MINIPRESS top
Safety instructions, set-up instructions and
instruction leaflet
Ensure that the instructions have been fully read and understood before oper-
ating the assembly machine. Only properly trained and authorised personnel
may operate the assembly machine. The instruction leaflet must be
accessible at all times.

3
MINIPRESS top
4
10
14
20
23
31
41
38
44
49
4
5
5
5
49
50
Contents Safety
Reference diagrams
Explanation of operating and control elements
Start-up
Setup
Drilling and insertion
Maintenance
Horizontal drilling*
Troubleshooting
Additional information
Intended use
Risk levels
Safety information
Warning signs
CE declaration
Technical data
Contents
* The horizontal drilling function is not available with type M70.2000.

4
MINIPRESS top
Handling
Safety principle
➢Please read the instruction leaflet and the safety information before start-up of the
assembly machine.
➢We recommend that you use the reference diagrams to make it easier to identify
the parts being described.
The assembly machine complies with current safety standards. Nevertheless, there
will still be certain residual risks if the information contained in this instruction leaflet is
not observed.
Residual risk according to
EN ISO 12100:2010
Intended use
Foreseeable misuse
■The assembly machine is equipped with all the necessary protection features.
■However, there will still be some residual risks for the user, particularly when
removing the protective equipment or when control units fail.
■Other residual risks are identified by warning signs and safety information.
It is therefore necessary to observe the safety information.
The designated purpose of the assembly machine is the drilling and insertion of furni-
ture fittings into work pieces made of wood, particle board or epoxy coated wood.
■The assembly machine may only be operated by fully-trained personnel.
■The assembly machine may only be used in skilled trade and industrial
applications.
■It should only be installed in dry, enclosed rooms.
■The assembly machine is only intended for stationary operation.
■Only original Blum tools may be used.
■No liability can be accepted for any other use.
■Work piece size: vertical board thickness 45 mm
horizontal board thickness 40 mm
■The MZK.224S (11 spindles) drilling head may only be used
with the supplied table extension.
■No metal or aluminium frames may be drilled.
■The MZK.2880 (17 spindles) drilling head may not be used.
■Only use drilling heads with a safety shield.
Safety

5
MINIPRESS top
Safety
Areas of responsibly
Risk levels
Safety information
Operation
Installation
The operator
■must ensure that only fully-trained personnel, who have read and understood
the instruction leaflet, especially the chapter on safety, operate and service
the assembly machine.
■is responsible for the safety-related condition of the assembly machine.
■will take the assembly machine out of service immediately when faults
are discovered that affect safety.
■CAUTION indicates a danger that could lead to injury if not avoided.
■WARNING indicates a danger that could lead to serious injury if not avoided.
■This NOTE symbol indicates information that should be observed.
CAUTION
NOTE
WARNING
Serious cuts.
Failure to heed this warning may result in personal
injury.
➢Always disconnect the assembly machine from the
power supply and the pressurised air network before all
cleaning and maintenance work.
WARNING
■The assembly machine is designed to only be operated by one person.
■The assembly machine is only intended for stationary operation.
■Ensure there is sufficient lighting.
■Only attach the assembly machine to a sufficiently stable table. Load bearing
capacity: minimum 250 kg. Height 850 mm (+/- 50 mm).
■The assembly machine may not be operated without the work table.
■The assembly machine is not explosion-proof. It should not be
set up near painting facilities.
■The assembly machine is not suitable for operation in an open environment.

6
MINIPRESS top Safety
Operation
Work piece
Repair and maintenance
Personal protective equipment
Tools
Protection equipment ■Do not make any changes or alterations to the assembly machine.
■Protection equipment may not be removed.
■Before starting work, before any shift change or change of personnel, you should
check that the protection equipment and machine parts are functioning properly.
Any damaged parts should be replaced by original parts from Blum.
■Only use drilling heads with leading protection.
■Only use sharp, clean drill bits. Attach drill bits securely.
■Always check that the drill bit is secure before start-up.
■When changing the drill bit, always unclamp the drilling head.
Set main switch [63] to "OFF" pos.
■For your own safety, only use those accessories which are recommended
or indicated in the instruction leaflet or Blum catalogue.
■Only Blum drilling heads may be used.
■Particular care must be taken when working on sections that jut out over
the work table. Use additional supports.
■Secure the work piece during drilling/insertion. Use the assembly machine
clamps or if these are not sufficient for the particular job, use suitable
clamping equipment.
■Make sure that no other tools or objects are on the work table aside from your work
piece before turning on the assembly machine.
■When you release the start button [18], the drill bit will continue to run,
you must wait until it comes to a stop.
■Only operate the assembly machine with the extraction system switched on.
■The negative pressure in the extraction system must be 250–300 mbar.
■Ensure that the average air velocity for the extraction system is at least 20 m/sec.
■Always set the main switch to the "OFF" POS. after finishing work.
■All national regulations regarding labour law, industrial safety as well as all
disposal guidelines must be followed.
■Wear eye protection.
■Wear ear protection.
■Wear appropriate work clothing.
■If there are any questions, please contact the BLUM Customer Service Department.
■Only an electrician may make the connection to the electrical grid.
■Every time before starting work, check the electrical cable and
the pneumatic hoses for damage.
■Repairs may only be performed by authorised personnel.

7
MINIPRESS top
Warning signs
Safety
Before connecting the assembly machine
to the power supply, you must ensure
that you have understood ALL the safety
instructions, warning signs and the instruc-
tion leaflet.
Keep unauthorised persons away from the
assembly machine. Only 1person at a time
should operate the assembly machine.
Always wear eye protection when operat-
ing this machine.
Wear proper ear protection when operating
this machine.
Caution crush danger!
Do not lift here.
Hot surface - risk of burns.
Do not touch the drill bit.
The assembly machine is not suitable for
operation in an open environment.

8
MINIPRESS top Safety
Position of warning signs and danger zones
Work area

MINIPRESS top
364 lbs / 165 kg
Ref. No.:
SN:
Drill- and insertion machine
M70.2000
2021W02
OM12345-6
Julius Blum GmbH
Industriestrasse 1
6973 Hoechst
Austria
Made in Austria
3/N/PE AC 400 V
50 / 60 Hz
1.1 kW / 2.75 A
S3-60%
A
9
MINIPRESS top
Position rating plates
Device type: drilling and insertion machine
Safety
Rating plate: MINIPRESS top [A]

19
18
17
15
16
20
21
22
23
24
25
10 912 11
1
3
P
6
5
4
7
8
13
14
10
MINIPRESS top
1
18
25
2
19
24
3
20
23
4
21
22
P
8
5
9
15
12
6
7
10
16
11
17
13
14
Reference diagrams
Cable chain
Mounting foot
Vertical extraction system
Drilling head
Drilling head locking lever
Drill bits
Drilling head holder
Ruler support
Operator panel
Stepper motor
Horizontal hold down clamp
Work table
Start button
Insertion ram
Hold down clamp
Hold down clamp/sight glass
Emergency off
Fitting
Machine centre of gravity
Horizontal drilling head
Height adjustment knob for horizontal drilling
Depth adjustment knob for horizontal drilling
Work piece
Additional table
Set-up plan rack
Ruler

32
65
33
30
34
36
35
11
MINIPRESS top
30
32
33
34
35
36
65
Reference diagrams
Return stroke limitation
Material thickness adjustment knob
Residue material thickness adjustment knob
Horizontal extraction system
Air pressure regulator
Compressed air shut-off valve
Speed controller for creep speed

40
41
42
44 43
12
MINIPRESS top
40
42
41
43
44
Reference diagrams
Valve block
Vertical extraction system
Y hose extraction system
Funnel extraction system
Ruler attachment

4
60 61 62 63
13
MINIPRESS top
60
62
61
63
4
Reference diagrams
Work mode selector switch
*Drilling mode selector switch
Hold down clamp selector switch
Main switch
Operator panel
* The horizontal drilling function is not available with type M70.2000.

R
T
D
R= D - T
R
30
34
35
33
35
14
MINIPRESS top Explanation of operating and control elements
Residue material thickness adjustment knob [35]:
Adjustment range: 2 - 37 mm
■The residue material thickness
pertains to drill length 57 mm
NOTE

10 - 25 mm
34
30
33
15
MINIPRESS top
Explanation of operating and control elements
Board thickness adjustment knob [34]
Setting the board thickness also sets the brake
point (rapid speed/creep speed).
After the drilling process, the drill unit returns to
the starting position.
The creep speed can be set using this revolving knob [33].
After the drilling process, the drill unit does not
move up completely. This is recommended for
continued cycles for line drilling and knocking in
hinges.

15
6
81
16
MINIPRESS top Explanation of operating and control elements

6 - 20 mm
0 - 50 mm
81
15
6
17
MINIPRESS top
Explanation of operating and control elements
Drilling depth adjustment knob [15] for horizontal drilling.
Drilling depth adjustment range: 0 - 50 mm.
Height adjustment knob [6] for horizontal drilling.
Drilling height adjustment range: 6 - 20 mm.
A clamping lever [81] secures the setting.

4
60 61 62 63
60
61
62
63
18
MINIPRESS top Explanation of operating and control elements
Test mode:
Low feed rate. (creep speed)
No drilling possible.
Work mode:
Normal feed rate
Vertical and horizontal drilling possible.
Drilling mode: vertical drilling.
*Drilling mode: horizontal drilling.
* The horizontal drilling function is not available with type M70.2000.
Hold down clamp operating mode:
The hold down clamps remain shut off.
When you press the start button [20], the hold down clamps [7] move down.
The work piece is clamped during the drilling process. When you release the start
button [20], the hold down clamps [7] move up.
Mode: drilling and knock-in.
See chapter "Drilling and knock-in". (for horizontal drilling - "Removing chips")
The main switch does not disconnect the assembly machine from the mains. Please
note that the main switch does not disconnect the assembly machine from the pressur-
ised air. No pneumatic motion is possible due to the use of solenoid valves.
Main switch: "ON"
The assembly machine is ready for operation.

21
20
21
20
19
MINIPRESS top
Explanation of operating and control elements
Start button [20] flashes slowly:
■Horizontal drilling mode [61] -
Horizontal hold down clamp [11] not clamped.
■Drilling / knock-in mode [62] the Y measurement
is over 100 mm
Start button [20] flashes rapidly:
■The emergency off button [21] has been pressed.
For further flashing modes see chapter "What to do
when"
Briefly press the start button [20] 2x:
■The work piece is clamped via the vertical hold down
clamp [8].
Press and hold the start button [20]:
■The work process (drilling / knock-in) is carried out.

65
31
42
36
32
68
43
20
MINIPRESS top Start-up
Connecting the pressurised air
Connecting the extraction system
➢Connect the air supply [68] to the air filter unit.
➢Open the compressed air shut-off valve [32].
➢The pressure indicated on the pressure gauge [31] should be 6 bar.
➢The pressure can be set using the revolving knob [65].
■During the following procedure, the drill unit makes an upward motion.
■Only oil-free pressurised air may be used.
NOTE
Air consumption per work cycle is 1.5 litres.
➢Insert the extraction hose into the upper extraction socket [42, 43] and secure it.
➢Insert the extraction hose into the lower extraction socket [36] and secure it.
➢Accessories, see www.blum.com.
