Blaupunkt New Orleans MP58 User manual

Radio CD USB MP3 WMA
New Orleans MP58 7 648 010 310
www.blaupunkt.com
Operating and installation instructions
Mode d’emploi et de montage
Instrucciones de manejo e instalación
Instruções de serviço e de montagem
操作及安裝手冊
사용 및 장착 설명서사용 및 장착 설명서
01_NewOrleansMP58us_gb.indd 101_NewOrleansMP58us_gb.indd 1 12/28/07 2:03:02 PM12/28/07 2:03:02 PM

2
8
1
IR
9
7
11
10
13
2 3 56
4
12
14 15
01_NewOrleansMP58us_gb.indd 201_NewOrleansMP58us_gb.indd 2 12/28/07 2:03:20 PM12/28/07 2:03:20 PM

3
ENGLISH
1button
to open the detachable control panel
(flip-release panel).
2SRC button
Sourceselectionbetweenradio andCD
and (if connected or switched on) CD
changer, USB data carrier and AUX.
3XBASS button
Switching X-BASS on/off and adjust-
ing it.
4Arrow buttons
5MENU•OK button
Short press: Calls up the menus for ba-
sic settings and confirms settings.
Ending the scan function.
Long press: Starts the Scan function.
6On/Off button
Short press: Switches the device on. In
operation: Mutes the device.
Long press: Switches the device off.
7Volume control
8Display
9Keys 1 - 6
:DIS button
Shows/hides time.
In MP3/WMA mode: Calls up the MP3
browse mode
;ESCAPE button
to exit the menus.
<BND button
Short press: Selects the FM memory
banks and the MW and LW wavebands.
Long press: Starts the Travelstore func-
tion.
=AUD button
Calls up the Audio menu: adjusts bass,
treble, centre, subout, balance and
fader.
Switching X-BASS on/off and adjust-
ing it.
Selects an equalizer presetting.
>button (eject)
to eject the CD from the device
?CD tray
Controls
01_NewOrleansMP58us_gb.indd 301_NewOrleansMP58us_gb.indd 3 12/28/07 2:03:21 PM12/28/07 2:03:21 PM

4
Contents
About these instructions....................6
Symbols used..................................6
Use as directed................................6
Declaration of conformity..................6
For your safety ..................................7
If you are installing device yourself......7
Observe the following!......................7
Cleaning instructions........................ 7
Disposal of old unit ..........................7
Scope of delivery...............................8
Optional equipment
(not part of the scope of delivery) ......8
Warranty...........................................9
Service ..........................................9
Detachable control panel ...................9
Theft protection...............................9
Detaching the control panel...............9
Attaching the control panel..............10
Switch-off time (OFF TIMER)...........10
Timeout function ...........................10
Switching on/off..............................11
Switching on/off with the On/Off
button.......................................... 11
Switching on/off using the vehicle
ignition.........................................11
Switching off with detachable
control panel.................................11
Changing the welcome text.............. 11
Adjusting the volume .......................12
Setting the power-on volume ...........12
Quickly reducing the volume (Mute).. 12
Telephone Audio/Navigation Audio... 13
Switching the confirmation beep
on/off .......................................... 13
Automatic Sound ...........................14
Radio mode..................................... 14
Adjusting the tuner.........................14
Switching to radio mode .................14
Selecting the waveband/
memory bank................................15
Tuning into a station .......................15
Setting the sensitivity of station
seek tuning ................................... 15
Storing stations .............................15
Storing stations automatically
(Travelstore) .................................16
Listening to stored stations .............16
Scanning receivable stations
(SCAN) ........................................16
Setting the scanning time................16
CD mode ......................................... 17
Starting the CD mode.....................17
Selecting tracks.............................18
Fast searching (audible)..................18
Random track play (MIX).................18
Scanning tracks (SCAN)..................18
Repeating tracks (REPEAT) .............18
Interrupting playback (PAUSE).........18
Displaying the time ........................ 18
Ejecting a CD.................................19
MP3/WMA mode ............................. 19
Preparing an MP3 data carrier .........19
Switching to MP3 mode..................21
Configuring the display...................21
Selecting a directory ...................... 22
Selecting tracks/files......................22
Selecting directories and track in
MP3 browse mode......................... 22
Fast searching ...............................23
Random track play (MIX).................23
Scanning tracks (SCAN)..................23
Repeating individual tracks or
whole directories (REPEAT)............. 23
Interrupting playback (PAUSE).........24
01_NewOrleansMP58us_gb.indd 401_NewOrleansMP58us_gb.indd 4 12/28/07 2:03:21 PM12/28/07 2:03:21 PM

5
ENGLISH
Adjusting the display settings...........33
Adjusting the display brightness....... 33
Setting the display illumination
colour ..........................................33
Adjusting the display viewing angle... 34
External audio sources.....................35
Adjusting the rear AUX input mode ...36
Connecting other external audio
sources ........................................36
Bluetooth .....................................38
Restoring factory settings
(NORMSET).....................................39
Technical data .................................40
Amplifier ......................................40
Tuner ...........................................40
CD...............................................40
Pre-amp out.................................. 40
Input sensitivity............................. 40
Installation instructions .................237
Contents
CD-changer mode............................24
Switching to CD changer mode ........24
Selecting CDs................................ 24
Selecting tracks.............................24
Fast searching (audible)..................25
Repeating individual tracks or
whole CDs (REPEAT)......................25
Random track play (MIX).................25
Scanning all tracks on all CDs
(SCAN) ........................................25
Interrupting playback (PAUSE).........25
Displaying the time ........................ 25
Clock – Time....................................26
Adjusting the time..........................26
Selecting 12/24-hour clock mode....26
Displaying the time continuously
when the device is off and the ignition
is on.............................................26
Sound .............................................27
Adjusting the bass (BASS) ..............28
Adjusting the treble (TREBLE) .........28
Setting the left/right volume
distribution (BALANCE)..................28
Adjusting the front/rear volume
distribution (FADER)...................... 28
Adjusting equalizer bass (E-BASS) ...29
Adjusting equalizer middle
(E-MIDDLE) ..................................29
Adjusting equalizer treble
(E-TREBLE)...................................30
Preamplifier output
(Preamp-Out/Sub-Out) ....................30
Adjusting Sub-Out level and Sub-Out
cut-off frequency...........................30
X-BASS ...........................................31
Adjusting X-BASS boost (X-BASS) ....31
Adjusting equalizer X-BASS
(E-BASS)......................................31
Equalizer presettings (PRESETS)......32
Ins
01_NewOrleansMP58us_gb.indd 501_NewOrleansMP58us_gb.indd 5 12/28/07 2:03:21 PM12/28/07 2:03:21 PM

6
About these instructions
About these instructions
These instructions contain important infor-
mation to easily and safely install and oper-
ate the device.
Read these instructions carefully and
completely before using the device.
Keep the instructions at a location so
that they are always accessible to all
users.
Always pass on the device to third par-
ties together with these instructions.
In addition, observe the instructions of the
devices used in conjunction with this de-
vice.
Symbols used
These instructions employ the following
symbols:
CAUTION!
Warns about laser beam
CAUTION!
Warns about damaging the CD
drive
The CE mark confirms the compli-
ance with EU directives.
Identifies a sequencing step
Identifies a listing
•
•
•
쏅
•
Use as directed
This device is intended for installation and
operation in a vehicle with 12 V vehicle sys-
tem voltage and must be installed in a DIN
slot. Observe the performance limits in the
technical data. Repairs and installation, if
necessary, should be performed by a spe-
cialist.
Declaration of conformity
The Blaupunkt GmbH declares that the de-
vice New Orleans MP58 complies with the
basic requirements and the other relevant
regulations of the directive 89/336/EWG.
01_NewOrleansMP58us_gb.indd 601_NewOrleansMP58us_gb.indd 6 12/28/07 2:03:22 PM12/28/07 2:03:22 PM

7
ENGLISH
For your safety
For your safety
The device was manufactured according to
the state of the art and established safety
guidelines. Even so, dangers may occur if
you do not observe the safety notes in these
instructions.
If you are installing device
yourself
You may only install the device yourself
if you are experienced in installing car
sound systems and are very familiar with
the electrical system of the vehicle. For this
purpose, observe the installation instruc-
tions at the end of these instructions.
Observe the following!
CAUTION
The device contains a Class 1 laser
that can cause injuries to your eyes.
Do not open the device and do not perform
any modifications.
In operation
Operate the device only if traffic situa-
tion permits it! Stop at a suitable loca-
tion to perform more extensive opera-
tions.
Remove orattachthecontrolpanelonly
while the vehicle is standing an.
To protect your hearing, always listen
at a moderate volume. During mute
phases (e.g. when changing the au-
dio source or CD in the CD changer),
changing the volume is not audible.
Do not increase the volume during this
mute phase.
•
•
•
Always listen at a moderate volume so
thatyou canalwayshearacoustic warn-
ing signals (e.g. police).
After operation
The device is worthless to a thief with-
out the control panel. Always remove
the control panel whenever you leave
the vehicle.
Transport the control panel so that it is
protected against impacts and the con-
tacts cannot become dirty.
Cleaning instructions
Solvents, cleaning and scouring agents as
well as dashboard spray and plastics care
product may contain ingredients that will
damage the surface of the device.
Use only a dry or slightly moistened cloth
for cleaning the device.
Disposal of old unit
Do not dispose of your old unit in
the household trash!
Use the return and collection systems avail-
able to dispose of the old device.
•
•
•
01_NewOrleansMP58us_gb.indd 701_NewOrleansMP58us_gb.indd 7 12/28/07 2:03:22 PM12/28/07 2:03:22 PM

8
Scope of delivery
The scope of delivery includes:
1 Car sound system
1 Case for the control panel
1 Support frame
2 Disassembly tools
1 Guide pin
4 Connecting cables
1 Operating instructions
1 Handheld remote control
Optional equipment
(not part of the scope of delivery)
Use only accessories approved by
Blaupunkt.
Command and Control (C‘n‘C)
This device supports the command-and-
control interface (C‘n‘C) of Blaupunkt. The
C‘n‘C interface allows an even more con-
venient control of devices and data carriers
that are connected via a C‘n‘C-capable in-
terface with the car sound system (see also
Bluetooth/USB interface and iPod/USB in-
terface).
Steering wheel remote control
A steering wheel remote control allows for
safely and conveniently operating the basic
functionsofyourcar soundsystemfromthe
steering wheel.
You cannot switch the device on/off using
the remote control!
You can find out from your Blaupunkt dealer
or on the Internet at www.blaupunkt.com
which remote controls can be used with
your car sound system.
Bluetooth/USB interface
ForBluetoothapplications,suchaswireless
hands-freecallingandBluetooth streaming,
you can connect a Bluetooth interface. The
Bluetooth/USB interface provides an addi-
tional USB connection.
The Bluetooth/USB interface is also avail-
able in a C‘n‘C-capable version or can be
rendered C‘n‘C-capable with a software
update.
Information about the Bluetooth/USB in-
terface is available at your Blaupunkt spe-
cialised dealer or on the Internet under
www.blaupunkt.com.
iPod/USB interface
With the iPod interface or the iPod/USB
interface, you can connect an iPod to the
radio device and conveniently control the
playback via the radio device. The iPod/
USB interface provides an additional USB
connection.
The iPod/USB interface is also available in
a C‘n‘C-capable version or can be rendered
C‘n‘C-capable with a software update.
Information about the iPod/USB inter-
face is available at your Blaupunkt spe-
cialised dealer or on the Internet under
www.blaupunkt.com.
Amplifier
You can use all Blaupunkt and Velocity am-
plifiers.
CD changers
You can connect the following Blaupunkt
CD changers:
CDC A 03, CDC A 08 and IDC A 09.
Scope of delivery
01_NewOrleansMP58us_gb.indd 801_NewOrleansMP58us_gb.indd 8 12/28/07 2:03:22 PM12/28/07 2:03:22 PM

9
ENGLISH
Warranty
We provide a manufacturer's warranty
for products bought within the European
Union. For devices purchased outside the
European Union, the warranty terms issued
by our respective responsible domestic
agency are valid.
Service
Insome countries,Blaupunktoffersarepair
and pick-up service.
Information about the availability of this
service in your country can be found at
www.blaupunkt.com.
If you want to take advantage of this serv-
ice, you may request a pick-up service for
your device via the Internet.
Detachable control panel
Theft protection
The device is equipped with a detachable
control panel (flip-release panel) as a way
of protecting your equipment against theft.
The device is worthless to a thief without
this control panel.
Protect your device against theft by taking
the control panel with you whenever you
leave your vehicle. Do not leave the control
panel inside your vehicle - not even in a hid-
ing place.
Notes:
Never drop the control panel.
Do not expose the control panel to di-
rect sunlight or another heat source.
Avoid direct skin contact with the
control panel’s electrical contacts. If
necessary, clean the contacts with a
lint-free cloth moistened with clean-
ing alcohol.
Detaching the control panel
Press the button 1.
The control panel opens to the bottom.
Hold the control panel by its right side
and then pull it straight out of the
bracket.
•
•
•
쏅
쏅
Warranty Detachable control panel
01_NewOrleansMP58us_gb.indd 901_NewOrleansMP58us_gb.indd 9 12/28/07 2:03:22 PM12/28/07 2:03:22 PM

10
Notes:
The device is switched off after a time
preset by you. For further details,
please read the section "Switch-off
time (OFF TIMER)" in this chapter.
The device remembers the audio
source played last for the next switch-
on.
Any CD already inserted in the device
remains there.
Attaching the control panel
1.
2.
Hold the control panel approximately
at a right angle to the device. (see fig-
ure, 1.)
Push the control panel into the guides
at the bottom edge of the device.
Pushthe controlpanel carefullyinto the
bracket until it clicks into place.
Fold the control panel up into the slot
and press it gently into place until it
clicks. (see figure, 2.)
•
•
•
쏅
쏅
쏅
쏅
Switch-off time (OFF TIMER)
After opening the control panel, the device
is switched off after an adjustable time. You
can set this time from 15 to 30 seconds.
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VARIOUS MENU" appears on the
display.
Press the button 4to open the
menu.
Press the or button 4repeatedly
until the display shows "OFF TIMER".
Press the button 4to open the
menu.
Set the time with the or button
4.
When you have finished making your chang-
es,
press the ESCAPE button ;.
Timeout function
The device features a time-out function
(time window).
For example, if you press the MENU•OK
button 5and select a menu item, the de-
vice switches back after approx. 8 seconds
after the last button activation. The settings
performed are saved.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Detachable control panel
01_NewOrleansMP58us_gb.indd 1001_NewOrleansMP58us_gb.indd 10 12/28/07 2:03:22 PM12/28/07 2:03:22 PM

11
ENGLISH
Switching on/off
There are various ways of switching the
device on/off:
Switching on/off with the On/Off
button
For switch-on, press the On/Off button
6.
The device switches on.
To switch off the device, press and hold
down the On/Off button 6for longer
than 2 seconds.
The device switches off.
Note:
To protect the vehicle battery, the de-
vice will switch off automatically after
one hour if the ignition is off.
Switching on/off using the
vehicle ignition
The device will switch on/off simultane-
ously with the ignition if the device is cor-
rectly connected to the vehicle’s ignition as
shown in the installation instructions and
you did not switch the device off by press-
ing the On/Off button 6.
Switching off with detachable
control panel
Detach the control panel.
Thedevicesswitchesoffafterthetimesetin
the "OFF TIMER" menu. For further details,
please read the section "Switch-off time
(OFF TIMER)" in the chapter "Detachable
control panel".
쏅
쏅
쏅
Changing the welcome text
When you switch on the device, an ani-
mation appears, followed by a welcome
text. The welcome text is factory set to
"BLAUPUNKT".
You can enter your own welcome text of up
to 9 characters.
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VARIOUS MENU" appears on the
display.
Press the button 4to open the
menu.
"ON MESSAGE" appears on the display.
Press the button 4to open the
menu.
Press the or button 4to enter
the character at the current position.
Press the button 4to change to the
next position.
Press the MENU•OK button 5to
store the name.
When you have finished making your chang-
es,
press the ESCAPE button ;.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Switching on/off
01_NewOrleansMP58us_gb.indd 1101_NewOrleansMP58us_gb.indd 11 12/28/07 2:03:23 PM12/28/07 2:03:23 PM

12
was higher before switch-off, the value
is automatically set to "38" at switch-
on. This prevents an unintentionally
and unexpectedly high volume when
switching on the device.
When you have finished making your chang-
es,
press the ESCAPE button ;.
Quickly reducing the volume
(Mute)
You can quickly reduce the volume to a
preset level.
Briefly press the On/Off button 6.
"MUTE" appears on the display.
Cancelling mute
To return to your previously set volume
level,
briefly press the On/Off button 6
again.
Adjusting the mute level
You can adjust the mute level.
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VOLUME MENU" appears on the
display.
Press the button 4to open the
menu.
Press the or button 4repeatedly
until "MUTE LEVEL" appears on the dis-
play.
Press the button 4to open the
menu.
Set the mute level with the or but-
ton 4.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Adjusting the volume
You can adjust the volume in steps from 0
(off) to 50 (maximum).
To increase the volume,
turn the volume control 7clockwise.
To decrease the volume,
turn the volume control 7counter-
clockwise.
Setting the power-on volume
You can set the power-on volume.
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VOLUME MENU" appears on the
display.
Press the button 4to open the
menu.
"ON VOLUME" appears on the display.
Press the button 4to open the
menu.
Set a specific power-on volume with
the or button 4.
Or:
Press the button 4to select the
"LAST VOLUME" setting.
To help you adjust the setting more easily,
the device will increase or decrease the
volume as you make your changes.
Ifyouchangethesettingto"LASTVOLUME",
thevolumewhenthedeviceswitchesonwill
bethesame as thevolumelevelthatwas set
the last time you switched the device off.
Note:
To protect your hearing, the power-on
volume is limited to the value "38" for
the setting "Last Volume". If the volume
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Volume
01_NewOrleansMP58us_gb.indd 1201_NewOrleansMP58us_gb.indd 12 12/28/07 2:03:23 PM12/28/07 2:03:23 PM

13
ENGLISH
When you have finished making your chang-
es,
press the ESCAPE button ;.
Telephone Audio/Navigation
Audio
Muting during telephone/navigation
mode
If your car sound system is connected with
a cell phone or navigation system, the car
soundsystemismuted whena callisincom-
ing or during a voice output of the naviga-
tion. The call or the voice output is played
backvia theloudspeakers ofthe cardsound
system. In order for this feature to work, the
mobiletelephoneornavigationsystemmust
be connected to the car sound system as
described in the installation instructions.
You can find out from your Blaupunkt dealer
which navigation systems can be used with
your car sound system.
If a call is incoming or a navigation an-
nouncement takes place, the display shows
"TELEPHONE".
Adjusting the volume for telephone
audio/navigation audio
You can set the volume level at which the
telephone calls or navigation announce-
ments are mixed in.
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VOLUME MENU" appears on the
display.
Press the button 4to open the
menu.
Press the or button 4repeatedly
until "TEL VOLUME" appears on the dis-
play.
쏅
쏅
쏅
쏅
쏅
Press the button 4to open the
menu.
Set the desired volume with the or
button 4.
When you have finished making your chang-
es,
press the ESCAPE button ;.
Note:
You can use the volume control 7to
adjust the volume of telephone calls
and navigation announcements whilst
you are listening to them.
Switching the confirmation beep
on/off
The system will output a confirmation beep
for some functions if you keep a button
pressed down for longer than 2 seconds,
for instance, when assigning a radio station
to a station preset button. You can switch
the beep on or off.
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VOLUME MENU" appears on the
display.
Press the button 4to open the
menu.
Press the or button 4repeatedly
until"BEEPON" or"BEEP OFF" appears
on the display.
Switch the BEEP ON or OFF with the
button or 4.
When you have finished making your chang-
es,
press the ESCAPE button ;.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Volume
01_NewOrleansMP58us_gb.indd 1301_NewOrleansMP58us_gb.indd 13 12/28/07 2:03:24 PM12/28/07 2:03:24 PM

14
Automatic Sound
This function automatically adjusts the vol-
ume of the car sound system to the speed
driven and the associated driving noises.
For example, at an increased speed, the
volume is automatically increased to com-
pensate for the increased driving noise
(e.g. due to airstream).
For this purpose, your vehicle must provide
the tachometer signal and the car sound
system must be connected as described in
the installation instructions.
You can adjust the automatic volume in-
crease in 6 increments (OFF, 1-5).
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VOLUME MENU" appears on the
display.
Press the button 4to open the
menu.
Press the or button 4repeat-
edly until "AUTO SOUND" appears on
the display.
Press the button 4to open the
menu.
Set the volume adjustment OFF or 1 - 5
with the or button 4.
When you have finished making your chang-
es,
press the ESCAPE button ;.
Note:
The optimum setting for the speed-
dependent volume adjustment feature
depends on how noise levels develop in
your particular vehicle. Determine the
perfect value for your vehicle using trial
and error.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Radio mode
Adjusting the tuner
To ensure proper functioning of the tuner,
the device must be set for the region in
which it is being operated. You can select
betweenEurope (EUROPE),America (USA)
and Thailand (THAI). The tuner is factory
set to the region in which it was sold. If you
experience problems with your radio recep-
tion, please check this setting.
Note:
The radio functions described in these
operating instructions refer to the tun-
er setting America (USA).
Switch off the device by pressing the
On/Off button 6.
Hold the buttons 19and DIS :
pressed at the same time and switch
on the device again with the On/Off
button 6.
The current setting (EUROPE, USA or THAI)
is displayed.
Select your tuner region with the or
button 4.
To save the setting,
pressthe MENU-OKbutton5. The ra-
dio starts with the setting selected last
(radio, CD, CD changer, USB or AUX).
Switching to radio mode
If you are in CD, CD changer, USB or AUX
mode,
press the BND button <
OR
press the SRC button 2repeatedly
until "TUNER" appears on the display.
쏅
쏅
쏅
쏅
쏅
쏅
Volume Radio mode
01_NewOrleansMP58us_gb.indd 1401_NewOrleansMP58us_gb.indd 14 12/28/07 2:03:24 PM12/28/07 2:03:24 PM

15
ENGLISH
Selecting the waveband/
memory bank
This device can be used to receive stations
in the FM and AM frequency bands. Three
memory banks (FM1, FM2 and FMT) are
available for the FM waveband and two
memory banks (AM and AMT) for the AM
waveband.
Six stations can be stored in each memory
bank.
To switch between the FM1, FM2, FMT, AM,
and AMT memory banks,
press the BND button <.
Tuning into a station
There are various ways of tuning into a
station.
Automatic station seek tuning
Press the or button 4.
The radio tunes into the next receivable
station.
Tuning into stations manually
You can also tune into stations manually.
To change the set frequency in small incre-
ments,
briefly press the or button 4.
To change the set frequency quickly,
press and hold down the or button
4for a longer period of time.
Setting the sensitivity of station
seek tuning
You can choose whether the radio should
only tune into stations providing good re-
ception or whether it can also tune into
those with a weak reception.
쏅
쏅
쏅
쏅
Press the MENU•OK button 5.
Press the or button 4repeat-
edly until "TUNER MENU" appears on
the display.
Press the button 4to open the
menu.
Press the or button 4repeatedly
until "SENSITIVITY" appears on the dis-
play.
Press the button 4to open the
menu.
The display shows the currently set sensi-
tivitylevel."SENS HI" meansa highsensitiv-
ity, "SENS LO" a low sensitivity.
Set the desired sensitivity with the
or button 4.
When you have finished making your chang-
es,
press the ESCAPE button ;.
Notes:
This setting is only possible in radio
mode.
Thedevice storesthesensitivityvalue
setinthe respectiveFM andAM wave-
band.
Storing stations
Storing stations manually
Select the desired memory bank FM1,
FM2, FMT, AM or AMT waveband.
Tune into the desired station.
Press and hold down one of the station
buttons 1- 69for longer than 2 sec-
onds to assign the station to that but-
ton.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
•
•
쏅
쏅
쏅
Radio mode
01_NewOrleansMP58us_gb.indd 1501_NewOrleansMP58us_gb.indd 15 12/28/07 2:03:24 PM12/28/07 2:03:24 PM

16
Storing stations automatically
(Travelstore)
You can automatically store the six stations
offering the strongest reception in the re-
gion. The stations are stored in the FMT or
AMT memory bank.
Note:
Any stations that were previously
stored in this memory bank are deleted
in the process.
Use the BND button <to select one
of the memory banks FM1, FM2 or FMT
for storing FM stations or one of the
memory banks AM or AMT for storing
AM stations.
Press and hold down the BND button
<for longer than 2 seconds.
The storing procedure begins. The dis-
play shows "FM TRAVELSTORE" or "AM
TRAVELSTORE".Aftertheprocesshascom-
pleted, the radio will play the station that is
stored in memory location 1 of the FMT or
AMT memory bank.
Listening to stored stations
Select the memory bank or waveband.
Press one of the station buttons 1 - 6
9.
The stored station is played if it can be re-
ceived.
Scanning receivable stations
(SCAN)
You can use the scan function to play all
the receivable stations briefly. You can set
the scanning time in the menu to between
5 and 30 seconds.
쏅
쏅
쏅
쏅
Starting SCAN
Press and hold down the MENU•OK
button 5for longer than 2 seconds.
The radio scans the next receivable sta-
tion. "SCAN" and the current frequency are
shown on the display.
Cancelling the SCAN and continuing to
listen to a station
Press the MENU•OK button 5.
Scanning stops and the radio continues
playing the station that it tuned into last.
Setting the scanning time
Press the MENU•OK button 5.
Press the or button 4repeatedly
until "VARIOUS MENU" appears on the
display.
Press the button 4to open the
menu.
Press the or button 4repeat-
edly until "SCAN TIME" appears on the
display.
Press the button 4to open the
menu.
Set the desired scan time with the or
button 4.
When you have finished making your chang-
es,
press the ESCAPE button ;.
Note:
The defined scanning time is also ap-
plied by the system to scanning carried
out in CD and MP3 mode.
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
쏅
Radio mode
01_NewOrleansMP58us_gb.indd 1601_NewOrleansMP58us_gb.indd 16 12/28/07 2:03:25 PM12/28/07 2:03:25 PM

17
ENGLISH
CD mode
You can use this device to play standard
audio CDs, CD-Rs and CD-RWs with a di-
ameter of 8 (mini CD) or 12 cm. To avoid
problems when playing self-burned CDs,
you should not burn CDs at speeds greater
than 16-speed.
Risk of severe damage to the
CD drive!
Non-circular shaped CDs may not be used.
We accept no responsibility for any damage
to the CD drive that may occur as a result
of the use of unsuitable CDs.
To ensure proper functioning, use only CDs
withthe Compact-Disclogo. CDswithcopy-
protection may cause playback problems.
Blaupunkt cannot guarantee the proper
functioning of copy-protected CDs!
Besidesbeingable toplayaudio CDson this
device, you can also play CDs containing
MP3/WMA music files. For further informa-
tion,please readthe chapterentitled "MP3/
WMA mode".
Starting the CD mode
IfnoCD is inthe drive,start the CDmodeby
inserting a CD.
Note:
To insert a CD, you must open the con-
trol panel. With opened control panel,
the device is automatically switched off
after a preset switch-off time. Please
observe the following notes for this
purpose:
If the device switches off before you
insert the CD in the drive tray, it is not
automatically drawn in. In this case,
remove the CD, close the control
panel, and switch the device on again
with the On/Off button 6before you
attempt to reinsert the CD.
If the CD has already been drawn in
and the device switches off before
you close the control panel, switch on
the device again with closed control
panel with the On/Off button 6.
If necessary, increase the switch-
off time to prevent the device from
switching off too fast. For further de-
tails, please read the section "Switch-
off time (OFF TIMER)" in the chapter
"Detachable control panel".
To insert a CD,
press the button 1.
The control panel opens.
Gently insert the CD with its printed
side uppermost into the drive until you
feel some resistance.
The drive draws in the CD automatically.
You must not hinder or assist the drive as it
draws in the CD.
Gently close the control panel whilst
exerting a little pressure until you feel
it click into place.
The CD playback starts and "CD" is shown
on the display.
If a CD is already inserted in the drive,
press the SRC button 2repeatedly
until "CD" appears on the display.
The playback starts at the position where it
was interrupted.
•
•
•
쏅
쏅
쏅
쏅
CD mode
01_NewOrleansMP58us_gb.indd 1701_NewOrleansMP58us_gb.indd 17 12/28/07 2:03:25 PM12/28/07 2:03:25 PM

18
Selecting tracks
Press the or button 4to select
the next or previous track.
If you press the button 4once, the cur-
rent track will be played again from the be-
ginning.
Fast searching (audible)
To fast search backwards or forwards,
press and hold down the or button
4until fast searching backwards/for-
wards begins.
Random track play (MIX)
Press the 5 MIX button 9.
"MIXALL"appearsbriefly onthedisplayand
the MIX symbol is displayed. The next ran-
domly selected track will then be played.
Cancelling MIX
Press the 5 MIX button 9again.
"MIX OFF" appears briefly on the display
and the MIX symbol disappears.
Scanning tracks (SCAN)
You can scan (briefly play) all the tracks on
the CD.
Press and hold down the MENU•OK
button 5for longer than 2 seconds.
Thenext trackwill thenbe scanned."SCAN"
and the current track number are shown on
the display.
Note:
You can set the scan time. For further
information, please read the section
entitled "Setting the scanning time" in
the "Radio mode" chapter.
쏅
쏅
쏅
쏅
쏅
Cancelling Scan and continuing listening
to a track
To exit the scan process,
press the MENU•OK button 5.
The currently scanned track continues play-
ing.
Repeating tracks (REPEAT)
If you want to repeat a track,
press the 4 RPT button 9.
"RPT TRK" appears briefly on the display,
and the REPEAT symbol is shown. The track
is repeated continuously until you deacti-
vate Repeat.
Cancelling Repeat
If you want to cancel the repeat function,
press the 4 RPT button 9again.
"RPT OFF" appears briefly on the display
andtheREPEATsymboldisappears.Normal
playback is then resumed.
Interrupting playback (PAUSE)
Press the 3button 9.
"PAUSE" appears on the display.
Cancelling pause
During the pause, press the button 3
9.
Playback is continued.
Displaying the time
To show or hide the time,
press the DIS button :.
쏅
쏅
쏅
쏅
쏅
쏅
CD mode
01_NewOrleansMP58us_gb.indd 1801_NewOrleansMP58us_gb.indd 18 12/28/07 2:03:25 PM12/28/07 2:03:25 PM

19
ENGLISH
Ejecting a CD
Press the button 1.
The control panel opens to the bottom.
Press the button >next to the CD
compartment.
The CD is ejected.
Remove the CD and close the control
panel.
Notes:
If a CD is ejected, the drive will auto-
matically draw it back in again after
approx. 10 seconds.
You can also eject CDs whilst the de-
vice is switched off or whilst another
audio source is activated.
쏅
쏅
쏅
•
•
MP3/WMA mode
You can also use this car sound system to
play CD-Rs and CD-RWs as well as USB
data carriers that contain MP3 music files.
You can also play WMA files. This chapters
deals only with playing MP3 files since
the operation for MP3 and WMA files is
identical.
Notes:
WMA files with Digital Rights
Management (DRM) from online mu-
sic shops cannot be played with this
device.
WMA files can only be played back
safely if they were created with
Windows Media Player version 8 or
later.
Preparing an MP3 data carrier
Preparing an MP3 CD
The various combinations of CD burners,
CD burning software and CD blanks may
lead to problems arising with the device’s
ability to play certain CDs. If problems oc-
cur with your own burned CDs, you should
try another brand of CD blank or choose an-
other colour of CD blank.
The format of the CD must be ISO 9660
Level1/Level2or Joliet.Otherformats can-
not be played reliably.
When creating (coding) MP3/WMA files
from audio files, you should use bit rates
from 32 to 320 kbit/s for MP3 files or 32 to
192 kbps for WMA files.
This device supports up to 999 tracks in
99 directories. The directories and tracks
on the CD can be selected individually.
•
•
CD mode MP3/WMA mode
01_NewOrleansMP58us_gb.indd 1901_NewOrleansMP58us_gb.indd 19 12/28/07 2:03:26 PM12/28/07 2:03:26 PM

20
D01
D02
T001
T005
T004
T003
T002
D03
T001
T006
T005
T004
T003
T002
T011
T007
T008
T009
T010
D04
T001
T006
T005
T004
T003
T002
A
B
ADirectories
BTracks · Files
You can name each directory using a PC.
The device is capable of displaying the di-
rectory name. Name the directories and
tracks/files using your CD burner software.
The software’s instruction manual will pro-
vide details on how to do this.
Notes:
When naming files (directories and
tracks) you should avoid using ac-
cents and special characters.
If you use file names with more than
16 characters (including ".MP3" or
".WMA"), the maximum number of
tracks and directories is reduced.
If you like your files to be in the specific or-
der, save the files on the data carrier in the
desired sequence in which you want to play
•
•
them later. The devices plays back the files
in the order in which they were physically
stored on the data carrier.
Toplaybackfilesinthisdevice,theMP3files
must have the file extension ".MP3" and the
WMA files the file extension ".WMA".
Notes:
To ensure uninterrupted playback,
do not try changing the file extension
to ".MP3" of any files other than MP3
files and then attempt to play them!
The device will ignore these invalid
files during playback.
Do not use "mixed" CDs containing
both non-MP3 data and MP3 tracks
(the device only reads MP3 files dur-
ing MP3 playback).
do not use mix-mode CDs containing
bothCD-audiotracksandMP3tracks.
If you attempt to play a Mix Mode CD,
only the CD audio tracks are played.
Preparing a USB data carrier
For the device to recognise a USB data car-
rier, it must be specified as mass storage
device and formatted using the FAT16 or
FAT32 file system and contain MP3 or WMA
files.
You can created up to 1,500 files on a USB
data carrier (directories and tracks). The
directories and tracks can be selected in-
dividually with this device. If you use file
names with more than 24 characters (in-
cluding ".MP3" or ".WMA"), this maximum
number of files is reduced.
Blaupunkt cannot guarantee the proper
functioning of all USB data carriers avail-
able on the market.
•
•
•
MP3/WMA mode
01_NewOrleansMP58us_gb.indd 2001_NewOrleansMP58us_gb.indd 20 12/28/07 2:03:26 PM12/28/07 2:03:26 PM
