Blanco BCC774T Installation guide

Instructions for the Use and Care and Installation of
Touch Control Cooktop
04083AX77

Dear Customer
You will find that the clean lines and modern look of your Blanco cooktop blends in perfectly with your
kitchen décor. It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as ovens, rangehoods,
dishwashers, microwaves, sinks and taps. There are models to comple- ment your new Blanco cooktop.
Blanco now has a range of laundry products to choose from.
Of course, we make every effort to ensure that our products meet all your require- ments, and our Customer
Relations Department is at your disposal, to answer all your questions and to listen to all your suggestions.
Please complete the warranty section of this manual and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of Blanco product.
Blanco is committed to providing increasingly efficient products that are easy to use, respect the
environment and are attractive and reliable.
BLANCO

DESCRIPTION
6
SWITCH ON/OFF A HEATER ZONE
To switc ON a eater Touc any eater´s zone during 400 msec. Long beep will be eard and "0" value
will appear in target zone digit, indicating power level.
●If any cooking stage is in position 0, this display will switch OFF automatically after 10 seconds and
the zone OFF sequence will sound.
●If there is residual heat indication in the display which is ON but in 0power, “0” will appear changing
over.
●If lock function is active you cannot switch ON a zone.
To switc OFF a eater Touc any eater´s zone during 1, 2 sec. 3 s ort beeps will be eard and not ing
or "H" value will appear in target zone digit if residual eat exists. Zone will be OFF.
●If any cooking stage is in position 0, this display will switch OFF automatically after 10 seconds and the
zone OFF sequence will sound.
●If there is residual heat indication in the display which is OFF, "H" will be displayed.
●Even lock function is active you can switch OFF a zone.
●If only one heater is active and this one is switched off, 4 short beep will be heard indicating all cook top
is OFF.
INCREASE/DECREASE POWER LEVEL
Wit a s ort press on ‘+’ or ‘–‘ keys, increase or decrease power in t e selected zones digit: 0 - 1 - 2 -
3... 9 - P.
●Direct Access to Pfrom 0level pressing –key.
●For long presses in +or –keys, power level increases/decreases continuously. With a fast increase,
power stops at level 9, and for a higher power another short press is needed on the +key. No beep
sound is heard with fast increase/decrease.
●Once arrived to Ppower level, pressing +key again does not change power level to 0.
●With a zone ON at 0power level, if the zone is hot, 0will blink alternatively. After 10 seconds, 0 will
disappear an ‘H’ letter will appear fixed on display.
●When a heater is selected and ‘+’ and ‘–‘ keys are touched at the same time, power level will go to ‘0’
but heater will maintain selected during 10 seconds.
ARRANGEMENT OF THE HEATING ELEMENTS
LEFT FRONTLEFT REAR
RIGHT REARRIGHT FRONT
Model BCC774T

DESCRIPTION
7
CHILD LOC OPTION
When there isn’t a specific key to develop this function, press combination of FL and RL zones selection
keys for 2 sec. Short beep will be heard and displays will show "L" letter during 2 sec.
Then, any time when a key will be touched, displays will show "L" during 2 sec. heating remains at the
same state.
To deactivate Child Lock, follow the same process explained before. Then short beep will be heard and
displays will show "n" letter. Hob will remain unlocked.
Note: An automatic child lock will produce in 15 minutes after total switc OFF of t e ob. T is function
will appens automatically but previously is necessary to programme it. See User settings point.
Automatic Child Lock
Press key sequence: +and –combined and 1 long beep and 1 short beep will be heard. Before 2 sec
passed, touch +key.
When symbol appears, it means that automatic child lock is active.
Touching –key, automatic child lock deactivate. Settings validation will produce after a 5 sec. timeout
.
When any of these two option is selected, display will show the option active in this moment.
DOUBLE ZONES
To switch ON double extension ring, associated main zone must be already ON and
Indicating power level must be higher than 0.
1st short press on extension key switches ON extension ring.
LED over extension key turns ON if extension ring is ON.
2nd Short Press on extension key switches OFF extension ring.
Short beep each press on extension key .

USE
8
AUTOMATIC SAFETY OFF
If the power level is not changed during a preset time, the corresponding heater turns off automatically.
The maximum time a heater can stay on, depends on the selected cooking level.
OVERFLOW
Something (an object or a liquid) is pressing any key during more than 5s. 2 short beep + 1 long beep
every 30s while the key is pressed. Cook-top will turn OFF.
This symbol will maintain blinking while the matter persist.
Power level Max. time on
(hours)
110
25
35
44
53
62
72
82
91
P1
CAUT ON:
n case of hotplate glass breakage:
●shut immediately off all burners and any electrical
heating element and isolate the appliance from
the power supply;
●do not touch the appliance surface;
●do not use the appliance.
