Blizzard Lighting Torrent Keyframe 600 User manual

TORRENT
KEYFRAME 600
Blizzard Lighting, LLC
http://www.blizzardpro.com
Waukesha, WI USA
Copyright (c) 2021

Page 2
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
TABLE OF CONTENTS
1. Getting Started 3
What’s Included? 3
Unpacking Instructions 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions 4
2. Meet the Torrent™ Keyframe 600 5
Main Features 5
DMX Quick Reference (36/52-Channel Modes) 5
Torrent™ Keyframe 600 Pin-Up Picture 6
The Rear Connections 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch of Torrent Keyframe 600's 7
DMX Connections 7
Art-Net™ and sACN 7
Mounting Points 8
Clamp Mounting 9
Securing the Fixture 9
4. Operating Adjustments 10
The Control Panel 10
Control Panel Menu Structure 11
DMX Values In-Depth (36/52-Channel Modes) 12
Gobo Replacement 15
Rotating Gobos 15
Static Gobos 15
Color Wheel 16
Animation Wheel 16
Dimmer Modes 16
Fault Detection 16
5. Appendix 17
Keeping Your Torrent™ Keyframe 600 As Good As New 17
Returns (Gasp!) 17
Shipping Issues 17
Tech Specs! 18
Troubleshooting 18
Dimensional Drawings 19
Photometric Data 19

Page 3
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
1. GETTING STARTED
What’s Included?
• 1 x Torrent™ Keyframe 600
• 1 x Power Cord
• 2 x Mounting Brackets
• 1 x User Manual
• 1 x ATA Spec Road Case
Unpacking Instructions
Congratulations on purchasing Torrent™ Keyframe 600, professional framing
spot xture. Now that you’ve got your Torrent™ Keyframe 600, you should
carefully unpack it and check the contents to ensure that all parts are present
and in good condition. If anything looks as if it has been damaged in transit,
notify the shipper and keep any packing material for inspection. If a xture
must be returned to the factory, it is important that the xture be returned in
its original packaged condition.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run
o a rheostat (variable resistor) or dimmer circuit, even if the rheostat
or dimmer channel is used solely for a 0% to 100% switch.
Warning! All xtures must be connected to circuits with a suitable
Ground (Earthing).
Getting A Hold Of Us
If something happens to go wrong, visit blizzardpro.com/support and
open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are
subject to change without notice. Blizzard Lighting™ assumes no responsibility
or liability for any errors or omissions that may appear in this user manual.
Blizzard Lighting™ reserves the right to update the existing document or to
create a new document to correct any errors or omissions at any time. You can
download the latest version of this document from www.blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 2/4/2021 J. Thomas 2/4/2021

Page 4
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Please read these instructions carefully. They include
important information about the installation, usage and
maintenance of this product.
Safety Instructions
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the de-
cal or rear panel of the xture.
• This product is intended for indoor use only.
• To prevent risk of re or shock, do not expose xture to rain or moisture.
• Make sure there are no ammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
• ALWAYS secure xture using a safety chain. NEVER carry the xture by its
head. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 104°F (40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized tech-
nical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! With the exception of removing the covers for general maintenance
and cleaning as outlined in this manual, there are no user serviceable parts
inside the unit. Do not open the housing or attempt any repairs yourself. In the
unlikely event your unit may require service, please open a support ticket at
www.blizzardpro.com/support.

Page 5
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
2. MEET THE TORRENT™ KEYFRAME 600
Main Features
• 600W, 6500K white LED light source
• 4 blade framing shutter system with rotation (+/- 45°)
• Rotating gobo wheel with 6 gobos (2 glass & 4 metal) +open
• Fixed gobo wheel with 8 metal gobos +open
• 6 color wheel + white (open)
• CMY + CTO color mixing system
• Variable CRI lter (71 ~ 91)
• P/T ranges: 540°, 360°, 180° pan / 270°, 180°, 90° tilt
• 16-bit smooth dimming + 4 selectable dimming curves
• 7-40° linear motorized zoom
• Frost, iris, and continuous animation eect wheel
• 3-facet circular + 4-facet linear rotating prisms
• 0-25Hz strobe + variable, pulse, and random eects
• Flicker-free + 6 PWM setting options
• 8-16 bit focus (1M to innite + auto)
• 6-button control panel with touchscreen LCD display
• Protocol: USITT DMX-512, Art-Net, sACN, RDM
DMX Quick Reference (36/52-Channel Modes)
36CH 52CH What It Does 36CH 52CH What It Does
11Pan -- 27 Blade 2, Motor 2 (ne)
22Pan (ne) 22 28 Blade 3, Motor 1
3 3 Tilt -- 29 Blade 3, Motor 1 (ne)
44Tilt (ne) 23 30 Blade 3, Motor 2
5 5 Pan/Tilt Speed -- 31 Blade 3, Motor 2 (ne)
6 6 Dimmer 24 32 Blade 4, Motor 1
-- 7 Dimmer (ne) -- 33 Blade 4, Motor 1 (ne)
7 8 Strobe 25 34 Blade 4, Motor 2
8 9 Cyan -- 35 Blade 4, Motor 2 (ne)
9 10 Magenta 26 36 Frame Rotation
10 11 Yellow -- 37 Frame Rotation (ne)
11 12 CTO 27 38 Focus
12 13 Color Wheel -- 39 Focus (ne)
13 14 Gobo Wheel #1 -- 40 Auto Focus
14 15 Gobo Rotation 28 41 Zoom
-- 16 Gobo Rotation (ne) -- 42 Zoom (ne)
15 17 Gobo Wheel #2 29 43 Prism 1
16 18 Animation Wheel 30 44 Prism 1 Rotation
17 19 Animation Wheel Rotate 31 45 Prism 2
18 20 Blade 1, Motor 1 32 46 Prism 2 Rotation
-- 21 Blade 1, Motor 1 (ne) 33 47 Iris
19 22 Blade 1, Motor 2 34 48 Frost Filter
-- 23 Blade 1, Motor 2 (ne) 35 49 CRI Filter
20 24 Blade 2, Motor 1 -- 50 CMY Macros
-- 25 Blade 2, Motor 1 (ne) -- 51 CMY Macro Speed
21 26 Blade 2, Motor 2 36 52 Control Functions

Page 6
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
The Rear Connections
Torrent™ Keyframe 600 Pin-Up Picture
Arms
Control Panel
Menu
Carry
Handle
600W, 6500K
White LED
Head
Pan/Tilt
Lock
Power
Switch
3-Pin
DMX In
5-Pin
DMX In
RJ45
Input
Power
Input
3-Pin
DMX Out
5-Pin
DMX Out
RJ45
Output
Power
Output
Fuse
Holder

Page 7
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Fuse Replacement
Remove the fuse holder from of its housing. Then take out the damaged fuse
from its holder and replace with exact same type of fuse. Reattach the fuse
holder, and then reconnect power.
Connecting A Bunch of Torrent Keyframe 600's
This xture can receive DMX, Art-Net, or sCAN signals. It is equipped with both
3-pin and 5-pin DMX input/output, and RJ45 input/output connections.
DMX Connections
To link xtures together via DMX, you’ll need data cables. You should use
data-grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
Connect your controller to the DMX input of the rst xture, and then the
DMX output of the rst xture to the DMX input of the next in line. Continue
to connect the outputs to the inputs of any following xtures until all are
connected together. Up to 32 xtures, or 1,000 feet of total cable length
(whichever comes rst) can be connected.
Note: We recommended the use of a DMX terminator on the last xture.
Art-Net™ and sACN
This xture is equipped with an RJ45 input socket for Ethernet input connection
and RJ45 output socket for daisy chaining xtures.
Art-Net™ communication protocol is a 10 Base T Ethernet protocol based on the
TCP/IP. Its purpose is to allow transfer of large amounts of DMX-512 data over
a wide area using standard network technology.
To congure the xture network settings for use with Art-Net™ or sACN,
navigate the main menu to reach Network Setup where you can adjust the IP
Mode (Manual, DHCP, or Static), Universe, IP, and the SubMask settings (see
Control Panel Menu Structure, p.11).
Before replacing a fuse, disconnect the power cord.
ALWAYS replace with the same type and rating of fuse.
3. SETUP

Page 8
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Mounting Points
Overhead mounting requires extensive experience, which includes calculating
working load limits, knowledge of the installation material being used, and
periodic safety inspection of all installation material and the xture. If you lack
these qualications, do not attempt the installation yourself.
This unit can be mounted upside down, or upright
on a at level surface. Due to the inertia of the
xture when it moves and its weight, sideways
mounting is not recommended.
Be sure the xture is kept at least 12m (40ft)
away from any ammable materials, and always
install a safety cable as a measure to prevent
accidental damage and/or injury if the clamps fail.
Caution!
Please be aware, you should have a qualied electrician performing all of your
electrical connection needs.
Be sure to complete all rigging and installation procedures before connecting
the main power cord to the appropriate wall outlet.
Instead of sideways mounting,
you may consider hanging the
xture vertically on an sidearm
rated for at least 200 lbs.

Page 9
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Clamp Mounting
This xture provides a mounting bracket assembly that secures the bottom
base, mounting brackets, and safety cable rigging point together. When
mounting to truss, be sure to use an appropriately rated clamp tted through
the center hole of the mounting bracket.
1.) Clamp
2.) Mounting bracket
3.) ¼ Turn quick lock fasteners
Securing the Fixture
Regardless of the rigging option you choose for your xtures, always be sure
to secure them with a safety cable. Be sure to use the designated rigging point
found on the underside of the base assembly for the safety cable.
1. Attach clamps to both brackets through the hole in the bracket.
2. Fasten the mounting brackets to the base by inserting the quick-lock
fasteners into the holes, and turn them clockwise to tighten.
3. Hang the xture using the clamps and tighten. Fasten a safety cable
through the bottom of the base, and over the support.

Page 10
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
The control panel LCD display shows the menu items you select from the menu
map on page #11. When a menu function is selected, the display will immedi-
ately show the rst available options for the selected menu function. To select a
menu item, press <ENTER>.
Use the touchscreen icons, or the <UP>, <DOWN>, <LEFT>, and <RIGHT>
buttons to navigate the menu options. Press <ENTER> to select the menu
function currently displayed, or to enable a menu option. To return to the previ-
ous option or menu without changing the value, press the <MENU> button.
Note: The screen invert settings of NO/YES or AUTO can be adjusted by navi-
gating to Settings > Screen Reverse.
4. OPERATING ADJUSTMENTS
The Control Panel
All the features and dierent modes possible with Torrent™ Keyframe 600 can
be accessed by using the control panel on the front of the xture. It has a
touchscreen display, and 6 control buttons. Navigate the display by using the
buttons, or touching the desired menu option on the display. The touchscreen
can be calibrated and locked in the settings options in the menu.
Address
(52CH) 192.168.1.113
DMX Universe: 000
<UP>
Scrolls through menu items and
numbers in ascending order.
<MENU>
Is used to navigate to the previous
higher-level menu item.
<DOWN>
Scrolls through menu items and
numbers in descending order.
<LEFT>
Navigates through menu items moving
towards the left.
<ENTER>
Is used to select and conrm/store the
current selection.
<RIGHT>
Navigates through menu items moving
towards the right.

Page 11
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Control Panel Menu Structure
Address 001-512 Set the starting address
Network
Setup
IP Mode Manual (manually set IP address)
DHCP (network sets IP address)
Static (product sets IP address)
Universe 0-255/1-256
IP 002.243.075.222
SubMask 255.000.000.000
Personality DMX Mode 36CH/52CH
Settings Control Mode DMX/ArtNet/sACN
Pan Reverse NO/YES
Tilt Reverse NO/YES
Screen Reverse NO/YES/AUTO
Pan Angle 540/360/180
Tilt Angle 270/180/90
BL. O. P/T Move NO/YES (p/t movement blackout)
BL. O. Color Move NO/YES (color movement blackout)
BL. O. Gobo Move NO/YES (gobo movement blackout)
Calibration NO/YES (calibrate touchscreen)
Touchscreen Lock NO/YES (touchscreen on/o)
Swap XY NO/YES (swap pan/tilt)
Backlight Timer 30s/1m/5m/ON
Loss of Data Hold (last signal) / Close (blackout)
Fans Auto/Full/ECO (ECO = quiet mode)
Theatrical Dimming ON/OFF
Dimmer Curve Linear/Square/I Square/S-Curve
Dimmer Speed Smooth/Fast
PWM Option (Hz) 600/1200/2000/4000/6000/15000
Reset Function Pan/Tilt Frost/Animation
Iris/Prism All
Color/CMY/Blade Factory Settings
Gobo/Gobo Rot.
Test Auto Test NO/YES (auto test all functions)
Manual Test (0-255, manually test all settings using the control panel)
Pan Gobo Blade 2-2 Fine Focus Auto
Fine Pan Gobo Rotate Blade 3-1 Zoom
Tilt Gobo Index Blade 3-1 Fine Zoom Fine
Fine Tilt Gobo 2 Blade 3-2 Prism
P/T Speed Animation Blade 3-2 Fine Prism Rotate
Dimmer Animation Rotate Blade 4-1 Prism 2
Dimmer Fine Blade 1-1 Blade 4-1 Fine Prism 2 Rotate
Shutter Blade 1-1 Fine Blade 4-2 Iris
Cyan Blade 1-2 Blade 4-2 Fine Frost
Magenta Blade 1-2 Fine Blade Rotate CRI Filter
Yellow Blade 2-1 Blade Rotate Fine CMY Macro
CTO Blade 2-1 Fine Focus CMY Macro Speed
Color Blade 2-2 Focus Fine Special Function
Info Fixture Information
(shows current information)
Ver (version) IP
Running Mode SubMask
DMX Address MAC
Temperature Error Info
Fixture Hours --
Channel Information (shows all current values from input signals)
Calibration Password: 3323. Hold menu key for 2s on the standby screen to reset.

Page 12
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
DMX Values In-Depth (36/52-Channel Modes)
36CH 52CH Value What It Does
1 1 000 <-> 255 Pan
2 2 000 <-> 255 Fine Pan (16-bit)
3 3 000 <-> 255 Tilt
4 4 000 <-> 255 Fine Tilt (16-bit)
5 5 000 <-> 255 Pan/Tilt Speed (fast <-> slow)
6 6 000 <-> 255 Dimmer
-- 7 000 <-> 255 Fine Dimmer (16-bit)
7 8
000 <-> 003
004 <-> 007
008 <-> 076
077 <-> 145
146 <-> 215
216 <-> 255
Strobe
Closed
Open
Strobe
Pulse (slow <-> fast)
Random (slow <-> fast)
Open
8 9 000 <-> 255 Cyan (0% <--> 100%)
9 10 000 <-> 255 Magenta (0% <--> 100%)
10 11 000 <-> 255 Yellow (0% <--> 100%)
11 12 000 <-> 255 CTO (0% <--> 100%)
12 13
000 <-> 007
008 <-> 015
016 <-> 023
024 <-> 031
032 <-> 039
040 <-> 047
048 <-> 059
060 <-> 187
188 <-> 219
220 <-> 223
224 <-> 255
Color Wheel
Open
Red
Green
Blue
Yellow
Orange
Magenta
Index Rotation (0-360º)
Forward Scroll (fast <-> slow)
Stop
Backwards Scroll (slow <-> fast)
13 14
000 <-> 008
009 <-> 017
018 <-> 026
027 <-> 035
036 <-> 044
045 <-> 053
054 <-> 063
064 <-> 073
074 <-> 082
083 <-> 091
092 <-> 100
101 <-> 109
110 <-> 118
119 <-> 127
128 <-> 191
192 <-> 255
Gobo Wheel #1 (Rotating)
Open
Gobo 1 - Red Gatling Gun
Gobo 2 - Blue Sun
Gobo 3 - Quarter Circle
Gobo 4 - Waves
Gobo 5 - Vortex
Gobo 6 - Dotted Bar
Gobo 6 Shake - Dotted Bar
Gobo 5 Shake - Vortex
Gobo 4 Shake - Waves
Gobo 3 Shake - Quarter Circle
Gobo 2 Shake - Blue Sun
Gobo 1 Shake - Red Gatling Gun
Open
Counterclockwise Scroll (slow <-> fast)
Clockwise Scroll (slow <-> fast)
14 15
000 <-> 063
064 <-> 145
146 <-> 149
150 <-> 231
232 <-> 255
Gobo Rotation
Gobo Index
Counterclockwise Rotation (fast <-> slow)
Stop
Clockwise Rotation (fast <-> slow)
Gobo Rotation (bi-directional rainbow eect)
-- 16 000 <-> 255 Fine Gobo Rotation (16-bit)

Page 13
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
DMX Values In-Depth (36/52-Channel Modes)
36CH 52CH Value What It Does
15 17
000 <-> 006
007 <-> 013
014 <-> 020
021 <-> 027
028 <-> 034
035 <-> 041
042 <-> 048
049 <-> 055
056 <-> 063
064 <-> 069
070 <-> 075
076 <-> 081
082 <-> 087
088 <-> 093
094 <-> 099
100 <-> 105
106 <-> 111
112 <-> 117
118 <-> 127
128 <-> 191
192 <-> 255
Gobo Wheel #2 (Static)
Open
Gobo 1 - Pick-up Sticks
Gobo 2 - Segmented Ring
Gobo 3 - Spiral
Gobo 4 - Cross Hatch
Gobo 5 - Breakup
Gobo 6 - Stars
Gobo 7 - Dots
Gobo 8 - Square Tiles
Open
Gobo 8 Shake - Square Tiles
Gobo 7 Shake - Dots
Gobo 6 Shake - Stars
Gobo 5 Shake- Breakup
Gobo 4 Shake - Cross Hatch
Gobo 3 Shake - Spiral
Gobo 2 Shake - Segmented Ring
Gobo 1 Shake - Pick-up Sticks
Open
Counterclockwise Gobo Scroll (slow <-> fast)
Clockwise Scroll (slow <-> fast)
16 18 000 <-> 255 Animation Wheel
17 19
000 <-> 124
125 <-> 130
131 <-> 255
Animation Wheel Rotation
Counterclockwise Rotation (fast <-> slow)
Stop
Clockwise Rotation (slow <-> fast)
18 20 000 <-> 255 Framing Blade 1, Motor 1
-- 21 000 <-> 255 Framing Blade 1, Motor 1 (ne, 16-bit)
19 22 000 <-> 255 Framing Blade 1, Motor 2
-- 23 000 <-> 255 Framing Blade 1, Motor 2 (ne, 16-bit)
20 24 000 <-> 255 Framing Blade 2, Motor 1
-- 25 000 <-> 255 Framing Blade 2, Motor 1 (ne, 16-bit)
21 26 000 <-> 255 Framing Blade 2, Motor 2
-- 27 000 <-> 255 Framing Blade 2, Motor 2 (ne, 16-bit)
22 28 000 <-> 255 Framing Blade 3, Motor 1
-- 29 000 <-> 255 Framing Blade 3, Motor 1 (ne, 16-bit)
23 30 000 <-> 255 Framing Blade 3, Motor 2
-- 31 000 <-> 255 Framing Blade 3, Motor 2 (ne, 16-bit)
24 32 000 <-> 255 Framing Blade 4, Motor 1
-- 33 000 <-> 255 Framing Blade 4, Motor 1 (ne, 16-bit)
25 34 000 <-> 255 Framing Blade 4, Motor 2
-- 35 000 <-> 255 Framing Blade 4, Motor 2 (ne, 16-bit)
26 36 000 <-> 255 Framing System Rotation
-- 37 000 <-> 255 Framing System Rotation (ne, 16-bit)
27 38 000 <-> 255 Focus
-- 39 000 <-> 255 Fine Focus (16-bit)
-- 40
000 <-> 010
011 <-> 127
128 <-> 255
Auto Focus
No function
Automatic focus gobo wheel 2 (static)
Automatic focus gobo 1 wheel 1 (rotating)
28 41 000 <-> 255 Zoom (narrow <-> wide)
-- 42 000 <-> 255 Fine Zoom (16-bit)

Page 14
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
DMX Values In-Depth (36/52-Channel Modes)
36CH 52CH Value What It Does
29 43
000 <-> 004
005 <-> 255
Prism 1
No Function
Prism 1 Eect
30 44
000 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Prism 1 Rotation
Rotating Position
Counterclockwise Rotation (fast <-> slow)
Stop
Clockwise Rotation (slow <-> fast)
31 45
000 <-> 004
005 <-> 255
Prism 2
No Function
Prism 2 Eect
32 46
000 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Prism 2 Rotation
Rotating Position
Clockwise Rotation (fast <-> slow)
Stop
Counterclockwise Rotation (slow <-> fast)
33 47
000 <-> 063
064 <-> 127
128 <-> 191
192 <-> 255
Iris
Big to Small
Auto Change (slow <-> fast)
Slow Shrink, Fast Expand (slow <-> fast)
Slow Expand, Fast Shrink (slow <-> fast)
34 48 000 <-> 255 Frost Filter (0% <-> 100%)
35 49
000 <-> 004
005 <-> 255
CRI Filter
No Function
CRI Filter Eect
-- 50
000 <-> 009
010 <-> 255
CMY Macros
No Function
CMY Macro Functions
-- 51 000 <-> 255 CMY Macro Speed
36 52
000 <-> 007
008 <-> 015
016 <-> 023
024 <-> 031
032 <-> 039
040 <-> 047
048 <-> 055
056 <-> 095
096 <-> 103
104 <-> 111
112 <-> 119
120 <-> 127
128 <-> 135
136 <-> 143
144 <-> 151
152 <-> 159
160 <-> 167
168 <-> 175
176 <-> 183
184 <-> 191
192 <-> 199
200 <-> 207
208 <-> 215
216 <-> 225
226 <-> 230
231 <-> 235
236 <-> 240
241 <-> 245
246 <-> 255
Control Functions
No function
XY blackout
C blackout
G blackout
XYC blackout
XYG blackout
XYCG blackout
No function
X reset
Y reset
Color reset
Fixed & rotating gobo reset
No function
Prism reset
Framing system reset
All channels reset
Iris reset
Frost reset
Zoom reset
CMY reset
Fan low speed
Fan full speed
Fan auto
No function
Dimming Curve 1 (Linear)
Dimming Curve 2 (Square Law)
Dimming Curve 3 (Inverse Square Law)
Dimming Curve 4 (S-Curve)
No function

Page 15
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Rotating Gobos
4
Static Gobos
Gobo Replacement
1. Remove the gobo cover by removing the four screws on the top of the xture head.
2. Remove the slot-n-lock gobo from the wheel by lifting up slightly and sliding it out.
3. Using a small tool, pry the tension ring from the gobo holder.
4. Remove the old gobo, insert the new gobo, and replace using the reverse steps.
Gobo holder Gobo Tension ring
123
5 6
41 2 3
85 6 7

Page 16
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Color Wheel
1. Open
2. Red
3. Green
4. Blue
5. Yellow
6. Orange
7. Magenta
8. CRI lter
CRI = 71 (91 with lter)
Dimmer Modes
Allows users to set the xture to use 1 of 4 dimming curve settings for smoother (and
slower) dimming capabilities.
DMX% DMX% DMX% DMX%
Output
Output
Output
Output
Linear Square Law Inv. Square Law S-Curve
Animation Wheel
When used in conjunction with focus, the radial
animation wheel can create soft textures and depth
within the wash eld, or it can add sharp animated
projections & mid-air beam eects.
Fault Detection
If a problem is detected, the following error codes may be displayed. If an issue persists
after performing a reset, visit www.blizzardpro.com/support to open a support ticket.
Code Description Code Description
Focus Focus Fault MAGENTA CMY Red Fault
Zoom Zoom Fault YELLOW CMY Yellow Fault
Prism Prism 1 Fault CTO CMY CTO Fault
Prism2 Prism 2 Fault X_op Pan Optocoupler Fault
Prism2.R Prism 2 Rotation Fault Y_op Tilt Optocoupler Fault
Gobo Rotating Gobo Wheel Fault BladeR Framing System Rotation Fault
Gobo.R Gobo Rotation Fault R-OPEN Temp Disconnection Fault
Gobo2 Fixed Gobo Wheel Fault R-SHORT Temp Short Circuit Fault
Color Color Wheel Fault LED_HOT LED Overheat Fault
Iris IRIS Fault BladeR Framing System Rotation Fault
CYAN CMY Cyan Fault -- --
8
3
4
5
6
7
1
2

Page 17
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Keeping Your Torrent™ Keyframe 600 As Good As New
The xture you’ve received is a rugged, tough piece of pro lighting equipment,
and as long as you take care of it, it will take care of you. That said, you’ll need
to take care of it if you want it to operate as designed. You should keep the
xture clean, especially if you are using it in an environment with a lot of dust,
fog, haze, wild animals, wild teenagers or spilled drinks.
Cleaning the optics routinely with a suitable glass cleaner will greatly improve
the quality of light output. Keeping the fans free of dust and debris will keep the
xture running cool and prevent damage from overheating.
Use a new microber rag to gently clean your lenses (paper towels and cotton
towels will scratch them). To clean the fans, gently brush them with an eyelash
brush and vacuum up any leftover debris - and make sure to hold the fans so
they do not spin when vacuuming. *Do not use compressed air, this will push
the dirt further into your xture.
In transit, keep your xtures in cases. You wouldn’t throw a prized guitar,
drumset, or other piece of expensive gear into a gear trailer without a case, and
similarly, you shouldn’t even think about doing it with your shiny new xtures.
Returns (Gasp!)
We’ve taken a lot of precautions to make sure you never even have to worry
about sending a defective unit back, or sending a unit in for service. But,
like any complex piece of equipment designed and built by humans, once in a
while, something doesn’t go as planned. If you nd yourself with a xture that
isn’t behaving like a good little xture should, you’ll need to obtain a Return
Authorization (RA).
Don’t worry, this is easy. Just visit www.blizzardpro.com/support and open a
support ticket, and we’ll issue you an RA. Then, you’ll need to send the unit to
us using a trackable, pre-paid freight method. We suggest using USPS Priority
or UPS. Make sure you carefully pack the xture for transit, and whenever
possible, use the original box & packing for shipping.
When returning your xture for service, be sure to include the following:
1.) Your contact information (Name, Address, Phone Number, Email address).
2.) The RA# issued to you
3.) A brief description of the problem/symptoms.
We will, at our discretion, repair or replace the xture. Please remember
that any shipping damage which occurs in transit to us is the customer’s
responsibility, so pack it well!
Shipping Issues
Damage incurred in shipping is the responsibility of the shipper, and
must be reported to the carrier immediately upon receipt of the items.
Claims must be made within seven (7) days of receipt.
5. APPENDIX

Page 18
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Width 17.2 inches (435.5 mm)
Depth 11.6 inches (293 mm)
Height 29.7 inches (754 mm)
Weight 71.6 lbs. (32.5kg)
Power
Operating Voltage 100V-240VAC, 50-60Hz
Power Consumption 930W, 8.49A, PF: .99
Fuse 10A, 250V
Light Source
LED 600W white LED light source
Color Temperature 6500K
CRI Variable (71 ~ 91)
Optical
Beam Angle 7°- 40° beam angle
Gobo Size 27mm outer, 22mm inner, 1.2mm thickness
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Movement Range
Pan 540°, 360°, 180° (8-16 bit resolution)
Tilt 270°, 180°, 90° (8-16 bit resolution)
Control
Protocol USITT DMX-512, Art-Net, sACN, RDM
Modes/Personalities 36/52-channel modes
Data 3/5-pin XLR in/out, RJ45 in/out
Warranty
2-year limited warranty, does not cover malfunction caused by
damage to LEDs.
Troubleshooting
Symptom Solution
Fixture Auto-Shut O Check the fan in the xture. If it is stopped or moving slower
than normal, the unit may have shut itself o due to high heat.
This is to protect the xture from overheating. Clear the fan of
obstructions, or return the unit for service.
Beam is Dim Check optical system and clean excess dust/grime.
No Power Check fuse, AC cord and circuit for malfunction.
Blown Fuse Check AC cord and circuit for damage, verify that moving parts
are not restricted and that unit’s ventilation is not obstructed
Slow Movement Check that speed channels are set appropriately.
Fixture Not Respond-
ing / Responding
Erratically
Make sure all connectors are seated properly and securely.
Use Only DMX Cables.
Install a Terminator.
Check all cables for defects.
Reset xture(s).

Page 19
Torrent™ Keyframe 600 - Rev. A © 2021 Blizzard Lighting, LLC
Dimensional Drawings
Photometric Data
Beam 3m lux 3m fc 5m lux 5m fc 7m lux 7m fc 9m lux 9m fc
7° 84,545 7,854.5 29,165 2,709.6 14,705 1,366.2 8,564 795.7
40° 6,282 583.7 2,319 215.5 1,197 111.2 734 68.2
Luminous Intensity:
17.2" (435.5 mm)
29.7" (754 mm)
11.6" (293 mm)
Distance:
40°
7°
7° beam dia.
5m
2.1' (63 cm)
11.9' (360 cm)
7m
2.9' (89 cm)
16.6' (504 cm)
9m
2.9' (90 cm)
21.3' (648 cm)40° beam dia.
3m
1.3' (38 cm)
7.1' (216 cm)

Enjoy your product!
Our sincerest thanks for your purchase!
--The team @ Blizzard Lighting
