Blak-Ray UVL-4 User manual

Technical Support
Contact Analytik Jena’s offices using the contact information shown below with any
questions regarding this product. A Returned Goods Authorization number (RGA) must be
obtained from AJ prior to returning any item to AJ.
Corporate Headquarters: Analytik Jena US 2066 W. 11th Street, Upland, CA 91786
Telephone: [phone]
Fax: [phone] | Web Site: us.analytik-jena.com
European Operations: Ultra-Violet Products Ltd.
Unit 1, Trinity Hall Farm Estate, Cambridge CB41TG UK
Telephone: [phone] / Fax: [phone]
Warranty
REGISTER YOUR MINI UV LAMP WARRANTY ONLINE AT
HTTP://UVP.COM/REGISTER/
LIMITED WARRANTY: AJ’'s quality instruments are guaranteed to be free of defects in
materials, workmanship, and manufacture for one (1) year from date of purchase.
Transilluminators are similarly warranted for two (2) years from the date of purchase.
Consumable and disposable products, including, but not limited to lamps or light tubes,
filters, or rechargeable batteries are guaranteed to be free from defects in manufacture
and materials for ninety (90) days from date of purchase. If equipment failure or
malfunction occurs during the warranty period, AJ shall examine the inoperative
equipment and have the option of repairing or replacing any part(s) which, in the sole and
absolute discretion of AJ, were originally defective or became so under conditions of
normal usage and service. No warranty shall apply to any instrument, or part thereof, that
has been subject to accident, negligence, alteration, abuse or misuse by the end user.
Moreover, AJ makes no warranties whatsoever with respect to parts not supplied by AJ or
that have been installed, used and/or serviced other than in strict compliance with the
instructions appearing in this installation and instruction manual. In no event shall AJ be
responsible to the end-user for any incidental or consequential damages, whether
foreseeable or not, including but not limited to property damage, inability to use
equipment, loss of business, loss of profits, or inconvenience arising out of or connected
with the use of instruments produced by AJ. Nor is AJ liable or responsible for any personal
injuries occurring as a result of the use, misuse, installation and/or servicing of equipment.
Representations and warranties made by any person, including dealers and representatives
of AJ which are inconsistent or in conflict with the terms of this warranty (including but not
limited to the limitations of the liability of AJ as set forth above), shall not be binding upon
AJ unless reduced to writing and approved by an expressly authorized representative of AJ.
THIS WARRANTY IS EXPRESSED IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON
UVP’S PART AND UVP NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME
FOR UVP ANY OTHER LIABILITIES IN CONNECTION WITH THE SALE OF THE SAID
PRODUCTS.
Blak-Ray®and Mineralight®
Mini UV Lamps
User’s Guide
UVL-4 |UVG-4 | UVSL-14P
Blak-Ray® and Mineralight® are Registered Trademarks of Analytik Jena
81-0116-02 Rev D

End Cap
Clear Tube
Cover
UV Tube
Introduction
Ultraviolet light is electromagnetic radiation in the segment of the
spectrum between X-rays and visible light, approximately 180nm to
400nm. It differs from visible light in that its wavelengths are too short
to be seen by the human eye.
UV-A, or longwave radiation, is 315nm and above. UV-B, or midrange
radiation, is 280nm-315nm. UV-C, or shortwave radiation, is 280nm
and below.
When UV radiation falls upon phosphors, it causes the phosphors to
emit specific radiation. This is known as fluorescence. In some
materials, the fluorescence lingers on and slowly disappears after the
UV source is removed. This phenomenon is known as
phosphorescence.
CAUTION: SHORTWAVE UV IS HARMFUL TO THE EYES AND
SKIN. PROPER PROTECTION MUST BE WORN WHEN
OPERATING A LAMP EMITTING SHORTWAVE UV.
Tube Replacement
1. Remove the batteries prior to replacing the tube.
2. Pull off the circular bulb cover and end cap on the end of the unit,
followed by the clear tube cover.
3. Gently twist the tube by the base to release the tube.
4. Replace with a 4 watt longwave tube.
5. Replace the clear cover.
6. Reconnect the end cap and bulb cover back into position.
CAUTION: DO NOT EXPOSE EYES OR SKIN TO SHORTWAVE
ULTRAVIOLET LIGHT, AS RAYS MAY BURN UNPROTECTED EYES OR
SKIN (UVG-4, UVSL-14P). UV BLOCKING EYEWEAR IS RECOMMENDED.
Replacement Parts Part Number
365nm UV (for UVL-4) 34-0010-01
254nm UV (for UVG-4) 34-0003-01
254/365nm UV (for UVSL-14P) 34-0004-01
Spectacles 98-0002-01
Goggles 98-0002-02
Battery Replacement
The UVL-4, UVG-4 and UVSL-14P all operate on four (4) standard
AA batteries. Some alkaline batteries with test strips are slightly larger
than standard batteries and may cause a tight fit. Recommended
batteries for use in the Mini UV Lamps are Eveready Classic and
Rayovac without test strips.
To replace the batteries: Press the center of the battery housing
closure toward the back of the lamp and slide the hinged door forward
and up. Insert the 4 AA batteries, orienting the batteries as indicated
below. Close the door.
NOTE: Remove the batteries if the unit is to be stored for more than a
few months without use.
Bulb Cover
Battery Orientation
Battery Replacement (UVL-4 Shown)
