HEX70HDUK-KIT QUICK REFERENCE GUIDE
01Contact: [e-mail] |[e-mail] |[e-mail]
HEX70HDUK-KIT
Quick Reference Guide
The HEX70HDUK-KIT extender set is an industry leading HDMI2.0 4K 60Hz 4:4:4 (18Gbps)
HDCP2.2 HDBaseT™ multi-format solution utilising CSC technology to deliver HDMI,
USB-C and DisplayPort™ up to lengths of 40m at 4K 60Hz 4:4:4 (1080p to 70m) over a single
CAT cable.
The HEX70HDUK-KIT provides enhanced features including local HDMI input on the
HDBaseT™ Receiver for additional source input, web-GUI for control and configuration,
auto display control, audio breakout, and bi-directional IR pass-through. The
HEX70HDUK-KIT also features control via front panel, IR, RS-232 and TCP/IP, and advanced
EDID and HDCP management.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
• Features 1x HDMI, 1x USB-C and 1x DisplayPort™ input on the HDBaseT™ Transmitter with manual or auto source selection
• Features 1x local HDMI input on the HDBaseT™ Receiver for connection of a source local to the display
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p up to a distance of 70m over single CAT cable
• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
transmission
• Supports USB Type C up to 4K UHD 60Hz 4:4:4 DP1.2 with 60W charging capability*
• Supports DisplayPort™ up to 4K UHD 60Hz 4:4:4 DP1.2
• Audio breakout to analogue L/R audio and Coaxial digital (S/PDIF) outputs concurrently**
• Bi-directional IR pass-through
• Auto display on/o feature allowing control of display at the HDBaseT™ Receiver via CEC or RS-232
• Web interface module for control and configuration of HEX70HDUK-KIT
• Control via front panel, IR, RS-232 and TCP/IP
• Advanced EDID ad HDCP management
*USB-C video support is limited to 4K 60Hz 4:2:0 when charging feature is activated by the source device
**Analogue audio breakout supports 2ch PCM only
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2

HEX70HDUK-KIT QUICK REFERENCE GUIDE
02 www.blustream.com.au |www.blustream-us.com |www.blustream.co.uk
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
TX Panel Descriptions
1Input / Auto Select Button - Press to change source, hold for
3 seconds to enable / disable auto signal sense switching
2Auto Switching Status LED
3Remote (RX) HDBaseT™Link Status LED
4Source Input Status LED - Illuminates when corresponding
source device is connected
5USB Device Inputs - Connect to local USB peripherals
6USB Charging Input - Allows charging of USB devices only (2A)
7TCP/IP (RJ45) – Connect to LAN for TCP/IP control
Default IP of the HEX70HDUK-KIT is 192.168.0.200
8Reset Switch - Press and hold for 10 seconds to factoy reset unit
9GPIO Port - 3-pin Phoenix connector for input sense / output
relay / contact closure control of 3rd party devices
qRS-232 - 3-pin Phoenix connector for RS-232 pass-through,
or device control by RS-232 commands
wIR Control Port (to Blustream 5V 3.5mm IR receiver or IR
control device)
eIR In (to Blustream 5V 3.5mm IR receiver)
rIR Out (to Blustream 5V 3.5mm IR emitter)
tPower over Cable (PoC) switch (ON / OFF) - to enable /
disable PoC being sent or received
yDisplay Button - Press to triggers the output on / o sequence
uPower Status LED
iHDMI Input - Connect to source equipment
oDisplayPort™ Input - Connect to source equipment
pUSB-C Input - Connect to source equipment (supports 60w
charging)
aUSB Host Inputs - Connect to Host PC connected to
corresonding video input
sHDBaseT™ Output
dAudio Output - Balanced / unbalanced 2ch analogue audio out
fOptical Output - Connect to audio amplification or
distribution device
gEDID DIP Switch (UP=0, DOWN=1)
hUSB Upgrade Port
jPower Port – Use included 24V/5A DC adaptor to power the device
RX Panel Descriptions
15 16 17 18 19 20 21 22 23 24 25 26
1 2 3 4 5 6 7 8910 11 12 13 14 15 16
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
123457910 11 13 1412
68
1Power Status LED
2HDBaseT™Link Status LED
3Local (RX) HDMI Source Status LED
4Auto Switching Status LED
5Input / Auto Select Button - Press to change source, hold for
3 seconds to enable / disable auto signal sense switching
6Power over Cable (PoC) switch (ON / OFF) - to enable /
disable PoC being sent or received
7IR In (to Blustream 5V 3.5mm IR receiver)
8IR Out (to Blustream 5V 3.5mm IR emitter)
9RS-232 - 3-pin Phoenix connector for RS-232 pass-through,
or device control by RS-232 commands
qUSB Upgrade Port
wHDBaseT™ Input
eHDMI Input - Connect to local HDMI source device
rHDMI Output - Connect to HDMI display device
tRelay Contacts - 3-pin Phoenix connector to allow relay
control of a device such as a projector screen
yUSB Device Inputs - Connect to local USB peripherals
uPower Port – Use included 24V/5A DC adaptor to power the device

HEX70HDUK-KIT QUICK REFERENCE GUIDE
03Contact: [e-mail] |[e-mail] |[e-mail]
EDID Control
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source to negotiate the best
audio and video resolutions that are supported in the system. A global EDID of the HEX70HDUK-KIT can be configured using a
combination of DIP switch settings (see below) or via TCP/IP, RS-232 or web-GUI.
RS-232 Configuration & Control
The RS-232 ports can be used for configuration / control of the product, as well as pass through of RS-232 commands between
the serial ports of the HEX70HDUK-TX and RX. By default, the transmitter unit is allocated for control and feedback of switching,
however this can be changed to the receiver if required.
The default RS-232 communication settings are:
Baud Rate: 57600
Data Bit: 8
Stop Bit: 1
Parity Bit: none
For the complete RS-232 and TCP/IP command list please see the HEX70HDUK-KIT User Manual - available to download from the
Blustream website.
Global EDID Settings
DIP switch position ‘0’ = O / Up
DIP switch position ‘1’ = On / Down
EDID DIP Switches
[DIP] = 0000: HDMI 1080p @60Hz, Audio 2ch PCM (default)
[DIP] = 0001: HDMI 1080p @60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 0010: HDMI 1080p @60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 0011: HDMI 1080i @60Hz, Audio 2ch PCM
[DIP] = 0100: HDMI 1080i @60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 0101: HDMI 1080i @60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 0110: HDMI 4K @60Hz 4:2:0, Audio 2ch PCM
[DIP] = 0111: HDMI 4K @60Hz 4:2:0, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 1000: HDMI 4K @60Hz 4:2:0, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 1001: HDMI 4K @60Hz 4:4:4, Audio 2ch PCM
[DIP] = 1010: HDMI 4K @60Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 1011: HDMI 4K @60Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 1100: DVI 1920x1080 @60Hz, Audio None
[DIP] = 1101: DVI 1920x1200 @60Hz, Audio None
[DIP] = 1110: EDID Passthrough
[DIP] = 1111: Soware Controlled EDID (set EDID via web-GUI, TCP/IP, RS-232)
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID
UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
Auto On / O Display Control
The HEX70HDUK-KIT can be programmed to automatically power on / o a display connected to the HDBaseT™ receiver output
via CEC, RS-232 or Relay. Please refer to the HEX70HDUK-KIT User Manual - available to download from the Blustream website for
more details.
Web-GUI Control
The HEX70HDUK-KIT features an in-built web-GUI which can be used for control and configuration of the product.
Default Username is: blustream Default Password is: 1234 Default IP Address is: 192.168.0.200
For further information please see the HEX70HDUK-KIT User Manual - available to download from the Blustream website.

HEX70HDUK-KIT QUICK REFERENCE GUIDE
04 www.blustream.com.au |www.blustream-us.com |www.blustream.co.uk
RevA0_HEX70HDUK-KIT_QRG_210914
Schematic
RS-232 HDMI Infrared Cat 6 USB USB-C DisplayPort™ Analogue Audio Digital Audio
HEX70HDUK-KIT Example Schematic
A
C
D E
B
HDMI RS-232 IR PoC
A
B
C
D
USB
E
Projector
Screen
Projector
Amp
Speakers
Network Switch
Control Processor
Speakers
USB DEVICES

 
Audio Amplier
HDMI, DP & USB SOURCES
Local
Source
HDBaseT™ 1080p up to 70m | 4K up to 40m
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0 1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2

HEX70HDUK-KIT QUICK REFERENCE GUIDE
05Contact: [e-mail] |[e-mail] |[e-mail]
HEX70HDUK-TX
• Video Input Connectors: 1 x HDMI Type A, 19-pin, female;
1 x USB Type C; 1 x DisplayPort™
• Video Output Connectors: 1 x HDBaseT™ RJ45 connector
• RS-232 Serial Port: 1 x 3-pin Phoenix connector
• TCP/IP Control: 1 x RJ45, female
• IR Input Ports: 2 x 3.5mm stereo jack
• IR Output Port: 1 x 3.5mm mono jack
• USB Ports: 3 x USB Type-A, 2 x USB Type-B
• EDID: 4-pin DIP switch
• Product Upgrade: 1 x Micro USB, female
• Local Power Input: 1 x 24V/5A 4-pin DIN connector
• Casing Dimensions (W x H x D): 183mm x 44mm x 173mm
HEX70HDUK-KIT
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Packaging Dimensions: 400mm x 230mm x 110mm
• Shipping Weight: 3.6kg
• Power Supply: 24V/5A DC
HEX70HDUK-RX
• Video Input Connectors: 1 x HDMI Type A, 19-pin, female;
1 x HDBaseT™ RJ45 connector
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female
• Audio Output Connectors: 5-pin Phoenix connector (2ch
balanced / unbalanced analogue audio); 1 x RCA (S/PDIF)
• RS-232 Serial Port: 1 x 3-pin Phoenix connector
• Relay Control: 2 x 3-pin Phoenix connectors
• IR Input Port: 1 x 3.5mm stereo jack
• IR Output Port: 1 x 3.5mm mono jack
• USB Ports: 2 x USB Type-A
• Product Upgrade: 1 x Micro USB, female
• Local Power Input: 1 x 24V/5A 4-pin DIN connector
• Casing Dimensions (W x H x D): 155mm x 24mm x 155mm
Package Contents
Specifications
HEX70HDUK-KIT
• 1 x HEX70HDUK-TX
• 1 x HEX70HDUK-RX
• 1 x 24V/5A DC Power Supply
• 1 x USB-A to USB-B cable
• 1 x IR Emitter
• 1 x IR Receiver
• 1 x RS-232 Control Cable
• 2 x Mounting Kits
• 1 x Quick Reference Guide
Acknowledgements
DisplayPort™ and the DisplayPort™ logo are trademarks
owned by the Video Electronics Standards Association (VESA®)
in the United States and other countries.
NOTE: Specifications are subject to change without notice. Weights and
dimensions are approximate.
FCC NOTICE
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired
operation of the device.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed
with other household wastes. To prevent possible harm to the
environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmentally safe
recycling.
Certifications

www.blustream-us.com
www.blustream.com.au
www.blustream.co.uk
