Blaupunkt SM 01 User manual

User manual
Mobile phone SM 01

Table of Contents
1. Safety instructions.......................................................................1
2. Technical Specifications..............................................................4
3. Getting started ............................................................................6
3.1 Insert the memory card and SIM card..............................6
3.2 Unlock the device...............................................................7
4. Charging the battery...................................................................8
5. Switch the device on and off......................................................8
6. Using the Touch screen...............................................................9
7. Using the Phone’s Buttons........................................................10
7.1 Physical buttons ...............................................................10
7.2 Submenus and Options....................................................10
7.3 Menu icons.......................................................................11
8. Manage calls..............................................................................11
8.1 Make calls.........................................................................11
8.2 Disable Phone Calls (Airplane mode)..............................12
8.3 Receive a call....................................................................12
8.4 Emergency calls................................................................12
9. The Home screen ......................................................................12
9.1 Notification bar ................................................................13
9.2 Application Launcher.......................................................14
9.3 Customize your home screen..........................................15
10. Connecting to the Internet.....................................................16
10.1 Configure the Internet:..................................................16
10.2 Access Internet via Wi-Fi: ..............................................16
11. Messaging ...............................................................................17
12. Multimedia..............................................................................18

12.1 Camera ...........................................................................18
12.2 Photos.............................................................................18
12.3 Music ..............................................................................18
13. Contacts...................................................................................20
14. Phone.......................................................................................21
15. Search......................................................................................22
16. Google Play Store....................................................................22
17. More applications ...................................................................22
17.1 Clock ...............................................................................22
17.2 Downloads......................................................................22
17.3 E-mail..............................................................................23
17.4 File manager...................................................................23
17.5 Voice recorder................................................................23
18. Settings....................................................................................23
18.1 Wireless and networks ..................................................23
18.2 Device.............................................................................25
18.3 Personal..........................................................................25
19. Handling and maintenance ....................................................27
20. Recycling your device..............................................................29
21. Declaration of Compliance .....................................................29

1
1. Safety instructions
ATTENTION: Please read this guide carefully. Failure to comply with
the safety regulations may be dangerous or illegal, and the
manufacturer can not be held liable for any malfunction resulting
from improper use.
Safe switch-on
The owner of the device is responsible for the use of the device.
Never switch the device on in areas where wireless devices are
prohibited or radio interference may be dangerous.
Road safety
Observe the local laws and regulations regarding smartphone
usage while driving. If you make a phone call while driving,
observe the following rules: Focus on driving to become aware of
traffic conditions; If the device has a hands-free function, use
handsfree. If the traffic situation requires, stop the car before you
pick up the phone.
Interference
Wireless devices may be sensitive to interference that affects
performance.
Electronic devices
To avoid demagnetisation, do not leave your device for a long time
close to electronic devices.

2
Use in hospitals
Hospitals and other healthcare facilities can use devices that are
particularly sensitive to RF signals. Switch off your phone if
prohibited signals are instructed to do so, or hospital staff ask for
it.
Electrical medical devices
Your phone is a radio transmitter that can interfere with electronic
medical devices or implants such as hearing aids, pacemakers,
insulin pumps, and so on. operation. We recommend that you
keep a distance of at least 15 cm between the implant and the
device, never wear your phone in the breast pocket. Follow the
instructions of the manufacturer of the medical device. If you have
a medical implant and have any other questions about using
mobile or wireless devices, ask your doctor.
Use on the airplane
Your device supports flying mode, please use this feature on the
airplane. Follow the instructions on the airplane.
Explosion hazards and restricted areas
Turn off the device in explosion hazardous areas. Sparks in such
places may lead to an explosion or fire that may result in serious
injury or death. Turn off the devicce at gasoline or gas filling
stations, especially near the fuel pumps. Follow the instructions
strictly in locations such as fuel tanks, chemical plants, and
explosive substances.
Use environment
The device complies with the recommended emission values for
radio waves when kept at a minimum distance of 1.5 cm from the
ear. When carrying the phone in a case, belt clip or holder, make

3
sure that it does not contain metal and that the phone is slightly
distracted from the body. When using other accessories, it is not
possible to operate in accordance with radio frequency guidelines.
If you do not use a case and do not hold the phone on your ear,
keep it at least 2.5 cm away from your body, especially during data
transfer.
Proper use
Please do not attempt to disassemble the device. If the product is
defective, contact your distributor.
Battery and other accessories
Only use parts and accessories approved by the manufacturer.
Using non-factory accessories and spare parts may result in
warranty loss. Please do not charge the device before inserting the
battery. Do not short-circuit the battery.
Charge the appliance in a well-ventilated and suitable temperature
environment away from flammable and explosive materials.
Handle the used battery according to local regulations and do not
throw it into household trash.
Water resistance
The appliance is not waterproof and dry. Precipitation, fog, and
other liquids can corrode electronic circuits. If moisture has
reached the phone, remove the battery and contact the dealer.
Backup
Make a backup of all the data stored on your device.
Connect to another device
Before connecting an external device, read the safety instructions
in this manual. Do not connect an incompatible device.

4
2. Technical Specifications
Basic Features
•AndroidTM 7.0 Nougat
•4” WVGA display, 480x800 pixel
•2 MP front camera
•5 MP back camera
•1.3 GHz Quad Core processor
•1 GB RAM + 8 GB ROM memory
•microSD card up to 32 GB
•Single SIM
•Multimedia functions
•Wi-fi
•Bluetooth
•1400 mAh battery
•GSM 900 / 1800 MHz
•WCDMA 900 / 2100 MHz
Android is a trademark of GoogleTM Inc.
Power Supply Features:
• Input: AC 100-240V~50/60Hz 0.20 A
• Output: DC 5.0V 750 mAh
Battery and Voltage: 1400 mAh; 3.7 V

5
SAR value:
• 0.187W/Kg (Head)
• 0.756W/Kg (Body)
Phone layout
The following illustration of the phone is for informational
purposes only; your device may be different.

6
3. Getting started
3.1 Insert the memory card and SIM card
When subscribing to a service provider, they provides a SIM card
to use the network. Your SIM card has a phone number and
various services, but you can store data on it, for example. phone
numbers.
Turn off the power and remove the back cover and battery. Insert
the SIM card according to the mark on the device. Make sure that
the chip contact and the cut edge of the card are aligned in the
correct direction. Slide the card into the slot until it stops.
Tip: Insert an SD card to store more media.
Caution: Do not scratch or bend the SIM card. Be careful not to get
dust or water. Keep away from children.

7
3.2 Unlock the device
To unlock the device, you may need the PIN
(not the SIM card PIN), password, or pattern
drawing.
Unlock the screen:
1. Press the power key to wake up the
phone.
2. Hold and drag the unlock icon to
the upward to unlock.
The process of unlocking depends on the pre-configured.
To set the unlock method:
▪On the main menu, touch Settings > Security.
▪Touch Set up screen lock.
▪Choose the type of locking as desired. You can set your
screen lock on the basis of pattern, PIN, Password or
none.

8
4. Charging the battery
➢Connect one end of the charger to the device.
➢Connect the charger to the power outlet.
➢Charging will start regardless of whether the device is
turned on or not.
➢When the phone is turned on, the movement of the
battery icon in the upper right corner indicates charging.
When the motion stops, the phone is charged.
➢When the phone is turned off, the movement of the
battery icon on the screen indicates charging. When the
motion stops, the phone is charged.
➢Disconnect the charger from the power outlet.
➢Disconnect the charger from the phone.
5. Switch the device on and off
Press and hold the Power button to turn on the power.
Press and hold the power button and select “Power off” from the
Options menu.

9
6. Using the Touch screen
You can use the touch screen in the following ways:
•Touch: Acts on items on the screen, such as application and
settings icons, to type letters and symbols using the onscreen
keyboard, or to press onscreen buttons.
•Touch and hold: Touch and hold an item on the screen until an
action occurs.
•Drag: Touch and hold an item and move your finger on the
screen until you reach the target position.
•Swipe or slide: Quickly slide your finger across the surface of
the screen, (without dragging an item). For example, slide the
screen up or down to scroll a list,
•Double-tap: Tap quickly twice on a webpage, map, or other
screen to zoom. For example, double-tap a section of a
webpage in Browser to zoom that section to fit the width of
the screen. You can also double-tap to control t zoom, in Maps,
and in other applications.
•Pinch: In some applications (Such as Maps, Browser, and
Gallery) you can zoom in and out by placing two fingers on the
screen at once and pinching them together (to zoom out) or
spreading them apart (to zoom in).
•Rotate the screen: On most screens, the orientation of the
screen changes as you rotate it. You can turn this feature on
and off.

10
7. Using the Phone’s Buttons
7.1 Physical buttons
Button
Description
Menu: Opens the related menu
with additional options and
actions, depending on the
application. Press and hold to
open a list of recent applications.
Home: returns to Home screen.
Back: returns to the previous
screen you were working in
7.2 Submenus and Options
You can open context menu by touching key. Not all screens
have context menus.
Options menus contain tools that apply to specific items on the
screen. You can open an option by touching and holding an item
on the screen. Not all items have options menus.
When you touch and hold some items on a screen, an Options
menu opens.

11
7.3 Menu icons
Opens the dialer
Opens messages
Opens the main menu
Opens the contacts list
Opens the (Chrome)
browser
8. Manage calls
8.1 Make calls
▪Tap the icon on main menu or the home screen to dial the
desired number.
▪Touch the icon on main menu or the home screen to
make a call from contact, groups or favorites.
▪To dial an international number, touch and hold the 0 key to
enter the Plus (+) symbol, and then enter the international
country prefix, followed by the phone number
▪Touch the icon to call with SIM 1 or SIM 2.
▪Press the Volume Up/ Down keys to adjust the call volume.
▪You can access Call Logs, Contacts from the dialer screen.

12
▪While during a call, touch the icon to end a call.
8.2 Disable Phone Calls (Airplane mode)
Some locations like airplanes may require you to turn off your
mobile, Wi-Fi, and Bluetooth wireless connections.
▪Press and hold the Power button.
▪Touch the Airplane mode.
8.3 Receive a call
In an incoming call, you can choose from the following options:
▪Drag the phone icon to the right to receive the call.
▪Drag the phone icon to the left to reject the call.
▪Drag the phone icon upwards to reject with SMS.
8.4 Emergency calls
You can also make emergency calls without a SIM card. For more
information, contact your network service provider.
9. The Home screen
When you sign in, the home screen opens.
The Home screen is your starting point to access all the features
on your phone. Touch the main menu icon at the bottom of the
screen to view all installed applications.
The status bar shows the time, signal
strength, battery
satus and notification
Touch and hold an empty spot to
change wallpaper.

13
9.1 Notification bar
The notification bar shows your device status and notifications.
Notification icons indicate new messages and events. When a new
notification arrives, its icon appears in the Notification Bar.
Notification Icons Status Icons
To see more information about notifications, open the notification
panel by swiping your finger over the top of the screen.
Status icons:
Icon
Description
Icon
Description
Signal strength
indicator
Alarm has been set
New missed calls
Wi-Fi is activated
USB is connected
Bluetooth is on
The headphone is
being used
Battery charging symbol
New message from
SIM 1
Airplane mode is
activated
Close the notification bar:
Drag the bottom of the notification panel to the top of the screen
or simply press the back button. The notification panel will also
close when responding to a notification.

14
9.2 Application Launcher
Press the Launcher icon to enter the Main
Menu. From here you can access all installed
applications and widgets.
Touch the app to start.
To add an application shortcut to the desktop
screen, press and hold it until it vibrates and
enters Home screen. Place it and release your
finger.
Slide the Launcher left or right to bring more
icons into view.
As soon as you install a new application, it comes in this list.
To access widgets, press the menu button on
the Home screen, then tap the widget icon at
the bottom of the screen. Widgets can not be
started as an application.
Press and hold the selected widget until it
vibrates and the Home screen open. Place and
release your finger from the screen. The app
may request further action to activate the
widget.
You can configure the widget in the submenu,
for example, size. The options displayed, depend on the given
widget. If there is not enough space on the Home screen, the
widget will not be added.
To close the launcher, press the Home button or the Back button.

15
9.3 Customize your home screen
You can add apps, widgets, other links to your Home screens and
change the wallpaper.
Set up a wallpaper:
You can add a wallpaper from the Gallery, which includes live
wallpapers and pre-installed wallpapers.
Tap on the Home screen anywhere, on an empty surface. From the
list that appears, select Wallpapers. Choose an image from the
viewer, or choose My Photos from other sources (eg Downloads,
Google Photos, Gallery) in My Photos. Select the photo you want
to set up and confirm it by pressing the Wallpaper Setup at the top
of the screen. You can set the selected image to the background of
the Home screen, the Background screen of the Lock screen, or
both.
Creating folders:
Easily group your apps on the Home screen by creating folders.
Besides grouping, you can save space in folders by sorting.
Press the application icon and hold it to move the application.
Drag to the icon you want to sort into a folder. This creates a folder
to add additional apps.
To rename the folder, click the folder and then type the name on
the popup screen keyboard.

16
10. Connecting to the Internet
Your device has pre-installed browsers to access websites through
your mobile device. Open your browser and enter the URL of the
page you want to access in the address bar. You must have a
subscription to access the web pages, and you must complete the
appropriate configuration settings on your device.
10.1 Configure the Internet:
▪Go to Settings> Wireless & Networks >More > Mobile
Networks >Tap Data Enabled.
▪By default, your network provider sends the Access Point
Name settings via SMS, or it comes automatically with your
SIM card. You may need to install these settings. After this,
you can choose from the listed access point names. If the
access point names are not listed by default, please contact
your network provider for the same.
▪To add any operator Access point Name, go to settings >
More > Mobile networks > Access Point Name.
10.2 Access Internet via Wi-Fi:
▪Go to Menu> System settings> wireless & networks and then
tap Wi-Fi.
▪Next, go to Menu> settings> wireless & networks > Wi-Fi
Settings and then enable Wi-Fi. Next, select the WIFI
connection listed under Wi-Fi networks.

17
11. Messaging
Select Messages in the Main Menu or the Standby screen.
11.1 Send Message
To send a new message, tap the +icon in the right corner of the
screen.
Enter the recipient's phone number or select from the Contacts
list.
If you have selected the recipients, confirm the arrow icon at the
top right of the screen.
Enter the text of the message and press the send key.
To add an attachment, press the +icon on the left.
When you edit a message, the default message type is SMS. As
soon as you add an attachment or reach 10 SMS messages, the
machine automatically switches to MMS.
11.2 Input metods
The device contains various input modes. In Editing mode, press
and hold [,] to display Input Options and to set the keyboard.
Writing Numbers
Press to display the number keys directly. You can also enter a
number with the letters containing the numbers: press and hold,
then swipe to the desired character.
Writing Symbols
Press to open the list of symbols. Press the symbol you want to
enter.
Press and hold [. ] to display the list of symbols, slide your finger to
the symbol you want to enter.
