Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
TABLE OF CONTENTS
Motif™ Atelier 16FX 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4
2. Meet The Motif™ Atelier 16FX 5
Features 5
DMX Quick Reference 5
The Motif™ Atelier 16FX Pin-up Picture 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch Of Motif™ Atelier 16FX Fixtures 7
Data/DMX Cables 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
4. Operating Adjustments 10
Navigating The Control Panel 10
Control Panel Menu Structure 11
DMX Mode 12
Slave Mode 12
Dimming Mode Settings 12
LED Display Settings 12
Custom Programs 13
Auto Mode and Speed Settings 13
Color Calibration Settings 14
Custom Static Colors 14
Fixture Reset Functions 14
Data Sync Feature 15
Fixture ID Settings 15
Fixture Inormation 15
DMX Value In-Depth Reference Guide 16
 LEDPixelGroupCongurations    17
DMX In-Depth Reference 18
5. Appendix 20
A Quick DMX Lesson 20
Troubleshooting 20
Keeping Your Motif™ Atelier 16FX As Good As New 21
Returns (Gasp!) 21
Shipping Issues 21
Tech Specs 22
Dimensional Drawings 23

Page 3
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Motif™ Atelier 16FX LED Fixture
• An Ever-So-Handy Power Cord
• DMX Signal Cable
• This Lovely User Manual
Getting It Out Of The Box
Congratulations! You just purchased an awesome, most excellent linear LED wash
xturewith10-40°asymmetricallightingdistribution.Nowthatyou’vegotyourMotif™
Atelier (or hopefully, Ateliers!), you should carefully unpack the box and check the
contents to ensure that all parts are present and in good condition. If anything looks as
if it has been damaged in transit, notify the shipper immediately and keep the packing
materialforinspection.Again,pleasesavethecartonandallpackingmaterials.Ifax-
turemustbereturnedtothefactory,itisimportantthatthexturebereturnedinthe
original factory box and packing.
Powering Up!
Allxturesmustbepowereddirectlyoaswitchedcircuitandcannot be run o a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch -Notallxtureshaveavoltageselectswitch,sopleaseverifythat
thextureyoureceiveissuitableforyourlocalpowersupply.Seethelabelonthe
xtureorrefertothexture’sspecicationschartformoreinformation.Axture’s
listed current rating is its average current draw under normal conditions. Check the
xtureordevicecarefullytomakesurethatifavoltageselectionswitchexiststhatitis
set to the correct line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied
does not match the voltage indicated on the voltage selector switch. All
xtures must be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, please just visit our website at www.blizzardpro.com
and open a support ticket. We’ll be happy to help, honest.
Disclaimer:Theinformationandspecicationscontainedinthisdocumentaresubject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability
for any errors or omissions that may appear in this user manual. Blizzard Lighting™
reserves the right to update the existing document or to create a new document to
correct any errors or omissions at any time. You can download the latest version of this
document from www.blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 7/21/2018 J. Thomas 7/21/2018

Page 4
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Please read these instructions carefully. They include
important information about the installation, usage and
maintenance of this product.
SAFETY INSTRUCTIONS
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the de-
calorrearpanelofthexture.
•Makesuretherearenoammablematerialsclosetotheunitwhileoperating.
• The unit must be installed in a location with adequate ventilation, at least
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
•ALWAYSsecurextureusingasafetychain.NEVERcarrythexturebyits
head. Use its carrying handles.
•DONOToperateatambienttemperatureshigherthan104°F(40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized tech-
nical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! There are no user serviceable parts inside the unit. Do not
open the housing or attempt any repairs yourself. In the unlikely event
your unit may require service, please open a support ticket at www.
blizzardpro.com/support.

Page 5
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Ch. 72-Channel
1 Dimmer
2-65 Individual Pixel Control
66 Strobe
67 Eect
68 Speed
69 Virtual Color Wheel
70 Dimming Modes
71 ID Function
72 ID Address
Ch. 40-Channel
1 Dimmer
2-33 8 Pixel Groups (2x8)
34 Strobe
35 Eect
36 Speed
37 Virtual Color Wheel
38 Dimming Modes
39 ID Function
40 ID Address
Ch. 24-Channel
1 Dimmer
2-17 4 Pixel Groups (4x4)
18 Strobe
19 Eect
20 Speed
21 Virtual Color Wheel
22 Dimming Modes
23 ID Function
24 ID Address
Ch. 16-Channel
1 Dimmer
2-9 2 Pixel Groups (8x2)
10 Strobe
11 Eect
12 Speed
13 Virtual Color Wheel
14 Dimming Modes
15 ID Function
16 ID Address
2. MEET THE MOTIF™ ATELIER 16FX
MAIN FEATURES
• Color mixing via 16x 15W RGB+WW 4-in-1 LEDs
• 10-40°asymmetricalbeamspread
• IP65ratedoutdoorLEDxture
• Built-in color and pixel chase macros via DMX
• Virtualcolorwheeleect
• 33 built-in automated programs
• 10 custom color, and 3 custom program banks
• RGB+WW color mixing ability in standalone mode
• Custom global color calibration settings
• Variable electronic dimmer & strobe
• SynccustomsettingsbetweenxturesviaDMX
• Fixture ID addressing
• Easy to use LED control panel
• Durable cast aluminum housing
• Tempered glass lens and watertight internal gaskets
• IP rated power and 3-pin input/output connections
• Ecientconvectioncoolingforzerofannoise
• Mountingbracketwithlockingknobsforpositioningexibility
• Flicker-free constant-current LED driver
• IP rated 3-pin male input and 3-pin female output
• IP rated powerCON-compatible AC In/Out connections
Ch. 64-Channel
1-64 Individual Pixel Control
Ch. 10-Channel
1 Dimmer
2-5 Full Bar Color Mixing
6 Strobe
7Eect
8 Speed
9 Virtual Color Wheel
10 Dimming Modes
Ch. 5-Channel
1 Dimmer
2-5 Full Bar Color Mixing
Ch. 4-Channel
1-4 Full Bar Color Mixing
DMX Quick Reference (4/5/10/16/24/40/72-Channel Modes)

Page 6
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Figure 1: The Motif™ Atelier 16FX Pin-Up Picture
Mounting Bracket with
Adjustment / Locking Knobs
Power Output
Figure 2: The Rear Connections
16x 15W RGB+WW
4-in-1 LEDs
LED Control Panel
Tempered Glass Lens
DMX Output
Power Input
DMX Input

Page 7
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
3. SETUP
Fuse Replacement
CAUTION! The Motif™ Atelier 16FX utilizes a high-output switch-mode power
supply with an internal fuse. Under normal operating conditions, the fuse
shouldnotrequirereplacement.Thefuseiseldreplaceable,howeveritisan
advancedproceduresuitedtoqualiedindividuals.ShouldyourMotif™Atelier
16FX fuse require replacement, please contact Blizzard Lighting for instruc-
tions, or to return your unit for service.
Connecting A Bunch of Motif™ Atelier 16FX Fixtures
You will need a serial data link to run light shows using a DMX-512 controller
ortorunshowsontwoormorexturessettosyncinmaster/slaveoperating
mode.Thecombinednumberofchannelsrequiredbyallthexturesonaserial
datalinkdeterminesthenumberofxturesthedatalinkcansupport.
Fixtures on a serial data link must be daisy chained in one single line. Also, con-
nectingmorethan32xturesononeserialdatalinkwithouttheuseofaDMX
optically-isolated splitter may result in deterioration of the digital DMX signal.
The maximum recommended cable-run distance is 500 meters (1640 ft). The
maximumrecommendednumberofxturesonaserialdatalinkis32xtures.
Data/DMX Cabling
Tolinkxturestogetheryou’llneeddatacables.Youshouldusedata-grade
cables that can carry a high quality signal and are less prone to electromagnetic
interference.
Forinstance,Belden©9841meetsthespecicationsforEIARS-485applica-
tions. Standard microphone cables will “probably” be OK, but note that they
cannot transmit DMX data as reliably over long distances. In any event, the
cable should have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor & shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms
Please read these instructions carefully. They include
important information about the installation, usage and
maintenance of this product.

Page 8
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Cable Connectors
Cables must have a male XLR connector on one end and a female XLR connec-
tor on the other end. (Duh!)
CAUTION: Do not allow contact between the common and the
xture’schassisground.Groundingthecommoncancauseaground
loop,andyourxturemayperformerratically.Testcableswithan
ohm meter to verify correct polarity and to make sure the pins are not
grounded or shorted to the shield or each other.
3-Pin??? 5-Pin??? Huh?!?
If you use a controller with a 5-pin DMX output connector, it’s no problem! You can simply use the in-
stalled5-pinDMXinputand/oroutputconnectionsfoundonthebackofyourxture(s).
Conductor 3-Pin Female (Output) 5-Pin Male (Input)
Ground/Shield Pin 1 Pin 1
Data 1- (Primary Data Link) Pin 2 Pin 2
Data 1+ (Primary Data Link) Pin 3 Pin 3
Data 2- (Optional Secondary Data Link) Pin 4 Pin 4
Data 2+ (Optional Secondary Data Link) Pin 5 Pin 5
Take It To The Next Level: Setting Up DMX Control
Step 1: Connect the male connector of the
DMX cable to the female connector (output)
on the controller.
Step 2: Connect the female connector of
theDMXcabletotherstxture’smale
connector (input). Note: It doesn’t matter
whichxtureaddressistherstone
connected. We recommend connecting the
xturesintermsoftheirproximitytothe
controller, rather than connecting the lowest
xturenumberrst,andsoon.
Step 3:Connectotherxturesinthechain
from output to input as above. Place a DMX
terminatorontheoutputofthenalxture
to ensure best communication.

Page 9
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Fixture Linking (Master/Slave Mode)
1. Connect the (male) 3-pin connector side of the
DMX cable to the output (female) 3-pin connector of
therstxture.
2. Connect the end of the cable coming from
therstxturewhichwillhavea(female)3-pin
connectortotheinputconnectorofthenextxture
consisting of a (male) 3-pin connector. Then,
proceed to connect from the output as stated above
totheinputofthefollowingxtureandsoon.
A quick note: Often,
the setup for Master-
Slave and Standalone
operation requires that
therstxtureinthe
chain be initialized for
this purpose via either
settings in the control
panel or DIP-switches.
Secondarily,thextures
that follow may also
require a slave setting.
Check the “Operating Adjustments” section in this manual for com-
pleteinstructionsforthistypeofsetupandconguration.
Mounting & Rigging
ThisxturemaybemountedinanySAFEpositionprovidedthereis
enough room for ventilation.
It is important never to obstruct the fan or vents pathway. Mount the
xtureusingasuitable“C”or“O”typeclamp.Theclampshouldbe
ratedtoholdatleast10xthexture’sweighttoensurestructuralsta-
bility. Do not mount to surfaces with unknown strength, and ensure
properly“rated”riggingisusedwhenmountingxturesoverhead.
Adjusttheangleofthexturebylooseningbothknobsandtiltingthe
xture.Afterndingthedesiredposition,retightenbothknobs.
• When selecting installation location, take into consideration lamp
replacement access (if applicable) and routine maintenance.
• Safety cables MUST ALWAYS be used.
•Nevermountinplaceswherethexturewillbeexposedtorain,
high humidity, extreme temperature changes or restricted ventilation.

Page 10
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
AllthegoodiesanddierentmodespossiblewiththeMotif™Atelier16FXare
accessedbyusingthecontrolpanelontherearofthexture.Thereare4
control buttons below the LED display which allow you to navigate through the
various control panel menus.
<MENU>
Is used to navigate to the previous higher-level menu item.
<UP>
Scrolls through menu items and numbers in ascending order.
<DOWN>
Scrolls through menu items and numbers in descending order.
<ENTER>
Isusedtoselectandconrm/storethecurrentselection.
The control panel LED display shows the menu items you select from the menu
map on page #11. When a menu function is selected, the display will show im-
mediatelytherstavailableoptionfortheselectedmenufunction.Toselecta
menu item, press <ENTER>.
Press the <MENU> button repeatedly until you reach the desired menu func-
tion. Use the <UP> and <DOWN> buttons to navigate the menu options.
Press the <ENTER> button to select the menu function currently displayed,
or to enable a menu option. To return to the previous option or menu without
changing the value, press the <MENU> button.
MENU ENTER
UP DOWN

Page 11
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Control Panel Menu Structure
ADDR 001-512 To choose the DMX address
STAT R1 Red intensity - Group 1 (0% <--> 100%)
G1 Green intensity - Group 1 (0% <--> 100%)
B1 Blue intensity - Group 1 (0% <--> 100%)
W1 Warm white intensity - Group 1 (0% <--> 100%)
R2 Red intensity - Group 2 (0% <--> 100%)
G2 Green intensity - Group 2 (0% <--> 100%)
B2 Blue intensity - Group 2 (0% <--> 100%)
W2 Warm white intensity - Group 2 (0% <--> 100%)
SHUT Flash / strobe speed (0-255)
SET CAL To set global intensity levels of each color + USE: YES/NO
CHMD 72CH To run in 72-channel mode
64CH To run in 64-channel mode
40CH To run in 40-channel mode
24CH To run in 24-channel mode
16CH To run in 16-channel mode
10CH To run in 10-channel mode
5CH To run in 5-channel mode
4CH To run in 4-channel mode
DIM
(dimming)
LIN Linear dimming curve
SQR Square law curve
ISQR Inverse square law curve
SCUR S-curve
LIN. Linear dimming curve (smooth)
SQR. Square law curve (smooth)
ISQR. Inverse square law curve (smooth)
SCUR. S-curve (smooth)
DISY
(display)
ON LED menu display is on continually
2MIN LEDmenudisplayshutsoafter2minutesofinactivity.Tounlock,
press the buttons in this order: <MENU>, <UP>, <DOWN>,
<ENTER> 3x times in a row with no longer than 2 seconds between
each button press.
CTST CT01-CT10 <ENTER> R/G/B/W adjustments for custom color banks 01-10
AUTO AT01-AT33 <ENTER> Auto programs 1-33
ATSP
(speed)
<ENTER> Auto Speed
CHS1 <ENTER> Custom program 1
CHS2 <ENTER> Custom program 2
CHS3 <ENTER> Custom program 3
PROG CHS1-
CHS3
Custom
programs
1-3.
SC01-
SC20
20 scenes
for each
custom
program.
R1 (0-255) R2 (0-255) AUTO (None, AT01-AT05)
G1 (0-255) G2 (0-255) ATSP (speed, 0-255)
B1 (0-255) B2 (0-255) TIME (duration, 0-255)
W1 (0-255) W2 (0-255) WAIT (before fade, 0-255)
SHUT (strobe, 0-255) USE (use scene, YES/NO)
INFO SOFT Software version information
TEMP Current automated overheat protection level (100%/80%/50%)
POW Current temperature (C) of the LED board
LOAD ST L Restore factory settings
PR L Restore factory program settings
SEND YES/NO SyncsettingsbetweenxturesviaDMX
ID 0-255 Fixture ID

Page 12
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
Setting the DMX Address:
1.)ThedefaultmodeforthextureisDMX,whichappearsas001 on the LED readout. To
selectadierentDMXaddress,usingthe<MENU> button, select ADDR, then hit <ENTER>.
Use the <UP/DOWN> buttons to select the correct address, then hit <ENTER>toconrm.
Setting the DMX Channel Mode:
1.) To select a DMX channel mode, press the <MENU> button, then use the <UP/DOWN>
buttons until the display reads SET and press the <ENTER> button. Then use the <UP/
DOWN> buttons until the display reaches CHMD, and press <ENTER>. Now press the <UP/
DOWN> buttons again to highlight your desired DMX channel mode, and press the <ENTER>
buttontoconrm.
Slave Mode:
1.)DaisychainthexturesDMXin/out,havingthecontrolleratthebeginningoftheline.
2.)Thereisnothingelsetoit!TherstxtureintheDMXchainisthemasterxture,andthe
followingxtureswillfollowthemaster.
Dimming Mode Settings:
Allows users to set the xture to use 1 of 4 (x2) dimming curve settings for smoother (and slower)
dimming capabilities. In the control panel menu, there are two settings for each curve that are
distinguishable from one another by the trailing dot.
*The curve settings with the trailing dot adds a bit more delay to the curve for a smoother eect.
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to SET and press <ENTER>,
then <UP/DOWN> buttons again to scroll to DIM, and press the <ENTER> button.
2.) Now use the <UP/DOWN> buttons to highlight either LIN (Linear), SQR (Square), ISQR
(Inverse Square), SCUR (S-Curve), LIN. (Smooth Linear), SQR. (Smooth Square), ISQR.
(Smooth Inverse Square), or SCUR. (Smooth S-Curve), then hit <ENTER>.
LED Display Setting:
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to SET and press <ENTER>,
then navigate to DISY (display). Press the <ENTER> button.
2.) In DISY,youcansettheLEDmenudisplaytobecontinuallyon,orautomaticallyshuto
after 2 min of inactivity.
DMX% DMX% DMX% DMX%
Output Output Output Output
(LIN, LIN.) (SQR, SQR.) (ISQR, ISQR.) (SCUR, SCUR.)
Linear Curve Square Law Inverse Square Law S-Curve

Page 13
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Custom Programs:
Allows users to create up to 3 customizable, 20 scene programs that are directly accessible via the control
panel and also in DMX mode.
Creating A Custom Program:
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to PROG, and press <ENTER>.
2.) Now use the <UP/DOWN> buttons to highlight your choice of either CHS1, CHS2, or
CHS3 and press <ENTER>.
3.) Start with editing scene 1 (SC01), customizing it to your liking by using the choices outlined
in the table below. You can insert any of its 33 built-in auto programs (AT01-AT33), and adjust
its speed (ATSP 0-255), and also set the duration (in seconds) before moving on to the next
scene (TIME 0-255). Or, you can create a custom scene by color mixing any (or all) of the 3
pixelgroups,thenaddinafadeineect(WAIT 0-255), and/or strobe (SHUT 0-255). Finally,
if you want to use this scene in your program, be sure to enable it (USE: YES/NO).
4.) Repeat the above process to create up to 20 scenes in each of the 3 customizable programs.
R1 / R2 (0-255) - Red Intensity AUTO (AT01-AT05) - Auto Programs
IMPORTANT:
If USE is set to NO, or TIME is set
to 0, the scene will not run!
G1 / G2 (0-255) - Green Intensity ATSP (0-255) - Auto Speed (fast - slow)
B1 / B2 (0-255) - Blue Intensity TIME (0-255) - Scene Time (seconds)
W1 / W2 (0-255) - WW Intensity WAIT (0-255) - Fade In (fast - slow)
SHUT (0-255) - Strobe (slow - fast) USE (YES/NO) Use Scene in Program?
Running A Custom Program:
1.) To view your newly created lighting masterpiece, use the <MENU> and <UP/DOWN>
buttons to navigate to AUTO, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to highlight your choice of either CHS1, CHS2, or CHS3 and
press <ENTER>. These are also directly accessible from the Eect Channel in DMX mode.
Auto Mode and Speed Settings:
Set single or Master/Slaved units to run automated programs at user selectable speeds.
Auto Mode:
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to navigate to AUTO, and press
the <ENTER> button.
2.) Now use the <UP/DOWN> buttons to highlight any program ranging from AT01-AT33,
and press <ENTER>.
Auto Speed:
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to AUTO and press <ENTER>,
then with the <UP/DOWN> buttons navigate to ATSP, and press the <ENTER> button.
2.) Make a selection from 0-255, and press <ENTER> to choose a speed (slow <--> fast).

Page 14
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Color Calibration Settings:
Allows the user to setup and save 1 customized R/G/B/WW color balance setting and save it for future use.
This custom setting is global, and it will eect all modes.
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to SET and press <ENTER>,
then on while CAL, push <ENTER> again.
2.) Use the <UP/DOWN> buttons to highlight either R(Red), G(Green), B(Blue), or W
(Warm White), then hit <ENTER>.
3.) Now using the <UP/DOWN> buttons, select the maximum level for each color between
000-255(000=o),andhit<ENTER>toconrmyourchoice.
4.) You have now just setup and saved a custom global color calibration setting that you can use
at you convenience. To use your custom setting now (or later), press the <UP/DOWN> buttons
to reach USE, and press <ENTER>. Then choose either YES or NO and press <ENTER>. When
you select YES, it enables this custom color calibration globally, and when choosing NO the
xturewillcontinuetousethedefaultcolorcalibrationsettings.Yourcustomizedsettingswill
besavedforlateruseevenafterpoweringothexture.Itcanbealteredtoyourlikingatany
time. Just remember to return to this setting to either enable or disable it when needed.
Custom Static Colors:
Allows the user to create and save up to 10 custom static colors for use in standalone or DMX mode.
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to CTST and press <ENTER>,
then <UP/DOWN> buttons to select a color bank from CT01-CT10, and push <ENTER> to
conrmyourselection.
2.) Now use the <UP/DOWN> buttons to highlight either R(Red), G(Green), B(Blue), or W
(Warm White), then hit <ENTER>.
3.) Finally, using the <UP/DOWN> buttons, select the maximum level for each color between
000-255(000=o),andhit<ENTER>toconrmyourchoice(s).
4.) These 10 custom colors can be accessed and edited to your liking at any time, and will be
savedevenafterpoweringothexture.
5.) These static colors are directly accessible from the Eect Channel in DMX mode.
Fixture Reset Functions:
Allows users to reset the xture to factory default settings, without loosing customized settings, or reset
the custom programs exclusively.
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to LOAD and press <ENTER>,
then use the <UP/DOWN> buttons to highlight ST L or PR L, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to highlight either YES or NO, then press <ENTER>.
3.) The ST L reset function will reset all default values with the exception of those in ADDR
(address), CTST (10 custom colors), and PROG (custom scenes and programs).
4.) The PR L reset function will only reset all customized program settings found in the PROG
settings (custom scenes and programs).

Page 15
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
Data Sync Feature:
Users can transfer their custom settings from one xture to another via DMX.
1.)DisconnectxturesfromanyDMXcontrollers,andlinkthemtogetherviaDMXin/out.
2.)Onthesendingxture(DMXout),navigatethemainmenuusingthe<UP/DOWN> buttons
to reach SEND, and press the <ENTER> button.
3.) Select YES, and press the <ENTER> button to begin the transfer.
4.) Information for ADDR (address), CAL (global intensity), or ID (Fixture ID) will not be sent.
5.)Afterthedatahasbeentransferred,thereceivingxturewillbeautomaticallybereset.
Fixture ID Settings:
ID settings give you the ability to assign ID numbers to individual or groups of xtures for quick and easy
DMX control access. This is available in 72/40/24 and 16-channel DMX modes.
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to ID and press <ENTER>.
2.) Now use the <UP/DOWN> buttons to select any ID value you would like to assign to this
xture,andpressthe<ENTER> button to save it.
3.)WhileusingaDMXchannelmodewherextureIDcontrolavailable,youcannowsettheID
Function Slider to a value ranging from 010-020 for “1 ID control per each 1 digit”, ex. 21 =
ID21, 22=ID22, or you can set the ID FUNCTION slider to a value ranging from 021-030 for
“1 ID control per each 10 digit” functionality, ex. 010 <--> 019 = ID1, etc.
4.) Now use the ID Address SlideronyourcontrollertoselectthextureIDnumber(orID
range) setup in steps 1 & 2, while keeping in mind the function method you selected in step 3.
5.)YoushouldnowhaveDMXcontrolofanyxtureswiththisID.
Fixture Information:
These are not editable features, they are for informational purposes only.
1.) Use the <MENU> and <UP/DOWN> buttons to navigate to INFO and press <ENTER>,
then use the <UP/DOWN> buttons to highlight SOFT, TEMP, or POW, and press <ENTER>.
2.) The SOFTinformationdisplaysthecurrentsoftwareversioninstalledonthexture,TEMP
displays the temperature (C) of the LED board, and POWdisplaysthexturescurrentpower
levelsetting.Normally,itwillbeat100%...butthisxturehasbuilt-inoverheatprotectionthat
may automatically reduce the output level to 80%, or 50% in high temperature situations.

Page 16
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
DMX Value In-Depth Reference Guide
Function Value What It Does
Dimmer 000 <--> 255 (0% <--> 100%)
Red Intensity 000 <--> 255 (0% <--> 100%)
Green Intensity 000 <--> 255 (0% <--> 100%)
Blue Intensity 000 <--> 255 (0% <--> 100%)
Warm White Intensity 000 <--> 255 (0% <--> 100%)
Strobe 000 <--> 005
006 <--> 020
021 <--> 060
061 <--> 100
101 <--> 140
141 <--> 180
181 <--> 220
221 <--> 255
No strobe
Non-synchronous strobe (slow <--> fast)
Synchronous strobe (slow <--> fast)
Electronic sine wave (slow <--> fast)
Random strobe (slow <--> fast)
Opening pulse (slow <--> fast)
Closing pulse (slow <--> fast)
Electronic square wave (slow <--> fast)
Eect 000 <--> 005
006 <--> 010
011 <--> 015
016 <--> 020
021 <--> 025
026 <--> 030
031 <--> 035
036 <--> 040
041 <--> 045
046 <--> 050
051 <--> 055
056 <--> 060
061 <--> 065
066 <--> 070
071 <--> 075
076 <--> 080
081 <--> 085
086 <--> 090
091 <--> 095
096 <--> 100
101 <--> 105
106 <--> 110
111 <--> 115
116 <--> 120
121 <--> 125
126 <--> 130
131 <--> 135
136 <--> 140
141 <--> 145
146 <--> 150
151 <--> 155
156 <--> 160
161 <--> 165
166 <--> 170
171 <--> 175
176 <--> 180
181 <--> 185
186 <--> 190
191 <--> 195
196 <--> 200
201 <--> 205
206 <--> 210
211 <--> 215
216 <--> 220
221 <--> 225
226 <--> 230
231 <--> 235
236 <--> 255
No Function
Custom color 1 (CT01 in menu settings)
Custom color 2 (CT02 in menu settings)
Custom color 3 (CT03 in menu settings)
Custom color 4 (CT04 in menu settings)
Custom color 5 (CT05 in menu settings)
Custom color 6 (CT06 in menu settings)
Custom color 7 (CT07 in menu settings)
Custom color 8 (CT08 in menu settings)
Custom color 9 (CT09 in menu settings)
Custom color 10 (CT10 in menu settings)
Auto 1 - R, G, B, W, RG, RB, GB, RGBW
Auto 2 - R↑, R↓, G↑, G↓, B↑, B↓, W↑, W↓
Auto 3 - R↑G↑, R↓G↓, R↑B↑, R↓B↓, B↑G↑, B↓G↓
Auto 4 - R↑G↑B↑W↑, R↓G↓B↓W↓
Auto 5 - B, BG↑, BG, B↓G, G, GR↑, GR, G↓R, R, RB↑, RB, R↓B
Auto 6 - 1 to 16 pixel chase, then color change
Auto 7 - RGBY step running
Auto 8 - 4Y running with fade
Auto 9 - 4P step running
Auto 10 - 4R running on G
Auto 11 - 4G running on B
Auto 12 - 4Y running on P
Auto 13 - 4R step running
Auto 14 - 4C step running
Auto 15 - 6Y running with fade
Auto 16 - 6P running with fade
Auto 17 - Y open from 1-16 then dark
Auto 18 - B open from 1-16 then dark
Auto 19 - Each piece change with RGBYPC
Auto 20 - Inverse direction of AUTO 6
Auto 21 - Inverse direction AUTO 7
Auto 22 - 4P running with fade
Auto 23 - Inverse direction AUTO 9
Auto 24 - Inverse direction AUTO 10
Auto 25 - Inverse direction AUTO 11
Auto 26 - Inverse direction AUTO 12
Auto 27 - Inverse direction AUTO 13
Auto 28 - Inverse direction AUTO 14
Auto 29 - 4R running with fade
Auto 30 - 4B running with fade
Auto 31 - Inverse direction AUTO 17
Auto 32 - Inverse direction AUTO 18
Auto33-Eachpiecerainboweect
Custom program 1 (CH01 in menu settings)
Custom program 2 (CH02 in menu settings)
Custom program 3 (CH03 in menu settings)
No Function

Page 17
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
DMX Value In-Depth Reference Guide (continued)
Function Value What It Does
Auto Speed 000 <--> 255 (fast <--> slow)
Virtual Color Wheel 000 <--> 010
011
012 <--> 050
051
052 <--> 090
091
092 <--> 130
131
132 <--> 170
171
172 <--> 210
211
212 <--> 250
251 <--> 255
No Function
Blue
Blue (+ green)
Teal
Teal (- blue)
Green
Green (+ red)
Yellow
Yellow (- green)
Red
Red (+ blue)
Magenta
Magenta (- red)
Blue
Dimming Mode 000 <--> 010
011 <--> 020
021 <--> 030
031 <--> 040
041 <--> 050
051 <--> 060
061 <--> 070
071 <--> 080
081 <--> 090
091 <--> 255
Default (as set in the LED menu)
Linear curve
Square law curve
Inverse square law curve
S-curve
Linear curve (smooth)
Square law curve (smooth)
Inverse square law curve (smooth)
S-curve (smooth)
Default (as set in the LED menu)
ID Function 000 <--> 010
010 <--> 020
021 <--> 030
031 <--> 255
No Function
1 ID per each 1, ex. 210 = ID21, 211=ID22
1 ID per each 10, ex. 010 <--> 019 = ID1
No function
ID Address 000 <--> 255 Controlxture(s)IDnumber0-255
72ch/64ch
40ch
24ch
16ch
10ch/5ch/4ch
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1122334455
1 1
6 6 7 7 8 8
11222233334444
1111111122222222
1111111111111111
LED Pixel Group Congurations
Belowareillustrationsofthextures5dierentpixelgroupcongurations.

Page 18
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
DMX In-Depth Reference: 72-Channel Mode
Ch. Name Ch. Name Ch. Name Ch. Name
1 Dimmer 19 Green 5 37 Warm White 9 55 Green 14
2 Red 1 20 Blue 5 38 Red 10 56 Blue 14
3 Green 1 21 Warm White 5 39 Green 10 57 Warm White 14
4 Blue 1 22 Red 6 40 Blue 10 58 Red 15
5 Warm White 1 23 Green 6 41 Warm White 10 59 Green 15
6 Red 2 24 Blue 6 42 Red 11 60 Blue 15
7 Green 2 25 Warm White 6 43 Green 11 61 Warm White 15
8 Blue 2 26 Red 7 44 Blue 11 62 Red 16
9 Warm White 2 27 Green 7 45 Warm White 11 63 Green 16
10 Red 3 28 Blue 7 46 Red 12 64 Blue 16
11 Green 3 29 Warm White 7 47 Green 12 65 Warm White 16
12 Blue 3 30 Red 8 48 Blue 12 66 Strobe
13 Warm White 3 31 Green 8 49 Warm White 12 67 Eect
14 Red 4 32 Blue 8 50 Red 13 68 Speed
15 Green 4 33 Warm White 8 51 Green 13 69 Virtual Color Wheel
16 Blue 4 34 Red 9 52 Blue 13 70 Dimming Mode
17 Warm White 4 35 Green 9 53 Warm White 13 71 ID Function
18 Red 5 36 Blue 9 54 Red 14 72 ID Address
DMX In-Depth Reference: 64-Channel Mode
Ch. Name Ch. Name Ch. Name Ch. Name
1 Red 1 17 Red 5 33 Red 9 49 Red 13
2 Green 1 18 Green 5 34 Green 9 50 Green 13
3 Blue 1 19 Blue 5 35 Blue 9 51 Blue 13
4 Warm White 1 20 Warm White 5 36 Warm White 9 52 Warm White 13
5 Red 2 21 Red 6 37 Red 10 53 Red 14
6 Green 2 22 Green 6 38 Green 10 54 Green 14
7 Blue 2 23 Blue 6 39 Blue 10 55 Blue 14
8 Warm White 2 24 Warm White 6 40 Warm White 10 56 Warm White 14
9 Red 3 25 Red 7 41 Red 11 57 Red 15
10 Green 3 26 Green 7 42 Green 11 58 Green 15
11 Blue 3 27 Blue 7 43 Blue 11 59 Blue 15
12 Warm White 3 28 Warm White 7 44 Warm White 11 60 Warm White 15
13 Red 4 29 Red 8 45 Red 12 61 Red 16
14 Green 4 30 Green 8 46 Green 12 62 Green 16
15 Blue 4 31 Blue 8 47 Blue 12 63 Blue 16
16 Warm White 4 32 Warm White 8 48 Warm White 12 64 Warm White 16

Page 19
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
DMX In-Depth Reference: 40-Channel Mode
Ch. Name Ch. Name Ch. Name Ch. Name
1 Dimmer 11 Green 3 21 Warm White 5 31 Green 8
2 Red 1 12 Blue 3 22 Red 6 32 Blue 8
3 Green 1 13 Warm White 3 23 Green 6 33 Warm White 8
4 Blue 1 14 Red 4 24 Blue 6 34 Strobe
5 Warm White 1 15 Green 4 25 Warm White 6 35 Eect
6 Red 2 16 Blue 4 26 Red 7 36 Speed
7 Green 2 17 Warm White 4 27 Green 7 37 Virtual Color Wheel
8 Blue 2 18 Red 5 28 Blue 7 38 Dimming Mode
9 Warm White 2 19 Green 5 29 Warm White 7 39 ID Function
10 Red 3 20 Blue 5 30 Red 8 40 ID Address
DMX In-Depth Reference: 24-Channel Mode
Ch. Name Ch. Name Ch. Name Ch. Name
1 Dimmer 7 Green 2 13 Warm White 3 19 Eect
2 Red 1 8 Blue 2 14 Red 4 20 Speed
3 Green 1 9 Warm White 2 15 Green 4 21 Virtual Color Wheel
4 Blue 1 10 Red 3 16 Blue 4 22 Dimming Mode
5 Warm White 1 11 Green 3 17 Warm White 4 23 ID Function
6 Red 2 12 Blue 3 18 Strobe 24 ID Address
DMX In-Depth Reference: 10-Channel Mode
Ch. Name Ch. Name Ch. Name Ch. Name
1 Dimmer 4 Blue 1 7 Eect 10 Dimming Mode
2 Red 1 5 Warm White 1 8 Speed
3 Green 1 6 Strobe 9 Virtual Color Wheel
DMX In-Depth Reference: 5-Channel Mode
Ch. Name Ch. Name Ch. Name
1 Dimmer 3 Green 1 5 White 1
2 Red 1 4 Blue 1
DMX In-Depth Reference: 4-Channel Mode
Ch. Name Ch. Name
1Red 1 3 Blue 1
2Green 1 4 Warm White 1

Page 20
Motif™ Atelier 16FX User Manual Rev. A Copyright © 2018 Blizzard Lighting, LLC
5. APPENDIX
A Quick Lesson On DMX
DMX (aka DMX-512) was created in 1986 by the United States Institute for Theatre
Technology (USITT) as a standardized method for connecting lighting consoles to lighting
dimmermodules.Itwasrevisedin1990andagainin2000toallowmoreexibility.The
Entertainment Services and Technology Association (ESTA) has since assumed control over
the DMX512 standard. It has also been approved and recognized for ANSI standard clas-
sication.
DMX covers (and is an abbreviation for) Digital MultipleXed signals. It is the most common
communications standard used by lighting and related stage equipment.
DMX provides up to 512 control “channels” per data link. Each of these channels was origi-
nally intended to control lamp dimmer levels. You can think of it as 512 faders on a lighting
console, connected to 512 light bulbs. Each slider’s position is sent over the data link as an
8-bit number having a value between 0 and 255. The value 0 corresponds to the light bulb
beingcompletelyowhile255correspondstothelightbulbbeingfullyon.
DMX data is transmitted at 250,000 bits per second using the RS-485 transmission stan-
dard over two wires. As with microphone cables, a grounded cable shield is used to prevent
interference with other signals.
TherearevepinsonaDMXconnector:awireforground(cableshield),twowiresfor
“Primary” communication which goes from a DMX source to a DMX receiver, and two wires
for a “Secondary” communication which goes from a DMX receiver back to a DMX source.
Generally,the“Secondary”channelisnotusedsodataowsonlyfromsourcestoreceiv-
ers. Hence, most of us are most familiar with DMX-512 as being employer over typical
3-pin“miccables,”althoughthisdoesnotconformtothedenedstandard.
DMXisconnectedusingadaisy-chaincongurationwherethesourceconnectstotheinput
oftherstdevice,theoutputoftherstdeviceconnectstotheinputofthenextdevice,
and so on. The standard allows for up to 32 devices on a single DMX link.
Troubleshooting
Symptom Solution
FixtureAuto-ShutO If it is stopped or running slower than normal, the unit may have
shutitselfoduetohighheat.Thisistoprotectthexture
from overheating.
No Light Output Checktoensurextureisoperatingundercorrectmode,IE
auto/DMX/Etc., if applicable.
Chase Speed Too
Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power Check AC cord and circuit for malfunction.
Fixture Not Respond-
ing / Responding
Erratically
Make sure all connectors are seated properly and securely.
Use Only DMX Cables and/or check cables for defects
Install a Terminator.
Resetxture(s).
