Blackbe;rry 8820 SMARTPHONE User manual

Use your phone for more than just talking
Quick Start Guide

Volume keys
Adjust the volume during a call
End key
End a call. Move back to Home screen
Escape key
Move back a screen. Close a menu
Speakerphone key
Turn on/off the speakerphone during a call
Backspace/Delete key
Enter key
Microphone
Right Shift key (CAP)
Type capital letters
Send key
Open the phone application
Call a highlighted phone number
Menu key
Open the menu in an application
ALT key
Type the alternate character on a key
Symbol key
Open the symbol list
USB port
Headset jack
Mute key
Trackball
Roll to move around a screen
Click (press) to select an item
Push to Talk Activation Key
Open the Push to Talk application
Speak to a Push to Talk contact
Power key Speaker
Left Shift key (NUM)
Capitalize letters or press the ALT key
+ this key to turn on NUM lock
Getting to know your Phone

Making Phone Calls
Make phone calls
1.Onthe Home screen or in the Phone Screen,
perform one of the following:
a. Type aphone number
b. Type part of acontact name. Use the
trackball to scroll to and highlight acontact
or phone number and click/press the trackball
or the Send key to place the call.
2.Toend the call, press the End key.
Make aphone call using Voice Dialing
1.Onthe Home screen, scroll to
and click the Voice Dialing icon.
2.Wait for the sound.
3.Say “Call” and acontact name or
phone number.
4.Toend the call, press the End key.
Note: To turn the
speakerphone on or
off during acall, press
the Speakerphone ($)
key, or click the
trackball and then
click Activate
Speakerphone /
Handset.
Note: To learn more
about voice dialing
features, press the
Menu key and
choose Help.
Menu key only
works when call is
in progress.

MEdia™Net
With MEdia Net, you can get the information that is important to you at a
glance. Check your local weather, your team scores or movie listings with just
afew clicks.
1.Onthe Home screen, scroll downto and select the MEdia Net icon.
2. Scroll the trackball to acategory of interest and then click to explore that category.
For quick access to your favorite categories, personalize
your MEdia Net home page.
1.From the MEdia Net home page, scroll to and click Edit nextto My Links.
2.ClickEdit My Links.
3. Select the categories you would like to appear on your
home page.
4. Scroll to the bottom of the page and click Save.
How to bookmark aweb page
1. Press the Menu key, then click Add Bookmark.
2.ClickAdd.

Downloadable Fun
Customizeand personalizeyour BlackBerry 8820 with downloadable**
games, graphics and ring tones.
Use the MEdia™Net browser to access your favorite web pages and
downloads using MEdia™Net content service.
Using MEdia™Net
• On the Home Screen, scroll downto and select MEdia™Net.
• Select Tones, Games, Pics.
• You can now shop Applications, Games, Graphics,
Multimedia & Tones.
**Additional charges may apply for downloadable content.
Your use of third party products and services shall be governed by and subject to you
agreeing to the terms of separate software licenses, if any, for those products or services.
RIM and AT&T makes no representation, warranty or guarantee whatsoever in relation to
the third party products and services and assumes no liability whatsoever in relation to
the third party products and services even if RIM and AT&T has been advised of the
possibility of such damages or can anticipate such damages.

OrganizeMe
The BlackBerry 8820 allowsyou to take your Address Book and Calendar with
you and stay on top of your day, stay organized and on schedule with time saving
tools including acalendar, address book and alarm clock.
Add acontact
1.From the Home screen, click on Address Book.
2.Clickon the Menu key, click on New Address.
3.Type in the contact information.
4.Clickon trackball and click Save when complete.
Set-up atask
1.From the Home screen, click on Applications.
2.Clickon Tasks icon. Press the Menu key,
click on New and enter your task (an errand).
Set the alarm
1.From the Home screen, click on Settings.
2.Clickon the Alarm icon.
3.Setup the Alarm by selecting On for the Daily Alarm and
Selecting the Time, Snooze.
You can also synchronize your BlackBerry 8820 with local information on your home/work computer such as calendar,
contacts, tasks, and media files by using BlackBerry® Desktop software that comes on the enclosed BlackBerry® User
Tools CD in the box. See page 31 of the Getting Started Guide for minimum requirements

TextMessaging
Let your thumbs do the talking. With the BlackBerry 8820’sfull QWERTY keyboard
sending and receiving email, SMS, and MMS messages is easy and fast. AnSMS can
be sent to other mobile phones or wireless devices while an MMS can be sent to
both mobile phones and email addresses.
To compose atextmessage
1.From the Home screen, click on the Messages icon.
2. Press the Menu key.Click Compose SMS Text.
3. Select aname in the address book or click Use Once and add
the recipient’sphone number(s) and separate with asemicolon
if necessary.
4. Enter the message text.
5.When you’re through typing, click the trackball and Send.
To respond to atextmessage
1.Clickon the Messages icon on the Home Screen.
2. Using the trackball, scroll to and press the Text Message in your messages list.
3.Clickthe trackball and select Reply.
4.Type your message. Click the trackball, select Send.

Multimedia Messaging
You can also send apicture that is stored on your memory card through MMS.
To send amultimedia message
1. Press the Media icon on the Home Screen.
2.Onthe Media screen roll the trackball to click the Pictures icon.
3. Select My Pictures.
4. Roll the trackball to highlight the desired picture and press the Menu button.
5. Select Send as MMS.
6. Select aname in the address book or click on Use Once and add the recipients phone number(s)
or email addresses and separate with asemicolon if necessary.
7. Enter the message textthen press the trackball and enter Send.

Personal Email
BlackBerry Internet Service email provides wireless “push” delivery and access
up to 10 supported personal and work email accounts including MSN™, Yahoo!™,
GMail™, AT&T, and many other popular ISP and personal email providers.
How to set up supported email accounts from your BlackBerry 8820.
1.From the Home screen, click the BlackBerry Setup icon.
2.Onthe BlackBerry Setup screen, click the Personal Email Setup icon.
3. Roll the trackball, scroll downand click Create New Account.
4. Read the BlackBerry Internet Service terms and conditions carefully, and if you agree, then
scroll to and click Yes to accept.
5.Type the following information in the Account Setup screen: User Name & Password.
6.You now havethe option to add up to 10 supported Internet email accounts and/or create an
optional BlackBerry email address.
How to compose email
1.From the Home screen, click on the Messages icon.
2. Press the Menu key, scroll to and click Compose Email.
3.Type an email address or contact in the To: field.
4.Type the Subject.
5.Type your message, click the trackball and click Send.
For more information on Corporate email solutions please visit att.com/blackberry.
To set up your BlackBerry Internet Service email using a web browser on your computer, visit att.com/blackberrystart.

Transfer Music
You can listen to your favorite music on the BlackBerry 8820*.The built-in Media
Player provides the ultimate in control and flexibility to organizeyour music and
listen to it the way you want to.
How to load MP3 files
1. Ensure that you haveinserted amicroSD Media card into the back of your BlackBerry 8820
to optimizethe memory available for music.
2.Install the BlackBerry Desktop Manager software on your PC computer using the
BlackBerry User Tools CD included in the box.
3. Connect your BlackBerry 8820 to your computer using the USB cable provided.
4.Onyour PC, open the Desktop Manager software with your computer mouse.
5. Double click on the Media Manager icon.
NOTE: Twosections will appear: the top showsyour PC files, the bottom showsyour BlackBerry Media card files under
the My Device section.
6.Inthe BlackBerry section below, click on the Music folder for the BlackBerry Media card.
7.Inthe PC section above, select the folder and then the music file you would like to copy
to your Media card.
8.Clickon Copy Down button and then OK to movethe song file to the Music folder on your
Media card. Repeat as desired.
*Additional charges may apply for downloadable content.
Your use of third party products and services shall be governed by and subject to you agreeing to the terms of separate software
licenses, if any, for those products or services. RIM and AT&T makes no representation, warranty or guarantee whatsoever in
relation to the third party products and services and assumes no liability whatsoever in relation to the third party products and
services even if RIM and AT&T has been advised of the possibility of such damages or can anticipate such damages.
For more information on loading media files, see the Getting Started Guide.

Play Music
Listen to your favorite music on the BlackBerry 8820 while on the road, relaxing
at home or at the gym.
How to play MP3 files*
1.From the Home screen, click the Media icon.
2.Onthe Media screen, you will find (4)directories. Click the trackball on the already highlighted
Music directory.
3. Scroll the trackball to and click Media Card. To play all songs you see stored on the media
card, press the Menu key and roll and press the trackball to select Play All.
Note: All audio files must be transferred to the BlackBerry 8820 before playing. Use the Media Manager
application of the BlackBerry Desktop Manager Software found on the BlackBerry User Tools CD in the box to
transfer files.
*When listening to audio files using headphones, permanent hearing loss might occur if headphones are used
at a high volume. Avoid increasing the volume of your headphones to block out noisy surroundings. If you
experience ringing in your ears or muffled speech, consult a physician to have your hearing checked. For more
information, see the Product and Safety Guide on the BlackBerry User Tools CD that came in the box with your
BlackBerry 8820.

Push to Talk
Push to Talk (PTT) lets you view the availability of family, friends or co-workers
before you call.
Add aPush to Talk Contact
1.On the Home screen, click the Push to Talk icon.
2.On the PTT Menu screen, click Add Contact.
3.Type the contact information and click OK.Your BlackBerry 8820
will now send the invitation to your new contact.

Push to Talk... cont’d
Make aPush to Talk Call
1.Press and release the PTT key (Left Convenience Key)
to display your PTT contacts.
2.Scroll the trackball to highlight the contact you wish
to reach then press and hold the PTT key to establish
aconnection.
3.When the BlackBerry 8820 beeps, you can perform
one of the following actions:
a) To speak, press and hold the PTT key.
b) To listen, release the PTT key.
4.To end the Push to Talk call,
press and hold the End key.

TeleNavGPS Navigator™
Turn your BlackBerry 8820 into aGPS navigation system.
Download TeleNav GPS Navigator*:
1.Clickthe TeleNav GPS Navigator icon on the Home Screen or Go to:
http://ota.telenav.com/ota/at
2.You will nextcome to the Download Summary screen. Click the
Download button. A progress bar appears.
3. Once TeleNav GPS Navigator has downloaded and installed
successfully, select Run on the pop-up and press the trackball.
Generate aroute with TeleNav GPS Navigator:
1.Clickthe GPS Navigation icon on the application main menu.
2. Enter your desired destination and click the ‘Get Route’ button.
3. TeleNav GPS Navigator will connect to the satellites
Note: user must be outdoors to establish GPS connection.Additional Features:
TeleNav® is a registered trademark and
TeleNav GPS Navigator™ and TeleNav Track™
are trademarks of TeleNav, Inc. Additional
charges may apply.
*Your use of third party products and services shall be governed
by and subject to you agreeing to the terms of separate licenses,
if any, for those products or services. RIM and AT&T makes no
representation, warranty or guarantee whatsoever in relation to
the third party products and services and assumes no liability
whatsoever in relation to the third party products and services
even if RIM and AT&T has been advised of the possibility of such
damages or can anticipate such damages.
Fuel Finder Business Finder

BlackBerry accessories are available for productivity, convenience and fashion.
You can shop accessories at att.com/wirelessaccessories.
ACAdapter Skins microSD™ Card
Leather Cases Vehicle Mounts and Cradles
Stereo Headset
Accessories
Note: Use only accessories that Research In Motion has approved for use with your BlackBerry 8820. Use of other accessories
might invalidate any approval or warranty/might result in non-operation of the BlackBerry 8820 and might be dangerous.

© 2007 AT&T Knowledge Ventures. All rights reserved. AT&T and the AT&T logo are trademarks of AT&T Knowledge
Ventures. Research In Motion, the RIM logo, BlackBerry, the BlackBerry logo and SureType are registered with the
U.S. Patent and Trademark Office and may be pending or registered in other countries - these and other marks of
Research In Motion Limited are used under license. All other brands, product names, company names, trademarks,
and service marks are the properties of their respective owners.
MAT-16241-001 AT&TQSG BUS MS P0906 2335 E
