bluesmart P Series User manual

Integrated/All In One Solar LED Street Light
User Manual
How to turn on our solar street lights?
Installation
P Series
Thank you for choosing P Series Solar Street Light.
For any questions, please email us [email protected].
Please refer to the actual products if the provided diagrams show
slight differences.
Do not remove or dismantle the waterproof connectors or try to
plug in the light as the polarity can go wrong IN CASE OF
DAMAGE OF LIGHT.
Do not open the light fixture by unauthorized persons, can affect
15 second delay for working mode changes. The light will turn
Clean surface of solar panel regular such as dirty leaves, oil. ect,
ensure high photoeletric conversion efficiency.
Please avoid solar panel being shielded by buildings, trees,
working efficiency of solar panel.
℃to 55℃, the
discharging temperature is from -20℃to 60℃, make sure that
ambient temperature is in this range when used, avoid damage
The solar street light will automically lighng at night without any manually
operaon
Solar street light Unit turn on at dusk and turn off at dawn automacally.
If you want to check whether the solar street light Unit are lighng during the
dayme;
* Cover the solar panels with shelters, the lamp will be lighng
Attention to operation
1
2
3
4
5
6
7
8
9
1. Loosen 6pcs M8x16 screws by φ6mm Allen key
2. Fit the lamp into the pole and fix φ6pcs M8*16 screws by 6mm Allen key
1. Loosen M16*45 screws by φ12mm Allen key
2. Adjust bracket by 90°
3. Fit the lamp into the pole with 6pcs M8*16 screws by φ6mm Allen key
φ60 or φ89mm
φ60 or φ89mm
step 1 step 2
step 3
step 1 step 2
Adjustable sleeve
90°
bluesmart
Address: F4, 6th Building, Hengguangyao Industrial Park, Yonghe Road, Heping Village,
Fuyong Street, Bao'an District, Shenzhen City, Guangdong Province, China.
E-mail: [email protected] Website: www.obluesmart.com
Tel: [phone] Fax: [phone]
Notice: Please do not need Press ON button of the small black
remote to turn on the lamp, because our solar street light units
have automatic Activation Function.
Activation:
User Manual
Integrated/All In One Solar LED Street Light

prove that the lamp
How to check if your solar street light is
working properly?
Trouble Shooting
1
2
3
Packing List
Installation Height and Distance
Remark:
Components
Light body
6mm Allen key
12mm Allen key
1pc
1pc
1pc
6pcs
40W-80W Images
User Manual 1pc
Remote 1pc
User Manual
20%
20%
SupperBrightness
L
TSM
U
Power Height of pole Distance between pole
40W 5-6m 23-25m
60W 6-7m 25-28m
80W
100W
120W
150W
180W
7-8m
8-9m
9-10m
10-11m
11-12m
28-30m
30-35m
35-40m
40-45m
45-50m
1No light at night
Check if the solar panel is
solar panel at the night
of interference or change the
Test solar panel voltage
Test solar panel voltage at sunshine.
if the volatge of solar panel lower
Please use solar panel charge the
Put the solar lamp in strong sunshine
lights at night
2
Aserious
shortageof
Check if the surface of the
solar panelis dusty or covered
Clean the surface of solar panels as
Use the remote control to readjust
the working mode to M
Check if the solar panel is
correct or not
3
Check the working mode is
corret or not
Check if the air temperature
temperature
It is recommend to reduce the
Lights fail to turn
on properly when
humans approach
adjust working mode to M or U
when the air temperature us close
temperature changes
too high
Bracket 1pc
Humanize Intelligent Remote Control
Technology
Working Modes
U
M
s
T
L
20%
20%
20%
20%
SupperBrightne ss
L
TSM
U
T
L
20%
20%
LIGHT CONTROL
TIMING CONTROL SUPPER BRIGHTNESS MICRNWAVE CONTROL
TIMING+MICROWAVE -20% +20%
M
U
s
TURN ON THE LIGHT TURN OFF THE LIGHT
M8x16 screws
M16*45 scews 1set
