BlackBerry Enterprise Server for
Microsoft Exchange
Version 4.1
Performance Benchmarking

BlackBerry Enterprise Server Version 4.1 for Microsoft Exchange Performance Benchmarking
Last modified: 14 August 2006
Part number: 9182501 Version 7
At the time of publication, this documentation is based on BlackBerry Enterprise Server Version 4.1 for Microsoft Exchange.
©2006 Research In Motion Limited. All Rights Reserved. The BlackBerry and RIM families of related marks, images, and symbols are the
exclusive properties of Research In Motion Limited. RIM, Research In Motion, BlackBerry, “Always On, Always Connected” and the “envelope in
motion” symbol are registered with the U.S. Patent and Trademark Office and may be pending or registered in other countries.
Compaq is a registered trademark of Hewlett-Packard Development Company, L.P. IBM, Lotus, and Sametime are registered trademarks of
International Business Machines Corporation in the United States, other countries, or both. Intel and Pentium are registered trademarks of
Intel Corporation or its subsidiaries in the United States and other countries. Microsoft, Excel, Outlook, PowerPoint, and Windows are
registered trademarks of Microsoft Corporation in the United States and/or other countries. Novell and GroupWise are registered trademarks
of Novell, Inc. in the United States and other countries. Java, J2RE, and J2SE are trademarks of Sun Microsystems, Inc. in the United States or
other countries. All other brands, product names, company names, trademarks and service marks are the properties of their respective owners.
The BlackBerry device and/or associated software are protected by copyright, international treaties, and various patents, including one or more
of the following U.S. patents: 6,278,442; 6,271,605; 6,219,694; 6,075,470; 6,073,318; D445,428; D433,460; D416,256. Other patents are
registered or pending in various countries around the world. Visit www.rim.com/patents for a list of RIM [as hereinafter defined] patents.
This document is provided “as is” and Research In Motion Limited and its affiliated companies (“RIM”) assume no responsibility for any
typographical, technical, or other inaccuracies in this document. In order to protect RIM proprietary and confidential information and/or trade
secrets, this document may describe some aspects of RIM technology in generalized terms. RIM reserves the right to periodically change
information that is contained in this document; however, RIM makes no commitment to provide any such changes, updates, enhancements, or
other additions to this document to you in a timely manner or at all. RIM MAKES NO REPRESENTATIONS, WARRANTIES, CONDITIONS, OR
COVENANTS, EITHER EXPRESS OR IMPLIED (INCLUDING WITHOUT LIMITATION, ANY EXPRESS OR IMPLIED WARRANTIES OR
CONDITIONS OF FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT, MERCHANTABILITY, DURABILITY, TITLE, OR RELATED TO
THE PERFORMANCE OR NON-PERFORMANCE OF ANY SOFTWARE REFERENCED HEREIN OR PERFORMANCE OF ANY SERVICES
REFERENCED HEREIN). IN CONNECTION WITH YOUR USE OF THIS DOCUMENTATION, NEITHER RIM NOR ITS RESPECTIVE DIRECTORS,
OFFICERS, EMPLOYEES, OR CONSULTANTS SHALL BE LIABLE TO YOU FOR ANY DAMAGES WHATSOEVER BE THEY DIRECT, ECONOMIC,
COMMERCIAL, SPECIAL, CONSEQUENTIAL, INCIDENTAL, EXEMPLARY, OR INDIRECT DAMAGES, EVEN IF RIM HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES, INCLUDING WITHOUT LIMITATION, LOSS OF BUSINESS REVENUE OR EARNINGS, LOST DATA,
DAMAGES CAUSED BY DELAYS, LOST PROFITS, OR A FAILURE TO REALIZE EXPECTED SAVINGS.
This document might contain references to third-party sources of information, hardware or software, products or services and/or third-party
web sites (collectively the “Third-Party Information”). RIM does not control, and is not responsible for, any Third-Party Information, including,
without limitation the content, accuracy, copyright compliance, compatibility, performance, trustworthiness, legality, decency, links, or any
other aspect of Third-Party Information. The inclusion of Third-Party Information in this document does not imply endorsement by RIM of the
Third-Party Information or the third-party in any way. Installation and use of Third-Party Information with RIM's products and services may
require one or more patent, trademark, or copyright licenses in order to avoid infringement of the intellectual property rights of others. Any
dealings with Third-Party Information, including, without limitation, compliance with applicable licenses and terms and conditions, are solely
between you and the third-party. You are solely responsible for determining whether such third-party licenses are required and are responsible
for acquiring any such licenses relating to Third-Party Information. To the extent that such intellectual property licenses may be required, RIM
expressly recommends that you do not install or use Third-Party Information until all such applicable licenses have been acquired by you or on
your behalf. Your use of Third-Party Information shall be governed by and subject to you agreeing to the terms of the Third-Party Information
licenses. Any Third-Party Information that is provided with RIM's products and services is provided “as is”. RIM makes no representation,
warranty or guarantee whatsoever in relation to the Third-Party Information and RIM assumes no liability whatsoever in relation to the Third-
Party Information even if RIM has been advised of the possibility of such damages or can anticipate such damages.

Published in Canada
Research In Motion Limited
295 Phillip Street
Waterloo, ON N2L 3W8
Canada
Research In Motion UK Limited
Centrum House, 36 Station Road
Egham, Surrey TW20 9LF
United Kingdom

Contents
1Overview ...............................................................................................................................................................9
About this document ........................................................................................................................................ 9
Audience ....................................................................................................................................................10
2BlackBerry Enterprise Server components .................................................................................................... 11
BlackBerry Dispatcher......................................................................................................................................11
BlackBerry Messaging Agent..........................................................................................................................11
MAPI ...........................................................................................................................................................12
CDO ............................................................................................................................................................12
BlackBerry Router ............................................................................................................................................12
BlackBerry Controller ......................................................................................................................................12
BlackBerry MDS Services................................................................................................................................12
BlackBerry MDS Connection Service............................................................................................................13
BlackBerry Attachment Service .....................................................................................................................13
BlackBerry Synchronization Service .............................................................................................................14
BlackBerry Policy Service ...............................................................................................................................14
BlackBerry Collaboration Service..................................................................................................................14
3BlackBerry Enterprise Server implementation considerations ...................................................................15
Proximity to messaging and collaboration servers.....................................................................................15
BlackBerry Desktop Software connection....................................................................................................15
Internet connection.........................................................................................................................................15
BlackBerry MDS Connection Service traffic ................................................................................................16
BlackBerry Attachment Service traffic .........................................................................................................16
Wireless message reconciliation....................................................................................................................16
BlackBerry Configuration Database .............................................................................................................16
Wireless enterprise activation........................................................................................................................ 17
4Test environment................................................................................................................................................ 19
Components......................................................................................................................................................19
Microsoft Exchange Server equipment .................................................................................................19
BlackBerry Enterprise Server equipment.............................................................................................20
Microsoft SQL Server 2000 equipment ...............................................................................................20

Domain controller equipment................................................................................................................20
Load generator computer equipment....................................................................................................21
Performance testing tools ..............................................................................................................................21
Microsoft Load Simulator 2003..............................................................................................................21
BlackBerry MDS Connection Service Push Load Testing tool .......................................................... 22
BlackBerry Synchronization Service Load Testing tool ..................................................................... 22
Measurement counters .................................................................................................................................. 22
Lab initialization.............................................................................................................................................. 22
5Performance tests...............................................................................................................................................23
Overview of the performance tests.............................................................................................................. 23
6Microsoft Exchange 2003 performance test results .................................................................................... 27
Overview of the test results........................................................................................................................... 27
Processor use...................................................................................................................................................28
Memory use......................................................................................................................................................29
Disk use ............................................................................................................................................................29
Network use......................................................................................................................................................31
Performance impact considerations .............................................................................................................31
7Microsoft SQL Server 2000 performance test results .................................................................................33
Overview of the test results........................................................................................................................... 33
Processor use...................................................................................................................................................34
Disk use ............................................................................................................................................................34
Transactions/sec.............................................................................................................................................36
User connection count................................................................................................................................... 37
Summary ..........................................................................................................................................................38
Performance impact considerations ............................................................................................................39
8BlackBerry Enterprise Server performance test results ...............................................................................41
Overview of the performance test results....................................................................................................41
Processor use...................................................................................................................................................42
Memory use......................................................................................................................................................43
Messages queued for delivery.......................................................................................................................44
Messages received per minute .....................................................................................................................44
Network use.....................................................................................................................................................45
Performance impact considerations ............................................................................................................46

9Conclusions ........................................................................................................................................................ 49
Conclusions and recommendations.............................................................................................................49
AAppendix: MMB and MMB2 comparison .........................................................................................................51
Overview............................................................................................................................................................51
BlackBerry Attachment Service traffic for MMB2 ..............................................................................55
BAppendix: BlackBerry MDS Connection Service traffic rate derivation ................................................... 57
Message test load traffic ............................................................................................................................... 57
BlackBerry MDS Connection Service load traffic....................................................................................... 57
CAppendix: Calculations and data.................................................................................................................... 59
Sample calculations........................................................................................................................................59

1
Overview
About this document
This document describes the performance characteristics of the BlackBerry® Enterprise Server Version 4.1 for
Microsoft® Exchange. It presents the results of performance testing on the BlackBerry Enterprise Server and
describes the impact of the BlackBerry Enterprise Server on a Microsoft® Exchange 2003 Server and a Microsoft
SQL 2000 Server. Finally, this document includes important information for system administrators who are
responsible for implementing the BlackBerry Enterprise Solution™ in a Microsoft Exchange environment.
The performance tests that this document describes are based on the ability of the BlackBerry Enterprise Server to
support 2000 user accounts. Each test was run for four hours. Research In Motion (RIM) used the data collected in
the last two hours of the test, when the load driver reached a steady state load, for analysis.
The BlackBerry Enterprise Server performance was measured using Messaging Application Programming
Interface (MAPI) Messaging Benchmark 2 (MMB2), a standard developed by Compaq® Computer Corporation
(now Hewlett-Packard Development Company) and Microsoft to compare Microsoft Exchange Server benchmarks
based on the MAPI protocol with those of other servers. See “Appendix: MMB and MMB2 comparison” on page 51
for more information about the MMB2 workload.
As part of the performance testing, the impact on the BlackBerry Enterprise Server performance was measured
when the following features and services were enabled:
•email, calendar, and sent folder redirection
•wireless message reconciliation
•BlackBerry MDS™ Connection Service
•BlackBerry Attachment Service
•BlackBerry Synchronization Service
The performance testing included both incoming and outgoing traffic to the BlackBerry Enterprise Server. The
incoming traffic included pull traffic for the BlackBerry MDS Connection Service and synchronization commands
sent from BlackBerry devices to the BlackBerry Synchronization Service.
About this document

10
BlackBerry Enterprise Server for Microsoft ExchangePerformance Benchmarking
Audience
This document assumes that you have a working knowledge of the following items:
•BlackBerry Enterprise Server for Microsoft Exchange installation, configuration, administration, and
architecture
•Microsoft Exchange Server 2000 and, or 2003 installation and administration
•Microsoft SQL Server 2000 installation and administration
•System Monitor counters and performance metrics

2
BlackBerry Enterprise Server components
BlackBerry Dispatcher
The BlackBerry Dispatcher handles traffic to the BlackBerry Infrastructure. It compresses/decompresses and
encrypts/decrypts wireless data. The BlackBerry Dispatcher handles all internal Service Routing Protocol (SRP)
connections from the BlackBerry Messaging Agent and also manages communication from the BlackBerry MDS
Connection Service, the BlackBerry Synchronization Service, the BlackBerry Policy Service, and the BlackBerry
Collaboration Service to the BlackBerry Infrastructure. These components connect to the BlackBerry Dispatcher
through specific ports and communicate with the BlackBerry Infrastructure through the BlackBerry Router using a
unique SRP identifier that the BlackBerry Dispatcher establishes.
BlackBerry Messaging Agent
The BlackBerry Messaging Agent handles BlackBerry Synchronization Service traffic, including contacts, tasks,
memos, message settings, and message filters. The BlackBerry Messaging Agent also has a mechanism for
wireless calendar initialization before wireless calendar synchronization is enabled. This mechanism is used to
initially synchronize the BlackBerry device and the Microsoft Exchange message store, enabling wireless
synchronization to occur. Each BlackBerry Messaging Agent owns a unique internal SRP identifier that connects to
the BlackBerry Dispatcher.
The BlackBerry Messaging Agent also handles all Microsoft Exchange-related traffic using Messaging Application
Programming Interface (MAPI) and Collaboration Data Objects (CDO).
BlackBerry Dispatcher
BlackBerry Messaging Agent
BlackBerry Router
BlackBerry Controller
BlackBerry MDS Services
BlackBerry MDS Connection Service
BlackBerry Attachment Service
BlackBerry Synchronization Service
BlackBerry Policy Service
BlackBerry Collaboration Service

12
BlackBerry Enterprise Server for Microsoft Exchange Performance Benchmarking
MAPI
The BlackBerry Messaging Agent uses thread pools that have a MAPI session to the Microsoft Exchange Server.
New thread pools are created when an existing thread pool exceeds the 50-mailbox maximum or the BlackBerry
Enterprise Server connects to another Microsoft Exchange Server. This thread pool system minimizes the number
of MAPI sessions to the Microsoft Exchange Server, which provides added product stability.
CDO
The BlackBerry Messaging Agent uses CDO sessions for wireless calendar activity. A CDO session is established
for a user when a calendar-related request is made. If no activity occurs within five minutes, the session ends.
BlackBerry Router
The BlackBerry Router acts as a gateway to the BlackBerry Infrastructure and user computers. It determines
whether data should be transmitted wirelessly or routed through a network connection. When a BlackBerry device
is connected to a computer, the BlackBerry Router routes data to the BlackBerry device and bypasses the wireless
network.
BlackBerry Controller
The BlackBerry Controller starts the BlackBerry Messaging Agents and monitors their health. If the BlackBerry
Controller detects nonresponsive threads or if a BlackBerry Messaging Agent stops responding, the BlackBerry
Controller restarts the BlackBerry Messaging Agent. The BlackBerry Controller assigns BlackBerry user accounts
to BlackBerry Messaging Agents based on the following criteria:
•Microsoft Exchange Server on which the user accounts reside (groups user accounts together or, if most user
accounts reside on the same Microsoft Exchange Server, distributes the user accounts evenly)
•amount of user accounts that currently reside on each BlackBerry Messaging Agent (up to 500 users)
The BlackBerry Controller also monitors all BlackBerry processes and restarts them if they are not in a running
state.
BlackBerry MDS Services
In BlackBerry Enterprise Server Version 4.1, RIM introduced a new component called the BlackBerry MDS Services.
The BlackBerry MDS Services also require the BlackBerry MDS Connection Service to send data to BlackBerry
devices.
The BlackBerry MDS Services are responsible for managing interactions and requests between BlackBerry devices
and enterprise applications. The BlackBerry MDS Services include the following services:
•BlackBerry MDS Management Service: deals with policies, such as those that specify which applications
users can download, the services available to applications, and so on
•BlackBerry MDS Provisioning Service: controls and manages which applications users can download to
BlackBerry devices

13
2: BlackBerry Enterprise Server components
•BlackBerry MDS Data Optimization Service: transforms data for efficient wireless transmission and use on
BlackBerry devices
•BlackBerry MDS Connection Service: provides TCP/IP and HTTP-based connectivity between BlackBerry
MDS Studio Java™ Applications and enterprise applications and between BlackBerry MDS Browser
Applications and enterprise applications
•BlackBerry MDS Application Integration Service: supports the integration and transmission of data between
BlackBerry MDS Studio on the BlackBerry device and web services applications
•BlackBerry MDS Studio Application Repository: manages published BlackBerry MDS Studio Applications
centrally
The current version of this document includes benchmarking information for the BlackBerry MDS Connection
Service. The document does not include benchmarking information for the BlackBerry MDS Services.
BlackBerry MDS Connection Service
The BlackBerry MDS Connection Service enables push-based access to enterprise data and applications.
Capitalizing on the BlackBerry Enterprise Server architecture, the BlackBerry MDS Connection Service provides a
safe connection between the BlackBerry device and corporate application servers. Through this connection, users
can access corporate data from enterprise applications. The data travels between the BlackBerry device and the
BlackBerry Enterprise Server using the same path as the BlackBerry Collaboration Service, so no extra connections
or firewall openings are required.
The BlackBerry MDS Connection Service also communicates with the BlackBerry Dispatcher. It permits persistent
socket connections from the BlackBerry device to the corporate application server.
You can configure the BlackBerry MDS Connection Service to run on a computer that is remote from the
BlackBerry Enterprise Server computer.
In BlackBerry Enterprise Server Version 4.0.x, the BlackBerry MDS Connection Service was called the BlackBerry
Mobile Data Service. RIM benchmarked the BlackBerry MDS Connection Service using the same load
characteristics used to benchmark the BlackBerry Mobile Data Service in Version 4.0.x, but with different content.
BlackBerry Attachment Service
The BlackBerry Attachment Service enables users to open and view message attachments on their BlackBerry
devices. Attachment content is formatted and delivered to the BlackBerry device using the Universal Content
Stream (UCS) format. When a user requests to view an attachment on the BlackBerry device, the BlackBerry
Messaging Agent sends the request information to the BlackBerry Attachment Service, and the BlackBerry
Attachment Service performs the conversion of the attachment content to UCS format. The BlackBerry Enterprise
Server compresses and encrypts the attachment data and then sends the formatted attachment to the BlackBerry
device.
The BlackBerry Attachment Service also enables users to view Microsoft PowerPoint® presentations in a slide
format.
Visit www.blackberry.com/knowledgecenterpublic/ to read the BlackBerry Attachment Service guide for more
information.

14
BlackBerry Enterprise Server for Microsoft Exchange Performance Benchmarking
BlackBerry Synchronization Service
The BlackBerry Synchronization Service synchronizes contacts, tasks, and memos between the email application
on a user’s computer and the user’s BlackBerry device using Microsoft Exchange through the BlackBerry
Messaging Agent. The BlackBerry Synchronization Service also synchronizes message settings and message
filters. The wireless protocol also synchronizes a variety of database configurations, backs up databases on the
BlackBerry device, and synchronizes items when necessary.
Initialization of the BlackBerry Synchronization Service is triggered when items on the BlackBerry device and the
BlackBerry Configuration Database are not synchronized. This initialization can be triggered by activating a
BlackBerry device wirelessly or moving user accounts. The initialization mechanism is also used to initially
synchronize the BlackBerry device and message store, enabling wireless synchronization to occur.
Because the initialization feature is not considered to maintain a steady state load on the BlackBerry Enterprise
Server, its impact on the BlackBerry Enterprise Server performance is not included in this document. There are
load conditions that the initialization places on the system that you should consider when initialization occurs.
BlackBerry Policy Service
The BlackBerry Policy Service pushes IT policies and IT administrative commands to BlackBerry devices wirelessly.
It is also responsible for creating and pushing service books to BlackBerry devices that are being activated
wirelessly and for sending third-party applications to BlackBerry devices wirelessly.
Because the BlackBerry Policy Service is not considered to maintain a steady state load on the BlackBerry
Enterprise Server, its impact on the BlackBerry Enterprise Server performance is not included in this document.
BlackBerry Collaboration Service
The BlackBerry Collaboration Service is designed to keep users in touch with their instant messaging community
when they are connected to the wireless network. The BlackBerry Collaboration Service includes contact list
management, presence awareness, notifications, and emoticons. It also supports the IBM® Lotus® Sametime®,
Microsoft Live Communications Server 2005, and Novell® GroupWise® platforms.
This document does not include benchmarking information for the BlackBerry Collaboration Service.

3
BlackBerry Enterprise Server implementation
considerations
Proximity to messaging and collaboration servers
The BlackBerry Enterprise Server should have access to messaging and collaboration servers through a local,
high-speed, switched network connection. For a decentralized server topology, consider the physical link speeds
between the sites and the geographical placement of BlackBerry users. RIM recommends that you place the
BlackBerry Enterprise Server as close to the messaging servers as possible and target the messaging servers that
host the majority of BlackBerry users. Depending on the WAN infrastructure, you might want to implement a
BlackBerry Enterprise Server in more than one site for optimal performance.
BlackBerry Desktop Software connection
If you use the BlackBerry Desktop Software, a network connection to the BlackBerry Enterprise Server and the
messaging server must be available.
Internet connection
The BlackBerry Enterprise Server requires an outbound-initiated Internet connection on port 3101. Any firewall
that is placed between the BlackBerry Enterprise Server and the Internet must allow this connection. You must
also verify that you have enough Internet bandwidth to manage the additional traffic that the BlackBerry
Enterprise Server generates. Messages are sent to BlackBerry devices in 2-KB sections; however, because of
compression, only 1 KB goes through the Internet connection.
Proximity to messaging and collaboration servers
BlackBerry Desktop Software connection
Internet connection
BlackBerry MDS Connection Service traffic
BlackBerry Attachment Service traffic
Wireless message reconciliation
BlackBerry Configuration Database
Wireless enterprise activation

16
BlackBerry Enterprise Server for Microsoft Exchange Performance Benchmarking
BlackBerry MDS Connection Service traffic
When implementing the BlackBerry MDS Connection Service, consider both the rate at which data is sent to
BlackBerry devices and the amount of transcoding that the data requires. Do not push too much data that requires
transcoding to BlackBerry devices when messaging traffic is heavy; doing so might cause message delivery to
slow. If you often push data that requires transcoding, the system might experience processor bottlenecks. There is
less control over the rate at which pages are pulled, so you should control the rate at which content is pushed. If
you plan to push a large amount of data that requires transcoding, consider installing the BlackBerry MDS
Connection Service on a computer that is remote from the BlackBerry Enterprise Server computer.
BlackBerry Attachment Service traffic
Potential issues processing attachments might occur in the following situations:
•when processing concurrent requests
•when processing large attachments
•when processing complex attachments (for example, .pdf files or ASCII text)
Visit www.blackberry.com/knowledgecenterpublic/ to read article TAE-00094-001 for more information.
Wireless message reconciliation
When there are pending changes on a BlackBerry device that require immediate reconciliation, users can reconcile
messages from the BlackBerry device manually using the Reconcile Now option in the BlackBerry Desktop
Software. If users use the option excessively, a significant increase in network traffic might occur.
BlackBerry Configuration Database
The BlackBerry Enterprise Server Version 4.1 requires either Microsoft Desktop Engine (MSDE) 2000, Microsoft
SQL Server 2005 Express Edition, or Microsoft SQL Server 2000.
There are two limitations that prevent MSDE 2000 from scaling:
•The workload governor is activated if more than eight concurrent requests are made. If you use MSDE 2000
with a BlackBerry Enterprise Server that is configured for 2000 user accounts, the BlackBerry Enterprise
Server limits the number of BlackBerry Messaging Agents to two and minimizes the number of connections to
the BlackBerry Configuration Database. These limitations do not guarantee that the workload governor will
not be impacted. The risk in running a large number of user accounts on two BlackBerry Messaging Agents is
that there are more user accounts for each BlackBerry Messaging Agent to handle, which might result in
longer start-up times and more non-responsive threads caused by MAPI or Microsoft Exchange issues.
•The maximum size of a database cannot exceed 2 GB. If users have 16-MB BlackBerry devices, database
memory should not exceed 1 MB for each user account. However, if users have 32-MB BlackBerry devices, the
database memory use is greater.

17
3: BlackBerry Enterprise Server implementation considerations
If you are enabling more than 500 BlackBerry user accounts, you should use Microsoft SQL Server 2000. If you
enable a large number of user accounts with MSDE 2000, monitor the Event Viewer for warnings that indicate that
the workload governor has been activated. There might also be an event from the BlackBerry Enterprise Server
warning that MSDE is approaching its 2-GB database size limit. These warnings indicate that you should upgrade
from MSDE 2000 to Microsoft SQL Server 2000.
RIM conducted the benchmarking of the BlackBerry Configuration Database using Microsoft SQL Server 2000.
RIM has not evaluated the limitations of Microsoft SQL Server 2005 Express Edition at this time. Microsoft SQL
Server 2000 is the updated equivalent to MSDE 2000.
Wireless enterprise activation
The wireless enterprise activation feature eliminates the need for users to synchronize their BlackBerry devices
with their computers using the BlackBerry Desktop Software. Although RIM did not load test this feature, you
should consider how many BlackBerry devices (running BlackBerry Device Software Version 4.0 and later) you
want to activate wirelessly at one time. Activating BlackBerry devices wirelessly involves pushing content from a
user's mailbox to a BlackBerry device that is not connected to a computer. A large amount of data is sent through
the BlackBerry Enterprise Server to the BlackBerry device, which results in increased wireless traffic, increased
activity by the BlackBerry Enterprise Server, and increased activity by the messaging and collaboration servers.
Stagger the wireless activation of BlackBerry devices so that the load on the BlackBerry Enterprise Server does not
impact message delivery for existing users.

18
BlackBerry Enterprise Server for Microsoft Exchange Performance Benchmarking

4
Test environment
Components
The following tables provide information about the various components that RIM used in the performance test
environment. In some cases, these components are greater than the minimum requirements established for the
BlackBerry Enterprise Server Version 4.1 for Microsoft Exchange.
Microsoft Exchange Server equipment
Components
Performance testing tools
Measurement counters
Lab initialization
Type Components
hardware 2 Compaq®DL380 - G3 servers with the following features:
•Dual PIV - 2.4 GHz processor (Hyper Threading turned off)
•2560 MB memory
•HP NC7781 Gigabit Server Adapter
•6 36-GB [15,000 rpm] drives in a RAID 0 array with Smart Array 5312 Controller
software •Microsoft Windows®2003 Service Pack 1
•Microsoft Exchange 2003 Server SP 1
configuration •Microsoft Exchange 2003 SP 1 (default options with circular logging enabled) installed on the Microsoft Exchange
Servers; each Microsoft Exchange Server had one information store, which was mounted on the 6-drive RAID 0
set

20
BlackBerry Enterprise Server for Microsoft Exchange Performance Benchmarking
BlackBerry Enterprise Server equipment
Microsoft SQL Server 2000 equipment
Domain controller equipment
Type Components
hardware 1 Compaq DL360 G3 server with the following features:
•Dual PIV 2.8 GHz processors (Hyper Threading disabled)
•3920 MB memory
•HP NC7781 Gigabit Server Adapter
•2 36-GB RAID 0 drives with Smart Array 5i Controller
software •Windows Server 2003 SP 1
•Microsoft Exchange 2003 System Manager SP 1
•BlackBerry Enterprise Server Version 4.1 for Microsoft Exchange
•Microsoft XML Version 4.0 SP 2 (MSXML)
•Java™ 2 Runtime Environment, SE 1.4.2_03
configuration The BlackBerry Enterprise Server was configured with one administrative service account.
The service account was given the following permissions for each Microsoft Exchange Server information store:
•Send As
•Receive As
•Administer Information Store
Type Components
hardware 1 Compaq DL360 G4 server with the following features:
•PIV 3.0 GHz processor
•1024 MB memory
•NC3163 Fast Ethernet NIC 10/100 LAN
•2 72-GB RAID 1+0 drives with Integrated Smart Array Controller
software •Windows Server 2003 SP 1
•Microsoft SQL Server 2000 (Enterprise Edition)
Type Components
hardware 1 Compaq DL360-G3 server with the following features:
•PIV 2.8 GHz processor
•1024 MB memory
•HP NC7782 Gigabit Server Adapter
•2 36-GB RAID 1+0 drives with Integrated Smart Array Controller
software •Windows Server 2003 SP 1
