Blueshape BMBP9 Series User manual

Li-Ion Battery Pack
The battery packs are equipped with built-
in safety/protection features. Should these
features be compromised in any way what
so ever, the battery pack may leak corrosive
chemicals, overheat, emit smoke, burst and/
or ignite.
Danger
1. Do not disassemble or modify the battery pack.
2. Do not connect the positive (+) and negative (-) terminals to
a metal object such as a wire. Do not transport or store the
battery pack together with metal objects without adequate
insulation.
3. Do not discard the battery pack into re or heat.
4. Do not use or leave the battery pack near a heat source such
as a re or a heater (> 80°C).
5. Do not immerse the battery pack in uids, water or seawater
and do not allow it to get wet.
6. Do not recharge the battery pack near re or in extremely hot
environments.
7. To recharge the battery pack, use the battery charger spe-
cically designed for the device and observe the recharging
conditions specied by the maker of the charger.
8. Do not pierce the battery pack with pointed or other sharp
objects.
9. Do not strike it with blunt objects.
10. Do not subject to excessive mechanical loads or shocks, such
as by striking or throwing the battery pack.
11. Do not use an apparently damaged or deformed battery pack.
12. Do not directly solder the battery pack.
13. Do not reverse the positive (+) and negative (-) terminals, dur-
ing charging, operation or otherwise.
14. Do not force the connection if you may not easily connect the
battery pack terminals to the battery pack charger or other
equipment. Conrm that the terminals are correctly oriented.
15. If the battery pack leaks, and the electrolyte reaches the eyes,
do not rub them. Instead, rinse the eyes with clean running
water and immediately seek medical attention. Failure to do
this may result in eye injury.
Warning
1. Do not use the battery pack for other purposes other than
those specied. Otherwise, its guaranteed performance will
be lost and/or its service life will be shortened.
2. If recharging operation fails to complete even when a spec-
ied recharging time has elapsed, immediately stop further
recharging.
3. Do not subject to excessive micro-wave radiation.
4. Do not subject to excessive ambient pressures.
5. If the battery pack gives o󰀨 an odour, generates heat, be-
comes discoloured or deformed, or in any way appears abnor-
mal during use, recharging or storage, immediately remove it
from the equipment or battery pack charger and stop usage
immediately.
Caution
1. Do not use or subject the battery pack to intense sunlight or
hot temperatures such as in a car in hot weather.
2. Do not use it in a place where high static electricity may be
present.
3. The guaranteed operating temperature range is 0°C to 40°C.
4. If electrolyte leaking from the battery pack contacts your skin
or clothing, immediately wash it away with running water. Fail-
ure to do this may result in skin inammation.
5. Keep out of reach of children.
6. If you nd discolouration, a bad odour due to leakage, over-
heating and/or other irregularities when using the battery pack
for the rst time return it to your supplier or vendor.
7. Do not store battery packs on chargers or idle equipment
Charging Battery Packs with CMDUAL
Danger
1. The charger is intended for specic Li-Ion batteries only. Do
not use with other battery chemistries or with incompatible
battery mounts.
Warning
1. Improper use of the charger might cause electric shock, do not
disassemble charger.
2. Charger for indoor use only.
3. Do not subject charger to excessive mechanical loads or
shocks, such as by dropping it.
4. The guaranteed recharging temperature range is 0°C to 40°C.
A recharging operation outside this temperature range may
lead to damage to the battery pack.
5. Do not expose to excessive direct sunlight.
6. Do not cover charger during use.
1. Overview
CMDUAL is equipped with two congurable battery bay slots, AC/
DC input , a USB output and an LCD Display. Note that their func-
tionality varies with the scenario’s listed in the following sections.
Mode Select
LCD Display
AC Input
DC Input
Battery Plate Slot
Battery Plate Slot
2. Plate Installation
1. Attach desired plates to the slots ensuring correct mating and
locking of plate in its slot.
2. You may use di󰀨erent charging voltages, at the same time,
with some limitations. Refer to the table below.
Input
DC 24V
DC 12V
AC
Dual 8.4V 1x 8.4V &
1x16.8V
Dual 16.8V
Plate Combination
3. Operation
1. Take note that functionality varies with the power input and
the selected mode.
2. The LCD Display will show the actual battery capacity in per-
centage.
Charger Performance
Single Dual USB
High
Power 1500mA 800mA ✖
H
Low
Power 1000mA 500mA ✔
2100mA
L
Mode

BMBP955 Replaces Canon BP-955
Main Features:
• Charge Indicator (4-Step LED)
• Battery Data Communication with RED®KOMODO™
• High Capacity
Operation:
• The LED charge indicator will show the battery’s state of charge.
Each LED indicates a state of charge increment of 25%. When the
rst LED ashes, this indicates that capacity is at 10% or less. During
charging, the LED charge indicator will show the actual state of charge
with the top-most LED blinks slowly.
• When using with RED®KOMODO™and the battery capacity approach-
es a critical state of charge (≤ 3%), the battery alerts the camera to
initiate an emergency shut down to safeguard your data.
Specications:
Nominal Voltage: 7.2V
Nominal Capacity: 5000mAh - 36Wh
Size: 39 x 70 x 43 mm
1.53x2.75x1.69 in
Weight: 212g
BMBP975 Replaces Canon BP-975
Main Features:
• Charge Indicator (4-Step LED)
• Battery Data Communication with RED®KOMODO™
• High Capacity
Operation:
• The LED charge indicator will show the battery’s state of charge.
Each LED indicates a state of charge increment of 25%. When the
rst LED ashes, this indicates that capacity is at 10% or less. During
charging, the LED charge indicator will show the actual state of charge
with the top-most LED blinks slowly.
• When using with RED®KOMODO™and the battery capacity approach-
es a critical state of charge (≤ 3%), the battery alerts the camera to
initiate an emergency shut down to safeguard your data.
Specications:
Nominal Voltage: 7.2V
Nominal Capacity: 7500mAh - 54Wh
Size: 39 x 70 x 61 mm
1.53x2.75x2.75 in
Weight: 293g
NEW CELL TOP Srl VIA LIGURIA 4-6, 42124 REGGIO EMILIA, ITALY TEL. [phone] FAX. [phone] WEB: www.blueshape.net EMAIL: [email protected]
DV PowerPacks
BMBP9 Series
Li-Ion Batteries for Camcorders, On-Camera
Lights and Accessories
Revision 1.0C www.blueshape.net Printed in Malta 2020
USER MANUAL
Warranty Information
BLUESHAPE batteries are warranted to be free from defects in materials, workmanship and functionality for a period
of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that
have been subjected to misuse, negligence, accidental or abnormal conditions of operation. The buyer should always
contact the place of purchase for any return of defective product. It is important that the buyer provides us with as much
information as possible about the failure being claimed. In the event of product failure for which warranty applies, we will
repair or replace the product free of charge.
In these cases, all expenses including transport charges will be borne by us.
In the case where the failure has been caused by one of the causes explained above, repairs would be billed at a
nominal cost. Prior to the carrying out of any repairs, we will inform the customer of the estimated costs of these
repairs. These warranty conditions are the only ones applicable to our products and overrule any other expressed or
implied warranties. We shall not be held liable for any damages resulting from warranty statements other than those
contained in this declaration.
This warranty is not transferable and is only applicable to the original buyer. In all warranty claims, the buyer must
reproduce the original purchase invoice.
CMDUAL Charger + CMAD975 Plate
Main Features
• Dual Bay Simultaneous Chargin
• LCD Display
• USB Output
• Includes Automobile Power Outlet Adapter
and Power Chord
Specications
Charge Voltages: 8.4V,12.6V,16.8V
Power Input: Autot-select AC Mains
100V-240V ~50/60Hz 1500mA (max)
DC 12-24V 3000mA (min)
USB Output: 5V 2100mA
