BlissLights Spright User manual
Manufactured by Blisslights
Phone: (626) 709-3319
Fax: (626) 205-4013
www.BlissLights.com
MADE IN USA
Please ONLY use
manufacture
provided transformer
USER’S GUIDE
Notice 1
Before you begin 2
Parts List 2
Setting up the BlissLights Spright 3
Operating the BlissLights Spright 4
Installation Tips 4
Product Specications 5
Limited Warranty 6
Contents
CAUTION – Use of controls or adjustments or performance of
procedures other than those specied herein may result in hazardous
radiation exposure.
This laser product is certied as a CLASS 2M laser product to the
requirements of the US Federal Laser Product Performance Standard
(FLPPS) contained in the regulations in 21 CFR Subchapter J. Class 2
laser products can be hazardous when directly viewed.
Avoid direct viewing of Class 2M laser energy. For reference the FLPPS
requirements for demonstration laser products like laser pointers are
limited to Class 2M levels of laser energy. This product uses diffractive
optics to scatter the beam energy. This scattering effect causes the
energy concentration to drop below the exposure limits for momentary
or accidental viewing at a relatively short distance from the laser
aperture. As similar with all bright light sources, when you operate this
device in unsupervised general public areas, it is recommended that
up close access to the Blisslights be restricted or prevented.
This laser display device incorporates a Class 2M laser system which,
by itself, may be hazardous. However, this laser display device
incorporates a protective housing and diffractive holographic optics in
the machine design such that there is no exposure or human access
to laser radiation during operation or maintenance above the Class
2 limits. Each individual laser beam power is under 1mw which is less
than a standard laser pointer.
UNDER NO CIRCUMSTANCE shall attempts be made to open the
protective housing or operate the device if the aperture windows are
damaged.
All service to this laser display device requiring the protective housing
to be opened and/ or removed shall be performed by Blisslights service
personnel or their authorized agents. Opening the BlissLights protective
housing voids the warranty.
NO LASERS SHOULD BE POINTED INTO THE SKY WITH 10 NAUTICAL MILES
OF AN AIRPORT. IF YOU ARE LOCATED WITHIN THIS SPECIFIC PERIMETER
WE RECOMMEND THE LASERS BE POINTED DOWN AT THE GROUND SO NO
STRAY BEAMS ARE PROJECTED INTO THE AIR.
Notice
1
Thank you for purchasing the BlissLights Spright. The BlissLights
Spright projects thousands of green pin points of light that is
perfect for putting “reies” in your garden or creating a truly
unique holiday display. We hope you enjoy this incredibly unique
lighting xture.
Before you Begin
Immediately upon receiving a xture, carefully unpack the carton,
check the contents to ensure that all parts are present, and have
been received in good condition. Notify the shipper immediately
and retain packing material for inspection if any parts appear
damaged from shipping or the carton itself shows signs
of mishandling. Save the carton and all packing materials. In the
event that a xture must be returned to the factory, it is important
that the xture be returned in the original factory box. Please see
parts list below for box contents.
Parts List
(1) BlissLights- Spright (1) Transformer
2
Setting up the BlissLights
**Before operating the BlissLights Spright, please read the “Before you Begin”
section and “Notice” section of this user guide.**
STEP 1: First locate the 2-prong plug connected to the cable
exiting the BlissLights Spright head. Plug this end into the matching
hole on the end of the 12V Manufacture provided transformer.
Screw the cap on to complete the water tight seal. Next plug the
standard 3-prong plug on the other end of the transformer into an
outdoor/Indoor outlet.
STEP 2: Stake the BlissLights Spright into the desired location. To
attach or detach the stake, twist the stake into place on the
bottom of the Spright. Do not use xture head to stake light into
the ground, grasp by stake only. Use the thumb screw on the side
of the xture to adjust the angle.
3
Operating the BlissLights Spright
The BlissLights Spright operates in temperatures of -15o F to 90o F.
There may be a slight delay if operating in temperatures below
55 o F. Please allow up to 10 minutes for light to warm up and
reach its full projection.
Installation Tips
• For scheduled or nighttime-only operation, use with a timer. Do
not connect the light to a dimmer pack, it will damage the light.
Use with manufacture provided transformer only.
• The darker the area the light is being used in, the brighter the
projection. Try to stay away from areas with street lights or other
bright lights.
• If you are going to hang the BlissLights Spright, it is recommended
that, for safety purposes, your lights are properly mounted using a
suitable hanging clip and safety cable.
• The BlissLights Spright will cover an area of about 30’ X 30’ for
every 10 feet away from surface (equivalent to the size of about 2
two-car garages).
3 feet
1 foot
3 feet of coverage for every 1 foot of throw
4
Product Specications
Laser Classification Class 2
Maximum Laser Power
(Single Beam) Less than 1 mw
Laser Wavelength 532 nm – Green, 650nm-Red, 445nm-Blue
Laser Optics Single source holographic optical element
Power Consumption Up to 8 watts
Power Input
Operation Indoor / Outdoor
Operating Temperature -15º F to 90º F
Projection Coverage 30ft. X 30ft.
Maintenance Maintenance Free
Dimensions 13”H x 5 ”L x 4”W
Warranty
BlissLights Spright
110/120V
(when used with manufacturer provided transformer)
Limited 1 Year
5
For tips and ideas visit www.blisslights.com where you can also
learn more about other Blisslights products and accessories.
Blisslights Spright Move
Blisslights Timer
Blisslights
Garden Accent Light
16-color user selectable
M
LIMITED WARRANTY
The manufacturer warrants this product to be free from defects in materials and workmanship for a period of
one (1) year from date of purchase. This warranty applies only to the original consumer purchaser and only
to products used in normal use and service. If this product is found to be defective, the manufacturer’s only
obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s
discretion, provided that the product has not been damaged through misuse, abuse, accident, modica-
tions, alterations, neglect or mishandling. This warranty shall not apply to any product that is found to have
been improperly installed, set-up, or used in any way not in accordance with the instructions supplied with the
product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negli-
gence, alteration, or faulty installation, or any other failure not relating to faulty material or workmanship. This
warranty shall not apply to the nish on any portion of the product, such as surface and/or weathering, as this
is considered normal wear and tear. The manufacturer does not warrant and specially disclaims any warranty,
whether expressed or implied, of tness for a particular purpose, other than the warranty contained herein. The
manufacturer specically disclaims any liability and shall not be liable for any consequential or incidental loss
of damage, including any labor/expense costs involved in the replacement or repair of said product. Please
contact BlissLights at [email protected], or (626) 709- 3319.
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ __ _
Owner Registration Card
Please ll out, cut along dashed line, afx proper postage and return this Owner
registration card within 10 days to insure that your new BlissLightsis covered by
the limited warranty. You can also go to www.blisslights.com and ll out your
registration card online.
Mailing Address: BlissLights, 1155 Industrial Avenue, Escondido, CA 92029
Purchaser’s Name ____________________________________________
Address ____________________________________________________
State __________________________ Zip_________________________
Email: _____________________________________________________
BlissLights Product: ________________ Purchase Date: _____________
Where Purchased (Store Name) _________________________________
Where will the BlissLight be used: ______________________________
If commercial institution, what type of business?
__Restaurant __Bar __Store __Ofce __Other
If home installation, where?
__Walkway __Patio __Garden Area __Porch __Other
Model/UPC Number:_______________________
6
