Bluebird Torricol User manual

Piyo Pure Jiyo More
WATER FILTER WITH HOT & COLD DISPENSER
USER MANUAL
Torricol

Dear Valued Customers
Thanks for selecting the Bluebird brand products.More than 3
decades Bluebird is a trusted brand in stabilizer for its quality
products and Services.
We assure you to provide the best quality products in water purifier
too which will match the international standard and also assure for
the quality services.
Please read this manual carefully to know about the product
function, operation and safety measures.
Thank you again for selecting Bluebird Brand of water purifiers.
Best Wishes,
Team Bluebird water Purifier.
Piyo Pure Jiyo More

1
Contents
1). Know your Product ------------------------------------------1
2). How it Functions ---------------------------------------------2
3). Important Instructions---------------------------------------2
4). Installation Instructions-------------------------------------3
5). Technical Specifications------------------------------------4
6). Trouble Shooting---------------------------------------------4
7). Warranty Card------------------------------------------------5
8). Warranty Term & Conditions-------------------------------6
9). Key Features-------------------------------------------------7

Upper Tank
LowerTank
Hot Water Knob
Hot Water
ON/OFF
Switch
ColdWater
ON/OFF
Switch
Know your Product
Tank Cover
PP Filters
Cold Water Knob
Carbon Filters
Mineral Cartridge
Function Indicator
Child Safety Lock
Back
Power Supply Cord
Reset
Button
1

1. Pre filter: It is 8 microne pre filter. When you put water
into upper Tank, the water passes through pre filter which
filters all fine suspended particles from water if any.
2.Double Pre Carbon: After filtration through pre filter water
passes through double pre carbon filter which adsorbs
chlorine & organic impurities like harmful pesticides from
water . It also adsorbs bad taste & odor from water.
3. Mineral cartridge: After carbon filter water goes to 4
stage mineral cartridge which enhance the essential
mineral composition in water.
1. Do not Power on in case there is no water in Tank.
2. Use only Municipal water.
3. Keep the tank close with lead.
4. Keep the Hot water safety switch off all the time to avoid
any injury to child.
5. Wash the sediment filter at least once in a week.
6. Do not use any detergent or chemical for washing
sediment mesh filter.
How it Functions
Important Instructions
2

1.Take out your Torricol water filter with Hot & Cold water
dispenser from the packaging.
2. Wash the carbon filter for 4-5 minutes to release the color of
carbon if any.
3. Fix the minerals cartridge in the groove of the upper tank
where pipe fitting connection is available . In other 2 grooves, fix
the Carbon Filters. Fix one end of pipe in the bottom of both the
carbon filters and other end at the pipe fitting connections which
are fixed with mineral cartridge fixing groove.
4. Insert the upper tank into lower tank.
5. Pour Municipal water into upper tank upto the water level mark.
6. Close the tank with lid.
7. Wait for two minutes till water comes in the lower tank after
filtration & mineralization.
8. Keep Torricol product in dry & clean place where three plug
electricity power point is available.
9. Insert the power plug into power socket.
10. Before turning on the main power supply, switch off the Hot &
cold water tank power switch. which is in the back of the machine.
11. Before Plugging on the main power suppply, check that water
availability into the Hot & Cold water tank by pushing the both tap
button.
12. First time , Plug the main power switch on only when water is
available in both the tank. If water is available in tank, switch on
the main power supply & Switch on both the button behind the
machine.
13. After 4-5 minutes,enjoy Hot water & after10-15 minutes,
enjoy purified cold water.
Installation Instructions
3

Filter Life ------------------------------
Hot Tank-------------------------------------2 ltrs (Steel Tank)
Cold water---------------------------------- 08 ltrs (ABS Tank)
Filter Cartridge-----------------------------Carbon 2 unit only
Mineral Cartridge
Heating Time -------------------------------10-15 Minutes upto 98 C
Cooling time -------------------------------15-20 Minutes upto15 C
Input voltage--------------------------------220V AC 50 Hz
4000 ltrs.(Max.) 500 times filling
Storage Tank Capacity------------------- 8 ltrs.
------------------------------ 1 unit (4 Stage)
Technical Specifications
Trouble Shooting
No Hot water
Problem Reason Remedies
1.No Power supply
2. Heating Switch Off
3. Reset button off
1.Check main power
Supply on
2. Check Heating
Switch on
3. Push the reset Button
Safety lock closed Open safety Lock
Sediment PP Filter
Choked Wash Sediment Filter
Electric Cooling
Not Working Contact Company
Per Filling 8 Ltrs.
4
No hot water Coming
No water filtration
No Cold Water

5
Warranty Card
Product Serial No.:
Customer Details
Customer’s Name____________________________
Customer’s Address__________________________
__________________________________________
Customer’s Ph.No.___________________________
Warranty Details
Name of the Dealer with Address_________________
___________________________________________
Invoice No.& Date_____________________________
Torricol
Dealer’s Signature with Stamp

Torricol water filter with hot & cold water dispenser is having
warranty of one year from the date of purchasing under
below mention terms & condition:-
1. No warranty on sediment filter (PP Mesh Filter)
2. One year warranty on carbon filter and mineral cartridge
when 4000 (Four thousand only) liters of water is used in a
year.If more than 4000 liters of water is used, there is no
warranty on carbon filter mineral cartridge.
3. The warranty on heating and cooling system is for one
year from date of purchase only when the desired power
supply involtage has been given.
4. No any warranty on plastic part of body including water
storage tanks.
5.The warranty will be void if the machine has been opened
by any person other than the authorised company
technician.
6.Warranty is void on electrical parts if it is burnt due to
high voltage.
6
Warranty Terms & Conditions

1. 3 stage filtration.
2. 4 stage mineralization.
3. All time pure instant hot water for tea coffee making,
preparing milk for babies and for drinking purpose.
4. All time pure cold water for drinking .
5.Safety child lock to prevent child for burning by hot water.
6. Temperature sensor to avoid burning of tank due to no
water & high voltage.
7
Key Features
Piyo Pure Jiyo More

Marketed by
Bluebird Water Purifiers
70, Rajasthani Udyog Nagar
G.T. Karnal Road, Delhi-110033
www.bluebirdwaterpurifiers.com
Toll Free No. : 1800113911
