Blaupunkt IDC A09 User manual

CD-Changer
Operating and installation instructions (GB)
IDC A09

2
Bitte ausklappen
Please fold out
Ouvrirs.v.p.
Prego aprire
Openslaan graag
Öppna
Desplegar aquí
Favorabrir
Deutsch
Übersichtsbild ................................. 3
Hinweise ......................................... 4
Sicherheitshinweise......................... 4
Einbau ............................................. 5
Bedienung....................................... 7
English-GB
Overview diagram ........................... 3
Notes .............................................. 8
Safety instructions ........................... 8
Installation ....................................... 9
Operation ...................................... 11
English-US
Overview diagram ........................... 3
Notes ............................................ 12
Safety instructions ......................... 12
Installation ..................................... 13
Operation ...................................... 15
Français
Aperçu ............................................ 3
Remarques.................................... 16
Consignes de sécurité.................... 16
Montage ........................................ 17
Utilisation ...................................... 19
Italiano
Vista d’insieme ................................ 3
Indicazioni ..................................... 20
Note di sicurezza ........................... 20
Montaggio ..................................... 21
Comandi ....................................... 23
Nederlands
Overzichtsfoto ................................. 3
Aanwijzingen ................................. 24
Adviezen voor de veiligheid ............. 24
Montage ........................................ 25
Bediening ...................................... 27
Svenska
Översiktsbild ................................... 3
Allmänt .......................................... 28
Skyddsanvisningar ........................ 28
Montering ...................................... 29
Handhavande ................................ 31
Español
Vista general ................................... 3
Indicaciones .................................. 32
Normas de seguridad .................... 32
Montaje ......................................... 33
Manejo .......................................... 35
Português
Vista de conjunto ............................. 3
Informações .................................. 36
Instruções de segurança ................ 36
Montagem ..................................... 37
Comando ...................................... 39

3
ENGLISH-GB DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
ENGLISH-US
ÜBERSICHTSBILD/OVERVIEW DIAGRAM/
APERÇU/VISTA D’INSIEME/
OVERZICHTSFOTO/ÖVERSIKTSBILD/
VISTA GENERAL/VISTA DE CONJUNTO
12345 6789:
6- :Select-/Eject-Knöpfe
Select/eject button
Boutons Select / Eject
Tasti di selezione/espulsione
Select-/eject-toetsen
Fack-/Ejectknappar
Botones Select/Eject
Botões de selecção/ejecção
1- 5CD-Schächte
CD Compartments
Compartiments CD
Vano di CD
Cd-openingen
Cd-fack
Bandejas
Compartimentos

8
Thank you for deciding to use a
Blaupunkt product. We hope you enjoy
using this new piece of equipment.
Please read these operating instruc-
tionsbeforeusingtheequipment for
the first time.
The Blaupunkt editors are constantly
working on making the operating in-
structions clearer and easier to under-
stand. However, if you still have any
questions on how to operate the equip-
ment, please contact your dealer or the
telephone hotline for your country. You
will find the hotline telephone numbers
printed at the back of this booklet.
We provide a manufacturer guarantee
for our products bought within the Eu-
ropean Union. You can view the guar-
anteeconditionsatwww.blaupunkt.de
or ask for them directly at:
Blaupunkt GmbH
Hotline CM/PSS 6
Robert Bosch Str. 200
D-31139 Hildesheim
Safety instructions
When carrying out installation work
and making connections please
observe the following safety
instructions:
- Electronic vehicle systems may fail
if they are incorrectly installed or
serviced.
- Disconnect the negative terminal of
the battery! When doing so, please
observe the vehicle manufacturer’s
safety instructions.
- Make sure you do not damage
vehicle components when drilling
any holes.
- Depending on the model, your
vehicle may differ from the descrip-
tion provided here. We accept no
responsibility for any damages due
to incorrect installation or connec-
tion or for any consequential
damages.
If the information provided here is not
suitable for your specific installation re-
quirements, please contact your
Blaupunkt dealer, your vehicle manu-
facturer or our telephone hotline.
12V
NOTES SAFETY INSTRUCTIONS

9
ENGLISH-GB DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
ENGLISH-US
INSTALLATION
Recommended location for
installation
Dashboard
Vehicle boot
Installation position
From -10°to 105°Spacer installation frame 6 mm
7 608 002 076
Spacer installation frame 10 mm
7 608 002 176
53
182 165
1-20
Supplied installation materials Recommended accessories
Extension cable 1.3 m
7 607 621 154
Extension cable 6 m
7 607 621 155
Universal mounting frame
7 608 002 377

10
INSTALLATION
C3
13 CDC Data-IN
14 CDC Data-OUT
15 +12V Permanent
16 +12V switch voltage (max. 300mA)
17 CDC Data-GND
18 CDC AF/AUX-GND
19 CDCAF/AUX-L
20 CDC AF/AUX-R
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
C
B
A
14 710 13 16 19
36912 15 18
258
11 14 17 20
C-1 C-2 C-3
5A
IDC A09
radio

11
ENGLISH-GB DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
ENGLISH-US
OPERATION
Inserting a CD
When you connect the CD changer for
thefirsttime,pleasewaitapproximately
1 minute before inserting a CD.
Insert one CD with the printed side up
into each of the compartments 1-5.
The buttons will now light up green.
Selecting a CD
To listen to a particular CD, press the
correspondingselect/ejectbutton6-:
for less than 1 second.
Removing a CD
To remove a CD from compartments
1-5,pressthecorrespondingselect/
ejectbutton6-:forlongerthan1sec-
ond. The button light will go out.
If a CD is being played, e.g. CD 5, you
can insert or eject any of the remaining
CDs in compartments 1-4. During
thistime,CD playback isinterruptedfor
5 seconds.
Notes on CD mode
You must not play shaped CDs (non-
round, virtual) or CDs with a diameter
of 8 cm with or without an adapter ring.
For further operating details, please
refer to your car radio’s operating
instructions.

Service-Nummern / Service numbers / Numéros du service après-
vente / Numeri del servizio di assistenza / Servicenummers /
Telefonnummer för service / Números de servicio / Números de
serviço / Servicenumre
Country: Phone: Fax: WWW:
Germany (D) 0180-5000225 05121-49 4002 http://www.blaupunkt.com
Austria (A) 01-610 390 01-610 393 91
Belgium (B) 02-525 5454 02-525 5263
Denmark (DK) 44 898 360 44-898 644
Finland (FIN) 09-435 991 09-435 99236
France (F) 01-4010 7007 01-4010 7320
Great Britain (GB) 01-89583 8880 01-89583 8394
Greece (GR) 0800-550 6550 01-576 9473
Ireland (IRL) 01-4149400 01-4598830
Italy (I) 02-369 6331 02-369 6464
Luxembourg (L) 40 4078 40 2085
Netherland (NL) 023-565 6348 023-565 6331
Norway (N) 66-817 000 66-817 157
Portugal (P) 01-2185 00144 01-2185 11111
Spain (E) 902-120234 916-467952
Sweden (S) 08-7501500 08-7501810
Switzerland (CH) 01-8471644 01-8471650
Czech. Rep. (CZ) 02-6130 0441 02-6130 0514
Hungary (H) 01-333 9575 01-324 8756
Poland (PL) 0800-118922 022-8771260
Turkey (TR) 0212-3350677 0212-3460040
USA (USA) 800-2662528 708-6817188
Brasil
(Mercosur) (BR) [phone] [phone]
Malaysia
(Asia Pacific) (MAL) [phone] [phone]
07/02 CM/PSS 8 622 403 467
Blaupunkt GmbH

CD-Changer
Operating and installation instructions (GB)
IDC A09
with encoding

3
ENGLISH-GB DEUTSCHFRANÇAISITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
ENGLISH-US
1- 5CD Schächte,
CD Compartments,
Compartiments CD,
Vano di CD,
Cd-openingen,
Cd-fack,
Bandejas,
Compartimentos
ÜBERSICHTSBILD/OVERVIEW DIAGRAM/
APERÇU/VISTA D’INSIEME/
OVERZICHTSFOTO/ÖVERSIKTSBILD/
VISTA GENERAL/VISTA DE CONJUNTO
12345 6789:
6- :Eject-Knöpfe,
Eject buttons,
Bouton d’éjection,
Tasto di espulsione,
Eject-toetsen,
Utmatningsknapar,
Botones de expulsión,
Botão de ejecção

8
INSTALLATION
Safety notice
– Electronic vehicle systems may fail
if they are incorrectly installed or
serviced.
– Disconnect the negative terminal of
the battery before installing or
removing any equipment.
– When drilling any holes, ensure
that no vehicle components are
damaged.
Recommended location for
installation
Dashboard
Vehicle boot
Installation position
From -10°to 105°
Recommended accessories
Extension cable 1.3 m
7 607 621 154
Extension cable 6 m
7 607 621 155
Universal mounting frame
7 608 002 377
Supplied installation materials
Spacer installation frame 6 mm
7 608 002 076
Spacer installation frame 10 mm
7 608 002 176
12V
53
182
165
1-20

9
ENGLISH-GB DEUTSCHFRANÇAISITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
ENGLISH-US
OPERATION
Theft protection
The IDC A09 is equipped with a theft
protection system that is supported by
several car radios.
Radios supporting this system show
"CDC-CODE"intheirdisplayswhenthe
CD changer is selected.
The methods for activating and
deactivating the theft protection
systemwhenthechangeris installed
or uninstalled are described on
pages 10 - 11.
Inserting a CD
Insert one CD with the printed side up
into each of the compartments 1-5.
Ejecting a CD
Press the eject button 6-:that cor-
responds with the CD you want to re-
move from compartments 1-5.
If a CD is being played, e.g. CD 5, you
can insert or eject any of the remaining
CDs in compartments 1-4.
For further operating details, please
refer to your car radio’s operating
instructions.
ENCODING (AFTER INSTALL.)
Activating the code for car
radios with a key card
Themaster code isprinted on yourIDC
A09 pass card.
1. Switch on the radio.
2. Press the CDC button.
The following appears briefly in the
display:
"CDC-CODE"
The display then changes to:
"0000"
3. You can set digits 0-9 using the /
buttons.
You can move from one digit to the
nextbypressingthe << />>buttons.
Example 1234:
a) Press the button once.
b) Press the >> button once.
c) Press the button twice.
d) Press the >> button once.
e) Press the button three times.
f) Press the >> button once.
g) Press the button four times.
4. Onceyouhavecorrectlyenteredthe
entire code, confirm your entry by
pressing the ENT button.

10
Before uninstalling the IDC A09 and
usingitwithadifferentcarradio, you
must first of all decode the IDCA09.
Decoding using a car radio that
has a key card
Themaster code isprinted on yourIDC
A09 pass card.
1. Switch on the radio.
2. Press the CDC button.
3. Press the IDC A09’s eject buttons
2+5 simultaneously, keep them
pressed for at least 1 second and
then release them.
The IDCA09 stops playing.
The red LEDs for all the eject buttons
begin to light up.
4. Switch off the radio.
5. Switch on the radio again.
The following appears briefly in the
display:
"CDC-CODE"
The display then changes to:
"0000"
6. You can set digits 0-9 using the /
buttons.
You can move from one digit to the
nextbypressingthe << />>buttons.
ENCODING (AFTER INSTALL.)
Activating the code for car
radios that have a fixed code
Themaster code isprinted on yourIDC
A09 pass card.
1. Switch on the radio.
2. Press the CDC button.
The following appears briefly in the
display:
"CDC-CODE"
The display then changes to:
"0000"
3. You can enter the master code by
pressing the station buttons 1-4.
Example 4321:
a) Press station button 1 four times.
b) Press station button 2 three times.
c) Press station button 3 twice.
d) Press station button 4 once.
4. Onceyouhavecorrectlyenteredthe
entire code, confirm your entry by
pressing the search button once.
UNINSTALLING (IDC A09)

11
ENGLISH-GB DEUTSCHFRANÇAISITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
ENGLISH-US
UNINSTALLING (IDC A09)
Example 1234:
a) Press the button once.
b) Press the >> button once.
c) Press the button twice.
d) Press the >> button once.
e) Press the button three times.
f) Press the >> button once.
g) Press the button four times.
7. Onceyouhavecorrectlyenteredthe
entire code, confirm your entry by
pressing the ENT button.
The red LEDs for all the eject buttons
begin to light up.
Switch off the radio (do not switch it
on again).
TheIDCA09’s code isnowdeactivated.
You may now remove the IDC A09.
Decoding using a car radio that
has a fixed code
Themaster code isprinted on yourIDC
A09 pass card.
1. Switch on the radio.
2. Press the CDC button.
3. Press the IDC A09’s eject buttons
2+5 simultaneously, keep them
pressed for at least 1 second and
then release them.
The IDCA09 stops playing.
The red LEDs for all the eject buttons
begin to light up.
4. Switch off the radio.
5. Switch on the radio again.
The following appears briefly in the
display:
"CDC-CODE"
The display then changes to:
"0000"
6. You can enter the master code by
pressing the station buttons 1-4.
Example 4321:
a) Press station button 1 four times.
b) Press station button 2 three times.
c) Press station button 3 twice.
d) Press station button 4 once.
7. Onceyouhavecorrectlyenteredthe
entire code, confirm your entry by
pressing the search button once.
The red LEDs for all the eject buttons
begin to light up.
Switch off the radio (do not switch it
on again).
TheIDCA09’scodeisnowdeactivated.
You may now remove the IDC A09.

Service-Nummern / Service numbers / Numéros du service après-
vente / Numeri del servizio di assistenza / Servicenummers /
Telefonnummer för service / Números de servicio / Número de
serviçco
Tel.: Fax:
Deutschland 018 050 002 25 051 214 940 02
Belgique 025 255 444 025 255 448
France 014 010 70 07 014 010 73 20
Nederland 023 565 63 48 023 565 63 31
Great Britain 018 958 383 66 018 958 383 94
Danmark 44 89 83 60 44 89 86 44
Sverige 08 750 15 00 08 750 18 10
Norway 66 81 70 00 66 81 71 57
Suomi 094 359 91 094 359 92 36
Österreich 045 989 90 28 016 103 93 91
Greece 015 762 241 015 769 473
âeská republika 026 130 04 41 026 130 05 14
USA 800-266 25 28 708-681 71 88
Singapore 006 535 054 47 006 535 053 12
Slovensko 042 175 873 212 042 175 873 229
11/99 K7/VKD 8 622 402 201
Blaupunkt-Werke GmbH
Bosch Gruppe
