INSTRUCTION MANUAL FOR BLANCO
FREE-STANDING COOKERS
90x60 cm – BFD914WX

Dear Customer,
Thank you for buying a BLANCO freestanding oven.
Before we continue telling you about this appliance, we cordially invite you to become part of the
Blanco family by subscribing online. Please visit our website where you can easily register for
product/cooking demonstrations, and request Blanco’s gourmet recipes. Go to www.blanco-
australia.com and fill in the subscription details in the contact us/showrooms section.
You will find that the clean lines and modern look of your Blanco appliance blends in perfectly with
your kitchen décor. It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as cooktops, range
hoods, dishwashers, microwaves, sinks and taps. There are models to complement your new
Blanco Oven.
Of course, we make every effort to ensure that our products meet all your requirements, and our
Customer Relations department is at your disposal, to answer all your questions and to listen to
all your suggestions.
Please complete the warranty card and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of this product
Blanco is committed to providing increasingly efficient products that are easy to use.
READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE
AP P LIAN CE.
It is important that you retain these instructions, proof of purchase as well as other important documents
about this product for future reference.
The manufacturer will not be responsible for any damage to property or to persons caused by incorrect
installation or improper use of the appliance.
Due to continual product development, Blanco reserves the right to alter specifications and appearances without
notice.
THIS APPLIANCE HAS BEEN DESIGNED FOR DOMESTIC USE ON LY
TO BE INSTALLED BY AN AUTHORISED PERSON
CONTEN TS
SECTION Page #
WARNINGS 2
LOCAL AUTHORITY REQUIREMENTS 3
IMPORTANT INFORMATION FOR INSTALLING THE APPLIANCE 4
APPLIANCE GAS CONNECTION 5
SUPPORT LEGS 7
CONVERTION TO A DIFFERENT TYPE OF GAS 9
APPLIANCE ELECTRIC CONNECTION 10
APPLIANCE USE AND MAINTENANCE 11
TROUBLESHOOTING 18
DISPOSAL INFORMATION 18
1

WARNINGS:
1. This appliance is not intended for use by persons ( including children) with reduced physical, sen so r y or mental
capabilities, or lack of experience or knowledge, unless they have been given supervision or i n s t r u ctio n
concerning
the use of the appliance by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the a pp lianc e.
2. DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE STORAGE DRAWER OR NEAR THIS
APPLIANCE. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
3. DO NOT MODIFY THIS APPLIANCE. This appliance is not suitable for use with aftermarket lids or covers.
4. After removing the packaging, make sure to check if there is any damage to the appliance. If there is any damage,
never attempt to use the appliance and
immediately contact your a u t h or i s ed Service Centre. As packaging
materials can be dangerous to children, they need to be collected im m e d i a t e ly and put out of re a c h .
5. In certain circumstances electrical appliances may be a safety hazard. The unit MUST be co nn ecte d to the
electrical supply before operation to enable the electronic ignition to work. The e l ectrical connection mu s t b e
accessible after installation. The appliance must be electrically isolated before any maintenance can b e p er for m ed .
6. Do not place heavy objects on this appliance
(cooktop or door), use for storage or as a c u tting surface, as sharp
edges can damage the surface. This appliance is designed for cooking only. If any damage such as chips
or cracks are seen in the glass, turn off all control knobs and do not use until the appliance has been
inspected by an authorised service person or replaced.
7. This appliance is designed for
domestic household use only and for the cooking of domestic foo d products. Use as
a
commercial appliance will void the warranty. It should not to be used outdoors and must be fully installed. Do not
use the appliance until fully installed. If this appliance is installed on a base, measures must be taken to prevent the
appliance from slipping from the base.
8. Damage can occur to bench tops if pots and pans are able to overlap the
b ench top. This can result i n heat being
transferred to the bench top. Ensure that correct sized pots & pans are used. Refer to guide i n i n s truct i ons.
9. Do not allow pot handles or utensils to be placed near gas burners in operation, as they c a n cause the handles to
become hot to touch. Always turn handles away when small children are nearby. It
i s recommended that children
are kept away from the cooktop at all ti me s .
10. Do not leave the cooktop while cooking with solid or liquid oils. There may be flaming up in c ond i ti on s of extreme
heating. Never pour water onto the flames
occurring from oil. Immediately turn the co o k to p o ff and cover the pan
with a lid or fire blanket in order to smother the f l am e.
11. If the
electrical supply cord is damaged, either when being installed or after installation, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to prevent a h aza rd .
12. The appliance is not intended to be operated by means of an external timer or separate remote cont r o l s yst em .
13.
Electrical connection must be made as per local wiring rules and r e gu l a t i on s.. D o n o t disconnect the appliance with
wet hands or bare feet, and do not disconnect the power cord with extreme force. If the elect r i c a l supply is
restricted, means of all-pole disconnection must be accessible and i n co rp o r ate d in the fixed wiring in accordance
with the wiring rules . The electrical and gas connections must be accessible after installation.
14. Ensure that the kitchen is well ventilated or mechanical ventilation is in use while cooking on th e a pp lian ce.
15. The cooktop and oven will become hot during and directly after use. Do not touch any c ompon e n ts during this
time, as they may be hot and can cause burns. To avoid burns young children should be kept a
w a y . Care should be
taken to avoid
touching heating elements inside the ov e n.
16. Cleaning may only be
commenced on the appliance once it has cooled down and is turned off. Fa il ur e to clean
properly can damage the unit. Do not use a steam jet or any other high pressure cleaning equipment to clean the
a
pp lia n c e .
17. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass surface as they
c a n scratch the
surface, which may result in the glass shattering. Clean the glass using a w arm damp cloth (e .g . dishcloth).
18. When the appliance is not being used, the knobs must be kept in the ‘OFF’ p ositio n .
19. The appliance must be
installed and put into operation by an authorised person under the co nd iti o ns provided by
the manufacturer in this manual. The manufacturer cannot be held re s pon si ble for any damage t h at might occur
due to faulty installation. Do not modify this ap p lia n ce.
20. Use the
anti-tilt kit to prevent the appliance from accidentally falling over .
21. DO NOT USE THIS APPLIANCE AS A SPACE HEATER.
2

LOCAL AUTHORITY REQUIREMENTS
Before installation, unpack all parts from carton, remove all internal packaging and check for da mage. Check Gas Type and
specifications plate placed on the rear of the unit, alternatively there is a second label supplied supplied – this should be fixed in
an accessible position close to the appliance (on the side of a cabinet, etc.). All gas fitting work, service and repairs can only be
performed by an authorised person in accordance with AS/NZS 5601 and local gas regulations. Failure to comply with this
condition will void the warranty. Always unplug the appliance before carrying out any maintenance operations or repairs. The
walls of the units must not be higher than worktop and must be capable of resisting temperatures of 65⁰C or higher. Do not
install the appliance near flammable materials (eg. curtains). The final act of any installation or gas type conversion must be the
full testing of this appliance, which includes leak testing, ignition of each burner and the functionality of the burners separately
and together.
Keep all the
dangerous packing parts (polystyrene foam, bags, cardboard, staples, etc.) away from c h il d r en .
Any walls of the adjacent furniture pieces and the wall behind the cooker must be made of heat-resistant material that can
withstand a minimum
temperature of 65°C.
Clearance above and around domestic co o ker s
Extract from AS5601
REQUIREMENTS
1. Overhead clearances – (Measurement A)
Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s ins t ructions. However, in no case shall
the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 650 mm or, for an
overhead exhaust fan, 750 mm.
Any other downward facing combustible surface less than 650 mm above the highest part of th e hob shall be protected for the
full width and depth of the cooking surface area in accordance with clause 5.12.1.2. However, in no case shall the clearance to
any surface be less than 450mm.
2. Side clearances – (Measurements B & C)
Where B, measured from the periphery of the nearest burner to any vertical combustible sur f ace, is less than 200 mm, the
surface shall be protected in accordance with Clause 5.12.1.2 to a height C of not less than 15 0 mm above the hob for the full
dimension (width or depth) of the cooking surface area. Where the cooking appliance is fitted with a “splash back”, protection of
the rear wall is not required.
3. Additional requirements for Freestanding and Elevated Cooking Appliances – (Measurements D & E)
Where D, the distance from the periphery of the nearest burner to a horizontal combustible surface is less th an 200 mm, then E
shall be 10 mm or more, or the horizontal surface shall be above the trivet. See insets above.
3

IMPORTANT INFORMATION FOR INSTALLING THE A P PL IAN CE
The cooker can be installed separately, a s a freestanding unit, or between kitchen u nits or between a ki t c h e n unit and the
w a ll.
This appliance is not connected to devices which exhaust combustion pr od uc t s.
Special attention must be focused on the instructions described below regarding room aeration and ventilation..
The dimensions of the appliance are listed below:
LENGTH DEPTH HEIGHT
897mm 600mm 900mm (adjustable 870-940)
Room Ventilation
To ensure that the appliance operates correctly, the room where it is installed must be con t inuously ventilated. The room
volume should not be less than 25m3 and the quantity of air should be based on the regular combustion of gas and on the
ventilation of the room. Natural air will flow through permanent openings in the walls of the room to be ventilated. These
openings will be connected with the outside environment and should have a minimum cross-section defined by current national
standards regarding room ventilation (Fig. 02).
These openings should be built so that they cannot be clogged.
Indirect ventilation is also permitted by taking air from the rooms adjacent to the one to be ventilated.
Fig. 02
Location and Aeration
Gas cooking appliances must always evacuate the combustion products by means of hoods connected to chimneys, flues or
directly outside (Fig. 03). If a hood cannot be installed It is possible to use a fan installed on a window or directly facing outdoors,
to be operated together with the appliance ( Fig. 04), provided that there is strict compliance with the ventilation regulations.
Fig. 03 Fig. 04
4

APPLIANCE GAS CONNECTION
IMPORTANT: This appliance must be installed by an authorised p e rso n.
WARNING: DO NOT MODIFY THIS AP P L IA NC E
If the appliance cannot be adjusted to perform correctly, contact the service department.
This appliance utilises a threaded 1/2" gas male fitting.
To connect the appliance to the gas network with a flexible hose, a supplemental hose nipple fitting is needed which is
supplied with the appliance. (Fig. 05).
Fig. 05
Gas inlet positions with different leg heights – mm
Gas inlet (mm) - Nat gas Gas inlet (mm) - L PG
From RH rear side: 35 mm From RH rear side: 35mm
Up from floor: 560 - 595mm (590mm nominal) Up from floor: 645 – 680mm (675 mm nominal)
Gas Regu l a to r
The gas connection is via 1/2" tapered thread. Connect the cooker to the gas supply and test for leaks. NEVER use a
naked flame to check for gas le a ks .
Natural Gas: Gas regulator supplied with the appliance must be installed.
LPG: Test point adaptor to be fitted and checked at time of installation.
Using a flexible connection
This appliance is approved for connection with a flexible hose, which complies with the AS/NZS 1869 (AGA Approved),
10mm ID, class B or D, between 1-1.2m long.
Connection shall be in compliance with AS5601.
When installing the hose restraint device, the appliance anchor point is the rear panel.
Using a Copper Pipe co nn ectio n
The cooker must be connected to the gas supply with upstream connection of an isolation valve in accordance with the
respectively valid regulations. We recommend that the isolation valve be fitted prior to the cooker to enable isolation of the
cooker from the gas supply. The valve must be easily accessible at all times.
To find out the gas type factory settings, see label on the rear of the appliance.
5

TABLE N°1: Energy Consumption
Ene
r
gy c on s um pt i on
Bur n ers Gas t y p e Pressure
(kPa ) Injector (
mm ) Mj /h r W a tts
Auxiliary Natural
U-LPG
1. 0
2 . 75
0.90
0.54
4
4
3500W
Semi-rapid Natural
U-LPG
1. 0
2 . 75
1.18
0.70
7
7
Rapid Natural
U-LPG
1. 0
2
. 75
1.55
0.92
12
12
Wok Natural
U-LPG
1. 0
2
. 75
1.8
1.02
16
14.8
Test the operation of the cooker before l ea v in g
Note: These burners have no aeration adjustment.
Check correct operation of the ignitions system and operation of the regulator and operation of the burners individually and in
combination. Burner flames should be clear blue, with no yellow tipping. If the burners show any abnormality check that the
burners are correctly located. If satisfactory performance cannot be obtained, contact Blanco service.
Imp o rt an t
Before leaving instruct the owner in the use of the cooker it should be expressly noted that we cannot accept any liability for
direct or indirect damage caused by wrong connection or improper installation. When being repaired, the appliance must always
be disconnected from the mains supply; if required, notify our customer service.
TABLE N°2: GAS BURNER DIMENSION
Bu
r
n e
r
Dimension (mm)
Auxiliar
y
Ø 50
Semi-rapid Ø 70
Rapid Ø 95
W ok Ø 125
6

SUPPORT LEGS
The cookers are supplied with four transit supports (one for each corner).
Four support legs are supplied separately and are fitted on location to the four corners of the lower support frame. Each support
leg is pushed over the relevant transit support until flush with the support frame.
Each leg is adjusted by screwing the lowe r section in or out as required for fitting to a 900mm bench height. For lower bench
tops adjust the height of the legs to 180mm so the hob is located 10mm above the horizontal combustible surface, ref. AS/NZS
5601
Fig. 06
Legs should be installed with the appliance close to its final
destination, as the legs are not designed for excessive force and
will snap off if too much side force is exerted on them (dragging
along or angled too much). When fitting, try to keep the
appliance as close to a horizontal position as possible. Use of a
pallet jack is recommended.
If the legs are not used and the cooker is mounted onto a plinth,
four transit supports allow for clearance.
With the legs fitted, the splash-back can be fitted. Follow the
instructions shown in Fig. 07.
See separate instruction sheet for kick-plate installation.
Fig. 07
7

With the legs adjusted to a nominal cooker height of 910 mm, and the splash-back fitted, anti-tilt restraint bracket can be added
to the rear of the appliance.
First fit the flat strap to the rear of the cooker at the centre point of the lower rear edge. Use the supplied screw (Fig. 08).
Mark a line on the floor marking the mid-point of the cooker once installed (see Fig. 09) from the back wall. Measure in (from the
back wall) the distance from the hob back (at top) to the rear of the cooker (dimension A), and mark on the mid-point line (see
Fig. 09). Place the retaining bracket against this mark and mark the fixing screw point on the floor. Mount the retaining bracket
to the floor using the supplied fixing screw (for concrete only, for other surfaces an appropriate fixing screw should be
purchased). Place the appliance in position and attach the 2 brackets with the supplied retaining screws accessing from
beneath the appliance.
Fig 08 Fig 08A
Fig. 09
8

CONVERSION TO DIFFERENT TYPES OF GA S
Before performing any maintenance operation, disconnect the appliance from the gas supply and ele c t r ic i t y
n
et w o rk.
REPLACING THE NOZZLES TO OPERATE WITH ANOTHER TYPE OF GAS
When converting to LPG remove the NG gas regulator (if fitted) and fit LPG test point adaptor.
If converting to Natural Gas, fit gas regulator.
Follow the instructions below to change the burner nozzles on the work s u r f ac e:
1) Pull out the plug from the electric outlet to avoid any type of electric contact.
2) Remove the grids from the work surface (Fig. 10).
3) Remove the burners (Fig. 10).
Fig. 10 (representation only)
4) Unscrew the nozzles using a 7 mm spanner, and replace them (Fig.11) with those needed for the new type of gas
according to what is indicated in the Energy Consumption Table.
Fig. 11
5) Burner " MINIMUM " adjustment:
Work surface burner
adjustment: follow the instructions below to adjust the work surface burner minimum:
 Light the burner and set the knob to the MINIMUM position (small flame).
 Remove the knob of the valve that is press fit on the rod of that valve.
 For all burners except for the wok burner, insert a small slotted screwdriver into the hole on the valve rod (Fig. 12) and
turn the choke screw to the right or left until the burner flame is adjusted to minimum.
 The wok burner has 2 adjustment screws on either side of the body of the valve (Fig. 13). Screw A is for the outer ring and
screw B is for the inner ring. Turn the choke screw to the right or left until the burner flam e is adjusted to minimum.
Ensure sure that the flame does not go out when s witching quickly from the MAXIMUM to
t he MINIMUM position
Fig. 12 Fig. 13
9

APPLIANCE ELECTRICAL CONNECTION
The electric connection must comply with the current legal standards and regulations.
Before making the connection, check that:
 The system electrical rating and the current outlet are adequate for the maximum power output of the appliance (see the
label applied to the bottom of the casing).
 The outlet or the system is equipped with an efficient ground connection in accordance with the current legal standards
and regulations. The manufacturer will not be responsible for the non-compliance with these instructions.
 The power cord is supplied with a 15A plug, suitable for the load indicated on the label and a standard 15A GPO.
Letter L (phase) =brown w i r e ;
Letter N (neutral) = blue w i r e ;
Ground symbol =
green - yello w
wi r e ;
Fig. 14
 The power cord must be positioned so that a temperature of 75°C will not be reached at any point.
 Do not use reductions, adapters or splitters since they might cause false contacts and lead to dangerous
overheating.
When the
connection is made directly to the electric netw or k :
 Use a device that ensures disconnection from the mains in which the contacts are opened to a distance that
permits complete disconnection according to the conditions for over-voltage category III.
 The ground wire must not be interrupted by the circuit-breaker.
 As an alternative, the electric connection can also be protected by a high-sensitivity residual current circuit-
breaker but this may be subject to nuisance tripping due to residual humidity in hea
t ing elements.
 It is highly recommended to attach the special green-yellow ground wire to an
effi cient ground system.
WARNING: If the power cord is replaced, the ground w i r e (yellow-green) connected to the terminal, s ho ul d be
longer than the other wires by about 2
c m.
WARNING: if the supply cord is damaged, it must be replaced by the manufacturer or its service agent or similarly
qualified person in order to avoid a hazard.
TABLE N°3: TYPES OF POWER CORDS
Work s u
r
fa c e
op e r at i on
O
v
en
o pe r a t i on
C
r
oss s ecti on
230V ~ 230V 3~ 400V 2N~ 400V 3N~
Only gas burner Gas oven / Electric grill 3x1mm² - - -
Ventilated Electric Oven 3x1,5mm² - - -
The appliance conforms to the regulation AS/NZS 5263 regarding gas appliance for domestic use and
A S/ N ZS 60335.26 regarding safety and CSPR 14 regarding electromagnetic compatibility.
Three-Phase electric connection
The cookers that can also be connected to three-phase systems normally are factory built for the single-phase 230V connection
and are supplied with a power cord. Based on the connection system used, install the power cord type indicated in table No.3.
To use the selected connection system change the jumpers on the terminal strip as indicated in the diagram of (Fig.15)
Fig. 15
10

APPLIANCE U S E A N D MAIN TEN AN CE
ATTENTION: Important Warnings.
 For cookers resting on base
ATTENTION: if the cooker rest on a base, take the measures necessary to prevent the cooker from sliding along the support
base.
 For cookers with electric ovens
ATTENTION: The unit becomes hot during use. Do not touch the heating elements inside the oven.
ATTENTION: The accessible parts can become hot during use. Keep children away from the appliance.
 For glass doors
ATTENTION: Do not use harsh abrasive cleaning products or metal spatulas with sharp edges to clean the oven door’s glass
since this could scratch the surface and the glass could break.
 For gas cooktops
ATTENTION: Clean burner tops and trivets at least once a week, or after any spillage. Check injectors are not blocked and the
probes and electrodes are clean. Gas inlet pipes should be checked periodically for leakages (see section on leak testing), at
intervals not exceeding 12 months. Lubrication of valves should only be performed by an authorised person, and is required if
the gas control knobs become stiff and difficult to turn.
Do not use steam cleaner to clean the appliance.
WARNING: DO NOT MODIFY THIS APPLIANCE
Please maintain your appliance regularly
REPLACING PARTS
Before performing any maintenance operations, disconnect the appliance f r o m the g a s supply and el ec t r i c i t y
ne t w ork .
To replace parts such as knobs and burners, just remove them from the seats without dis assembling any part of the
cooker.
To replace parts such as nozzle supports, valves and electric components follow the procedure described in the burner
adjustment paragraph. To replace the valve or the gas thermostat, it is also necessary to disassemble the two rear gas train
brackets, loosening the 4 screws (2 per bracket) that attach it to the rest of the cooker and, unscrew the nuts that attach the
front burner valves to the control support, after removing all the knobs. To replace the gas or electric thermostat, also
disassemble the rear cooker guard, loosening the relative screws, to be able to pull down and reposition the thermostat bulb.
To replace the oven bulb, just unscrew the protection cap that projects out inside the oven (Fig.16).
Fig.16
WARNING: Before replacing the bulb, disconnect the appliance from the electric power su pp l y .
WARNING: The power cord supplied with the appliance is connected to the appliance with an X type connection (in
compliance with standards AS/NZS 60335-1, AS/NZS 60335-2-6 and subsequent amendments) for which it can be
installed without the use of special tools, with the same type of cord as the one installed.
If the power cord becomes worn or damaged, replace it based on the information reported in t able 2. To replace the power
cable, lift the terminal board’s cover and replace the cable.
11

Greasing the va l v e s :
If it becomes difficult to operate the valve, it should be greased immediately by following the instructions listed below:
1) Disassemble the valve body by loosening the two screws located on the body of the valve (Fig.17)
Fig. 17
2) Extract and clean the seal cone and its housing with a cloth.
3) Lightly grease the cone with special grease.
4) Insert the cone, moving it several times, remove it again, remove the excess grease and make sure that the gas
passage ways are unobstructed.
5) Replace all the pieces by reversing the order in which they were disassembled and check that the valve operates
correctly.
CONTROL PANEL DESCRIPTION
On the control panel, small symbols show the function of each knob or key. Here are the several controls that a cooker can
have:
Indicates which burner on the gas cooktop a control knob controls, a full square identifying the
particular burner.
Indicates the control knob adjusts the functions of the electric oven.
Indicates the control knob adjusts the internal thermostat of the oven (the light below is lit when the
elements are running).
WARNING: If the power is cut off, the cook top burners can be lit with matches. When cooking foods with
oil and fat, which are very flammable, t he user should n o t leave the appliance unattended. Do not use s p r a ys
near the appliance when it is being used. When using the burners, make sure that the handles of the pots a r e
correctly positioned. Keep children away from the ap p li a n c e.
OVEN RACKS AND TRAY S
The oven is supplied with a baking tray (with removable wire rack) and wire racks.
Internally there is a wire support on either side with 5 mounting positions. The racks and tray are designed with a
small stop at the back. To insert, push the rack into one of the mounting positions angled down at the front so the
stop passes over the front of the support, and then push fully in. To remove, pull the rack out until the stop catches
at the front of the support & angle down to fully remove.
USING BURNERS ON CO OKTOP
A diagram is etched on the control panel above each knob which indicates which burner corresponds to that knob.
 Manual lighting (it is always possible even when the power is cut off): Turn the control knob that corresponds
to the burner selected anticlockwise, setting it to the MAXIMUM position at the
etched star (large flame on the control knob (Fig. 18) and hold a lit match to
the burner. Press the control knob down and hold for 2 seconds after the
burner ignites so the flame safety device (thermocouple) engages. Release the
control knob and adjust to the correct setting.
 Electric ignition : Turn the knob that corresponds to the burner selected
an
t iclockwise, setting it to the MAXIMUM position (large flame on the control
knob (Fig. 18). Keep pressing the knob down at this position until the burner
ignites and then wait for 2 seconds so the flame safety device (thermocouple)
engages. Release the control knob and adjust to the correct setting.
Fig. 18
12

Note: It is recommended not to try to ignite a burner if the relative flame cap is not in the correct position.
Tips for using burners correctly :
 Use suitably sized pots for each burner (see tab. 4 and Fig. 19).
Fig. 19
 When the liquid is boiling turn the knob to the MINIMUM position (small flame Fig. 18).
 Use pots with a cover when available.
 Large utensils exceeding the recommended maximum size can cause excessive heat to reflect back onto the appliance,
potentially damaging the appliance and causing a temperature hazard.
TABLE N°4 Pan Sizes
BURNER PAN DIAMETER recommended
(cm)
Auxiliary 12-14
Semi-rapid 14-26
Rapid 18-26
Wok 22-26
ATTENTION: Use Pots with a flat bottom for more efficient heat transfer.
USING THE OVEN THERMOSTAT CONTROL
K NO B
The thermostat is used to set the maximum internal temperature of the oven. Turn the thermostat control knob clockwise and
align the selected temperature indicated on the knob with the index etched on the control panel above it. Thermostat operation
is indicated by an orange light which will turn off when the temperature inside the oven is 10°C greater than the temperature
setting, and will turn on when the oven is 10°C less than the temperature setting. The thermostat can control the oven elements
only if an oven function has been set. For electronic timers, the timer must be off (“A” symbol off) or running.
USING THE OVEN FUNCTION CONTROL KNOB (Fig. 20)
The oven function knob is used to control the electric fan and the oven
elements in set combinations in conjunction with the timer and thermostat.
The electric oven is heated by 4 elements:
a) Upper element (1200W) and grill element (1500W) combined at the
top of the oven cavity.
b) Lower element (1600W) at the bottom of the oven cavity.
c) Two circular elements (1200W) at the rear of the oven cavity,
situated around the 2 internal fans.
Select an oven function by turning the oven function control knob so that
the symbol for the required function is at the top and in line with the index
etched on the control panel above it.
Note: The timer and thermostat must be set correctly for the oven to
function.
To turn electric oven off adjust the oven function control knob to position
0 (no function selected). Setting the thermostat con
t rol knob to position
0 turns off the elements but it is still possible, using the oven function
knob, to turn on the electric fan and the oven light.
13

There are 9 functions as per below:
QUICK START/DEFROST FUNCTION: This function runs the rear fans and all elements. The heat generated is too
hot to cook in, but is perfect for preheating the oven (run at the required
t emperature until the thermostat light turns
off and on a couple of time, then adjusts to the required function setting. To use as a defrost function, leave the
thermostat on 0. This allows air to flow over frozen food speeding up defrost times.
CONVENTIONAL COOKING FUNCTION: This function runs the upper and lower elements. It is dependent on the
timer and the thermostat setting.
LOWER ELEMENT COOKING FUNCTION: This function runs the lower element. It is dependent on the timer and
the thermostat setting. It can be used at low temperatures, for slow cooking casseroles & custard, and at high
temperatures for pastries.
UPPER ELEMENT COOKING FUNCTION: This function runs the upper element. It is dependent on the timer
and the thermostat setting. With less power than the grill, this can be used to brown cauliflower cheese and to
reheat lasagne.
GRILL COOKING FUNCTION: This function runs the upper and grill elements. It is dependent on the timer and the
thermostat setting. Best used for shorter grilling times, like toast or crumpets.
GRILL AND FAN COOKING FUNCTION: This function runs the upper and grills elements, and runs both rear
internal fans. It is dependent on the timer and the thermostat setting. Best used for longer grilling times, or when
grilling foods with a lot of moisture.
FAN ASSIST COOKING FUNCTION: This function runs the upper and lower elements, and runs both rear internal
fans. It is dependent on the timer and the thermostat setting. Best used when cooking large amounts of food at one
time, for frozen potato products and crumbed/battered chicken or fish.
FAN OVEN COOKING FUNCTION: This function runs the circular rear elements; and runs both rear internal
fans. It is dependent on the timer and the thermostat setting. This function is suitable to most types of cooking,
with even temperatures throughout the oven.
PIZZA COOKING FUNCTION: This function runs the lower and circular rear elements, and runs both rear
internal fans. It is dependent on the timer and the thermostat setting. Great for Pizza s, pastries or flat breads,
where you want the base crispy and the rest cooked.
14

USING THE ELECTRIC OVEN
When using the oven for the first time it should be operated for a maximum of 30 minutes at a temperature of about 250°C to
eliminate any odours generated by the internal insulation. During normal oven use, select the desired cooking temperature
using the thermostat knob and wait until the orange light turns off (set temperature has been reached) before putting in any food.
The oven is equipped with 5 guides at different heights (Fig. 21) which can be used to insert shelves or the tray. To keep the
oven as clean as possible it is recommended to cook meat on the tray or on the shelf that has been inserted inside the tray.
Always turn the oven off by adjusting the oven function control knob to off (0).
NOTE: After use, the cooling fan will continue to run until the internal electrical system has cooled sufficiently.
Fig. 21
When cooking, always open the oven door slightly first (head away from the door), to allow any built-up steam to escape, and
then open fully. Always use heat resistant gloves when removing hot items from the oven. Never line the sides or base of the
oven, or enamel backing dishes with aluminium foil (it can damage the enamel sur
f ace). Never cook or place cookware on the
base – always use trays and shelves provided.
Always preheat your oven before cooking (see the quick start function), which allows more accurate timing of cooking.
CONVENTIONAL COOKING
Conventional cooking cooks with heat coming from both the top and bottom, ideal for roasts and pastries. After preheating oven
to the correct temperature (50⁰C to 250⁰C), adjust oven function control knob
t o conventional cooking and place food inside
oven. Set timer if needed.
FAN OVEN COOKING
Fan Oven cooking cooks with heat coming from the rear of the oven, with hot air circulated around by the fans, ideal for cooking
different types of food together without mixing the tastes. Pre-heat the oven for 10 minutes before inserting the trays. Adjust
oven function control knob to fan oven cooking and place food inside oven. Set timer if needed.
GRILLING
The grill is controlled using the oven’s temperature knob. The grill function uses both elements at the top of the oven, so is
faster and more powerful than using the top element alone. Run this function with the door closed and at a temperature not
exceeding 150°C for up to 15 minutes. Use the enamel tray with wire rack insert at positions 1 or 2 (or lower to slow down the
grilling process). Do not leave the tray in the upper positions when not in use, as they will deflect heat away from food.
Preheat for 5 minutes first before adding the food and tray. This function is best for thinner, quickly cooked food like toast; for
thicker food that will take longer, use the grill and fan cooking function.
GRILLING WITH FANS
This function is similar to the grilling function, but with the rear fans added, allowing a more even heat to flow around the food.
Run this function with the door closed. Place the food on a wire rack and insert at position 3. Place a baking dish on level 5 to
catch any juice or crumbs (this allows the heat to circulate the food). This is better for thicker foods which need to be cooked for
longer times. Preheat for 5 minutes first before adding the food and tray
15

USING THE ELECTRONIC TIMER
Selecting and adjusting timer fu nc tions
Select a timer function by pressing the function button and set the
required time with the +/- buttons.
Pressing the “+” button increases the time set, pressing “-“ decreases
it. The count-up and count down speed increases the longer the
button is held in the appropriate position.
Manual op e r a t io n
The oven needs to be put into manual mode to operate without the timer.
Press duration and end time button together. This will allow the oven to
bypass the timer and run manually. The “A” symbol will be erased and
the pot symbol illuminated. Any program which has been set is
cancelled.
Setting the time of d a y
Select the function by pressing the duration and end buttons
together, and then adjust the time of day with the +/- buttons.
Semi-automatic operation with cooking du r a ti on
Select the desired cooking function and temperatures using the oven control knobs. Press the duration button and set the
required duration with
t he +/- buttons. The “A” and cook pot symbols appear and the oven becomes active. When the time has
been reached, the oven and the cook pot symbol are turned off. An audible signal sounds and the symbol “A” will begin to
flash. Reset the oven to off using the oven control knob and press any of the 3 buttons to the left to stop the audible sound.
Semi-automatic operation with cooking end t i me
Select the desired cooking function and temperatures using the oven control knobs. Press the end button and set the required
end time with t h e +/- buttons. T he “A” and cook pot symbols appear and the oven becomes active. When the end time has
been reached, the oven and the cook pot symbol are turned off. An audible signal sounds and the symbol “A” will begin to
flash. Reset the oven to off using the oven control knob and press any of the 3 buttons to the left to stop the audible sound.
Fully automatic op e r a t io n
Select the desired cooking function and temperatures using the oven control knobs. Press the duration button and set the
required cooking duration with t he +/- buttons. T he “A” and cook pot symbols appear and the oven becomes active. Press the
end button (the earliest end time will be displayed) and set the required end time with
t h e +/- buttons. The oven and the cook
pot symbol will both turn off.
When the start time is reached (end time – duration), the cook pot symbol appears again and the oven becomes active. When
the end time has been reached, the oven and the cook pot symbol are turned off. An audible signal sounds and the symbol “A”
will begin to flash. Reset the oven to off using the oven control knob and press any of the 3 buttons to the left to stop the
audible sound.
Minute mi nd er
Press the minute minder button and set required time with the +/- buttons. While the function is running, the bell symbol is
displayed. When the time set has elapsed, the audible signal sounds. Press any of the 3 buttons to the left to stop the audible
sound.
Audible signal
The audible signal sounds at the end of a minute minder cycle or of a cooking program for a period of 7 minutes (unless
stopped by pressing one of the 3 buttons to the left). The sound can be adjusted by pressing the “-“button with no other function
selected. There are 3 different sounds to choose from
Timer function v e r i f i cation
A function which has been set is carried out after setting the time required. The “time to run” can be verified at any point by
pressing the appropriate function button.
Cancelling timer fu nc ti ons
A program can be cancelled by selecting the manual function. When a program finishes, it is automatically cancel.
16

CLEANING THE APPLIANCE
Before cleaning the appliance, it should be disconnected from the power supply and turned off the main gas feeder
valve.
Cleaning the work s u r f a c e
Periodically clean the burner parts and trivets as listed below. Note that all parts must be thoroughly rinsed and dried
before being replaced.
Any liquid that overflows from pots must always be removed using a rag.
If it becomes difficult to open or close a valve, do not force it, but immediately contact the Blanco service department.
Cleaning the enamelled p ar t s
The trivets and burner covers are cast iron with an enamel coating. To maintain the original features of the enamelled
parts they should be cleaned frequently with soapy water. Never use abrasive powders. Do note leave acidic or alkaline
substances on the enamelled parts (vinegar, lemon juice, salt, tomato sauce, etc.) and do not wash the enamelled parts
while they are still hot.
Cleaning the STAINLESS steel p a r t s
Clean the parts with soapy water and then dry them with a soft cloth. The shine is maintained by periodically using
special products that generally are found in the market. Never use abrasive powders.
Cleaning the burner bodies
The aluminium burner bodies sit on the burner bases. Remove from the base and wash them with soapy water. Rinse and dry,
and check that all holes and slots are fully cleaned. Replace on the burner bases, taking care that they are positioned and
orientated correctly.
Cleaning the inside of the o v en
To thoroughly clean the inside of the oven, it is recommended that the door be removed first. First lock the hinge in place with
the nail supplied (01-02). With the hinges fixed, grab both sides of the door and slowly work the door off the hinges towards you.
Once fully removed, place in a safe position until it is time to fix back in place (in the opposite order). The internal rack guides
can also be temporarily removed by undoing the screws holding them in place and lifting out.
17

TROUBLESHOOTING
If you have a problem with your appliance, check the following before contacting service.
PROBLEM SOLUTION
Oven or hob not working Check the electricity is turned on.
Check your fuses. If the fuse continues to blow, call Blanco service.
Check the circuit breaker.
Ensure correct knob is positioned correctly.
Dry or clean ignition electrodes.
Make sure flame ports and ignition areas are clean and dry.
Check gas main supply is on.
Ensure cap/crown correctly fitted.
Replace or tighten light globes.
Hobs ignite but don’t stay on Hold control knob in longer to engage flame safety device.
Clean thermocouple and check burner ports are clean.
Heating up problems Oven not pre-heated: Pre-heat oven for 10 minutes.
Check oven door is closed properly.
Remove foil or trays from bottom of oven.
Change oven temperature.
Pre-heat oven before putting the food in to be cooked.
Unit smoking/odours Turn the oven on high to remove protective oils.
Persistent gas smell: do not operate the cooker call Blanco service.
Condensation note: some
Condensation is normal and is
to be expected during cooking.
Reduce the amount of water used for cooking.
Leave the door open after cooking if food remains in cooker for
warming.
Oven shelves are tight Remove oven shelf and re-insert.
Cooling fan runs after ovens
turns off
This is normal and not a fault.
DISPOSAL INFORMATION
Most of the packing materials are recyclable. Please dispose of those materials through your local recycling depot or by placing
them in appropriate collection containers.
If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.
18
