Blaupunkt FM 02 User manual

User's Guide
Mobile phone FM 02

Contents
1. General Information ............................................................1
2. Safety....................................................................................1
3. Product specifications .........................................................7
4. About the keys .....................................................................8
5. Getting Started.....................................................................9
5.1. Insert a SIM card.........................................................9
5.2. Insert a memory card.................................................9
5.3. Insert battery ............................................................10
5.4. Remove the battery..................................................10
5.5. Charging the battery ................................................10
5.6. Maintaining the battery ...........................................11
6. Power On/Off .....................................................................12
7. Call functions .....................................................................12
7.1. Make a call ................................................................13
7.2. Auto redial ................................................................13
7.3. Receive call ...............................................................13
7.4. Conference ...............................................................15
7.5. Available functions during call .................................15
7.6. Emergency call..........................................................16
7.7. Handsfree function...................................................16
7.8. View and answer a missed call ................................16
7.9. Dial a previously dialed number ..............................16

8. Main menu.........................................................................16
9. Messages............................................................................17
9.1. Write a message .......................................................17
9.2. Incoming messages ..................................................18
10. Call logs ............................................................................18
11. Phonebook .......................................................................19
11.1. Add new contact ....................................................19
11.2. Search and view a contact .....................................19
12. Camera .............................................................................20
12.1. Take photos.............................................................20
12.2. Video recorder........................................................21
12.3. Video player............................................................22
13. Audio player .....................................................................22
14. FM radio ...........................................................................23
15. Sound recorder ................................................................24
16. Settings.............................................................................24
16.1. Call settings.............................................................24
16.2. Phone settings........................................................25
16.3. Security settings .....................................................26
16.4. Network settings ....................................................27
16.5. Restore factory settings .........................................27
17. Profiles..............................................................................28

18. Extras................................................................................29
18.1. Bluetooth ................................................................29
18.2. File manager ...........................................................30
18.3. Calculator................................................................30
18.4. Alarm.......................................................................30
18.5. Torch .......................................................................30
18.6. Games .....................................................................30
19. USB connection................................................................31
20. Appendix ..........................................................................32
20.1. Errors, Error Messages...........................................32
20.2. Handling and maintenance....................................33
20.3. Declaration of Conformity .....................................34

1
1. General Information
Thank you for choosing our device. This manual contains
general information, in addition to the information required
for operation.
Note:
•For your safety, use only accessories approved by the
manufacturer. Use of unapproved accessories may
result in a warranty revocation.
•If the device that appears in this manual does not
match your device, rely on the information displayed
on the device. The manufacturer reserves the right to
change the operation of the device without prior
notice.
The manufacturer reserves the right to change the operating
instructions as well.
2. Safety
Safety regulations
Please read the safety instructions carefully, as ignoring it may
be dangerous or illegal.
The owner of the device is responsible for the use of this
appliance. Do not switch on the device, where it is prohibited
to use a mobile phone or to interfere with radio waves.
Airplane
When traveling via airplane, your device must be switched off
whenever the crew or warning signals are instructed to do so.
Using a mobile phone may be dangerous to the operation of

2
the aircraft and may interfere with network communication.
Use of the device despite the ban may have legal
consequences.
Explosion hazards and restricted areas
Turn off the device in explosion hazardous areas. Sparks in
such places may lead to an explosion or fire that may result
in serious injury or death. Turn off the devicce at gasoline or
gas filling stations, especially near the fuel pumps. Follow the
instructions strictly in locations such as fuel tanks, chemical
plants, and explosive substances.
Electronic devices
To avoid demagnetisation, do not leave your device for a long
time close to electronic devices.
Electrical medical devices
Your phone is a radio transmitter that can interfere with
electronic medical devices or implants such as hearing aids,
pacemakers, insulin pumps, and so on. operation. We
recommend that you keep a distance of at least 15 cm
between the implant and the device, never wear your phone
in the breast pocket. Follow the instructions of the
manufacturer of the medical device. If you have a medical
implant and have any other questions about using mobile or
wireless devices, ask your doctor.
Use in hospitals
Hospitals and other healthcare facilities can use devices that
are particularly sensitive to RF signals. Switch off your phone
if prohibited signals are instructed to do so, or hospital staff
ask for it.

3
Road safety
Observe the local laws and regulations regarding smartphone
usage while driving. If you make a phone call while driving,
observe the following rules: Focus on driving to become
aware of traffic conditions; If the device has a hands-free
function, use handsfree. If the traffic situation requires, stop
the car before you pick up the phone.
Use environment
The device complies with the recommended emission values
for radio waves when kept at a minimum distance of 1.5 cm
from the ear. When carrying the phone in a case, belt clip or
holder, make sure that it does not contain metal and that the
phone is slightly distracted from the body. When using other
accessories, it is not possible to operate in accordance with
radio frequency guidelines. If you do not use a case and do
not hold the phone on your ear, keep it at least 2.5 cm away
from your body, especially during data transfer.
Note on using this unit
Do not place the device close to magnetic cards or other
magnetic devices. The phone's magnetism can erase the
data found on the disc on the card.
Wired telephone, television, radio may cause
interference and may affect the operation of the mobile
phone.
Keep the appliance dry, all moisture may damage the
electrical circuits.
Keep the unit away from extreme temperature
conditions.

4
Keep the appliance away from places where the
temperature can reach 60 ° C, such as dashboard,
window sill, fire, burning cigarette.
Do not paint the appliance.
Do not shake the appliance, do not drop it or crush it.
Do not disassemble or modify the phone as this may
damage the phone, which may cause leakage, which
interrupts the internal circuits.
Clean only the phone with a damp or non-static cloth.
Do not use alcohol, thinner, benzine or other chemical,
scouring agent to clean the appliance.
The product may become warm during normal use or
during charging.Ne hagyja a készüléket hosszú időre
lemerült akkumulátorral, mert adatvesztést okozhat.
Metal parts of the device may cause skin irritation.
Do not put the device in the back pocket if it is damaged,
damaging the phone. Do not put the device in the
bottom of the bag as it may break.
If the phone is in vibrating mode, place it in a place
where it can not fall off during vibration.
Do not press the display with a needle or other sharp
object, as it may damage the LCD display, which will give
you a surplus.
Store the device in an appropriate location when not in
use. Keep away from children.
If you lose or steal your device, contact your network
service provider immediately to prevent the SIM card

5
from being used by unauthorized persons. The service
provider may ask for the IMEI number of the device that
you can find on the battery sticker or by dialing the code
*#06#. Record this number if you need it in the future.
To prevent unauthorized use, lock the SIM card or the
device, change the passwords if necessary.
Always switch off the appliance before removing the
battery. Otherwise, it may cause data loss.
When leaving your vehicle, carry the appliance or put it
in the glove compartment to prevent theft.
Keep the device, battery, and charger away from
children.
Notes on using the battery
Do not disassemble or modify the battery as this may
cause leakage, overheating, or explosion.
Do not dispose of the battery in a fire as it may cause an
explosion. Dispose of the old battery according to local
regulations. Do not throw it into household rubbish.
Do not short circuit the battery circuits with a needle or
other metal object as it may cause leakage, overheating
or explosion.
If the battery is exposed to a liquid, it may cause
blindness. If this happens, do not rub your eyes, but
rinse with water and seek medical attention
immediately.
If the liquid spilled from the battery contacts skin, burns
the skin. Wash your skin with clean water and consult a
physician immediately.

6
Do not take the battery in your mouth as it may be
poisonous.
Do not continue to use the battery if it finds too hot or
has changed its color or shape.
Keep the battery dry.
Do not store the battery near fire or other hot places.
Store the battery in a cool, well-ventilated area and do
not expose it to direct sunlight.
Do not charge the battery for more than 24 hours.
The battery can be charged for hundreds of times, but
each charge will shorten its life and wear out after a
while.
When replacing a battery, use only a battery approved
by the manufacturer. Using an incorrect battery may
result in a warranty.
Qualified service
The product can only be repaired by a qualified person.
Hearing protection
To avoid hearing loss, do not listen to music or radio for a long
time at high volume.
Water resistance
The appliance is not waterproof, so keep it dry.

7
3. Product specifications
Power Supply Features:
Input: (AC), 100-240 V - 50/60 Hz – 0.1 A
Output: (DC), 5 V - 500 mA
Battery Type and Voltage:
Li-ion battery, 3.7 V, 800 mAh
Network type:
•GSM 900/1800 MHz
SAR values:
•0.635 W/Kg (Head)
•0.794 W/Kg (Body)
Note: Actual operating conditions depend on local conditions,
network environment, and user habits.

8
4. About the keys
1. Left soft key / Right Soft key: Opens the menu item in the
left / right corner of the screen.
2. Dial key: dial / answer the call and in standby mode, open
the call list.
3. End / Off Power Button: Press and hold to turn the power
on and off; briefly press it down, reject a call, or quit it from
the menu.
4. Ok key: press to execute the indicated function. In standby
mode, press to open the selected link.
5. Navigation keys: Press up / down / left / right directions to
scroll through the menu. In standby mode, press the up /
down / left / right arrows to access the quick menu at the top
of the screen and press OK to execute.
6. 0-9 alphanumeric keypad: Press the corresponding keys to
enter numbers when dialing or the characters of the numbers
when writing text.
In Idle mode: Press and hold "2" to "9" to use the Speed Dial
feature (if set in the menu [Phone Book / Speed Dial]).
Press * twice to display "+" the international developer signal.
7. * (Star) button: in standby mode press and hold * to display
the international prefix '+'. In Menu mode, briefly press to
lock the keypad.
8. # (Dual Cross) button: in standby mode, press and hold to
activate / deactivate Silent mode.

9
5. Getting Started
5.1. Insert a SIM card
To use your phone, you need to insert a valid SIM card to
connect to the GSM network.
To avoid missing or damaged the contents of the SIM card,
please DO NOT hold the metal part of the SIM card with your
hands free and keep it away from electromagnetic devices. If
the SIM card is damaged, it can not be connected to the GSM
network. Before inserting or removing the SIM card, make
sure that the device is turned off and removed from the back
of the device.
Note: Locate the SIM card slot on the back of the device and
in the direction of the signal, with the collisions slide the card.
5.2. Insert a memory card
The memory card is not part of the basic package, but the
memory of the device can be expanded with an SD card.
Please make sure that the memory card is inserted correctly
before use.
Note that the device may shake, the memory card may slide
out of the slot, so please do not bend it, scratch the memory
card or expose it to static electricity or dust, do not immerse
it in water. Place the memory card in the slot on the back of
the machine, with a chip down, as shown on the device.
Please be careful when using a memory card, especially when
it is removed. Some memory cards must be formatted with a
computer before use.

10
5.3. Insert battery
1. Insert the battery chip into the protruding metal point in
the battery slot, insert the battery, and push the top down
until the battery engages in the recess.
2. Put back the back cover.
5.4. Remove the battery
To remove the battery, turn off the device, remove the cover,
and then remove the battery at the top.
Note:
Please remove the battery when it is switched off, as it may
cause abnormal operation when the skin is switched on.
5.5. Charging the battery
Connect the charger to the appliance and plug the other end
into the socket. If the device is turned on while charging, the
battery icon will move in the right corner of the display.
Charging is completed when the charging indicator on the top
right is lit. If charging is switched off, a charging indicator
appears on the display. When charging is complete, unplug
the charger from the unit.
Note: When the battery voltage is low, a warning message is
displayed on the display. Charge the battery as soon as you
can, to avoid any inconvenience, the device can be switched
off during a telephone conversation. Your device can
automatically turn off when the power level is too low.

11
1. If you use the battery at a persistently low charge, it may
adversely affect the battery life and quality.
2. Use only the charger approved by the manufacturer for
proper operation.
3. Do not remove the battery during charging.
4. Fill the unit for at least 4 hours before first use. This can
increase the efficiency of the multiple charge and discharge
cycles.
5.6. Maintaining the battery
The device has a rechargeable battery. When not using the
charger, disconnect it from the power source. For more than
a week, do not leave the phone charging. Temperature
influences battery capacity. Battery may need to be cooled or
warmed up before charging. If the battery temperature is
lower than 0 ° C or higher than 45 ° C, do not charge the
battery. Use the battery according to its intended purpose.
Do not short-circuit the battery terminals. Do not use a
damaged battery. If you are using an appliance under
extreme temperature conditions, the battery will not work
properly and its life span will be reduced. DO NOT throw the
battery into fire, follow local laws and regulations regarding
the disposal of the spent battery.

12
6. Power On/Off
Press and hold the End / On-Off button to turn the unit on or
off.
1. If a SIM card is not inserted, it is defective or not fit correctly,
a warning message will be displayed after switching on the
display. Turn off your readiness and make sure the SIM card
is inserted correctly.
2. If you insert the SIM card into the device, the PIN request
and the phone password are active, the device prompts you
for the password and PIN code and switches to standby mode.
After switching on, the phone automatically searches for the
network. If the device has found the allowed network, it will
display its name and signal strength.
If your device does not find a suitable network, you can only
make an emergency call or access non-network services on
your phone
7. Call functions
If you have completed the steps in the previous chapter, the
machine is ready to make and receive calls. For more
information about call origination and basic call functions,
see this chapter.
Note:
If you are using a headset, gently insert and unplug the jack
plug to avoid possible injury.

13
7.1. Make a call
When the network service provider name appears on the
display, the phone is ready to make and receive calls.
Direct calling
In Standby mode, press the number keys to enter the number
you want to call, press the right soft key to clear the wrong
numbers, press the left soft key or the dial key to start the call
if the specified number is correct.
To enter an international phone number format, press and
hold the [*] key until "+" international call sign appears on the
display.
Dialing from Names
Use the right soft key to enter Names. Use the navigation keys
to scroll to the contact you want to dial, then press the call
key or Options (soft key left)> Call.
7.2. Auto redial
If you have set up automatic redial before (Menu> Settings>
Call settings> Advanced settings), the last called, but
unanswered call is redialed.
7.3. Receive call
When an incoming call is alerted to your device if your service
provider supports the number display, the display shows the
caller's number or the caller's name (depending on whether
you have saved it in the phone book).

14
1. Press the dial key or the left soft key and answer [Answer]
to the incoming call.
2. If Any key responds function is active, [Settings / Call
Settings / Advanced Settings / Answer Mode / Anykey], you
can answer any call using any key except the Right softkey and
the End / Off button.
3. When the headset is connected to the unit and [Headset]
is activated [Settings / Call settings / Advanced settings /
Answering mode / Automatic receiving in headset mode],
incoming calls will be automatically received by your phone
after 5 seconds of vibration or ringing.
4. If you do not want to answer the call, press the End / Off
button to reject the call.
The End / Off button can also be used to disconnect the call.
5. During a call, press the down / up navigation keys to reduce
or increase the loudspeaker volume.
Receive a second call
If the call waiting is active (you may need to be ordered from
the network service provider), if an incoming call is in
progress during an ongoing call, the device will briefly alert
you. You can either answer or reject the second call. If you
receive the second call, the ongoing call is held.
You can turn off the call waiting function in the device: Menu>
> Call settings> SIM1 / SIM2 call settings> Call Waiting
(Activate / Deactivate).

15
7.4. Conference
If supported by the network, multiple party calls can be made.
In Standby mode, enter the phone number, in international
format.
To dial, press the call key.
To add a new call, enter the second phone number and dial
the desired number. You can also make a new call from the
contacts stored in the phone book; during this active call,
press Options, select Phonebook, locate the contact you want
to dial, and press the call key. When the call is recovered,
select Options> Conference. You can repeat the above steps
to add more calls.
7.5. Available functions during call
Press <Menu> (left) to select from the following options
during a call:
• Hold / No hold
• End call
• Phonebook - Open a phonebook during a call
• Call list - to open call logs during a call
• Messages - Open messages during a call
• Start recording - Record the ongoing call
• Mute
• Volume - to decrease or increase the volume in the call
You can navigate through the available menu items on the
screen with the navigation key.
To end the call, press the end call key, or select Options> End
call.

16
7.6. Emergency call
You can immediately make an emergency call without a SIM
card. Different networks can use different emergency
numbers, so please contact your network operator.
7.7. Handsfree function
During a call, you can activate the loudspeaker using the
<Handsfree> (Right) softkey. To return to the student, press
<Handhold> (right) button.
7.8. View and answer a missed call
This menu shows missed calls. To dial the missed call, press
(Left) <View>, then press the call launcher or Options> Call to
dial the number.
7.9. Dial a previously dialed number
Press the call key in the standby mode to display the most
recently dialed numbers. Select the phone number you want
to dial and then press the call key again or Options> Call.
8. Main menu
In Standby mode, press the left soft key to enter the Main
Menu. Within the Main Menu, you can access many functions
and actions: Messaging, Call logs, Phonebook, Camera,
Multimedia, Games, Audio player, Extras, File manager,
Settings, FM radio, Profiles.
