Blanca Atmospheric water maker User manual

Address:Authorized Distributor in South Africa & AustraliaBlanca GIS (Pty) Ltd9 Isola di PalmeVictor Whitmill DriveSunward Park1459, Gauteng, South Africa

Tel: +27 11 306 7007Fax: +27 86 662 6060Email: [email protected]Website: www.blanca.co.za https://www.facebook.com/AtmosphericWaterGenerators1USER’S MANUAL

Atmospheric Water Generators

Desktop Unit Contact Information

Address:Authorized Distributor in South Africa & AustraliaBlanca GIS (Pty) Ltd9 Isola di PalmeVictor Whitmill DriveSunward Park1459, Gauteng, South Africa

Tel: +27 11 306 7007Fax: +27 86 662 6060Email: [email protected]Website: www.blanca.co.za https://www.facebook.com/AtmosphericWaterGenerators1USER’S MANUAL

Atmospheric Water Generators

Desktop Unit Contact Information

Atmospheric Water Generators

Desktop Unit

Safety Precautions

General Specifications

Contents

General Overview

Hybrid Connection

Installation & Operation

Location of installation

Installation precautions

Operational procedures

Maintenance

Operation precautions

Storage

Cleaning (top tank)

Cleaning (bottom tank)

Cleaning (exterior case)

Filter Replacement

Water Filter

U.V Light

Air Filter

Water Production Chart

Operational indicator

Menu/ Set button

Troubleshooting

Warranty

Table of Contents

Address:Authorized Distributor in South Africa & AustraliaBlanca GIS (Pty) Ltd9 Isola di PalmeVictor Whitmill DriveSunward Park1459, Gauteng, South Africa

Tel: +27 11 306 7007Fax: +27 86 662 6060Email: [email protected]Website: www.blanca.co.za https://www.facebook.com/AtmosphericWaterGenerators1USER’S MANUAL

Atmospheric Water Generators

Desktop Unit Contact Information

Atmospheric Water Generators

Desktop Unit

1. Check country electric power supply 230V or 115.2. Ensure to plug into appropriate grounded socket.3. Use socket connected to circuit breaker only.4. DO NOT share socket with other appliances. 5. DO NOT touch power plug with wet hands.6. DO NOT place heavy object on power cord.7. Avoid exposure to extreme temperature or rain.8. Place unit on hard, flat surface.9. Place unit in an well-ventilated area.10. Place unit 30 cm away from wall for proper air flow.11. DO NOT place unit near inflammables.12. DO NOT place objects on top of unit.13. If transporting, unit keep up-right.14. Drain water prior to moving & installing unit.15. DO NOT modify or disassemble unit / warranty void.16. If leak occurs, unplug unit, drain water, call Service Centre. 17. In case of electric leak, unplug, call Service Centre.18. Using incorrect filter may cause operational failure.19. For all operational problems, call Service Centre.20. For Service Centre contact, refer to back of manual.

Safety Precautions

Desktop Unit - Safety Instructions

Address:Authorized Distributor in South Africa & AustraliaBlanca GIS (Pty) Ltd9 Isola di PalmeVictor Whitmill DriveSunward Park1459, Gauteng, South Africa

Tel: +27 11 306 7007Fax: +27 86 662 6060Email: [email protected]Website: www.blanca.co.za https://www.facebook.com/AtmosphericWaterGenerators1USER’S MANUAL

Atmospheric Water Generators

Desktop Unit Contact Information

Atmospheric Water Generators

Desktop Unit

Safety Precautions

Desktop Unit - Safety Instructions

Specification Contents

Owner s manualDrain hoseDimension WeightPowerCold Water Storage CapacityUnit After Packing Unit After Packing Input PowerPower Consumption Electrical CurrentCold WaterMild Cold Normal Temperature

380 (W) x 520 (D) x 560(H)mm 455(W) x 580 (D) x 640 (H)mm

39.5 Kg42 Kg230V 50Hz 115V 60Hz 440 W 550 W2.35 A7 ~ 12 15 ~ 20 20 ~ 25 13.5 litersDesktop Unit

General Overview

Hybrid Connection

Front

Rear

Ventilation fan

Air outlet

Top cap

Menu Button

Set Button

Power Button

FND Display

Water valve

Leg

Top cover

Air filter bracket

Air filter

Rear panel

Hybrid power connector

Drain connection

Hybrid connection plug

Power cord

Easy screws

(Simpiy unscrew for air

filter exchange)

1 : Hybrid power connection

2 : Hybrid Connection plug

3 : Hybrid power connection (Kit)

4 : Tap water out (Kit)

5 : Tap water in (Kit)

Connect to the tap water through only Hybrid Kit (Option)

AD-5

Hybrid kit

To the tap

②①

③④⑤

Location of installation (Indoor use only)

1. Avoid direct sunlight, exposure to rain and extreme heat or cold.

(water parts may freeze or rupture)

2. Place the unit on hard, flat surface to prevent noise, leakage or

shaking.

3. Place unit in an well-ventilated place.

4. For proper air flow and operation, place unit at least 30 cm away

from wall.

5. To keep unit sanitary, avoid harmful gas or excessive heat.

Installation Precautions

1. Check country power supply: 230V or 115V.

2. Ensure unit is plugged into the right socket.

3. Use grounded socket ONLY.

4. Use socket with circuit breaker.

5. DO NOT share plug with other appliances.

6. DO NOT touch power socket with wet hands.

7. DO NOT place heavy object on power cord.

Operational Procedures

1. If unit has been tilted or laid down on side, do not start-up for at

least 30 minutes.

2. Connect plug to socket.

3. Push Power Button for 3 seconds to start-up.

4. Do a priming process. (See image 1-1, 1-2)

5. Use Menu/Set button for desired water temperature. (see page 13)

6. Wait until unit has generated enough water to drink.

Note: Priming process

for Quick Start and

sanitary reason, open

cap on top of unit and

pour approx. 5 liters of

drinkable water.

(Image 1-1 , 1-2)

Installation & Operation

Image1-1 Image1-2

Operating Precautions

1. DO NOT place objects on-top of unit.

2. To prevent leakage DO NOT tilt unit on side.

3. Completely drain water when moving unit.

4. If leak occurs, unplug unit, drain water completely and call Service Centre.

5. DO NOT modify or disassemble unit.

6. In case of electric leak, unplug, call Service Centre.

7. Incorrect filter may cause poor operation.

Storage

1. If storing the unit for a long period of time, drain water completely.

2. Thoroughly clean unit.

3. Cover to prevent unit from dust and store in the original box if possible.

Cleaning (Top tank)

1. Unplug power cord.

2. Drain water completely.

3. Pull unit until the access to the bottom is

available.

4. Use Phillips screwdriver to loosen 2

screws at the bottom side of front

cover. (Image 2-1)

5. Remove the front cover.

6. Use Phillips screwdriver to

loosen 2 screws on the rear

side of top cover. (Image2-2)

7. Remove rubber plugs and loosen 2

screws. (Image2-2)

8. Remove top cover.

9. Use Phillips screwdriver to loosen 2

screws at the bottom side of top tank.

(Image 2-3)

10. Clean inside with clean dishcloth/soft cloth.

11. DO NOT use detergent or chemical cleanser.

Maintenance

Image2-1

Image2-2

Image2-3

1. Use Phillips screwdriver to loosen 2

screws and remove rear panel.

(Image 3-1)

2. Touch water level sensor with finger.

(5 seconds) (Image 3-2)

3. Wait 2 minutes before unplugging

power cord.

4. Disconnect fitting and wire from

booster pump and water level

sensor respectively. (Image 3-3)

5. Slide out bottom tank.

(Image 3-4)

6. Clean with clean soft dishcloth.

7. DO NOT use detergent or chemical

cleanser.

Cleaning (Exterior case)

Use clean dishcloth or soft cloth and mild detergent and water solution

if necessary.

Filter replacement

Water filter

1. Power off and unplug the unit.

2. Remove rear cover/ Loosen 2 screws with

Phillips screwdriver. (Image 3-1)

3. Carefully remove filter from filter clip.

(There may be water in hose, fitting and

filter) (Image 4-1)

4. Pull and remove filter while pushing the

adaptor of the fitting in opposite direction.

(Image 4-2)

5. Install new filter. (Place new filter in the

same way)

6. After filter exchange, reset the filter

replacement function by using Menu/Set

button. (see page 13)

Cleaning (Bottom tank)

Image3-1 Image3-2

Image3-3 Image3-4

Image4-1

Image4-2

UV light

1. Power Off and unplug unit. Separate rear cover. (loosen & remove 2

screws with Phillips screwdriver)

2. Remove filters. (See water filter replacement)

3. Disconnect the housing of the U.V from ballast.

4. Remove U.V from U.V clip carefully.

(There may be water in hose, fitting and U.V)

5. Pull to remove U.V while pushing the adaptor of the fitting in

opposite direction.

6. Install a new U.V.

7. After U.V exchange, reset the U.V replacement function by using

Menu/Set button. (see page 13)

Note: DO NOT look at UV ray with naked eyes

Air filter

1. Separate air filter bracket by

loosening 2 easy screws with

hand or Phillips screwdriver.

(Image 5-1)

2. Remove air filter and replace

with new air filter. (Image 5-2)

3. After air filter exchange, reset

the air filter replacement

function by using Menu/Set

button. (see page 13)

Water Generating Capacity

Daily Water Production in Lab (liters/day)

3.2

5.2

6.6

8.4

50% 60% 70% 80% 90%

4.1

5.8

8.3

11.5

5.9

7.2

11.7

16.1

6.4

8.2

13.9

18.2

8.3

11.3

17.0

23.0

Image5-1 Image5-2

Temp.

Humid.

Temperature indicator

- Two digits show the current room temperature

- If temperature is not optimum to generate water, Lo signal will

appear

Humidity indicator

- Two digits show the current room humidity

- If humidity is not optimum to generate water, Lo signal will appear

Notes: In low temperature and humidity conditions, the unit stop generating

water to save energy. Both temperature and humidity indicators will show as

Lo signal.

1100

Indicator Lights

1. Temperature indicator

2. Humidity indicator

3. Generating water indicator

4. Water level indicator

5. Refresh indicator

6. U.V indicator

7. Cold water temperature

indicator

8. Air filter replacement indicator

9. Water filters replacement

indicator

10. U.F replacement indicator

11. Hybrid connection indicator

12. Leakage indicator

8910

Self-Error detection function

In case of error during operation 2digits on the temperature/humidity

indicator show ERROR signals respectively. Turn off and unplug unit.

Wait few seconds and Plug In and Turn On again. If the ERROR

signal continues to light up, turn unit off and call the Service Centre

- Cold temp. sensing failure (Er / S1)

- Room temp. sensing failure (Er / S2)

- Fan motor failure (Er / Fn)

- Control board failure (Er / Cn)

- Pump failure (Er / BP)

Generating water indicator

- Dropping motion becomes active : Unit is now generating water

- Icon is in hold motion : Unit is in pause cycle

- No icon showing : Water generating function has stopped.

See Menu/Set button function

Water level indicator

- Shows level of water in top tank.

- If water level sensor is incorrect, text will start blinking and bars light

up intermittently

Refresh indicator

- Icons rotating clockwise : Unit is in re-circulation cycle.

U.V indicator

- Replacement of U.V indicated by red text light.

install new U.V and reset the U.V indication function by the Menu/Set

button (see page 13). Yellow light text will appear

- If both the U.V icon and U.V text blink : Check if U.V. light or ballast

has a problem

Notes : U.V is most important to keep water clean and pure. If both the

icon and text are blinking continuously, call the Service Centre

immediately.

1111

󳦈󳦈󳦈󳦈

󳦈󳦈󳦈

Cold water temperature indicator

- Shows water temperature selected by Menu/Set button.

- Coldest : 7 ~ 12 Celsius degrees

- Colder : 15 ~ 20 Celsius degrees

- Normal : 20 ~ 25 Celsius degrees.

- Yellow text light turns green when cooling system is active

Air filter replacement indicator

- Air filter needs replacing when the green light turns red.

- Replace with new air filter and reset the air filter replacement

indicator function by Menu/Set button (See page 13). Light will return

to Green.

Water filters replacement indicator

- Water Filter needs replacing when the green light turns red.

- Replace both 1st and 2nd filters with new ones and reset the water

filters replacement indicator function by Menu/Set button

(See page 13). Light will return to Green.

U. F replacement indicator

- U.F replacement : Green light becomes Red.

- Replace U.F filter with new one and reset the U.F replacement

indicator function by Menu/ Set button (See page 13 ). Light will return

to Green

Hybrid connection indicator

- Icon and text shows when hybrid water connection is active

- Customer s selection by Menu/Set button(see page 13)

Note: Connect to the tap water only through Hybrid Kit (Option)

Direct connection to the tap water cause serious leakage problem.

Leakage indicator

Note: If icon and text is showing, the unit has a leak.

Turn off and unplug the unit and drain water completely.

Call Customer Service Centre immediately.

1122

Set/ Reset function

1. Push the menu button for 3 seconds

2. Set/Reset function is selected with blinking text as indicated by

pushing the menu button for ½seconds in sequence, as follows;

1) AWS : Water Generating function - SET

2) U.V : U.V light self-detector function - RESET

3) Cold water temperature - Coldest ( 7~12 ) -SET

4) Cold water temperature - Colder ( 15~20 ) - SET

5) Cold water temperature - Normal ( 20~25 ) - SET

6) Air filter replacement function - RESET

7) Water filters replacement function - RESET

8) U.F replacement function - RESET

9) Hybrid connection function - SET

3. When function is selected (text blinking), push set button for

3 seconds to set/ reset the working mode.

4. To clear the Set/Reset stage, push the menu button again 3

seconds or leave it for more than 5 minutes. Then Set/Reset

function will return to previous stage.

Example)

1. To reset Air filter replacement after exchanging air filter.

1) Push menu button for 3 seconds.

2) Push menu button 5 times to go to Air filter indicator.

3) Push the Set button for more than 3 seconds.

Note: U.V/ Air filter/ Water filters/ U.V filter replacement function must be

individually reset. DO NOT reset any function without reset

indicator signal.

2. Setting normal cold water temperature

1) Push menu button for 3 seconds

2) Push menu button 4 times to go to Normal water temperature indicator.

3) Push the Set button for more than 3 seconds.

1133

Set / Reset Button

Water generating system-related problems.

1. Is unit connected to proper voltage socket?

2. Is humidity and temperature right to generate water ?

(Check if temperature and humidity shows Lo signal)

3. Has air filter been changed? Is RED indicator showing?

(Check if air filter exchange indicator shows red)

4. Is it time to change the water filters? Check indicator light.

5. Are the humidity digits showing Error?

(Turn off/ Unplug unit. Then plug-in & Turn back on.

If digits still show Error signal, call Service Center)

6. Is the unit installed in well-ventilated area?

7. Has a large amount of water just been consumed? Wait for unit to

regenerate more water.

Noise-related problems.

1. Move the unit to hard /flat surface

2. Has any object come in contact with the unit?

Cold water temperature-related problems.

1. Is the cold water temperature set to normal / colder?

(Set temperature to Coldest. Wait at 20 minutes, If water does not get

cold call Service Centre)

2. Has there been a large amount of water consumed?

(When approx. 1 liter of water has been taken out, the cold water

becomes lukewarm. Wait for 5~10 minutes for cold)

Leakage-related problems.

1. If a leak occurs, turn off and unplug the unit.

2. Disconnect the unit from hybrid connection, if any.

3. If water valve is leaking, press it down several times.

If it does not work, replace the valve.

4. Do the humidity digits show Er/ Bp signal?

(Turn off/ Unplug unit. Turn unit back on.

If leak continues, turn off/ unplug the unit and call for Service)

1144

Trouble shooting

Address:Authorized Distributor in South Africa & AustraliaBlanca GIS (Pty) Ltd9 Isola di PalmeVictor Whitmill DriveSunward Park1459, Gauteng, South Africa

Tel: +27 11 306 7007Fax: +27 86 662 6060Email: [email protected]Website: www.blanca.co.za https://www.facebook.com/AtmosphericWaterGenerators1USER’S MANUAL

Atmospheric Water Generators

Desktop Unit Contact Information

Atmospheric Water Generators

Desktop Unit

Safety Precautions

Desktop Unit - Safety Instructions

Specification Contents

Owner s manualDrain hoseDimension WeightPowerCold Water Storage CapacityUnit After Packing Unit After Packing Input PowerPower Consumption Electrical CurrentCold WaterMild Cold Normal Temperature

380 (W) x 520 (D) x 560(H)mm 455(W) x 580 (D) x 640 (H)mm

39.5 Kg42 Kg230V 50Hz 115V 60Hz 440 W 550 W2.35 A7 ~ 12 15 ~ 20 20 ~ 25 13.5 litersDesktop Unit Our products and accessories are warranted against natural defects in material or faulty workmanship.One(1) year warranty on defective product. Defective parts will be replaced free of charge. Defective parts must be returned to supplier and will be exchanged (at the discretion of the manufacturer) for new or rebuilt replacement parts. Warranty does not cover cosmetic damage or damage due to acts of god, accident, misuse, abuse, negligence, or modification of, or to any part of the unit.Warranty does not cover damage due to improper operation or maintenance, connection to improper voltage supply, or attempted repair by anyone other than a facility authorized to service the unit. Warranty does not cover the unit sold As-Is or With-All-Faults, or consumables as fuses or water valves.Warranty will be determined with proof of purchase, unit lot number and date of issue. Purchase receipt must accompany returning defective unit or parts. A return authorization from your supplier must be issued prior to returning the products for repair or warranty. RA# must be displayed on outside of box.

Warranty
