Blodgett MT3255G User manual

BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05402 • Phone: [phone] • Fax: [phone]
EXTERIOR CONSTRUCTION
Stainless steel front, top and sides
Aluminized steel back and bottom
Side loading glass door and handle
1-1/2" (38.1mm) Vitreous fiber insulation at bottom, back and top
Ceramic fiber insulation at blower installation and front control panel
INTERIOR CONSTRUCTION
Aluminized steel nozzles and bottom surface
Aluminized steel air flow plates at top
32" (813mm) stainless steel wire mesh conveyor belt
Three single inlet blowers above the combustion area for air circulation
OPERATION
Heat transferred through forced convection/impingement
Open vented baking compartment
Electronic spark ignition control system
Gas power type burner has mixer with adjustable shutter and sight window
Internal gas pressure regulator
Solid state 600°F (315.5°C) maximum thermostat and belt speed control with
digital display
Three blower motors (1/3 HP minimum) with thermal overload protectors
Four blower area cooling fans
Two control area cooling fans
STANDARD FEATURES
Control: Solid state front mounted
Belt direction: (must specify)
left to right right to left
Product stops
Oven start-up
One year parts & labor warranty*
* For all international markets, contact your local distributor.
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Legs/casters:
17-1/4" (438mm) black legs with casters
23-1/4" (591mm) black legs with casters
Triple stack base with casters
Shelf extension:
15" (381mm)
20" (508mm)
Flexible gas hose with quick disconnect and
restraining device:
36" (914mm)
48" (1219mm)
Note: Two 48" (1219mm) and one 36" (914mm)
hose on triple model
Twin belt - two 16" (406mm) wide belts
10' (3.0M) cord with receptacle
Stacking rail
One year additional extended warranty
MODEL MT3255G
Gas Conveyor Oven
MT3255G
Project
Item No.
Quantity
Blodgett conveyor oven with 32" (813mm) wide belt and 55" (1397mm)
baking zone length. Single, double or triple stack models are available.
All data is shown per oven section, unless otherwise indicated.

BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05402 • Phone: [phone] • Fax: [phone]
MODEL MT3255G
SHORT FORM SPECIFICATIONS
Provide Blodgett Conveyor Oven model MT3255G conveyor oven. Unit shall be gas fired and shall cook by means of forced, heated air/impingement. Unit shall be (single/double/triple)
deck supported by (specify stand type from options list) . Each deck shall be fully independent, of stainless steel construction, and fully insulated on all sides. Provide with electronic
spark ignition gas fired baking compartment with three blowers to evenly distribute heat across baking zone. Conveyor belt shall be 32" (815mm) wide and constructed of stainless steel
wire mesh; baking zone length shall be 55" (1395mm). Unit shall be provided with stainless steel side loading door fitted with tempered glass view port. Front mounted control panel
shall be solid state with 600°F (315.5°C) maximum thermostat and digital display of adjustable belt speed. Provide start-up inspection service by a factory authorized service agent.
Provide options and accessories as indicated.
DIMENSIONS:
Floor space 62" (1575mm) W x 91" (2311mm) L
Product clearance 3.5" (90mm)
Combustible wall clearance 2" (50mm)
Belt width
Standard belt 32" (815mm)
Optional twin belt 16" (405mm) each
Baking zone length 55" (1395mm)
GAS SUPPLY: (specify) Natural Propane
Single 3/4" NPT 3/4" NPT
Double stack 1" NPT 3/4" NPT
Triple stack 1-1/4" NPT 1" NPT
MAXIMUM INPUT:
Single 125,000 BTU/hr
Double 250,000 BTU/hr
Triple 375,000 BTU/hr
Minimum Gas Pressure: 4.5" W.C. for natural gas
11.0" W.C. for propane gas
Maximum Gas Pressure: 10.5" W.C. for natural gas
13" W.C. for propane gas
POWER SUPPLY:
Domestic Model:
120/208-240 VAC, 1 Phase, 60 Hz., 7 amp, 3 wire with
Ground
Export Model:
220-240, 1 phase, 50 Hz., 7 amp, 2 wire with Ground
MINIMUM ENTRY CLEARANCE:
Uncrated 24.2" (615mm)
Crated 32" (813mm)
SHIPPING INFORMATION:
Approx. Weight: Crated Uncrated
Single 1120 lbs. (510 kg) 1021 lbs. (463 kg)
Double 2930 lbs. (1060 kg) 2042 lbs. (926 kg)
Triple 3600 lbs. (1640 kg) 3063 lbs. (1389 kg)
Crate sizes:
32" (813mm) x 70" ( 1778mm) x 105" (2667mm)
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitu-
tions of components without prior notice
TOP VIEW
*58” (1473mm) without false front
91” (2310mm)
55” (1395mm)
18”
(455mm)
GAS
INPUT
32”
(815mm)
61”*
(1550mm)
END VIEW
3.5” (90mm)
PRODUCT CLEARANCE
3/4” NPT
GAS INPUT
48” (1219mm)
or 36” (914mm)
flexible gas hose available
SIDE VIEW
0” (0mm)
23.5” (595mm)
36.5” (925mm)
47.7” (1210mm)
0” (0mm)
17.5” (445mm)
SIDE VIEW
30.5” (775mm)
41.7” (1060mm)
54.5” (1385mm)
66” (1675mm)
SIDE VIEW 0” (0mm)
1.7” (45mm)
14.7” (375mm)
26” (660mm)
39” (990mm)
50” (1275mm)
63” (1600mm)
74.3” (1885mm
