Bobrick B-828 User manual

Troubleshooting Guide
for Bobrick B-828 SureFlo®Automatic, Top Fill Bulk Foam Soap Dispenser
Step 1: To determine cause: Unplug unit and reconnect unit look for Green LED light and sound of motor. Activate soap dispenser continually ve times.
Unit Not Dispensing
If motor running and LED does not light up consistently when hand is in the activation zone.
Likely Cause Action Instruction Replacement
Part/Kit Needed
Fiber Optic Nut may be thread
too tight onto connector port in
the Bottom Housing.
Check Fiber Optic Nut to see if nut has
been overtightened
Tighten Fiber Optic Connector Nut hand tight and then rotate nut
counterclockwise by 1/4 turn (90°).
n/a
No change. All steps above completed. Contact Bobrick Customer Service. n/a
If motor running and LED lights up.
Likely Cause Action Instruction Replacement
Part/Kit Needed
Clogged Nozzle Tip. Remove Nozzle Tip. Clean with warm water and replace. Flush whole system. If Nozzle
continutes to be clogged replace.
828-310
Soap may be too viscous. Ensure that soap meets specified
viscosity range.
Viscosity less than 100cps (CPS = center-
poise) Adjust viscosity and Flush system.
Flush whole system. Replace with soap that is within recommended
viscosity range.
n/a
If unit requires multiple (more
than 5) activations to dispense
foam. Duckbill inside Foam
Mixer Housing may be stuck
open.
Flush whole system. If still requires multiple activations, order new Foam Mixer Housing. 828-322
No change. All steps above completed. Contact Bobrick Customer Service n/a
If motor not running and LED lights up.
Likely Cause Action Instruction Replacement
Part/Kit Needed
Issue with Power Source this
is determined by Flasing RED
LED.
Check batteries. Check A/C adapter
connection.
Replace with new batteries. Reconnect A/C adapter connection. If
problem persists, send unit back to manufacturer.
n/a
Gear jamming. Check for dried soap. Purge system. Open Cover and pour warm water and then purge. n/a
Flashing red LED. Indicates
sensor obstruction.
Ensure all obstructions have been
removed from sensor path.
Refer to mounting template. 824-307
No change. All steps above completed. Contact Bobrick Customer Service n/a
If motor not running No LED light.
Likely Cause Action Instruction Replacement
Part/Kit Needed
No power to the unit Replace with new batteries. Check A/C
adapter connection.
If problem persists, send unit back to manufacturer. n/a
No change. All steps above completed. Contact Bobrick Customer Service n/a
Unit Leaking
Likely Cause Action Instruction Replacement
Part/Kit Needed
Loose Stem connection to
Bottle Cap.
Unscrew Stem Locking Nut. Push the Bottle Assembly up onto the Stem until it stops. While pushing
upwards on the Bottle, thread the Stem Locking Nut down onto the
Bottle Cap threads. Reference Instruction Sheet 828-391.
n/a
Leaking from bottom of Bottom
Housing.
Locate leak if from bottom of Bottom
Housing.
Unit needs to be returned. Replace with Bottom Housing Replacment Kit. 828-550
Soap
Likely Cause Action Instruction Replacement
Part/Kit Needed
Foam Soap too Airy. Adjust portion control knob. Also check
Nozzle Tip Mesh Screen.
Turn knob clockwise for less air in foam. Clean Mesh Screen and /or
replace.
828-310
Foam Soap too Liquidy/
Watery.
Adjust portion control knob. Also check
Nozzle Tip Mesh Screen.
Turn knob counter clockwise. If Mesh Screen is torn replace. 828-310

Parts List:
Item Description
1 Top Assembly with Spout, Door and Stem
2 LED Light Pipe
3 Foam Nozzle Tip with Mesh
4 Fiber Optic Insert with Sensor Lenses
5 Rubber Counter Gasket
6 Wave Washer
7 Mounting Nut
8 Stem Locking Nut
9 Foam Mixer Housing
10 Bottom Housing Assembly (includes Soap
Bottle)
11 Optional: Battery Pack (requires (4) “D” cell
alkaline batteries not included), order Part No.
824-241. For outlets not compatible with U.S.
plugs, order Part No. 3974-58
12 (3) Fiber Optic Cables for Sensor and LED
Light Pipe
13 Fiber Optic Connector Tip Assembly
14 Fiber Optic Nut
15 Portion Control Knob
16 Automatic System Flush Button
17 Key Hole
18 BobKey
19 Air Tube Adapter
20 Air Tube
21 A/C Adapter Kit with U.S. Plug
For outlets not compatible with U.S. plugs, order
Part No. 3974-58

In the U.S.A.: BOBRICK WASHROOM EQUIPMENT, INC.
200 Commerce Drive, Clifton Park, New York 12065-1350 • Tel: [phone] • FAX: [phone]
11611 Hart Street, North Hollywood, California 91605-5882 • Tel: [phone] • FAX: [phone]
or email [email protected]
In Canada: BOBRICK WASHROOM EQUIPMENT COMPANY
45 Rolark Drive, Scarborough, Ontario M1R 3B1 • FAX: [phone]
© 2020 by Bobrick Washroom Equipment, Inc.
Form No. TSG-B-828 Issued 11/10/20 Printed in U.S.A.
Replacement Parts List
Description Part #
A/C Adapter 3974-57
International AC Adapter Plug Kit (U. K., Europe, Australia) 3974-58
Mack Gasket Kit (To secure Top Assembly under the counter due to
irregular counter surface)
824-167
External A/C Multi Adapter Kit 828-201
Nozzle Tip Replacement Kit Foam 828-310
D Size Battery Pack (Batteries not included) 824-241
Foam Mixer Housing 828-322
Installation Hardware Packet with Foam Mixer Housing (Includes Wave
Washer, Counter Gasket, Mounting Nut, BobKey, Stem Locking Nut)
828-443
Top Housing Assembly Foam (Includes Installation Hardware Packet
and Foam Mixer Housing)
828-525
Bottom Housing Assembly Foam 828-550
Recommended Foam Soaps
Kutol Foaming Luxury Hand Soap
Kutol Foaming Antibacterial Handsoap
Chemcor Foaming Antibacterial Handsoap
State Chemical Gentle Fresh Foaming Hand Soap
State Chemical Gentle Fresh Defense Foaming Antibacterial Hand Soap
SCJ Professional - Refresh Azure Foam
Hillyard Cucumber-Melon, Premium Foam Soap
Hillyard Green Select, Foaming Hand Soap
Total Solutions, Green Apple Foam Soap
Novo Antibacterial Foaming Hand Soap, Lemon Scented
Spartan Lite'n Foamy, Citrus Fresh
Germ-X Antibacterial Foaming Hand Wash
Germ-X Green Foaming Hand Soap
Betco Pink Foaming Skin Cleanser
BETCO Green Earth Clear Foaming Skin Cleanser
Enviro-Chem Foam Care Hand Soap
DAYCON Foaming Hand Soap
