WARNING
Do not attempt to operate this inflator until it is fully
assembled.
Damage caused due to incomplete assembly will not
be covered under warranty.
Ensure the inflator is disconnected from the power
supply before carrying out any assembly, maintenance
or adjustments on the machine.

10
11
STARTING AND STOPPING YOUR INFLATOR
Pic. 3
NOTE: Always ensure that you plug your inflator into a
standard 240V AC power point. Never use an extension cord
as this can lead to a voltage drop which may cause power
loss and over heating. Use a longer air hose if you need to
get closer to your work area.
Always start and stop the inflator using the
ON/OFF button on the Pressure Switch (Pic. 3). Damage caused
by not using this button will not be covered by warranty.
To turn your inflator ON;
Lift up the red ON / OFF button on top of the pressure switch
To turn your inflator OFF;
Push down the red ON / OFF button on top of the pressure
switch
RUNNING IN YOUR NEW INFLATOR
Your inflator does not require running in. Before use ensure
you have read and understood these instructions.
Before use ensure this inflator is fully assembled as per
page 10.
POSITIONING YOUR NEW COMPRESSOR
Choose a location away from your work area and near to a
mains power point.
NOTE: 1. Never use an extension lead. Always use a
longer air hose
2. Always position compressor on level ground
3. Always position compressor away from work
area so that the inflator does not get covered in
dust or paint - use a longer air hose to ensure
inflator is in clean air
PIC. 3
Push button
down for off
Lift button
up for on

12
13
USING THE INFLATOR
Before starting run through this simple list;
1. Fully assembled.
2. Drain tap – open and drain tank
3. Drain tap – close fully
4. Check power lead for any damage. If damaged have
replaced by an authorised service centre.
5. Plug inflator into a standard 240V 10Amp AC power
point and turn ON.
6. Lift the red button to turn ON, see page 11, Pic.3.
7. Allow the inflator to fill the air tank.
8. Turn the inflator OFF.
9. Turn the power point OFF and disconnect the
power lead from the power point.
10. Connect your air hose and air tools.
11. Reconnect to the power lead to the power point and
turn ON.
12. Turn your inflator ON.
13. Once turned on and you begin using the connected air
tools the inflator will start and stop without warning.
This is controlled by the pressure switch. These
pressure settings are factory set and should not be
changed.
Pumping starts at (minimum) 85PSI and stops at
(maximum) 115PSI. Once the initial pump up stage
has finished you can use the inflator. Remember air
pressure is not regulated. If low pressure is required
buy a regulator.
TOOL CONFIGURATION
The configuration of tools and accessories can be varied to
suit your particular requirements. A basic recommended set
up is shown in Pic. 4 (accessories not included).
When you have finished using your inflator follow these
simple steps:
1. Turn your inflator OFF, using the ON/OFF button.
2. Turn the power point OFF and disconnect the power
lead.
3. Disconnect your air tools and air hose.
4. Clean your air hose and air tools.
5. Store your air hose and air tools in a secure well
ventilated cabinet.
6. Slowly open the tank drain tap, see page 14. This allows
excess air and moisture, water, to vent.
7. Leave the tank drain tap open. This allows any moisture
to drain while the inflator is stored.
NOTE: Use of a water trap may be of benefit to ensure no
water or moisture reaches your air tool.
PIC. 4
Above accessories and tools Not supplied, purchased separately.

12
13
IMPORTANT
NOTE
This inflator has been supplied with no adjustable
regulator and gauge.
Outlet pressure is 8 Bar (115 PSI).
If you require a lower pressure for your air tool please
buy an adjustable regulator and gauge from your
stockist.
AIR OUTLET
Pic. 6
Note: This inflator has been supplied with no adjustable
regulator and gauge.
Different air tools require different operating pressures.
Always check with the tool manufacturer if unsure.
This inflator only has 8Bar pressure. If you require adjustable
pressure you will need to buy a regulator.
PIC. 6
Tank pressure
gauge
Nitto style
outlet socket
(Air Outlet)
PIC. 5
Pull to check
operation
SAFETY VALVE
Pic. 5
NOTE: When checking the safety valve ALWAYS wear safety
glasses.
To check the operation of the safety valve the air tank will
need to be full. Gently pull the ring outwards. This should
release air under pressure. Release the ring and this should
stop the air out flow once the pressure has dropped.
If the safety valve does NOT work in this manner, STOP the
inflator immediately and have the inflator checked / serviced
by an authorised service centre.

14
15
PIC. 8
DRAIN TAP
Pic. 8
After use open the drain tap to drain excess air and any
moisture. The excess air will also help purge the moisture.
Leave the drain tap open when inflator is not in use, so any
moisture can continue to drain
To open the drain tap pull the lever down
to vertical.
To seal the drain tap push the lever up
to horizontal.
NOTE: Remember to seal the drain tap before starting the
inflator.
AIR OUTLET FITTING
Pic. 7
This inflator is fitted with a ‘Nitto style’ air fitting.
To use:
1. Slide the outer collar down.
2. Push in the male fitting (not included).
3. Release the collar.
4. Fully and completely push the male fitting (not included)
into the female until it clicks.
Note: This inflator has a maximum pressure of 8 bar. Always
regulate the air pressure to match your air tool. Different air
tools require different operating pressures. Always check
with the tool manufacturer if unsure.
Drain Tap Sealed
OR
To close and seal push lever up Right or left
To open and drain pull lever down
Drain tap opened unsealed
MAINTENANCE
Daily: Before Use
1. Seal the tank drain tap,
see above, Pic. 8.
2. Check safety valve operation,
see page 13, Pic. 5.
After Use
1. Open the tank drain tap,
see above, Pic. 8.
2. Wipe down the inflator.
3. Store safely and securely.
IMPORTANT
NOTE
This inflator has a maximum pressure of 8 bar.
Always regulate the air pressure to match your air
tool. Different air tools require different operating
pressures. Always check with the tool manufacturer
if unsure.
If less than 8 BAR (115PSI) is required, you will need
to purchase and adjustable regulator.
PIC. 7

14
15
CLEANING
ENSURE the inflator is NOT running whilst cleaning. To keep
the inflator clean, always wipe down after use. Wear eye
protection when cleaning. Only clean the inflator with a
damp soft cloth. NEVER use liquid or solvents of any type.
Ensure ventilation slots are kept clean and free from dust/
dirt build up.
STORAGE
When storing ensure the air tank has been emptied as
per ‘Drain Tap’ above. Always store away from children,
preferable in a locked room.
REPAIRS
Repairs to your inflator should only be carried out by an
authorised service agent.
Call BLACKRIDGE for your closest centre, Aust.
Aust. 1300 660 457 N.Z. 0800 474 876.
TROUBLE SHOOTING
Inflator will not start
Check that you have plugged the power lead into a standard 240V 10Amp power point and turned the switch ON.
Check that you have turned the inflator ON/OFF switch ON.
The air tank may be full. Use your air tool and the inflator should start when the pressure decreases to 85PSI.
Inflator does not build up pressure
Check that the tank drain tap is sealed
Check that the air fitting is not leaking. If leaking replace.
Inflator smells like burnt oil
Using beyond the 50% duty cycle, allow to cool for 30 minutes before reusing this inflator.
Part Description SMG Part No.
17 Tank pressure gauge 95 BRC95TPG
10 Rubber stopper with
bolt & nut 95 BRI40RS
11 Drain tap 95 BRC95DT
19 Nitto style socket
fitting (female) 95 BRI40NSF
5 & 6 Motor cover 95 BRI40MC
15 Safety valve 95 BRC95SPV
4 Handle grip 95 BRI40HG
3 Air filter 95 BRI60AF
8 Exhaust tube 95 BRI40ET
User replaceable parts listed below. All other parts
must be serviced/replaced by an authorised service
agent.
3
8
10
11
4
6
5
19
17
15

16
16
TECHNICAL INFORMATION
Blackridge® is a registered trademark of Super Cheap Auto Pty Ltd
For any queries or assistance call Customer Service
AUST. 1300 660 457 NZ 0800 474 876
Hours of operation:
Monday to Friday 8.00am - 5.00pm AEST
Do not return to place of purchase. Keep your purchase receipt, this will
be required to make any claims under the 12 month warranty.
Specifications
Inflator BR70i
Voltage 240V AC ~ 50Hz
Motor 1 HP
Wattage 750W
Oil Free
No Load Speed 2800 RPM
Free Air Delivery (FAD) 70L per minute*
Tank Size 8L
Duty Cycle 50%
Max Tank Pressure 115PSI (8BAR)
Outlet Pressure 115PSI - No Regulator
Lubrication Oil Free
Minimum Generator Size Pure Sine Wave 1500W
Noise Rating 77dB@3m
Motor/Pump Kicks In 85PSI
Pressure Cycle Stops 115PSI
Number Of Outlets 1 - No regulator
