blupura BLUSODA HOT Series Specification sheet

1
6
0
3
3
1
1
6
0
4
E
N
BLUSODA HOT
BLUSODA BOX HOT
U
s
e
&
M
a
i
n
t
e
n
a
n
c
e
M
a
n
u
a
l
Before Install or use the product read to the precautions and
general recommendations inside.

3
Precautions and general recommendations
This appliance is intended to be used in household and similar
applications such. Appliance for internal use only. Place the
unit away from water jets.
Always connect the water cooler to a water main that supplies
drinking water only.
Before each installation, the unit must be sanitized by an
authorized technician.
After installation, ensure that the unit is not resting on the
power cable.
Check that the unit is level and that it is resting on a floor with
sufficient load-bearing capacity, in an environment that is suitable for its dimensions and its
use.
Before any maintenance or cleaning operation is carried out, remove the plug from the
socket or disconnect the power supply.
Ensure that the product is not sited close to sources of heat.
To guarantee adequate ventilation, leave at least 10 cm of space around the unit.
Install the product in a clean, dry, well-ventilated environment. The product is designed to
function in environments with a temperature range of between 5°C and 32°C - Climate Class
N.
Take care not to damage the cooling fluid circuit: it is filled with R290, which is a highly
flammable gas. It is essential to ensure that the tubes of the refrigerant circuit are not
damaged.
Ensure that it is possible to disconnect the power supply either by removing the plug or via
a two-pole circuit-breaker, with an opening distance of the contacts that allows complete
disconnection in the conditions of overvoltage category III, placed upstream of the plug.
Check that the voltage shown on the serial number plate corresponds to the voltage being
supplied at the installation site.
The unit must not be cleaned with a water jet. Do not position other electrical equipment in
the immediate vicinity of the water cooler.
Turn off the main water inlet tap if the unit is not to be used for a long period.
Keep the areas surrounding the unit dry to avoid the risk of people slipping.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person in order to avoid a hazard. Do not use extension
leads or adapters.
This appliance is intended to be used by persons (including children aged from 8
years) with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, provided that they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance. The appliance is only to
be installed in locations where it can be overseen by trained personnel.
The Appliance shall be protected by a ground-fault circuit interrupter.
This equipment is to be installed in compliance with the local plumbing codes. Water
pipe connections and fixtures directly connected to a potable water supply shall be
sized, installed, and maintained in accordance with federal, state, and local codes.
This publication is based on information available when approved for printing. Continuing
design refinements could cause changes that may not be included in this publication.

4
Index
• BEFORE INSTALLING THE WATER COOLER 5
• RECOMMENDATIONS FOR SAFEGUARDING THE ENVIRONMENT 6
• CERTIFIED 7
• ASSOCIATIONS 8
• INTERNATIONAL AWARDS 8
• DESCRIPTION OF THE UNIT 9
• TECHNICAL FEATURES 15
• INSTALLATION 19
• INSTALLATION OF THE CO2CYLINDER 25
• HANDLING THE GAS CYLINDERS 26
• SANITIZATION – NOTES 29
• ORDINARY MAINTENANCE 30
• SERVICE HISTORY 31
• WARRANTY CONDITIONS 32

5
Before installing the water cooler
Congratulations for choosing a BLUPURA product.
We have designed and manufactured this product with great care to ensure that
it will dispense water of the highest quality.
In order to get the most out of your water cooler, please read the instructions in
this manual and retain the manual for future reference.

6
Recommendations for safeguarding the environment
Packaging materials
The packaging materials are 100% recyclable.
Please follow the local guidelines on waste
disposal. For safety reasons keep the packaging
material out of the reach and sight of children.
Scrappage
The water cooler is made using recyclable material.
This unit is marked in compliance with European Directive 2012/19/UE
on Waste Electrical and Electronic Equipment (WEEE). By ensuring that
the product is scrapped correctly, you are helping to prevent potential
negative consequences for the environment and for health. The symbol
on the unit indicates that the product should not be treated as domestic waste
but should be taken to a dedicated recycling centre for electrical and electronic
equipment. Immediately prior to scrapping, cut off the power cable.
For more information on the treatment, recovery and recycling of this product,
please contact the appropriate local office, the waste disposal service or the
reseller from which the product was purchased.
Information on the natural, eco-friendly refrigerant gas used in
this cooler
This product contains no CFCs or HFCs, which contribute to global warming.
Indeed, it is the first water cooler on the market to use natural refrigerant.
The refrigerating system is filled with HC R290 – Propane: a natural gas that does
not contribute to global warming and that, thanks to its specific characteristics,
allows for substantial energy savings to be made.

7
Certified
See official list
Materials compliant for contact with drinking water
This unit is intended for the dispensing of drinking water, and so the materials
that enter into direct contact with water meet the criteria for food-grade
components pursuant to the current legislation. In addition, the unit is
manufactured in compliance with Italian Ministerial Decrees 174 of 06/04/2004
and 25 of 07/02/2012.
Electrical safety
This water cooler is designed, manufactured and marketed in compliance with:
• the safety objectives of the Machinery Directive 2006/42/CE;
• the protection requirements of the Electromagnetic Compatibility Directive
2014/30/EU.
The electrical safety of the product is ensured only when it is properly connected
to an efficient, legally compliant grounding circuit.
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032 c
UNI EN ISO 9001:2015
UNI EN ISO 14001:2015
ANSI/UL 399

8
Associations
International Awards
2015 - BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2015, ROME
2015 - BEST ENVIRONMENTAL PRACTICE/GREEN INITIATIVE
EUROPEAN AQUA AWARDS 2015, ROME
2014 - BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2014, BUDAPEST
2013 - BEST PRODUCT INNOVATION
EUROPEAN AQUA AWARDS 2013, BERLIN
2012 - BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARDS 2012, ISTANBUL
2011 - BEST PRODUCT DESIGN/INNOVATION
EUROPEAN AQUA AWARDS 2011, ODESSA
2010 - BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARD 2010, PRAGUE

9
Description of the unit
Compact, powerful and entirely made of stainless steel, Blusoda is the
smallest cooler of BLUPURA’s range: perfect for your home and office, with
professional performances.
The main features of the unit are as follows:
• DRY COOLING technology: a noiseless, low
maintenance and innovative system, allowing you
to get great performances in a small size
• High quality stainless steel buttons, wear-
resistant and easy to use
• 3 dispensing options: cold water + cold
sparkling water + hot water
• Professional 1 litre boiler in stainless steel
AISI 304 for hot water.
• Modern and compact design in strong
stainless steel
• Fast and easy installation for home and office usage
• Filtration: on request, an UV lamp can be placed on the dispensing point and
a carbon block filter can be installed inside the unit.
• Mod. Blusoda Box Hot can be can be fitted to any type of tap. Visit the
website www.blupura.com to view our product range.

10
Frontal view - Mod. Blusoda Hot 30/45
Stainless steel buttons
1Detachable water dispensing
nozzle
3
Boiler condensation drain hose
Ø8mm
4
Drip tray with grid
2
1
2
3
4

11
Rear view - Mod. Blusoda Hot 30/45
Boiler switch
1CO2inlet pipe joint Ø8mm 5
Drinking water inlet pipe joint
Ø8mm
4
Adjustable boiler thermostat
7
Power button
2
IEC power cord plug
3
Adjustable cooler thermostat
6
1
2
3
4
5
6
6
7
7
Mod. Blusoda Hot 30 Mod. Blusoda Hot 45

12
Frontal view - Mod. Blusoda Box Hot 30/45
Power button
1Adjustable boiler thermostat 4
Ventilation conduit
5
Adjustable chiller thermostat
6
Boiler switch
2
IEC power cord plug
3
1
1
2
2
3
3
4
4
6
5
Mod. Blusoda Box Hot 30 Mod. Blusoda Box Hot 45

13
Rear view - Mod. Blusoda Box Hot 30/45
Sparkling water outlet pipe joint
Ø8mm
1
Boiler condensation drain hose
Ø8mm
6
Cold water outlet pipe joint
Ø8mm
3
Drinkable water inlet pipe joint
Ø8mm
4
CO2inlet pipe joint Ø8mm
5
Hot water outlet pipe joint
Ø6mm
2
1
2
4
5
6
3
7
8
Carbonator safety valve (mod.
FIZZ)
8
Compensator (mod. FIZZ)
7

14
Description of the keypad - Mod. Blusoda Hot
P.1/P.2 Hot water buttons
P.3 Cold still water button
P. 4 Cold sparkling water button
The water is dispensed while pressure is being applied to the button.
For safety reasons, to dispense hot water hold down buttons P.1 and P.2 at
the same time.
P. 1
P. 2
P. 3 P. 4

15
Technical Features – Technical Data Plate
16 Year of manufacture
05 Month of manufacture
01128 Serial number
16 Year of manufacture
05 Month of manufacture
01128 Serial number

16
Technical Features - dimensions (mm)
[mod. BluSoda Hot 30]
[mod. BluSoda Box Hot 30]
418
261 499
28
57
276
B
C
D
1 2
A
3 2 1 4
A
5 6
C
B
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
PRODUZIONE
PROTOTIPO
DISEGNO VALIDO PER
NOTE
- Quote di CONTROLLO Contrassegnate con:
*
Grado di Precisione: MEDIA - UNI EN 22768/1
- Quote senza indicazioni di Tolleranza:
BLUSODA
...................
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
02/02/2017
1:10
D.Natali
APPV'D
CHK'D
DRAWN
NAME SIGNATURE DATE
TITLE:
PRODUCT: MATERIAL:
WEIGHT:
A4
SHEET 1 OF 1 SCALE:
2 1
xxxxx
xxxxx
DISEGNO ANNULLATO
DATA
FIRMA
MOD. 503 Rev. 00 18/09/2015
BLUSODA FIZZ
Rev.01
416
260
133 377
416
B
C
D
1 2
A
3 2 1 4
A
5 6
C
B
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
NOTE
- Quote di CONTROLLO Contrassegnate con:
*
Grado di Precisione: MEDIA - UNI EN 22768/1
- Quote senza indicazioni di Tolleranza:
BLUSODA BOX
...................
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
30/08/2016
1:10
D.Natali
APPV'D
CHK'D
DRAWN
NAME SIGNATURE DATE
TITLE:
PRODUCT: MATERIAL:
WEIGHT:
A4
SHEET 1 OF 1 SCALE:
2 1
BLUSODA BOX FIZZ

17
Technical Features - dimensions (mm)
468
184
318
401
440
B
C
D
1 2
A
3 2 1 4
A
5 6
C
B
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
NOTE
- Quote di CONTROLLO Contrassegnate con:
*
Grado di Precisione: MEDIA - UNI EN 22768/1
- Quote senza indicazioni di Tolleranza:
BLUSODA BOX 60
...................
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
30/08/2016
1:10
D.Natali
APPV'D
CHK'D
DRAWN
NAME SIGNATURE DATE
TITLE:
PRODUCT: MATERIAL:
WEIGHT:
A4
SHEET 1 OF 1 SCALE:
2 1
BLUSODA BOX 60 FIZZ
18,56
472
12,52
318
1,08
28
2,25
57
12,95
329
19,65
499
B
C
D
1 2
A
3 2 1 4
A
5 6
C
B
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
PRODUZIONE
PROTOTIPO
DISEGNO VALIDO PER
NOTE
..../..../....
02
D.Natali
- Quote di CONTROLLO Contrassegnate con:
*
Grado di Precisione: MEDIA - UNI EN 22768/1
- Quote senza indicazioni di Tolleranza:
01
Rev. Descrizione Modifica
Data Disegnatore
BLUSODA 45
...................
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
06/03/2017
1:10
D.Natali
APPV'D
CHK'D
DRAWN
NAME SIGNATURE DATE
TITLE:
PRODUCT: MATERIAL:
WEIGHT:
A4
SHEET 1 OF 1 SCALE:
2 1
xxxxx
xxxxx
DISEGNO ANNULLATO
DATA
FIRMA
MOD. 503 Rev. 00 18/09/2015
........................./..../....
BLUSODA 45 FIZZ
Rev.01
[mod. BluSoda Hot 45]
[mod. BluSoda Box Hot 45]

18
Technical Data
Sheet
BluSoda Hot 30
BluSoda Box Hot 30
BluSoda Hot 45
BluSoda Box Hot 45
Cooling capacity 30 Lt/h 45 Lt/h
Continuous supply 6 Lt 12 Lt
Cold water temperature 5 – 12 °C *
Cooling technology Aluminium fusion block heat exchanger
Cold Water Coil Stainless Steel AISI 316
Hot water temperature 95°C
Hot water tank capacity
(lt) 1 Lt
Heater Wattage 1000 W
Pump Professional membrane carbonation pump
Condensation Ventilated
Adjustable Thermostat Yes
Refrigerant gas Natural HYDROCARBON gas R290
Supply 230 V - 50 Hz
Power 1/6 HP 1/4 HP
Watt 1220 W 1350 W
for Blusoda Box 1200 W 1330 W
Inlet water Pipe Ø 5/16” (8mm)
Inlet CO2Pipe Ø 5/16” (8mm)
Dispensing area height
He (Blusoda Hot 30/45) 281mm 331mm
Dimensions LxDxH (mm) 261x499x418 318x499x470
for Blusoda Box 260x416x416 318x440x468
Packaging dimensions
LxDxH (mm) 310x540x470 350x520x490
for Blusoda Box 330x480x540 350x450x490
Net weight (kg) 31 35
for Blusoda Box 26 32
Gross weight (kg) 33 38
for Blusoda Box 28 35
* rated at a room temp. of 25°C and inlet water temp. of 20°C
For the technical data sheet of other models, examine the technical data plate attacked in the unit.

19
Installation
Unpacking
Remove the machine from the box and remove
the inner packing. In mod. Blusoda 30, the
packaging can be easily moved by the handles
on the two sides of the box.
Once you have unpacked the unit, ensure that
it is not damaged. You must inform the reseller
about any damages as soon as possible after
delivery.
If the unit has been shipped horizontally or at
an angle, it will be necessary to wait at least 8
hours before setting it up, in order to allow the
cooling circuit to reset itself.
Ensure that the unit is installed and connected
to the main supply by a qualified technician in
compliance with the manufacturer’s instructions
and the local safety guidelines.
The end user is not permitted to access
the internal service parts of the unit. Only
technical personnel should carry out
operations of this nature.
Siting the unit
Wear safety gloves when handling the unit. The
unit must be handled by two people. Site the
unit away from sources of heat. Do not place on
inclined surfaces. Leave at least 10 cm around
the unit to allow for aeration.
SANITIZE the machine as described in the
paragraph on page 29.
On BLUSODA BOX HOT, drill a hole (1) of
37x130mm (mod. Box 30) or 36x182mm (mod.
Box 45) on the surface of the cabinet chosen
for the installation to allow the expulsion of
hot air from the cooling circuit. Make sure the
ventilation conduit (2) of the unit is matching
the hole.
If it is not possible to drill the support surface,
remove the ventilation conduit and make sure
there is still 10 cm of space around the unit.
5,12in
+
-
0,04
0,04
130mm
+
-
1
1
1,46in
+
-
0,04
0,04
37mm
+
-
1
1
B
C
D
1 2
A
3 2 1 4
A
5 6
SCALE: SHEET 1 OF 1
A4
C
WEIGHT:
B
MATERIAL:
PRODUCT:
TITLE:
DATE SIGNATURE NAME
DRAWN
CHK'D
APPV'D
NOTE:
T.D'Amico
1:1
20/10/2015
Box Blusoda 01 (sottobanco)
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
5,12in
+
-
0,04
0,04
130mm
+
-
1
1
1,46in
+
-
0,04
0,04
37mm
+
-
1
1
B
C
D
1 2
A
3 2 1 4
A
5 6
SCALE: SHEET 1 OF 1
A4
C
WEIGHT:
B
MATERIAL:
PRODUCT:
TITLE:
DATE SIGNATURE NAME
DRAWN
CHK'D
APPV'D
NOTE:
T.D'Amico
1:1
20/10/2015
Box Blusoda 01 (sottobanco)
Disegno di proprietà della BLUPURA Srl - Vietata qualsiasi riproduzione - Disegno eseguito con CAD, vietato fare modifiche o correzioni manuali
* Blusoda Installation. All of the operations must be carried
out exclusively by qualified technical personnel.To view the
video tutorial, scan the QR code.
1
2
Fig.19.1
Fig.19.2

20
Connection to the mains
water supply
Check that the mains pressure
is between 1 bar and 3,5 bar. To
enhance the quality of the sparkling
water dispensed, an incomin g
flow rate in excess of 3.5 l/min is
recommended.
Connect incoming water tube (1,
on pag. 21 for mod. Box Hot) to the
drinking-water main, ideally with a tap
upstream of the unit.
Connect the boiler condensation drain
pipe to a drain line or insert it into a
collecting bin.
On mod. Blusoda, you can connect
the drip tray (1), provided closed, to
a drainage pipe, by plunging it with
a drill with a max. 7mm tip (Fig. 20.2)
and inserting a pipe on the drain
connection ø10 (2) located below the
machine.
CAUTION!
To connect the water cooler to the
mains water supply, you will need to
use a new set of connectors (joints,
gaskets and pipes).
Do not use a set of connectors that has
already been used elsewhere.
The water pressure entering the unit
must be between a minimum of 1,0
bar (0.10 MPa) and a maximum of 3,5
bar (0.35 MPa).
In Box models, for a proper installation
of the system, the use of the Water
Block is compulsory (cod. 140065).
1
Fig.20.1
Fig. 20.2
2
Fig. 20.3
3
