Blomberg LRF2854121G User manual

LRF2854121G
Washer-Dryer
User manual

Please read these instructions
first before using your appliance
Dear Customer,
Thank you for choosing a Blomberg appliance.
Please take some time to read this user
manual before using your appliance, to ensure
you know how to safely operate the controls
and functions.Carefully follow all unpacking and
installation instructions to ensure the appliance
is correctly connected and fitted prior to use.
Please write your product model and serial
number on the last page of this user manual,
and store in a safe location close to the
appliance for easy future reference.
This user manual may also be applicable for
several other models. Differences between
models will be listed.
If you have any questions or concerns,
please call our contact centre or find help and
information online at www.beko.co.uk .com
Explanation of symbols used throughout
this User Manual
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
“The wool wash cycle of this
machine has been approved
by The Woolmark Company
for the washing of machine
washable wool products provided
that the products are washed
according to the instructions
on the garment label and those
issued by the manufacturer of
this washing machine. M1527 “
“In UK, Eire, Hong Kong and
India the Woolmark trade mark
is a Certification trade mark.”

3 / EN Washer-Dryer / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of
personal injury or property damage.
Failure to follow these instructions
shall invalidate any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities
were not fully developed or who
lack experience and knowledge
provided that they are supervised
or trained on the safe usage of the
product and the risks it brings out.
Children should not play with the
device. Cleaning and maintenance
works should not be performed by
children unless they are supervised
by someone. Children under the
age of 3 should be kept away
unless continuously supervised.
A
PRECAUTION!
• Never place the product on a
carpet-covered floor. Otherwise,
lack of airflow beneath the machine
will cause electrical parts to
overheat. This will cause problems
with your product.
C
INFORMATION
• Always have the installation
procedures carried out by the
competent persons. Manufacturer
shall not be held liable for damages
that may arise from procedures
carried out by unauthorised persons.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is the risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!
A
CAUTION!
• If the power cable is damaged,
it must be replaced by the
manufacturer, after sales service
or a similarly qualified person
(preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.

4 / EN Washer-Dryer / User’s Manual
A
PRECAUTION!
• Unplug the product when it is not
in use.
• Never touch the plug with wet
hands! Never unplug by pulling on
the cable, always unplug by holding
the plug.
• Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme,
see “Cancelling the programme”
section.
1.1.2 Product safety
B
DANGER!
• Never open the loading door or
remove the filter while there is
still water in the drum. Otherwise,
risk of flooding and injury from hot
water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
C
INFORMATION
• Do not force open the locked
loading door. Door can be opened
a few minutes after the washing
cycle ends. If the machine has not
cooled enough at the end of the
programme, loading door cannot
be opened. Do not force the loading
door to open. It must be left to cool
itself. The loading door and the lock
mechanism may get damaged.
• In the installation location of this
product, there must not be a
lockable, sliding or hinged door that
will restrict the full opening of the
loading door.
• Follow the instructions on the textile
tags and on the detergent package.
• Use only detergents, softeners and
supplements suitable for washing
machines.
• Do not install or leave this product
in places where it might be exposed
to outdoor conditions.
• Controls must not be tampered with.
1.1.3 Warnings for drying
DANGER!
• Laundry that is previously washed,
cleaned, soiled or stained with
petrol / gasoline, dry cleaning
solvents or other flammable or
explosive substances must not be
dried in the machine as they give
out flammable or explosive steam.
It may cause fire risk.

5 / EN Washer-Dryer / User’s Manual
DANGER!
• Laundry stained with Liquid
cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes and wax
removers must be washed in hot
water with plenty of detergent
before drying. It may cause fire risk.
• Foam rubber (latex foam), shower
caps, waterproof textiles, clothes
or pillows with rubber support or
rubber foam pads must not be
dried with drying function. It may
cause fire risk.
• If you use washing ball, detergent
scale, laundry clothing cages and
balls in your machine, they can
melt during drying. Do not use
these products if drying option will
be selected. It may cause fire risk.
• When you use industrial chemicals
for cleaning, do not use drying
function. It may cause fire risk.
B
DANGER!
• Do not touch loading door glass
with bare hands after drying. There
is the risk of getting burnt.
• In order to maintain laundry in a
temperature that will prevent them
from getting damaged, a cooling
step is performed as a final step.
You may be exposed to hot steam
if you open the door before cooling
is complete. There is the risk of
scalding.
B
DANGER!
• If the drying programmes
are interrupted (as a result of
programme cancellation or power
failure), laundry in the machine can
be hot. Be careful.
A
CAUTION!
• Do not stop the machine before
drying programme is completed.
If you have to stop the machine,
remove all laundry and lay them in a
suitable place to let them cool down.
• Your product is suitable to operate
in ambient temperatures between
0°C and +35°C.
A
CAUTION!
• Ambient temperatures between 15°C
and +25°C are ideal temperatures for
your product.
• Do not let pets enter the product.
Check inside the product before using.
• Do not overload the machine for
drying. Observe the maximum load
levels specified for drying.

6 / EN Washer-Dryer / User’s Manual
A
PRECAUTION!
• Do not dry leather laundry or laundry
that contains leather (such as leather
jeans label). The colour from Leather
parts can run into other textiles.
• In failures that cannot be repaired
using information given in safety
instructions, turn off the machine,
unplug the power cable and call the
Authorised Service Agent.
• You can just wash laundry, just dry
laundry or wash and dry laundry in
your washer-dryer. Machine must
not be used only to dry wet loads
for a long time. When machine is
used only for drying, it must be
operated empty without loading
laundry in a short wash programme
after every 15 operation.
• Check all clothes before loading
them into the machine and ensure
that they do not have objects such
as lighters, coins, metal pieces,
needles in the pockets or inside.
• Underwear with metal supports must
not be dried in the machine. Metal
supports might come off during drying
and cause damage in the machine.
Place in a bag or pillowcase.
A
PRECAUTION!
• Do not dry large laundry such as tulle
curtain, curtain, bedding, blanket, rug
in the machine. Your laundry might get
damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use fabric softeners or static
preventers in the machine unless
recommended by the manufacturer.
• Products such as fabric softeners
must be used in accordance with
manufacturer’s instructions.
• Do not dry sensitive clothes such
as silk, wool, etc. in the machine.
Otherwise, wool clothes may get
shrunken and other sensitive
clothes may get damaged.
• Check symbols on the garment tag
before washing and drying.
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must only be used for
washing, rinsing and drying of textile
products that are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.

7 / EN Washer-Dryer / User’s Manual
1.3 Children's safety
A
CAUTION!
• Children below the age of 3 must be
kept away from the machine unless
they are continuously supervised.
• Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
• Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing the
detergent package.
1.4 Compliance with WEEE
Directive and disposing
of the waste product
This product does not contain harmful and
forbidden materials described in the "Regulation on
the Control of the Waste Electrical and Electronic
Equipment". It complies with the WEEE Directive.
This product has been
manufactured with high quality
parts and materials which can
be reused and are suitable for
recycling. Therefore, do not
dispose the product with normal
domestic waste at the end of its
service life. Take it to a collection
point for the recycling of electrical
and electronic equipment. Please
consult your local authorities to
learn the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power cable
and break the locking mechanism of the
loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
with normal domestic waste. Take them
to the packaging material collection points
designated by the local authorities.
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable 5- Loading door
2- Top panel 6- Filter cover
3- Control panel 7- Adjustable feet
4- Water
discharge hose
8- Detergent drawer

8 / EN Washer-Dryer / User’s Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
C
INFORMATION
• Figures in this manual are schematic and may not match the product exactly.
(*) This may be supplied with the machine depending on the model of your product.

9 / EN Washer-Dryer / User’s Manual
2.3 Technical specifications
Complying Commission Delegated Regulation (EU) No.96/60/EC/1996
Supplier name or trademark Blomberg
Model name LRF2854121G
7170242800
Energy effciency class on a scale of A (more efficient) to G (less efficient) A
Energy consumption for washing, spinning, and drying (kWh) 5,44
Energy consumption for washing, spinning only (kWh) 0,76
Washing performance class on a scale of A (higher) to G (lower) A
Water remaining after spin (as a proportion of dry weight of wash) % 44
Maximum spin speed (rpm) 1400
Washing capacity (cotton) (kg) 8
Drying capacity (cotton) (kg) 5
Water consumption for washing, spinning and drying (l) 78
Water consumption for washing and spinning only (l) 47
Washing and drying time (min) 610
Estimated annual consumption of energy and water for a four-person household, always
using the drier (200 cycles) (kWh / l) 1088 / 15600
Estimated annual consumption of energy and water for a four-person household, never
using the drier (200 cycles) (kWh / l) 172 / 9400
Noise washing / spinning / drying [dB(A) re 1 pW] 57/77/64
Technical specifications may be changed without prior notice to improve the quality of the product.
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Net weight (±4 kg.) 71
Single Water inlet / Double Water inlet •/-
•Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 9620

10 / EN Washer-Dryer / User’s Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Placetheproductonasolidandlevel
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
•Donotplacetheproductclosetothe
edge if the floor contains steps. Do not
also place the product on a platform.
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductinenvironments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leavingagapatthesidesofthemachine
is suggested to reduce vibration and noise
• Intheareawherethisproductis
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operatetheproductinawellventilated
and dust free environment.
•DonotplaceheatsourcessuchasHobs,
Irons,Ovens,etc.onthewashingmachine
and do not use them on the product.
3.2 Removing packaging
reinforcement
Tilt the machine
backwards to remove
the packaging
reinforcement.
Remove the
packaging
reinforcement
attached to
the ribbon.
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
thewashingmachine!Otherwise,
the product will get damaged.

11 / EN Washer-Dryer / User’s Manual
3
2
1
1 Use a tool to
loosen all bolts until
they rotate freely.
3
2
1
2 Remove the transit
bolts by turning
them slightly.
3
2
1
3 Attach the plastic
covers supplied in
the user manual
bag into the holes
on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place
to reuse when the product needs
to be moved again in the future.
• Never move the product without the
transit bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• The water supply pressure required to
run the product is between 1 to 10 bars
(0.1 – 1 MPa). It is necessary to have
10 – 80 liters of water flowing from the
fully open tap in one minute to have your
product run smoothly. Attach a pressure
reducing valve if water pressure is higher.
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1 2 3
1 Connect the special
hose supplied
with the product
to the water inlet
on the product.
A
CAUTION!
• Ensure that the cold water connection
is made correctly when installing the
product.Otherwise,yourlaundry
will come out hot at the end of the
washing process and wear out.
1 2 3
2 Tighten the hose
nuts securely
by hand. Never
use a tool when
tightening the nuts.
1 2 3
3 Openthetaps
completely after
making the hose
connection to
check for water
leaks at the
connection points.
If any leak occurs, turn off the tap and
remove the nut. Retighten the nut carefully
after checking the seal. In order to prevent
the water leaks, keep the taps closed
when you do not use the product.

12 / EN Washer-Dryer / User’s Manual
3.5 Connecting to the drain
• Attachtheendofthedrainhosedirectly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the hose
comes out of its housing during water
discharge. Moreover, there is risk of
scalding due to high washing temperatures!
To prevent such situations and to ensure
smooth water intake and discharge of
the machine, fix the end of the discharge
hose tightly so that it cannot displace.
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
• Connectthehosetoaminimumheightof
40 cm and a maximum height of 90 cm.
• Ifthehoseisrunalongthefloor(oratless
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
• Topreventflowingofdirtywaterbackinto
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• Theendofthehoseshouldnotbe
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• Ifthelengthofthehoseistooshort,addan
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the
product from upper diagonal edges.
• Otherwise,theproductmaymove
from its place and cause crushing,
noise and vibration problems.
• Do not use any tools to loosen
thelocknuts.Otherwise,the
lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product stands level
and balanced.
c) Tighten all lock nuts again by hand.
3.7 Electrical connection
Connect the product to a grounded outlet
protectedbya13Afuse.Ourcompanyshall
not be liable for any damages that will arise
when the product is used without grounding
in accordance with the local regulations.
• Connectionmustcomplywith
national regulations.
• Thewiringfortheelectricaloutletcircuit
must be sufficient to meet the appliance
requirements. Use of a Groud Fault Circuit
Interrupter (GFCI) is recommended.
• Powercableplugmustbewithin
easy reach after installation.

13 / EN Washer-Dryer / User’s Manual
• Ifthecurrentvalueofthefuseorbreaker
in the house is less than 13 Amps, have a
qualified electrician install a 13 Amp fuse.
• Thevoltagespecifiedinthe“Technical
specifications” section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
Important
Fitting a different plug
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals on your plug, proceed as follows:
1 Connect the green - yellow or green
(earth) wire to the terminal in the plug
marked ‘E’ or with the symbol f or
coloured green and yellow or green.
2 Connect the blue (neutral) wire to the terminal
in the plug marked ‘N’ or coloured black.
3 Connect the brown (live) wire to the terminal
in the plug marked ‘L’ or coloured red.
With the alternative plugs a 13A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, and degree of soiling
and allowable water temperature.
* Always observe the instructions given
on the garment care labels.
4.2 Preparing laundry for washing
• Laundryitemswithmetalattachments
such as, underwired bras, belt buckles or
metal buttons will damage the machine.
Remove the metal pieces or wash such
clothes by putting them in a cotton laundry
bag or cotton pillow case. Also these
type of clothes can heat too much during
drying and damage your other clothes.
Do not dry such laundry in the machine.
• Putsmallsizeclothessuchasinfant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Placecurtainsinwithoutcompressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fastenzips,sewloosebuttons
and mend rips and tears.
DANGER!
• Your product is too heavy for
one person to carry.
• Your product is heavy; two persons
must carry it and extra precaution
taken on stairs. If your product falls
on you, it may cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the
transit bolts properly fixed in place!

14 / EN Washer-Dryer / User’s Manual
• Wash“machinewashable”or“hand
washable” labelled products only with an
appropriate programme. Dry these type
of clothes by hanging or laying down.
Do not dry them in the machine.
• Donotwashcoloursandwhitestogether.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Onlyusethedyes/colourchangersand
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.
C
INFORMATION
• Laundry that is subjected to heavy deposits of
materials such as flour, lime dust, milk powder,
etc. Must be shaken off before placing into
the machine. Such dusts and powders on
the laundry may build up on the inner parts of
the product in time and can cause damage.
• Keep laundry items made of Angora
wool in the freezer for a few hours before
washing. This will reduce pilling.
• Wash trousers and delicate
laundry turned inside out.
• Tough stains must be treated properly before
washing. If unsure, check with a dry cleaner.
• Take out all substances in the pockets such as
coins, pens and paper clips, and turn pockets
inside out and brush. Such objects may
damage the product or cause noise problem.
4.3 Tips for energy saving
Energy efficiency will be improved by
using lower temperature programmes
and appropriate detergents.
• Operatetheproductinthehighest
capacity allowed by the programme you
have selected, but do not overload; see,
"Programme and consumption table". See,
“Programme and consumption table"
• Alwaysfollowtheinstructionson
the detergent packaging.
• Washslightlysoiledlaundryatlowtemperatures.
• Usefasterprogrammesforsmall
quantities of lightly soiled laundry.
• Donotuseprewashandhightemperatures
for laundry that is not heavily soiled or stained.
• Ifyouplantodryyourlaundryina
dryer, select the highest spin speed
recommended during washing process.
• Donotusemoredetergentthanthe
recommended on the detergent packaging.
4.4 Initial use
Before starting to use
the product make sure
that all preparations are
made in accordance
with the “Important
safety and environment
instructions” and the
instructions in the
“Installation” section.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this programme is not
available in your machine, apply the method
which is described in the section 6.2.
C
INFORMATION
• Use an anti-limescale product suitable
for the washing machines.
• Some water may remain in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the desired washing programme.
The product automatically adjusts
the water amount according to the
weight of the laundry put inside it.
A
CAUTION!
• Follow the information in the
“Programme and consumption table”.
When overloaded, machine’s washing
performance will drop. Moreover, noise
and vibration problems may occur. For
a successful drying performance, do
not dry more laundry than stated.

15 / EN Washer-Dryer / User’s Manual
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100 Women‘s night gown 200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s overalls 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100
4.6 Loading the laundry
1.Opentheloadingdoor.
2. Put the laundry items into the
product in a loose manner.
3. Push the loading door to close until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
• The loading door is locked while a
programme is running. The loading door
is unlocked a while after the programme
comes to an end. If the inside part of
the machine is too hot at the end of
the programme, loading door will not
open until the temperature decreases.
A
CAUTION!
• If the laundry is misplaced,
noise and vibration problems
may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach and descaling agents;
read the manufacturer’s instructions written
on the package and follow the dosages
specified. Use a measuring cup if available.
4.7.1 Detergent drawer
The detergent drawer is composed
of three compartments:
1
3
2
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition,
there is a siphon
piece in the softener
compartment.
4.7.2 Detergent, softener
and other cleaning agents
• Adddetergentandsoftenerbefore
starting the washing programme.
• Neverleavethedetergentdraweropen
while the washing programme is running!
• Whenusingaprogrammewithoutprewash,
do not put any detergent into the prewash
compartment (compartment nr. "1").
• Inaprogrammewithprewash,donot
put liquid detergent into the prewash
compartment (compartment nr. "1").
• Donotselectaprogrammewithprewashif
you are using a detergent bag or dispensing
ball. Place the detergent bag or the
dispensing ball directly among the laundry
in the machine. Remove these if drying
• Ifyouareusingliquiddetergent,
do not forget to place the liquid
detergent container into the main wash
compartment (compartment nr. “2”).
• WhenmachineisinDryingstep,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.3 Choosing the detergent
Detergent type to be used depends
on the fabric type and colour.
• Usedifferentdetergentsfor
coloured and white laundry.
• Washyourdelicateclothesonlywithspecial
detergents (liquid detergent, wool shampoo,
etc.) intended solely for delicate clothes.
• Whenwashingdarkcolouredclothesandquilts,
it is recommended to use liquid detergent.
• Washwoollenswithspecialdetergent
made specifically for woollens.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use Powdered Soap.

16 / EN Washer-Dryer / User’s Manual
4.7.4 Adjusting the
amount of detergent
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.
• Donotuseamountsexceedingthedosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Uselesserdetergentforsmall
amounts or lightly soiled clothes.
4.7.5 Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Donotexceedthe(>max<)levelsign
on the softener compartment.
• Ifthesoftenerhaslostitsfluidityorthe
concentrated type, dilute it with water
before putting it in the detergent drawer.
4.7.6 Using liquid detergents
4.7.6.1 If the product contains
a liquid detergent container
• Puttheliquiddetergentcontainer
into the compartment no “2”.
• Iftheliquiddetergentlostitsfluidity,
dilute it with water before putting
it into the detergent container.
2
4.7.6.2 If the product is equipped
with a liquid detergent part
• Whenyouwanttouseliquiddetergent,
pull the apparatus towards yourself.
The part that falls down will serve as
a barrier for the liquid detergent.
• Ifrequired,cleantheapparatuswithwater
when it is in place or by removing it.
• Ifyouwillusepowderdetergent,the
apparatus must be secured at top position.
4.7.6.3 If the product does not
contain a liquid detergent container
• Donotuseliquiddetergentfortheprewash
step in a programme with prewash.
• Liquiddetergentstainsyourclothes
when used with Delayed Start function.
If you are going to use the Delayed Start
function, do not use liquid detergent.
4.7.7 Using gel and
tablet detergent
• Ifthegeldetergentthicknessisfluidaland
your machine does not contain a special liquid
detergent cup, put the gel detergent into the
main wash detergent compartment during first
water intake. If your machine contains a liquid
detergent container, fill the detergent into this
container before starting the programme.
• Ifthegeldetergentthicknessisnotfluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Puttabletdetergentsintothemainwash
compartment (compartment nr. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in
the detergent compartment. If you notice
such residues, place the tablet detergent
between the laundry, close to the lower
part of the drum in future washings.
C
INFORMATION
• Use the tablet or gel detergent without
selecting the prewash function.
• Bear in mind that any plastic detergent
cup, bowl etc in the drum should
be removed before drying..

17 / EN Washer-Dryer / User’s Manual
4.7.8 Using laundry starch
• Addliquidstarch,powderstarchorthe
dyestuff into the softener compartment.
• Donotusesoftenerandstarch
together in a washing cycle.
• Wipetheinsideofthemachinewitha
damp and clean cloth after using starch.
4.7.9 Using bleaches
• Selectaprogrammewithprewashand
add the bleach at the beginning of the
prewash. Do not put detergent in the
prewash compartment. As an alternative
application, select a programme with
extra rinse, add the bleach into an empty
detergent drawer compartment and
also add 1 glass of water from the same
compartment when you see the rinsing
step on the display for the first time.
• Donotusebleachanddetergent
by mixing them.
• Usejustalittleamount(approx.50ml)
of bleaching agent and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the coloured items.
• Whenusingoxygen-basedwhitener,
select a programme which washes
the laundry at a low temperature.
• Oxygen-basedwhitenercanbeusedwith
the detergent; however, if it is a different
consistency, first put detergent in the
compartment number “2” in the detergent
dispenser and wait for the machine to flush
the detergent when taking in water. While
the product continues taking in water, add
whitener in the same compartment.
4.7.10 Using limescale remover
•Whenrequired,uselimescale
removers manufactured specifically
for washing machines only.
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woollens/Silks
(Recommended temperature
range based on soiling level:
40-90 oC)
(Recommended temperature
range based on soiling level:
cold -40 oC)
(Recommended
temperature range
based on soiling level:
cold -40 oC)
(Recommended
temperature range based
on soiling level: cold
-30 oC)
Soiling Level
Heavily
Soiled
(difficult stains
such as grass,
coffee, fruits and
blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for heavily soiled
clothes. It is recommended
to use powder detergents to
clean clay and soil stains and
the stains that are sensitive to
bleaches. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed
with special woollen
detergents.
Normally
Soiled
(For example,
stains caused by
body on collars
and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for normally
soiled clothes. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed
with special woollen
detergents.
Lightly
Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for lightly soiled
clothes. Detergents which do
not contain bleach should be
used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed
with special woollen
detergents.

18 / EN Washer-Dryer / User’s Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Wash&Dry Wash&Wear
Types of Clothes
Durable
Clothes
with Cotton-
Content
Bed sheet, bedding,
baby clothes, t-shirt,
sweatshirt, durable
knitted clothes,
denim, canvas
trousers, shirts,
cotton socks, etc.
Not recommended!
It washes and dries
consecutively! Bed sheet,
bedding, baby clothes,
t-shirt, sweatshirt, durable
knitted clothes, denim,
canvas trousers, shirts,
cotton socks, etc.
It washes and dries
consecutively! Bed sheet,
bedding, baby clothes,
t-shirt, sweatshirt, durable
knitted clothes, denim,
canvas trousers, shirts,
cotton socks, etc.
Clothes which are worn for
a short period of time an
unstained, such as shirts,
t-shirts, sweatshirts, etc.
A very small amount of
laundry should be loaded.
Synthetics
Clothes
(Polyester,
nylon, etc.)
Not recommended!
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes. Drying is
not recommended for the
viscose-content clothes.
Drying explanations in the
maintenance label should
be taken into account.
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes at low
temperatures with the
washing and drying
warnings given in the
maintenance label taken
into consideration.
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes at low
temperatures with the
washing and drying
warnings given in the
maintenance label taken
into consideration.
Very slightly soiled and
unstained shirts, t-shirts
and synthetic content items.
A very small amount of
laundry should be loaded.
Delicate
(Silk,
Woollens,
Cashmere,
Angora wool,
etc. content)
Clothes
Not recommended! Not recommended! Not recommended! Not recommended! Not recommended!
Bulky
laundry
such as
quilts, coats,
curtains,
etc.
Not recommended!
It is not appropriate
to dry bulky laundry
inside the washing
machine. Dry them
by hanging or laying
down.
Not recommended! It
is not appropriate to dry
bulky laundry inside the
washing machine. Dry
them by hanging or laying
down.
Not recommended! It is not
appropriate to dry bulky
laundry inside the washing
machine. Dry them by
hanging or laying down.
Not recommended! It
is not appropriate to dry
bulky laundry inside the
washing machine. Dry
them by hanging or laying
down.
Not recommended! It is
not appropriate to dry bulky
laundry inside the washing
machine. Dry them by
hanging or laying down.
4.10 Displayed Program Time
You can see the programme duration
on the display of your machine while
selecting a programme. Depending on the
amount of laundry you have loaded into
your machine, foaming, unbalanced load
conditions, fluctuations in power supply,
water pressure and program settings,
the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE: At programme start of
Cottons and Cotton Eco programmes,
display shows the duration of half load,
which is the most common use case. After
programme starts, in 20-25 minutes actual
load is detected by the machine. And if the
detected load is higher than half load; washing
program will be adjusted accordingly and
program duration increased automatically.
You may follow this change on the display.

19 / EN Washer-Dryer / User’s Manual
5 Operating the product
5.1 Control panel
1 2 3 4 5 6
789
101112
13
1 - Programme selection knob
2 - Temperature selection lights
3 - Spin speed selection lights
4 - Display
5 - Drying Programme Lights
6-On/Offbutton
7 - Start / Pause button
8 - End Time Adjustment button
9 - Drying Level Adjustment button
10 - Auxiliary Function buttons
11 - Spin Speed Adjustment button
12 - Temperature Adjustment button
13 - Programme Selection lights
5.2 Display symbols
a b c d e
f
g
h
i
a- Washing indicator
b - Rinsing indicator
c - Spinning indicator
d- Drying indicator
e- End indicator
f- No Water indicator
g - Duration Information display
h- Loading Door Lock indicator
i- Child Lock indicator
5.3 Preparing the machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4.Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting the washing
programme
1. Determine the programme suitable
for the type, quantity and soiling level
of the laundry in accordance with the
"Programme and consumption table".
2. Select the desired programme with
the Programme Selection knob.
C
INFORMATION
• Programmes are limited with the
highest spin speed appropriate for
that particular type of fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
• Always select the lowest appropriate
temperature. Higher temperature means
higher electricity consumption.
5.5 Washing programmes
Depending on the type of fabric, use
the following main programmes.
C
INFORMATION
• You can set you machine to switch to
drying step at the end of washing cycle
by pressing the Drying button after you
have selected the washing programme
for your laundry. Each time you press the
button, info line shows at which step the
drying process will take place and the
relevant symbol will turn on. If you want,
by continuing to press the button, you can
perform drying for the maximum period of
time allowed by the machine for drying.
• Symbols in the display are schematic
and may not match the product exactly.
• When you will perform washing and
drying by using the Drying function of
your machine, load maximum 5 kg of
laundry into the machine. If you load
excessively, your laundry will not dry
and machine will operate for a long
time and consume more energy.

20 / EN Washer-Dryer / User’s Manual
• Cottons
Use for your cotton laundry (such as bed
sheets, duvet and pillowcase sets, towels,
bathrobes, underwear, etc.). Your laundry
will be washed with vigorous washing
action for a longer washing cycle.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Synthetics
Use to wash your synthetic clothes (shirts,
blouses, synthetic/cotton blends, etc.).
Your laundry will be washed with a gentle
action for a shorter washing cycle when
compared to the Cottons programme.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Woollens
Use to wash your woollen laundry. Select
the appropriate temperature complying
with the tag of your clothes. Use
appropriate detergents for woollens.
C
INFORMATION
• Drying function cannot be selected
for the woollen wash programme.
• Cottons Eco
Use to wash your normally soiled, durable
cotton and linen laundry. Although it washes
longer than all other programmes, it provides
significant energy and water savings. Actual
water temperature may be different from
the stated washing temperature. When you
load the machine with less laundry (e.g.
½ capacity or less), programme duration
may automatically get shorter. In this
case, energy and water consumption will
decrease more, providing a more economic
wash. This programme is available in the
models with the remaining time indicator.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Delicates
Use to wash your delicate laundry. Your laundry
will be washed with more gentle washing action
compared to the Synthetics programme.
• Hand Wash
Use to wash woollen/delicate laundry that bear
“not machine-washable” care labels and for
which hand wash is recommended. Your laundry
will be washed with a very gentle washing
action in order not to damage the clothes.
