BLAUBERG S22 User manual

SenSor control panel
EN
S22
USER’S MANUAL

www.blaubergventilatoren.de S22
2
Safety requirements..................................................................................................................................................................... 2
Purpose................................................................................................................................................................................................ 3
Delivery set........................................................................................................................................................................................ 3
Technical data.................................................................................................................................................................................. 4
Installation and connection.................................................................................................................................................... 4
Setup and control ........................................................................................................................................................................ 6
UNIT MOUNTING AND OPERATION SAFETY PRECAUTIONS
• Disconnect the unit from power mains prior
to any installation operations.
• Do not operate the unit outside the
temperature range stated in the user's
manual.
• Do not operate the unit in aggressive or
explosive environments.
• Do not lay the power cable of the unit in
close proximity to heating equipment.
• While installing the unit follow the safety
regulations specific to the use of electric
tools.
• Do not change the power cable length at
your own discretion.
• Do not bend the power cable.
• Avoid damaging the power cable.
• Do not put any foreign objects on the power
cable.
• Unpack the unit with care.
CONTENTS
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the S22 unit and all its
modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
The information in this user’s manual is correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to
incorporate the latest technological developments.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means in any information
search system or translated into any language in any form without the prior written permission of the Company.
SAFETY REQUIREMENTS
• Please read the user’s manual carefully prior to installing and operating the unit.
• All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical
norms and standards must be observed when installing and operating the unit.
• The warnings contained in the user’s manual must be considered most seriously since they contain vital personal safety informa-
tion.
• Failure to follow the rules and safety precautions noted in this user’s manual may result in an injury or unit damage.
• After a careful reading of the manual, keep it for the entire service life of the unit.
• While transferring the unit control, the user’s manual must be turned over to the receiving operator.

www.blaubergventilatoren.de
S22
3
• Do not use damaged equipment or cables
when connecting the unit to power mains.
• When the unit generates unusual sounds,
odour or emits smoke disconnect it from
power supply and contact the Seller.
• Do not touch the unit controls with wet
hands.
• Do not carry out the installation and
maintenance operations with wet hands.
• Do not wash the unit with water.
• Protect the electric parts of the unit against
ingress of water.
• Do not allow children to operate the unit. • Disconnect the unit from power mains prior
to any technical maintenance.
PURPOSE
DELIVERY SET
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED
PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT THE APPROPRIATE
TRAINING.
THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED
PERSONNEL AFTER THE APPROPRIATE BRIEFING.
THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORIZED
ACCESS BY UNATTENDED CHILDREN.
The wall control panel with a sensor display is designed for controlling industrial and domestic supply and exhaust ventilation units (AHU)
as well as other air handling units.
The control panel is not designed for standalone operation.
It is rated for continuous operation.
NAME NUMBER
Control panel 1 pc.
Mounting box for wall surface mounting 1 pc.
Mounting box for wall flush mounting 1 pc.
Signal cable, 10 m 1 pc.
User’s manual 1 pc.
Packing 1 pc.

www.blaubergventilatoren.de S22
4
Power supply voltage [V] 24
Maximum load current [A] 0.025
Cable type 4x0.25 mm2
Temperature range [˚C] +10...+45
Humidity range [%] 10 - 80 (no condensation)
Ingress protection rate IP40
R 2 mm
4 mm
42.5 mm
13.5 mm
68 mm
 82 mm
 60 mm
Mounting box for surface wall mounting Mounting box for ush wall mounting
94 mm 34 mm
3 mm
53.5
mm
88 mm
53.5 mm
32 mm
TECHNICAL DATA
INSTALLATION AND CONNECTION
CHECK THAT THE UNIT IS DISCONNECTED FROM POWER SUPPLY PRIOR
TO ANY OPERATIONS!
THE UNIT MUST BE MOUNTED BY A QUALIFIED EXPERTS ONLY, PROPERLY TRAINED
AND POSSESSING THE REQUIRED TOOLS AND MATERIALS
DO NOT INSTALL THE UNIT ON AN UNEVEN SURFACE! WHEN TIGHTENING THE SCREWS
DO NOT APPLY EXCESSIVE FORCES TO AVOID THE UNIT DEFORMATION.
1. Install the mounting box.
Wall flush mounting: prepare a wall opening, lay required
wires and cables to the installation place and install the
mounting box.
Wall surface mounting: lay required wires and cables to the
installation place, bore the holes and fix the mounting box on
the wall using the screws (separate order).

www.blaubergventilatoren.de
S22
5
2. Connect the control panel in compliance with
the wiring diagram.
+–AB
+24VGNDAB
Bedienfeld
3. Unfasten gently the latches on the lower part of the glass control panel using a
screwdriver. Take off the control panel. Then disconnect the sensor board from the
connector on the casing.
4. Attach the control panel frame to the mounting box with the screws. The fastening screws for fixation of the control panel to the
mounting box are included in the delivery set.
5. ATTENTION! If more than one control panel must be connected, allocate a unique address to each control panel individually using
the DIP switch as described in the Setup and Control section.
DIP-switch
Circuit board socket
with sensor elements

www.blaubergventilatoren.de S22
6
SETUP AND CONTROL
ADDRESSING AND PARAMETERS OF RS-485 NETWORK
The control panel is compatible with the following RS-485 network parameters:
• baud rate: 115200 baud;
• stop bits: 2;
• parity: none.
ATTENTION! The addressing of the control panel and the air handling unit is not interdependent.
ATTENTION! The control panel enables control of the air handling unit possessing the address 1 only.
The address from 1to 16 (factory setting 1) is allocated in the mobile application.
DIP SWITCH
ON RSN
3 41 2 5 6
ON
DIP-switch
Termination resistor on/off
Do not change position of the levers!
For servicing only!
Not in use Position of levers for allocating an address
to the control panel in RS-485 network.
lever 1: the termination resistor on/off, the lever must be in the ON position, if the control panel is the first or the last in the RS-485
network.
lever 2: inactive.
levers 3, 4, 5, 6: control panel address from 1to 16.
Control panel
address 12345678910 11 12 13 14 15 16
DIP switch
6. Fasten the sensor board to the casing, and then the glass panel by pressing it until it clicks into place.

www.blaubergventilatoren.de
S22
7
INDICATION AND FUNCTIONS OF THE CONTROL PANEL BUTTONS
Speed 1 Alarm indicator
Speed 3
Speed 2
Filter maintenance
Bypass mode
To turn the unit on or change speed stage, press any inactive speed button. Once activated, the button starts glowing, and
the ventilation unit runs with the set speed.
To turn the unit o, press the active speed button.
In the Standby mode during the unit operation the buttons do not glow.
The sensor control panel indication during its joint operation with the mobile application and other control devices
is as follows:
the buttons are highlighted in a definite sequence when the speed that is set with the mobile application or the control
device is not supported with the sensor control panel.
Note: the parameter setting and speed setup with the mobile application as well as the link to download the program are
stated in the user’s manual for the wireless control system.
The parameter setting and speed setup with the control devices that are connected to the ventilation unit are stated in the
user’s manual for the wireless control system.
Bypass mode
Bypass/rotary heat exchanger operation modes — Auto and manual mode. Press the button once to switch modes.
• The indicator is off: the bypass damper/rotary heat exchanger runs in the Auto mode.
• The indicator glows steady: the bypass damper is open/the rotary heat exchanger is stopped in the manual mode.
• The indicator blinks: the bypass damper is closed/ the rotary heat exchanger runs in the manual mode.
Filter maintenance
The button glows steady: the filter must be cleaned or replaced.
After maintenance reset the filter timer.
To reset the filter timer, press and hold the button for 5 seconds until a beep tone is heard.
Release the filter maintenance button after all the buttons blink twice.
Alarm
The indicator glows steady in case of alarm.
The indicator blinks in case of communication loss with the ventilation unit.
After troubleshooting an alarm reset the alarm indication.
To reset alarm, press and hold the button for 5 seconds until a beep tone is heard.
Release the alarm button after all the buttons blink twice.

www.blaubergventilatoren.de
