Bluestream HEX70HDUK-KIT User manual

HEX70HDUK-KIT
User Manual
RevA1_HEX70HDUK-KIT_Manual_151122
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2

HEX70HDUK-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
02
Surge Protection Device
Recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc.
Use of surge protection systems is
highly recommended in order to
protect and extend the life of your
equipment.
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Introduction 03
Features 03
TX Panel Description 04
RX Panel Description 04
Mounting into the HEX70HDUK-TT 05
USB Hosts and USB-C Functionality 06
Front Panel LED’s and Auto Switching 06
EDID Control 06
Automatic System On/O Control 07
Relay Control 07
Infrared (IR) Control 08
CEC Control 08
Terminating CAT Cables for use with HDBT 09
Understanding the HDBaseT™ Status LED’s 09
Schematic 10
Web GUI Control 11-20
IR Commands 21
RS-232 Config & Telnet Commands 22-25
Specifications 26
Package Contents 26
Certifications 27

HEX70HDUK-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 03
The HEX70HDUK-KIT extender set is an industry leading HDMI2.0 4K 60Hz 4:4:4
(18Gbps) HDCP2.2 HDBaseT™ multi-format solution utilising CSC technology to
deliver HDMI, USB-C and DisplayPort™ up to lengths of 40m (70m at 1080p) over a
single CAT cable.
The HEX70HDUK-KIT provides enhanced features including USB 2.0 extension,
local HDMI input on the HDBaseT™ Receiver for additional source input, web-GUI
for control and configuration, auto display control, audio breakout and bi-
directional IR pass-through.
The HEX70HDUK-KIT also features control via front panel, IR, RS-232 and TCP/IP,
PoC (Power over Cable), and advanced EDID and HDCP management.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
• Features 1 x HDMI, 1 x USB-C and 1 x DisplayPort™ input on the HDBaseT™ Transmitter with manual or auto source
selection
• Features 1 x local HDMI input on the HDBaseT™ Receiver for connection of a source local to the display
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p up to a distance of 70m over single CAT cable
• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Supports USB Type C up to 4K UHD 60Hz 4:4:4 DP1.2 with 60W charging capability*
• Supports DisplayPort™ up to 4K UHD 60Hz 4:4:4 DP1.2
• Features 2 x USB-Type A devices (RX - peripherals), 2 x USB-Type A devices (TX - peripherals) and 2 x USB Type-B (TX
- host source specific) that support a combined data transmission bandwidth of up to 250Mbps
• USB Type-A connections support charging of devices up to 500mA when there is an active connection to a Host
device
• Independent USB Type-A connection to support charging only of devices up to 5V 2A
• Audio breakout to analogue L/R audio and Optical digital (S/PDIF) outputs concurrently**
• Bi-directional IR pass-through
• Auto display on/o feature allowing control of display at the HDBaseT™ Receiver via CEC or RS-232
• Web interface module for control and configuration of HEX70HDUK-KIT
• Control via front panel, IR, RS-232 and TCP/IP
• Supports bi-directional PoC (Power over Cable) to power extenders from either transmitter or receiver end
• Advanced EDID ad HDCP management
*USB-C video support is limited to 4K 60Hz 4:2:0 when charging feature is activated by the source device, and where the TX is powered directly from the supplied PSU
**Analogue audio breakout supports 2ch PCM only

HEX70HDUK-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
04
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
TX Panel Description
1Input / Auto select button - press to change source, hold for
3 seconds to enable / disable auto signal sense switching
2Auto switching input indicator
3HDBaseT™ link indicator (to HEX70HDUK-RX)
4Local (TX) HDMI input signal link indicator
5DisplayPort™ input signal link indicator Remote (RX)
6USB-C input signal link indicator
7Remote (RX) HDMI input signal link indicator
8USB Devices - connect to USB devices or peripherals
9USB charging only - max 5V 2A charging
qDisplay - triggers the output on / o sequence (see Display
On / O section)
wPower status indicator
eHDMI input - connect to source equipment
rDisplayPort™ input - connect to source equipment
using a cable capable of carrying video
tUSB-C input - connect to source / Host equipment
(combined video input and USB Host)
yUSB Hosts - connect to USB port of Host devices (USB Host
1 linked to HDMI input, Host 2 linked to DP input)
RX Panel Description
12345 6 789
10 11 12 13 14 15
16 17 18 19
uTCP/IP (RJ45) – connect to LAN for TCP/IP control. Default IP
address of the HEX70HDUK-TX is: 192.168.0.200
iGPIO Port - 3-pin Phoenix connector for input sense/output
relay/contact closure of 3rd party devices
iRS-232 - 3-pin Phoenix connector for RS-232 pass through, or
device control by RS-232 commands
oIR Control Input - 3.5mm stereo connector to connect to
Blustream IR receiver for IR control of the unit
aIR IN (from Blustream 5V 3.5mm IR receiver)
sIR OUT (to Blustream 5V 3.5mm IR emitter)
dPower over Cable (PoC) switch (ON / OFF) - to enable / disable
PoC being sent from the Transmitter
fHDBaseT™ output - connect to HEX70HDUK-RX
gReset HEX70HDUK to default factory / IP settings
hAnalogue L/R Audio Output - Phoenix connector supports
balanced or unbalanced variable analogue audio signals
jOptical Digital Audio Output (S/PDIF)
kEDID DIP switch (UP=0, DOWN=1)
kUSB Upgrade port
lPower port – use included 24V/5A DC adaptor to power the
device
1 2 3 4 5 6 7 8910 11 12 13 14 15 16
1Power status indicator
2HDBaseT™ link indicator (from HEX70HDUK-TX)
3Local HDMI input signal link indicator
4Auto input signal link indicator
5Input / Auto select button - press to change source, hold for
3 seconds to enable / disable auto signal sense switching
6Power over Cable (PoC) switch (ON / OFF) - to enable /
disable PoC being sent from the Receiver
7IR IN (from Blustream 5V 3.5mm IR receiver)
8IR OUT (to Blustream 5V 3.5mm IR emitter)
9RS-232 - 3-pin phoenix connector for RS-232 pass through,
or device control by RS-232 commands
qUSB Upgrade port
wHDBaseT™ input - connect to HEX70HDUK-TX
eHDMI input - connect to local source equipment
rHDMI output - connect to display equipment
tRelays - 3-pin Phoenix connector to allow relay control of a
device such as a projector screen
yUSB Devices - connect to USB devices or peripherals
uPower port - use included 24V/5A DC adaptor to power the
device
20 21 22
23 25 26 27 28 29
24

HEX70HDUK-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 05
Transmitter Mounting into the HEX70HDUK-TT
The HEX70HDUK transmitter can be mounted in the optional HEX70HDUK-TT table top mounting solution.
The HEX70HDUK transmitter is fixed into positon with the video connectors pointing upwards (to the lid of the TT),
There are two internal brackets that are attached to the Transmitter before sliding into the chassis of the TT. As per the
below diagram:

HEX70HDUK-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
06
EDID Control
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source to
negotiate the best audio and video resolutions that are supported in the system. A global EDID of the HEX70HDUK-KIT
can be configured using a combination of DIP switch settings (see below), or using TCP/IP or RS-232 commands.
Global EDID Settings
DIP switch position ‘0’ = O / Up
DIP switch position ‘1’ = On / Down
EDID DIP Switches
[DIP] = 0000: HDMI 1080p @60Hz, Audio 2ch PCM (default)
[DIP] = 0001: HDMI 1080p @60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 0010: HDMI 1080p @60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 0011: HDMI 1080i @60Hz, Audio 2ch PCM
[DIP] = 0100: HDMI 1080i @60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 0101: HDMI 1080i @60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 0110: HDMI 4K @60Hz 4:2:0, Audio 2ch PCM
[DIP] = 0111: HDMI 4K @60Hz 4:2:0, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 1000: HDMI 4K @60Hz 4:2:0, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 1001: HDMI 4K @60Hz 4:4:4, Audio 2ch PCM
[DIP] = 1010: HDMI 4K @60Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 1011: HDMI 4K @60Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 1100: DVI 1920x1080 @60Hz, Audio None
[DIP] = 1101: DVI 1920x1200 @60Hz, Audio None
[DIP] = 1110: EDID Passthrough
[DIP] = 1111: Soware Controlled EDID (set EDID via TCP/IP or RS-232)
USB Hosts and USB-C Functionality
The HEX70HDUK-TX features a USB3.0 hub for pass-through and switching alongside the peripheral devices and/
or video connected at the transmitter. USB Host 1 is paired to the swithcing of HDMI input1, USB Host 2 is paired
with the DIsplayPort input, whilst the USB-C connection allows for both video and data switching to be handled
simultaneously. The unit also allows for USB2.0 pass-through (up to a combined maximum data rate of 250Mbps) from
devices connected to the HEX70HDUK-RX over HDBaseT™.
The USB-C input supports a full 18Gbps 4K 60Hz 4:4:4 video signal. It also supports up to 60W charging, however, when
charging is activated, video bandwidth is automatically limited to 10Gbps and maximum resolution up to 4K 60Hz 4:2:0
video signals. Please note: the TX needs ot be powered directly from the PSU for USB-C charging.
Front Panel LED’s and Auto Switching
The HEX70HDUK-KIT includes LED indicator lights to identify what input is selected. On the Transmitter if an input LED
is solid then it is the selected source and in manual switching mode, if it is flashing then the unit is in auto switching
mode. On the Receiver, there is an input LED for showing whether remote HDBT or local HDMI source is selected, as
well as a dedicated LED indicator that will be solid if auto switching mode is enabled hence the RX LED’s will not flash.
Auto-switching is enabled by default on both Transmitter and Receiver. When enabled, if a source is disconnected, the
HEX70HDUK-KIT will go back to the previously active input, and if the previously active input isn’t available it will find
the next active input starting from input 1 to input 4.
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232
IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADE
OPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF

HEX70HDUK-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 07
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0
1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
Automatic System On/O Control
The HEX70HDUK is designed to help automate basic control of AV equipment within a room without the need for a
3rd party control system. It can control devices via RS-232 and from the relay outputs. The key function is to turn the
system on when a new video signal is sensed, and turn it o when that signal is lost.
Configuration of this functionality can be completed via RS-232. See the RS-232 Configuration and Telnet Commands
section at the rear of this manual for additional information and command API.
System On:
When the HEX70HDUK detects video signal (via TMDS or 5V), the system will start and automatically perform the
following actions at the same time:
• Send RS-232 On Command, then delay (between 1~180s, default 3s), then send user defined RS-232 command
once configured via RS-232
• Toggle the state of relay 1 for a predetermined time (enabled by default, between 3~180s, default 10s, 0 is always
open while the unit is on)
Please note: when setting video signal trigger to TMDS or 5V, please ensure the System On and System O settings
match, or the feature may not operate correctly.
System O:
When the controller detects the video signal is lost, and does not receive a signal sense trigger within the delay time
(between 5~180mins, default 10mins), the system will turn o and automatically perform the following actions:
• Send RS-232 O Command, then delay (between 1~180s, default 3s), then repeat the command once configured
via RS-232
• Toggle the state of relay 2 for a predetermined time (enabled by default, between 3~180s, default 10s, 0s will turn
o when the unit turns stops sensing)
Relay Control
The HEX70HDUK-RX features relay control to trigger external devices when a HDMI signal is sensed or lost.
By default when the unit is turned on or o, both relay 1 and 2 will open for 10 seconds and then close aerwards.
• For Relay 1, the delay time can be set to 0 seconds which will keep the relay open when the unit is turned on, and
close the relay when the unit is turned o
• Relay 2 does not have this feature
For relay API commands, please see the RS-232 Configuration and Telnet Commands section at the rear of this manual.
MOTORISED PROJECTOR SCREEN
12V
TRIGGER
POWER
SUPPLY
5V/12V

HEX70HDUK-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
08
The Blustream range of extender products include source switching control via IR.
IMPORTANT: Blustream Infrared products are all 5V and NOT compatible with alternative manufacturers
Infrared solutions. When using third party 12V IR control solutions please use the Blustream IRCAB cable for IR
conversion.
IR Receiver - IRR
Blustream 5V IR receiver to receive
an IR signal for control of the
extender.
IR Control Cable - IRCAB (not supplied)
Blustream IR Control cable 3.5mm Mono to
3.5mm Stereo for linking third party control
solutions to Blustream products.
Compatible with 12V IR 3rd party products.
Please Note: cable is directional as
indicated.
IR Receiver - Stereo 3.5mm
Infrared (IR) Control
Signal
5V
Ground
The HEX70HDUK features CEC control of source devices and displays via the products web GUI, TCP/IP and RS-232. It is
possible to send CEC commands such as power on / o, input selection, as well as volume up or down.
Please see the Telnet & RS-232 command list at the end of this document for a full list of CEC commands available.
Please note: CEC is subject to the support of standardised codes for the sources and displays connected to the
extender.
CEC Control

HEX70HDUK-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 09
Terminating CAT Cable for use with HDBaseT™
It is important that the interconnecting CAT cable between Blustream HDBaseT™ products is terminated using the
correct RJ45 pin configuration. The link CAT cable MUST be a ‘straight’ (pin-to-pin) CAT cable, and it is advised that this
is wired to the T568B wiring standard as this format is less prone to EMI (Electro-Magnetic Interference).
When installing CAT cables it is advised that you use the best possible CAT cable quality. HDMI distribution products
will only work if used with CAT5e standard cable or above. Blustream recommends using a CAT6 cable (or better) for
installations, especially when running longer distances, in areas of high EMI, or for 4K signal distribution. It is advised
that using any method of patch panel, wall plate, or join within the CAT cable is avoided as these can add degradation
to the signal. Blustream also recommend using RJ45 connectors that are recommended for use with the choice of CAT
cable.
RJ45 Wiring -
T568B
Understanding the HDBaseT™ Status LED’s
The extender includes status LED indicators on the HDBaseT™ RJ45 ports to show all connections are active, and to
help diagnose potential connectivity issues.
Understanding the Status Lights - HEX70HDU-KIT:
• The yellow HDBaseT™ status link light will be OFF when there is no HDBaseT™ link established with the Blustream
HDBaseT™ receiver
• The yellow HDBaseT™ status link light will be ON when there is a HDBaseT™ link established with the Blusream
HDBaseT™ receiver
• The green HDBaseT™ link light will be OFF when there is no video signal being transmitted between the HDBaseT™
Transmitter and HDBaseT™ receiver
• The green HDBaseT™ link light will be ON when a there is a HDCP enabled video signal being transmitted between
the HDBaseT™ Transmitter and HDBaseT™ receiver
• The green HDBaseT™ link light will BLINK when there is a video signal with no HDCP being transmitted between the
HDBaseT™ Transmitter and HDBaseT™ receiver
The link lights will only serve as an indication to the connectivity between the HDBaseT™ transmiter and receiver units.
The LED’s will not indicate a termination, bandwidth, interference or cable length issues on a CAT cable run. Blustream
always recommend qualifying / verifying / certifying a CAT cable run for suitability prior to the installation of HDBaseT™
equipment.

HEX70HDUK-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
10
Schematic
RS-232 HDMI Infrared Cat 6 USB USB-C DisplayPort™ Analogue Audio Digital Audio
HEX70HDUK-KIT Example Schematic
A
C
D E
B
HDMI RS-232 IR PoC
A
B
C
D
USB
E
Projector
Screen
Projector
Amplier
Speakers
Network Switch
Control Processor
Speakers
USB DEVICES

 
Amplier
HDMI, DP & USB SOURCES
Local
Source
HDBaseT™ 1080p up to 70m | 4K up to 40m
INPUT / AUTO AUTO USB-C HDMI RXHDMI DP
DISPLAY HDMI IN DISPLAY PORT IN 1 -USB HOST -2
CHARGINGUSB DEVICES
1 2
USB-C IN
TCP/IP GPIORESET RS-232 IR OUTIR INIR CTRL
0 1
ON OFF
PoC
24V 5A
EDID UPGRADEOPTICAL OUT
1
L+ R+L-R-
2 TX RX
AUDIO OUTHDBT OUT
HDBT HDMI AUTO
INPUT / AUTO
IR IN IR OUT RS-232 UPGRADE
TX RX
PoC
ON OFF
HDBT IN HDMI IN HDMI OUT RELAY 1
NO C NC NO C NC
RELAY 2 24V 5A
USB DEVICES
1 2
