BLUM LEGRABOX Assembly instructions

> For more information visit
youtube.com/bluminc
Step 1
Step 6
First, touch to open drawer.
Touch to extend the right
and left runner.
Step 2
Step 7
With the drawer fully
extended, reach under
the drawer and squeeze
the release levers for the
locking devices. Then pull
drawer straight out.
Insert the synchronization
rod.
Step 8
Insert the drawer.
Additional instructions -->
Repeat this process for
the other drawers in the
cabinet.
LEGRABOX
Installer’s Guide
For detailed videos visit
youtube.com/bluminc
Dimensions in millimeters (inch equivalents as noted) – Technical
specifications subject to change without notice For more information
about installing Blum products, please visit blum.com or call
1-800-438-6788 for customer service. © 2017 Blum, Inc.
Step 3
Carefully remove the synchronization rod. Repeat these
steps on the remaining drawers.
Further details - To watch the TIP-ON BLUMOTION synchronization rod
video, please visit youtube.com/bluminc
Step 4
Now install the cabinet, ensuring that the cabinet remains
square and true.
For proper function, it is important that the cabinet does not become
racked during installation.
Step 5
Next, use the gray front gap template to ensure the front
gap is set correctly for optimal function of TIP-ON
BLUMOTION.
Further details - To watch the TIP-ON BLUMOTION front gap template
video, please visit youtube.com/bluminc
+
-
part no. 65.5631.US

42
Level
Height adjustment -
moves drawer front
up and down
Drawer front
realease
Check to ensure that the runners are
level, perpendicular to the face of the
cabinet, and parallel to each other.
51
Square
3
Tilt adjustmentRemove cover cap
Check drawer box squareness, either by
measuring from inside corner to inside
corner, or by using a framing square.
Side-to-side
adjustment - moves
drawer front left or
right
Drawer front adjustmentHelpful hints Trouble shooting
If a front gap template is not present on the job site, a combination square can be used to set the
front gap. Please refer to the LEGRABOX brochure for more information.
TIP-ON BLUMOTION depth adjustment with a combination square
Top view
1
-1.5
Combination square
+
-
+
-
2
Front gap template alternative
Broken synchronization adapter
If a synchronization adapter is broken, it can easily be replaced by simply
sliding another in its place.
To remove or insert the
synchronization rod, the pinions
must be put in the open position
by touching the drawer front or
runners to open them.
Closed Open
