User’s Guide
ONU-6040BF-2x Series
GEPON Optical Network Unit
Version 1.00
Edition 1, 5/2009
2009 ZyXEL Communications Corporation
C

ENGLISH
2

3
Introduction
The ONU-6040BF-2x is an optical network unit (ONU)
that allows you to enjoy high-speed Internet access
over optical networks. The ONU-6040BF-2x comes with
one fiber, four 10/100 Mbps RJ-45 ports and one co-
axial CATV connector. No configuration is required. On
the ONU-6040BF-2x, all device configuration is done
remotely by the OLT (Optical Line Terminal). Once you
have connected the hardware, you are ready to enjoy
Internet access.
Two ONU-6040BF-2x models are discussed in this
guide: ONU-6040BF-21 (with a 10km transceiver) and
ONU-6040BF-22 (with a 20km transceiver).
Hardware Connections
1. PON:Follow the steps below to connect an SC-type,
single-mode optical cable to the PON port for
Internet access.
Only qualified technicians should perform these actions!
Please skip this section if you are not a qualified
technician.

4
a. Hold the ONU-6040BF-2x upright, push the top
cover forward with the LEDs (lights) facing you,
then lift up the top cover to remove it.

5

6
b. Wind the fiber-optic cable around the tray in the
ONU-6040BF-2x.
c. Connect the fiber-optic connector into the PON
port.
d. Put the top cover back.
To avoid possible eye injury, do NOT look into an
operating fiber-optic module’s connector.
2. LAN:Use the included Ethernet cable to connect the
LAN port to a computer.
2
3
1
4

7
3. CATV:Use a coaxial cable to connect the CATV port
to a television or set-top box with an F-connector.
 Overly tightened coaxial cable may affect
transmission quality and/or break the connector
pin.
4. POWER: Use the included power adaptor to connect
this power socket to an appropriate power source.
Check the LEDs (Lights)
•ThePWR LED turns steady on when you connect the
ONU-6040BF-2x to the power supply.
•ThePON LNK LED turns on when the fiber connection
is available.
•TheLAN LED turns on when the LAN port is properly
connected.
•TheCATV LED turns on when the CATV port is
properly connected and the ONU-6040BF-2x detects a
video signal.

8
The following table describes the LEDs in detail.
Label Color Status Description
PWR Green On The ONU-6040BF-2x is getting
proper input power voltage and is
turned on.
Red On The ONU-6040BF-2x is receiving
abnormal input power voltage.
Off The power is off or there is a
power failure.
PON
LNK
Green On Connection to the optical network
is up.
Off Connection to the optical network
is down.
Blinking The ONU-6040BF-2x is trying to
register to an OLT.
PON
STATUS
Red Off The ONU-6040BF-2x is receiving
good optical signals from the OLT
successfully and no error signals.
Blinking The ONU-6040BF-2x is receiving
error signals or no optical signals
from the OLT.

9
Test Your Internet Connection
After you have connected the hardware and turned on
the ONU-6040BF-2x, open a web browser on your
computer and go to any web site (for example,
www.zyxel.com) to test your Internet connection.
LAN 1 ~
4
Yellow On The LAN port is connected to an
Ethernet device at 100 Mbps.
Blinking The ONU-6040BF-2x is sending
or receiving data at 100 Mbps.
Green On The LAN port is connected to an
Ethernet device at 10 Mbps.
Blinking The ONU-6040BF-2x is sending
or receiving data at 10 Mbps.
Off No Ethernet device is connected
to the LAN port.
CATV Green On The ONU-6040BF-2x is receiving
video signals.
Off The ONU-6040BF-2x is not
receiving video signals.
Label Color Status Description

10
Hardware Installation
The ONU-6040BF-2x can be vertically placed on a
desktop with the included stand or mounted on a wall.
Standing Instructions
Place the right panel of the ONU-6040BF-2x (when
facing the LEDs) onto the included stand until the ONU-
6040BF-2x fits in the stand completely. Make sure the
label names of the LEDs are displayed correctly and
not upside-down. Place the ONU-6040BF-2x and the
stand on a flat, level surface that is strong enough to
support the weight of the ONU-6040BF-2x with
connection cables.

11
Wall-mounting Instructions
Complete the following steps to hang your ONU-
6040BF-2x on a wall.
1. Select a position free of obstructions on a sturdy
wall.
2. Drill two holes large enough for the M4 tap screws.
Make sure the distance between the centers of the
holes is 140mm.
Be careful to avoid damaging pipes or cables located
inside the wall when drilling holes for the screws.

12
3. Do not insert the screws all the way into the wall.
Leave a small gap of about 0.5 cm between the
heads of the screws and the wall.
4. Make sure the screws are snugly fastened to the
wall. They need to hold the weight of the ONU-
6040BF-2x with the connection cables.
5. Align the holes on the back of the ONU-6040BF-2x
with the screws on the wall. Hang the ONU-6040BF-
2x on the screws.
The following are dimensions of an M4 tap screw and
masonry plug used for wall mounting. All
measurements are in millimeters (mm).

13
Troubleshooting
1. The PWR light is not on when I connect power to the
ONU-6040BF-2x.
• Check that the power source is turned on.
• You might be using the wrong power adaptor. Use
the included power adaptor only.
• If you are using the correct power adaptor,
disconnect and re-connect the power adaptor to
turn on the ONU-6040BF-2x again.
• If the PWR light is still not on, use a different
power outlet.
• If the problem continues, contact your local
vendor.
2. The PON light is off.
• Check the connector on the optical cable and the
PON port. Make sure they are clean and dust-free.
Use an air duster to clean the connectors. Do
NOT use a wet cloth to clean the connectors.
• Check the optical cable. Make sure it is not
broken. If the cable is broken, contact your service
provider to have the cable/connector replaced. Do

14
NOT attempt to replace the optical cable/
connector yourself.
3. The CATV light is off.
• Check the PON light. If the PON light is off, see 2
The PON light is off. If the PON light is on, contact
your service provider and make sure the video
signals can be transmitted successfully.
4. The CATV light is on but no video is displayed.
• Check the coaxial cable connection between the
CATV port and your TV or set-top box.
• Check that the TV is turned on.
• Check the coaxial cable. Make sure it is not
broken. Try using another coaxial cable if you’re
unsure.
5. I cannot connect to the Internet.
• Check the port connections and the lights.
• There might be problems with the optical network
setting. Contact your service provider.

15
Specifications
Specifications are accurate at the time of writing.
Feature Specification
Dimensions (mm) 181 (Wide) x 123.4 (Deep) x 41 (High)
Weight < 1 kg
Interface
PON One PON port
Compliant with IEEE 802.3ah
PX-10 (ONU-6040BF-21)
PX-20 (ONU-6040BF-22)
SC optical connectors with shutters
Transmission distance:
10 km (ONU-6040BF-21)
20 km (ONU-6040BF-22)
Wavelength: 1310 nm upstream and
1490 nm downstream, 1550 nm analog
receiver for CATV
Ethernet Four 10/100 Mbps RJ-45 ports
Auto-negotiation
Auto-MDIX
CATV Female F-connector
Wavelength: 1550 nm, 47 ~ 870 MHz
Power Supply 12 VDC @ 1.5 A

16
Safety Warnings
• Do NOT use this product near water, for example, in a wet basement or near a
swimming pool.
• Do NOT expose your device to dampness, dust or corrosive liquids.
• Do NOT store things on the device.
• Do NOT install, use, or service this device during a thunderstorm. There is a
remote risk of electric shock from lightning.
• Connect ONLY suitable accessories to the device.
• Do NOT open the device or unit. Opening or removing covers can expose you
to dangerous high voltage points or other risks. ONLY qualified service per-
sonnel should service or disassemble this device. Please contact your vendor
for further information.
• Make sure to connect the cables to the correct ports.
• Place connecting cables carefully so that no one will step on them or stumble
over them.
• Always disconnect all cables from this device before servicing or disassem-
bling.
• Use ONLY an appropriate power adaptor or cord for your device.
• Connect the power adaptor or cord to the right supply voltage (for example,
110V AC in North America or 230V AC in Europe).
• Do NOT allow anything to rest on the power adaptor or cord and do NOT place
Operation
Temperature
0º C ~ 45º C
Storage
Temperature
-30º ~ 60º C
Operation Humidity < 95% RH
Storage Humidity < 95% RH
Safety EN60950 -1
EMI FCC Part 15 Class B, CE-EMC Class B
Feature Specification

17
the product where anyone can walk on the power adaptor or cord.
• Do NOT use the device if the power adaptor or cord is damaged as it might
cause electrocution.
• If the power adaptor or cord is damaged, remove it from the power outlet.
• Do NOT attempt to repair the power adaptor or cord. Contact your local vendor
to order a new one.
• Do NOT remove the plug and plug into a wall outlet by itself; always attach the
plug to the power supply first before you insert it into the wall.
• Do not use the device outside, and make sure all the connections are indoors.
There is a remote risk of electric shock from lightning.
• Do NOT obstruct the device ventilation slots, as insufficient airflow may harm
your device.
• Make sure that the cable system is grounded so as to provide some protection
against voltage surges.
Your product is marked with this symbol, which is known as the
WEEE mark. WEEE stands for Waste Electronics and
Electrical Equipment. It means that used electrical and
electronic products should not be mixed with general waste.
Used electrical and electronic equipment should be treated
separately.
Legal Information
Certifications
Federal Communications Commission (FCC) Interference
Statement
This device complies with Part 15 of FCC rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that
may cause undesired operations.
FCC Warning
This device has been tested and found to comply with the limits for a Class A
digital switch, pursuant to Part 15 of the FCC Rules. These limits are designed

18
to provide reasonable protection against harmful interference in a commercial
environment. This device generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this
device in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
CE Mark Warning:
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
Taiwanese BSMI (Bureau of Standards, Metrology and Inspection)
A Warning:
Notices
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
CLASS 1 LASER PRODUCT
APPAREIL A LASER DE CLASS 1
PRODUCT COMPLIES WITH 21 CFR 1040.10 AND 1040.11.
PRODUIT CONFORME SELON 21 CFR 1040.10 ET 1040.11.
ZyXEL Limited Warranty
ZyXEL warrants to the original end user (purchaser) that this product is free
from any defects in materials or workmanship for a period of up to two years
from the date of purchase. During the warranty period, and upon proof of

19
purchase, should the product have indications of failure due to faulty
workmanship and/or materials, ZyXEL will, at its discretion, repair or replace
the defective products or components without charge for either parts or labor,
and to whatever extent it shall deem necessary to restore the product or
components to proper operating condition. Any replacement will consist of a
new or re-manufactured functionally equivalent product of equal or higher
value, and will be solely at the discretion of ZyXEL. This warranty shall not
apply if the product has been modified, misused, tampered with, damaged by
an act of God, or subjected to abnormal working conditions.
Note
Repair or replacement, as provided under this warranty, is the exclusive
remedy of the purchaser. This warranty is in lieu of all other warranties, express
or implied, including any implied warranty of merchantability or fitness for a
particular use or purpose. ZyXEL shall in no event be held liable for indirect or
consequential damages of any kind to the purchaser.
To obtain the services of this warranty, contact your vendor. You may also refer
to the warranty policy for the region in which you bought the device at http://
www.zyxel.com/web/support_warranty_info.php.
Related Documentation
Please go to http://www.zyxel.com for product news, firmware, documentation,
and other support materials.
Registration
Register your product online to receive e-mail notices of firmware upgrades and
information at http://www.zyxel.com.
Documentation Feedback
Send your comments, questions or suggestions to: [email protected]
Thank you!
The Technical Writing Team, ZyXEL Communications Corp.,
6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 30099, Taiwan.
Copyright
Copyright © 2009 by ZyXEL Communications Corporation.
The contents of this publication may not be reproduced in any part or as a
whole, transcribed, stored in a retrieval system, translated into any language, or

20
transmitted in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, photocopying, manual, or otherwise, without the prior written
permission of ZyXEL Communications Corporation.
Published by ZyXEL Communications Corporation. All rights reserved.
Disclaimer
ZyXEL does not assume any liability arising out of the application or use of any
products, or software described herein. Neither does it convey any license
under its patent rights nor the patent rights of others. ZyXEL further reserves
the right to make changes in any products described herein without notice. This
publication is subject to change without notice.
Trademarks
Trademarks mentioned in this publication are used for identification purposes
only and may be properties of their respective owners.
Customer Support
Should problems arise that cannot be solved by using this manual, you should
contact your vendor. If you cannot contact your vendor, then contact a ZyXEL
office for the region in which you bought the device.
See http://www.zyxel.com/web/contact_us.php for contact information. Please
have the following information ready when you contact an office.
• Product model and serial number.
• Warranty Information.
• Date that you received your device.
• Brief description of the problem and the steps you took to solve it.
How to View a Product’s Certification(s)
• Go to www.zyxel.com.
• Select your product from the drop-down list box on the ZyXEL home
page to go to that product's page.
• Select the certification you wish to view from this page.
