USER MANUAL
Torriozo
WATER FILTER WITH HOT WATER DISPENSER
&
OZONISATION CABINET

Dear Valued Customers
Thanks for selecting the Bluebird brand water purifier
products.More than 3 decades Bluebird is a trusted brand in
stabilizer for its quality products and Services.
We assure you to provide the best quality products in water purifier
too which will match the international standard and also assure for
the quality services.
Please read this manual carefully to know about the product
function, operation and safety measures.
Thank you again for selecting Bluebird Brand of water purifiers.
Best Wishes,
Team Bluebird water Purifier.
Piyo Pure Jiyo More

1
Contents
1). Know your Product ------------------------------------------1
2). How it Functions ---------------------------------------------2
2 Important Instructions---------------------------------------2
3). Installation Instructions-------------------------------------3
5). Technical Specifications------------------------------------4
6). Trouble Shooting---------------------------------------------4
7). Warranty Card------------------------------------------------5
8). Warranty Term & Conditions-------------------------------6
Key Features-------------------------------------------------7
Child Safety Lock
10).

Know your Product
Tank Cover
Upper Tank
LowerTank
Hot Water Knob
PP Filters
Filter Water Knob
Carbon Filters
Mineral Cartridge
Function Indicator
Child Safety Lock
Hot Water
ON/OFF
Switch
ColdWater
ON/OFF
Switch
Back
Power Supply Cord
Reset
Button
1
Ozonoe Generator
Ozonoe Generator
Control knob
sterlization
cabinet

1. Pre filter: It is 8 micron pre filter. When you put water into
upper Tank, the water passes through pre filter which filters
all fine suspended particles from water if any.
2.Double Pre Carbon: After filtration through pre filter water
passes through double pre carbon filter which adsorbs
chlorine & organic impurities like harmful pesticides from
water . It also adsorbs bad taste & odor from water.
3. Mineral cartridge: After carbon filter water goes to 4
stage mineral cartridge which enhance the essential
mineral composition in water.
1. Do not Power on in case there is no water in Tank.
2. Use only Municipal water.
3. Keep the tank close with lead.
4. Keep the Hot water safety switch off all the time to avoid
any injury to child.
5. Wash the PP filter at least once in a week.
6. Do not use any detergent or chemical for washing
sediment mesh filter.
How it Functions
Important Instructions
2

1.Take out your Torriozo water filter with Hot water & sterilizing cabinet
dispenser from the packaging.
2. Wash the carbon filter for 4-5 minutes to release the color of carbon.
3. Fix the minerals cartridge in the groove of the upper tank where pipe
fitting connection is available . In other 2 grooves, fix the Carbon
Filters. Fix one end of pipe in the bottom of both the carbon filters and
other end at the pipe fitting connections which are fixed with mineral
cartridge fixing groove.
4. Insert the upper tank into lower tank.
5. Pour Municipal water into upper tank upto the water level mark.
6. Close the tank with lid.
7. Wait for two minutes till water comes in the lower tank after filtration
& mineralization.
8. Keep Torricol product in dry & clean place where three plug
electricity power point is available.
9. Insert the power plug into power socket.
10. Before turning on the main power supply, switch off the Hot water
tank power switch. which is in the back of the machine.
11. Before Plugging on the main power suppply, check that water
availability into the Hot & Cold water tank by pushing the both tap
button.
12. First time , Plug the main power switch on only when water is
available in hot tank. If water is available in tank, switch on the main
power supply & Switch on the button behind the machine.
13. After 10-15 minutes,enjoy Hot water for drinking,making tea/
coffee & preparing milk for your baby.
14. You may keep cup & saucers glass, baby milk bottle and other
untensil in sterilization cabinet.
15. Turn ozone generator control knob clockwise to start sterilizing
process to get bacteria free sterilized utensils.
Installation Instructions
3

Filter Life ------------------------------ 4000 ltrs.(Max.) 500 times filling
Storage Tank Capacity---------------10* ltrs.
Hot Tank-------------------------------- 2 ltrs (Steel Tank)
Ozonisation cabinet------------------ 8.5 ltrs
Filter Cartridge------------------------Carbon 2 unit only
Mineral Cartridge------------------------ 1 unit (4 Stage)
Heating Time --------------------------10-15 Minutes upto 98 C
Ozone generator capacity-----------20mg/h
For sterilization
Input voltage---------------------------220V AC 50 Hz
Technical Specifications
Trouble Shooting
No Hot water
Problem Reason Remedies
1.No Power supply
2. Heating Switch Off
3. Reset button off
1.Check main power
Supply on
2. Check Heating
Switch on
3. Push the reset Button
Safety lock closed Open safety Lock
Sediment PP Filter
Choked Wash Sediment Filter
2. Contact Company
Per Filling 8 Ltrs.
4
No hot water Coming
No water filtration
No strelization
1. Ozone generator
knob off
2. Ozone generator
not functioning
1. Turn on Ozone
generator knob

5
Warranty Card
Product Serial No.:
Customer Details
Customer’s Name____________________________
Customer’s Address__________________________
__________________________________________
Customer’s Ph.No.___________________________
Warranty Details
Name of the Dealer with Address_________________
___________________________________________
Invoice No.& Date_____________________________
Torriozo
Dealer’s Signature with Stamp

Torriozo water filter hot water with strelization cabinet
dispenser is having warranty of one year from the date of
purchasing under below mention terms & condition:-
1. No warranty on sediment filter (PP Mesh Filter)
2. One year warranty on carbon filter and mineral cartridge
when 4000 (Four thousand only) liters of water is used in a
year.If more than 4000 liters of water is used, there is no
warranty on carbon filter mineral cartridge.
3. The warranty on heating system and ozone generator is
for one year from date of purchase only when the desired
power supply in voltage has been given.
4. No any warranty on plastic part of body including water
storage tanks.
5.The warranty will be void if the machine has been opened
by any person other than the authorised company
technician.
6.Warranty is void on electrical parts if it is burnt due to
high voltage.
6
Warranty Terms & Conditions

1. 3 stage filtration.
2. 4 stage mineralization.
3. All time pure instant hot water for tea coffee making,
preparing milk for babies and for drinking purpose.
4. Sterilization cabinet to protect your utensils,crockeries
and baby feeding bottle from bacteria and virus through
ozonisation.
5. Sterilization control knob to control the ozone generating
as per requirement.
6. Temperature sensor to avoid burning of tank due to no
water & high voltage.
7
Key Features
Piyo Pure Jiyo More

Marketed by
Bluebird Water Purifiers
70, Rajasthani Udyog Nagar
G.T. Karnal Road, Delhi-110033
www.bluebirdwaterpurifiers.com
Toll Free No. : 1800113911
