Blankom 965x.01 series User manual

Professional Headend Solutions
Operating instructions
Contents
1. Safety and operating instructions ...................................................................2
2. Device variants.................................................................................................2
3. General ............................................................................................................2
4. Front view.........................................................................................................3
5. Functional description .....................................................................................3
6. Head end bus structure ...................................................................................3
6.1 Minimum configuration (without Bus Extender) ......................................3
6.2 Standard configuration (with Bus Extender) ...........................................4
7. Head end bus structure ...................................................................................4
8. Redundancy circuit ..........................................................................................4
9. Alarm function .................................................................................................5
10. Technical data .... ...........................................................................................5
11. Programming ................................................................................................6
10.1 Main program ........................................................................................6
10.2 Adjustments ...........................................................................................6
10.3 Subroutine “Change configuration“ .......................................................7
10.4 Adjusting of the IP number ....................................................................7
11. Bibliography ..................................................................................................8
12. Document history ..........................................................................................9
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply

2
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
1. Safety and operating instructions
When assembling, starting-up and adjusting the modules, it is necessary to consider the system specific
references in the manual instruction!
The modules may only be installed and started up by authorized technical personnel!
When assembling the modules into the receiving points, the adherence of the EMC regulations is to be secured!
The assembly and wiring have to be done without voltage!
All active modules may only be operated with the Headend Controller HCB x00 or Bus Extender BEB x00!
The main voltage and the operating voltage of the modules working by DC have to be in complience to the operating
parameters described in the technical data.
With all work the defaults of the DIN EN 50083 have to be considered! Especially the safetyrelevant execution of the
DIN EN 60728-11 [1] is necessary!
2. Device variants
HCB 200 9652.01 Headend control unit with 8A power supply (100 ... 240 V~ input)
HCB 300 9653.01 Headend control unit with 8A power supply (48 V– input)
3. General
The Headend Controller HCB x00 is a module of the head end system B-LINE, which can also be used in the head end system
C-LINE/ C-LINE+.
The B-LINE system is conceived as a complete system for middle sized distribution networks, the C-LINE/ C-LINE+for smaller
distribution networks. All active modules are programmed via the central Headend Controller.
The individual modules will be addressed by the address switch at the Bus Extender (line) (BEB x00) and at the respective module
(position).
The status of the modules will be displayed by colored LEDs:
· Red - ERROR Control bus error
· Green - READY Operating status
· Yellow - DATA Data traffic at the internal control bus
RJ 45 socket:
· Yellow - DATA Data traffic (LAN/ WAN)
· Blue - LINK Connection

3
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
5. Functional description
The Headend Controller HCB x00 is the central control module of the head end or the individual switch cabinet. It consists the data
interfaces to a PC/ LAN/ WAN and to the Bus Extender (BEB x00). The head end internal data bus has to be connected as seen in
chapter 6 to 8 and the alarm function is descriped in chapter 9. Both bus connections X1 and X2 can be used for that. The data inter-
face to a PC/ LAN/ WAN is implemented as a IP-/ Ethernet interface (RJ 45). Programming can be done but also directly at the control
unit (see programming). By pressing the reset-key the HCB x00 reboots and all data of the head end are read out again.
The internal power unit supplies the control unit and in case of a Bus Extender (BEB x00) error it will switch automatically to the
respective line. The Headend Controller HCB 200 has an integrated current display, but the HCB 300 hasn‘t this function. It is recom-
mended to use an individual control unit for every circuit (switch cabinet).
The IP address of each control unit can be edited and adapted to the respective LAN.
Additional information: Redundancy circuit (Headend Controller) (chapter 8)
Structure (minimum configuration) (chapter 6)
Option: SNMP and DHCP
HEADEND CONTROLLER
POWER SUPPLY
Type: HCB 200 Part No.: 9652.01
INPUT VOLTAGE 100 ... 240 V
INPUT FREQUENCY 50 / 60 Hz
INPUT POWER max. 110 W
ALARM SOURCE yes
OUTPUT (DC) 12 V / max. 8 A
Display
Control keys
Reset key
Operating voltage/
control bus (X1, X2)
LED „ERROR“ (red)
LED „READY“ (green)
LED „DATA“ (yellow)
LAN/ WAN
LED „DATA“ (yellow)
LED „LINK“ (blue)
Power supply
4. Front view
.
6. Head end bus structure
6.1 Minimum configuration (without Bus Extender)
The number of the possible module connections (00 ... 15) to a
BEB x00 depends on the total power consumption of this line!
HCB x00
Module
ADDR. 00
Module
ADDR. 15
HCB x00
Headend Contoller
Module
ADDR. 01

4
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
6.2 Standard configuration (with Bus Extender)
7. Redundancy circuit
(Power supply redundancy)
Description of the power supply redundancy
With the redundant operation of a system, the control unit HCB x00 will automatically take over the function of the power supply, if the
Bus Extender BEB x00 is failing .
HCB x00
Headend
Controller
BEB x00
Bus Extender
Module
signal processing
unit
HCB x00
Module
ADDR. 15
BEB x00
ADDR. 01
BEB x00
ADDR. 02
BEB x00
ADDR. 15
Module
ADDR. 01
Module
ADDR. 01
Module
ADDR. 01
Module
ADDR. 15
Module
ADDR. 15
The number of the possible module connections (01 ... 15) to a
BEB x00 depends on the total power consumption of this line!
HCB x00
Module
ADDR. 15
BEB x00
ADDR. 01
BEB x00
ADDR. 02
BEB x00
ADDR. 15
Module
ADDR. 01
Module
ADDR. 01
Module
ADDR. 01
Module
ADDR. 15
Module
ADDR. 15
broken
redundancy
supply

5
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
8. Alarm function
To activate the alarm function is additional hardware 9651.01 or 9651.02 necessary!
The device is endorsed by an additional alarm function and current limitations, voltage drops and communication disturbaces. The
contact 13 in the communication and supply bus is switched (+5V to 0 V) in case of alarm.
The alarm modules are available in 1 RU and in panel form. It is possible to insert the modules in any order into bus system. The si-
gnal is fed to a SUB-D 9 connector via relais in case of alarm. All the contacts are galvanically isolated. It is possible to trigger several
kinds of alarm.
9. Technical data
Manual operation
Input 3 operating keys,
reset key
Display LCD, lit
19 x 28 mm
Remote control
Network connection (LAN/ WAN) Ethernet, 10 Base T
Input connection RJ 45
Address extent
Without Bus Extender 16 modules
With Bus Extender 240 modules
(15 x 16)
Power supply HCB 200
Main voltage 100 ... 240 V (+10%/ -5%)
Voltage frequency 47 Hz … 63 Hz
Main connector built in connector
EN 60320-1/ C8
(IEC 320 C8) [3]
Power consumption max. 110 W
Output DC voltage 12 V
Rippled noise ratio 66 dB
Current drain max. 8 A**
Current limit yes (9 A typical)
Short circuit protection yes
Overvoltage protection yes (≤ 14,5 V)*
Internal device fuse G 5 x 20, T4A
(IEC 127 - 2/ V)
Protective system II acc.. DIN VDE 0860 [4]
Protection class IP 20
Radio noise suppression according DIN VDE 0871
(curve B) [5]
Temperature range -10 … +55°C
Power supply HCB 300
Input voltage 48 V DC (36 ... 72 V DC)
Input current (at 48 V) 2.4 A
Power consumption max. 125 W
Overcurrent protection fold back
(at 110 ... 143% IOUT)
Overvoltage protection 16.8 ... 20 V
Max. current drain 8 A (-10 ... +43 ˚C)**
6 A (+55 ˚C)
Voltage stability 1500 V DC (input/
output)
Radio noise suppression EN 55022 (CIS PR22)
Class B [6]
EN 61000-4-2,3,4,6,8 [7] /
ENV 50204 [8]
Environmental conditions
Relative humidity ≤ 80 % (non condensing)
Mounting method vertical
Mounting location splash-proof and
drip-proof
Physical information
Dimensions (l x w x h)
without 19“-adapter 50 x 276 x 148 mm
with 19”-adapter 50 x 301 x 148 mm
Weight HCB 200 about 1,500 g
HCB 300 about 1,600 g
Delivery contents
1 x Power cord
1 x Screw driver
2 x Wrenches
4 x Terminal resistance 75 Ω
2 x Multipole sockets
Software options
SNMP activation CKB 100 (9650.50)
*to reset device 2 minutes without voltage!
** > 6 A only use bus cable “8 A“ !

6
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
10. Programming
10.1 Main program
* only available for HCB 200
10.2 Adjustments
BLANKOM
ENTER
Selection modules
IP number
Type/ article number
Change module
( )
see operating instructions of the module
Change configration
Change IP number
System restart
NIT distribute
Temperature
Voltage
Contrast
Version
Back
Reset
Configuration
Address selection
display distribute static NIT
display temperature
display voltage
+/-display/ selection
display version
abort
any
key
any
key
any
key
OK

















any
key
Current *


display current any
key



1.1
1
2.1
2






System restart
Time
Language
starting timedisplay/ selection
hours/ minutesdisplay/ selection
display/ selection german/ english
Manuel adjustment
• Adjustment of the addresses at the Bus Extender BEB x00
and at the modules
• Activation of the data input at the Headend Controller HCB
x00 by pressing the “ENTER”-key
• Display/ adjustment of the parameter of the HCB x00 or a
selected module as in chapter 11.1
• Activation of the programming modus of each module by
selecting the line (BEB x00) and the module position (01 …
15) at the Headend Controller (HCB x00) →the yellow LED
at the module will be lit up til the beginning of the parameter
adjustment
• Adjustment of the parameter at the selected module accor-
ding to the individual product description
• After the programming the data will be transmitted automa-
tically to the modules →the yellow LED on the HCB x00 will
be lit up during the data transfer process
• The green LED shows the operating status
Adjustment with the PC/ laptop
• An “online connection” after IP-standard and an ethernet
connection at the PC/ laptop is necessary for the remote
programming
• Adjustment of the line/ position addresses at the Bus Exten-
der BEB x00 as well as at the modules
• At the HCB x00 IP-address input (e.g. 192.168.001.001)
• For “direct connection” between a PC and HCB x00 use a
crossed patch cable (RJ 45)
• For connection over a deviation use an uncrossed patch
cable
• HTML-browser start-up and IP-address as target address
input
• If connected correctly the HTML control surface at the PC
will open up and a blue LED (LINK) at the HCB x00 will be
lit up
• All adjustments of the modules are specified at the control
surface
Adjustment of removal of write protection
• Removal of write protection by input of “0000” (password)
and “0000” (user)
Default IP Address
• 192.168.2.80
see chapter 11.3
see chapter 11.4


ENTER
Going back
Going forward

7
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
10.3 Subroutine “Change configuration”
10.4 Adjusting of the IP number
Adjusting facilities of IP numbers
* Software option 9650.50
Change configuration
Address selection
All characters
Back
direct input or selection
all characters/ numbers & capital letters only
1
1






1.1
IP number webserver
xx or zz
(see fig. right)
Subnet mask
Gateway address
DHCP address
Trap address *
VEA/ EMA IP number
21
* Software option 9650.50
xx or zz
(see fig. right)
xx or zz
(see fig. right)
xx or zz
(see fig. right)
xx or zz
(see fig. right)
xx or zz
(see fig. right)
xx or zz
(see next figure)
xx or zz
(see next figure)
xx or zz
(see next figure)
xx or zz
(see next figure)
xx or zz
(see next figure)
xx or zz
(see next figure)

8
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
Subroutine “Change IP number“
IP number is displayed
4. Byte (MSB)
3. Byte
2. Byte
1. Byte (LSB)
change
YES
NO
21
zz
xx
2
11. Bibliography
[1] EN 60728-11: Cable networks for television signals, sound signals and interactive services Part 11: Safety
(IEC 60728-11:2005); German version EN 60728-11:2005
[2] EN 50083-2 : Cabled distribution systems for television and sound signals. Electromagnetic compatibility for equipment;
EN 50083-2:2001
[3] EN 60320-1: Appliance couplers for household and similar general purposes Part 1: General requirements
(IEC 60320-1:2001 + A1:2007); German version EN 60320-1:2001 + A1:2007
[4] DIN VDE 0860: Audio, video and similar electronic apparatus, Safety requirements (IEC 60065:2001, modified +
A1:2005, modified); German version EN 60065:2002 + A1:2006 + Cor.:2007 + A11:2008
[5] DIN VDE 0871: Radio noise suppression of high frequency units, Determination of limits for industrial, scientific and me-
dical equipment, identical with CISPR 23 :1987
[6] EN 55022: Information technology equipment - Radio disturbance characteristics - Limits and methods of measurement
(IEC/CISPR 22:2005, modified + A1:2005); German version EN 55022:2006 + A1:2007
[7] EN 61000-4-2: Electromagnetic compatibility (EMC) - Testing and measurement techniques-Electrostatic discharge
immunity test, 2009-05-31
EN 61000-4-3: Electromagnetic compatibility (EMC) - Part 4-3 : Testing and measurement techniques - Radiated, radio-
frequency, electromagnetic field immunity test (IEC 61000-4-3:2006 + A1:2007); German version EN 61000-4-3:2006 +
A1:2008
EN 61000-4-4: Electromagnetic compatibility (EMC) - Part 4-4: Testing and measurement techniques - Electrical fast
transient/burst immunity test (IEC 61000-4-4:2004); German version EN 61000-4-4:2004
EN 61000-4-6: Electromagnetic compatibility (EMC) - Part 4-6: Testing and measurement techniques - Immunity to con-
ducted disturbances, induced by radio-frequency fields (IEC 61000-4-6:2003 + A1:2004 + A2:2006)
EN 61000-4-8: Electromagnetic compatibility (EMC) - Part 4-8: Testing and measurement techniques - Power frequency
magnetic field immunity test (IEC 77A/694/FDIS:2009); German version FprEN 61000-4-8:2009
[8] ENV 50204: Radiated electromagnetic field from digital radio telephones - Immunity test, 1996-02-15

9
HCB x00
Part No: 965x.01
Headend Controller
Headend control unit with 8A power supply
B
LINE
12. Document history
Version Date Modification Author
1.00 15.04.2009 basic document Häußer, Rudolph
1.01 30.07.2009 revision Häußer
1.02 15.12.2009 revision (program flow) Häußer
1.03 11.01.2010 insert of HCB 300 Häußer
BLANKOM Antennentechnik GmbH
Hermann-Petersilge-Straße 1 • 07422 Bad Blankenburg • Germany • Telefon [phone] / 60-0 • Fax [phone] / 60-100
Options available upon request! Subjects to changes due to technical progress.

10
Declaration of Conformity
The Manufacturer
BLANKOM Antennentechnik GmbH ∙ Hermann-Petersilge-Str. 1 ∙ 07422 Bad Blankenburg ∙ Germany
herewith declares the conformity of the products
Product name: Headend Controller
Type: HCB 200 HCB 300
Product number: 9652.01 9653.01
according to the following regulations
EN 50083-2
EN 60728-11 (as far as relevant)
and additional device-specific regulations, enclosed above, which these products are subjected to.
Date: 11.01.2010
Signature:
Piero Kirchner
(Managing Director)
