HEX70CS-KIT QUICK REFERENCE GUIDE
01
Quick Reference Guide
HEX70CS-KITRev 2
Our HEX70CS-KIT HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 HDBaseT™ extender
set oers market leading features and outstanding value utilising CSC technology.
The product extends HDMI,bi-directional IR & RS-232, and bi-directional PoC
(Power over Cable) up to lengths of 70m (4K to 40m).The Transmitter includes a
HDMI loop-out for integrating local displays or cascading onto multiple devices.
The Receiver features simultaneous analogue stereo and digital optical (S/PDIF)
audio breakout.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR support
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p video up to 70m
• Features 1 x HDMI loop-out on HEX70CS-TX for integrating local displays or cascading to multiple devices
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
• HDMI re-clocking on the HDBaseT™ Receiver to help solve HDMI HDCP, compatibility and handshaking issues
• HDMI audio breakout to analogue L/R audio and optical (S/PDIF) digital outputs concurrently
• Supports bi-directional RS-232 pass through
• Supports bi-directional IR pass through
• Supplied with Blustream 5V IR receiver and emitter
• Advanced EDID management
• HDCP 2.2 support

HEX70CS-KIT QUICK REFERENCE GUIDE
02 www.blustream.com.au |www.blustream.co.uk |www.blustream-us.com
Panel Description HEX70CS-RX
Panel Description HEX70CS-TX
1 2
1Mode dip-switch - to switch RS-232 serial port
between pass-through and firmware update mode
2RS-232 / serial connector
3HDBaseT™ input
4HDBaseT™ signal link indicator
5DC 12V/2A screw type connector
6Power status indicator
Side of unit: IR switch - toggle between 5V and 12V IR
qHDMI input - connect to source device
wHDMI input link indicator
eHDMI loop output - connect to display / sink device
rHDMI loop output link indicator
7Optical digital output - de-embedded from HDMI input
8Analogue audio le / right output (3.5mm stereo jack)
de-embedded from HDMI input. Supports stereo 2ch
PCM audio only
9HDMI signal link indicator
qHDMI Output
wIR IN (from Blustream 5V 3.5mm IR receiver)
eIR OUT (to Blustream 5V 3.5mm IR emitter)
3 4 5 6 7 8
1IR switch - toggle between 5V and 12V IR
2EDID DIP switch (UP = 0, DOWN = 1)
3IR OUT (to Blustream 5V 3.5mm IR emitter)
4IR IN (from Blustream 5V 3.5mm IR receiver)
5RS-232 / Serial connector
6USB Upgrade port - For future use
7HDBaseT™ output
8Power status indicator
9DC 12V/2A screw type connector
10 11 12 13
9
1 2 3 4 5 6 7 8 9 10 11 12

contact [e-mail] |[e-mail] |[e-mail]
HEX70CS-KIT QUICK REFERENCE GUIDE
03
For the full HEX70CS-KIT Rev2 User Manual please visit the Blustream website.
Package Contents
Specifications
HEX70CS-KIT
• 1 x HEX70CS-TX and 1 x HEX70CS-RX
• 1 x 12V/2A DC Power Supply
• 1 x IR Emitter (IRE1)
• 1 x IR Receiver (IRR)
• 2 x Mounting Kits
• 1 x Quick Reference Guide
NOTE: Specifications are subject to change without notice. Weights and dimensions are approximate.
HEX70CS-RX (when sold individually)
• 1 x HEX70CS-RX
• 1 x Mounting Kit
HEX70CS-TX (when sold individually)
• 1 x HEX70CS-TX
• 1 x Mounting Kit
HEX70CS-TX
• Video Input: 1 x HDMI Type A, female
• Video Output: 1 x HDBaseT™ RJ45 connector
1 x HDMI Type A, female
• RS-232 Serial Port: 1 x DB9 female connector
• IR Input: 1 x 3.5mm stereo jack
• IR Output: 1 x 3.5mm mono jack
• EDID DIP Switch: 4-pin
• Mounting Kit: Included
• Dimensions excl. Connections (W x D x H):
143mm x 134mm x 22mm
• Shipping Weight (Kit): 0.5 kg
• Power: 12V/2A DC, screw type connector
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
HEX70CS-RX
• Video Input: 1 x HDBaseT™ RJ45 connector
• Video Output: 1 x HDMI Type A, female
• Audio Output: 1 x 3.5mm L/R analogue audio
1 x Optical digital (S/PDIF)
• RS-232 Serial Port: 1 x DB9 female connector
• IR Input: 1 x 3.5mm stereo jack
• IR Output: 1 x 3.5mm mono jack
• Mounting Kit: Included
• Dimensions excl. Connections (W x D x H):
113mm x 124mm x 22mm
• Shipping Weight (Kit): 0.4 kg
• Power: 12V/2A DC, screw type connector
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with
other household wastes. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was
purchased. They can take this product for environmentally safe recycling.
Certifications
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol,
paint thinner or benzene to clean this unit.

HEX70CS-KIT QUICK REFERENCE GUIDE
04 www.blustream.com.au |www.blustream.co.uk |www.blustream-us.com
RevB1_QRG_HEX70CS-KIT
Understanding the Transmitter / Receiver Status Lights
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by
the source to find out what audio and video resolutions are supported by the display. By pre-determining the video resolution
and audio format of the source and display device you can reduce the time needed for EDID hand shaking thus making
switching quicker and more reliable.
Configuration of extender EDID settings can be achieved using the product dip-switches on the HEX70CS-TX. EDID dip-switch
settings are shown below.
EDID Control
The Blustream HEX70CS-KIT extender solutions include status LED indicators on both the Transmitter and Receiver
products to show all connections are active and to help diagnose possible problems.
Receiver:
• The HDMI signal link light will be o when there is no connection with a display / sink
• The HDMI link light will be on when there is an active connection with a display
• The HDBaseT™ link light will be o when there is no CAT cable / active HDBaseT™ connection on the RJ45
HDBaseT ™input
• The HDBaseT™ link light will blink if there is an unstable connection between the Transmitter and Receiver
• The HDBaseT™link light will be lit when a CAT cable is connected to the HDBaseT™RJ45 output on the Transmitter
and an active connection is achieved with the Receiver
Transmitter:
• The Input HDMI signal link light will be o when there is no connection with a source device
• The Output HDMI signal link light will be o when there is no connection with a display / sink
• The Input HDMI link light will be on when there is an active connection with a source device
• The Output HDMI link light will be on when there is an active connection with a display / sink
• The HDBaseT™ link light will be o when there is no CAT cable / active HDBaseT™ connection on the RJ45
HDBaseT™ output
• The HDBaseT™ link light will blink if there is an unstable connection between the Transmitter and Receiver
• The HDBaseT™ link light will be lit when a CAT cable is connected to the HDBaseT™ RJ45 output on the Transmitter
and an active connection is achieved with the Receiver / Matrix
EDID Dip-switches
[DIP]=0000: HDMI 1080p@60Hz, Audio 2ch PCM (default)
[DIP]=0001: HDMI 1080p@60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=0010: HDMI 1080p@60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=0011: HDMI 1080i@60Hz, Audio 2ch PCM
[DIP]=0100: HDMI 1080i@60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=0101: HDMI 1080i@60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=0110: HDMI 4K@60Hz 4:2:0+4K@30Hz 4:4:4, Audio 2ch PCM
[DIP]=0111: HDMI 4K@60Hz 4:2:0+4K@30Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=1000: HDMI 4K@60Hz 4:2:0+4K@30Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=1001: HDMI 4K@60Hz 4:4:4, Audio 2ch PCM
[DIP]=1010: HDMI 4K@60Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP]=1011: HDMI 4K@60Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP]=1100: DVI 1280x1024@60Hz, Audio None
[DIP]=1101: DVI 1920x1080@60Hz, Audio None
[DIP]=1110: DVI 1920x1200@60Hz, Audio None
[DIP]=1111: Copy EDID of output
Global EDID Settings
Dip-switch position ‘0’ = O
Dip-switch position ‘1’ = On
