BM PRO BatteryPlus35 Series User manual

TEAM
BMPRO
.COM
BatteryPlus35
FOR MODELS
BP35-HA BP35-PM BP35-SR

2
Born by the innovative spirit of our parent company
Setec, with over 50 years’ experience in power
solutions, and design and manufacturing facilities in
Melbourne, we are the leading experts in RV power
management.
Inspired by the great Australian outdoors, we have
created a range of rugged, smart and reliable products
to power your adventures.
Our range of battery chargers, monitors and power
management systems for caravans gives you peace of
mind when you are on the road, so that you can relax in
even the most far-flung destinations, knowing that you
have control over your vehicle power.
To learn more about the BMPRO range of products,
please visit our website teambmpro.com
POWERING YOUR ADVENTURES
Copyright © 2019
MANUAL PART 033193
REV 8.0
Designed by BMPRO, one of Australia’s leading power solution experts, the
BMPRO product range is proudly designed and manufactured in Melbourne,
Australia, and represent a high-quality product that will provide years of
service.
DISCLAIMER BMPRO accepts no liability for any loss or damage which may
occur from the improper or unsafe use of its products. Warranty is only valid
if the unit has not been modified or misused by the customer.

3
SAFETY PRECAUTIONS
Correct installation is the most critical factor in ensuring the safe use of the BatteryPlus35. If every
consideration of these instructions has been satisfied, the BatteryPlus35 will be safe to operate.
This product is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
Children shall not play with this product. Cleaning and user maintenance should not be performed by
unsupervised children.
Ensure that the product is well ventilated and that if the product has a fan, the fan is not covered or
obstructed.
Metal conducts electricity. Take care not to drop or touch metal objects onto the battery terminals, which
if contacts the battery terminals, could cause short circuits and may lead to serious personal injury. Take
care and remove unwanted metal objects from the vicinity of the battery and BatteryPlus35. Remove any
personal metal adornment such as chain, watch or ring before handling the battery and BatteryPlus35.
Do not replace a damaged mains power cord. If the power cord is damaged, the product must be discarded.
Batteries are always electrically live and must be treated with extreme caution. They can supply high short
circuit currents, even if they appear damaged or undamaged.
Before servicing a battery, disconnect the power supply from all power sources.
Only charge battery types which are supported by this charger (see “Compatible Battery Types”)
Do not allow water or other liquids to enter the power supply area.
Do not drop or vigorously shake the product as this may cause damage. Do not shock the product, its
accessories or batteries as this may cause the product or battery to fail, catch fire or explode.
Stay away from magnetic equipment. Radiation may erase the information stored on this product causing it
to become inoperative.
Please note that your battery can only reach top performance level only after it has been fully charged and
discharged two or three times.
Electricity and water do not mix. Keep this product and your battery dry and do not expose it to water or
water vapour. Do not operate this product or battery near any sort of liquid. Do not operate this product with
wet hands.
Do not use this product in environments that are excessively hot, cold, dusty or humid or where it will be
exposed to magnetic fields or long periods of sunshine. Such exposure may cause the product or your
battery to fail, catch fire or explode.
Only use this product with the supplied power cable and with batteries or accessories recommended in this
manual. Use of other batteries or accessories not recommended in this manual may cause damage to the
unit and will void the warranty.
The BatteryPlus35 is a high precision electronic product. It contains no user-serviceable parts inside. Do not
try to dismantle, modify or repair it yourself. Disassembly, service or repair by an unauthorised person will
void the warranty.
Before using this product, check that cable connections to the battery are of correct polarity. To protect
against accidental short circuit, ensure that the shrouding supplied with the batteries are always fitted to the
battery terminals.
Consult caravan dealer or qualified personnel before servicing your battery.
Do not install this product in the same compartment where flammable materials, such as petrol is stored.
Product specifications are subject to change and improve without notice.
Please read the Safety Precautions before installing or using the BatteryPlus35. Be sure to observe all
precautions without fail. Failure to observe these instructions properly may result in personal damage, or
personal injury which depending on the circumstances may be serious and cause loss of life.

4
BMPRO’s BatteryPlus35 is a battery management system designed specially for
use in recreational vehicles. The BatteryPlus35 operates from 100 to 240V AC
mains power supply, towing vehicle auxiliary and solar panel to provide 35A of
current to simultaneously power caravan loads and charge the caravan battery.
The BatteryPlus35 is available is a range of models to suite any RV battery
management needs.
ABOUT THE BATTERYPLUS35
WHAT’S INCLUDED
Included with this product are:
9BatteryPlus35 Battery Management System
9BatteryPlus35 + Owner’s Manual
OPTIONAL ACCESSORIES
To get the most of your BatteryPlus35 it may be used with the following products
(sold separately) from the BMPRO range:
9BC300 + CommLink External Shunt for integration of additional
accessories and high current loads such as inverters
9RVView Battery Monitor to monitor battery parameters and charge sources
9Trek Battery Monitor to gain greater insights into battery usage, the ability to
monitor water tank levels and control water pumps
9Odyssey + OdysseyLink to monitor battery usage, caravan features (tanks
and temperature) and control caravan loads from an in-built monitor
9MiniBoost DC-to-DC charge-booster for RV applications
FEATURE BP35-PM BP35-SR BP35-HA
In-built Solar MPPT  
Solar Connection Requires External
Regulator
Direct to BP35-SR Direct to BP35-HA
Lithium (LiFePO4)
Charging
  
Maximum Charging
Current
20A 20A 30A
Table 1: Comparison of features for the models in the BatteryPlus35 range

5
COMPATIBLE BATTERY TYPES
The BatteryPlus35 is rated to charge battery banks of up to 600Ah in capacity and
of the following battery types:
Table 2: Batteries compatible for use with the BatteryPlus35
BATTERY BP35-PM BP35-SR BP35-HA*
Lead Acid Valve-Regulated (VRLA) 
Absorbed Glass Mat
(AGM) 
Gel 
Lithium LiFePO4   
* By default, the BP35-HA is configured to charge lead acid batteries
The BP35-HA is designed for use with LiFePO4 Lithium batteries only.
Do not connect other types of Lithium batteries to the BP35-HA.

6
SAFETY PRECAUTIONS 3
ABOUT THE BATTERYPLUS35 4
WHAT’S INCLUDED ................................4
OPTIONAL ACCESSORIES ................................4
COMPATIBLE BATTERY TYPES ................................5
BATTERYPLUS35 ................................7
INSTALLATION INSTRUCTIONS ................................9
REPLACING BATTERIES ................................9
DISCONNECTING A BATTERY FROM THE BATTERYPLUS35 ..............................10
CONNECTING A BATTERY TO THE BATTERYPLUS35 ..............................10
CONNECTING MULTIPLE BATTERIES ..............................10
USING YOUR BATTERYPLUS35 ..............................11
INPUT POWER SOURCES ..............................11
BATTERY CHARGING AND MANAGEMENT ..............................12
USING THE BATTERYPLUS35 AS A POWER SUPPLY ..............................15
FAULT PROTECTION ..............................15
SERVICING, MAINTENANCE AND STORAGE ..............................16
SERVICING ..............................16
MAINTENANCE ..............................16
STORAGE ..............................16
FAQS AND TROUBLESHOOTING ..............................17
BATTERY ..............................17
CARAVAN LOADS ..............................17
SOLAR ..............................18
APPENDICES ..............................19
BATTERYPLUS35 OPERATIONAL STATUS INDICATOR ..............................19
BATTERY CHARGING MANAGEMENT ALGORITHM ..............................20
SPECIFICATIONS ..............................22
WARRANTY TERMS AND CONDITIONS ..............................23
CONTENTS

7
BATTERYPLUS35
Figure 1: The BatteryPlus35
e LOAD TERMINAL BLOCK – POSITIVE CONNECTION
Positive wire connection point for the caravan’s 12V loads.
Terminal 1 will not turn off when ECO mode is activated and is thus ideal for
connecting lite loads that benefit from continual power such as electric step or
radio.
r SOLAR INPUT
t AUXILIARY INPUT
y BATTERY INPUT
w LOAD TERMINAL BLOCK – COMMON NEGATIVE CONNECTION
Negative wire connection point for the caravan’s 12V loads.
q MAINS CABLE
The BatteryPlus35 is pre-cabled with a permanent mains power supply cord for
use with 240V or 110V input power.
Do not replace a damaged power supply cord. If the power cord is damaged, the
BatteryPlus35 must be discarded. Ensure that the AC mains source always has an earth
terminal.

8
u REMOTE SWITCH TERMINAL BLOCK (RSW)
To connect the caravan’s remote switch. This switch is used to enter Storage
Mode and power off all outputs (load terminal block and CAN bus) on the
BatteryPlus35.
If the switch is activated and the BatteryPlus35 is connected to a charging source,
the BatteryPlus35 will enter ECO mode. Terminal 1 on the load terminal block and
CAN bus will still receive power.
Battery charging is not affected by use of the RSW.
As the caravan loads are no longer powered, activating the RSW to enter Storage
Mode is a convenient way to save remaining power of your battery if you are on
the road and have limited ability to charge the battery. When charging, Storage
Mode ensures that all available charging current is dedicated to charging your
battery.
i LOAD OUTPUT STATUS INDICATOR
LED bank indicating the operational status, one for each of the load outputs on the
BatteryPlus35 Load Terminal Block.
The LED bank is located inside of the BatteryPlus35 unit, and to view the LED, one
must be directly above the BatteryPlus35.
LED COLOUR LOAD OPERATIONAL STATUS
GREEN Load operating normally
RED Fault with load
OFF Load is off
Table 3: Load Output Operational Status Indications
o SYSTEM STATUS INDICATOR
Indicates the operational status of the BatteryPlus35.
a CAN BUS COMMUNICATION CONNECTOR
To connect to and power BMPRO accessories (BC300 + CommLink External Shunt
or OdysseyLink) or monitors (RVView or Trek).
sd NOT IN USE

9
Figure 2 details connection of the caravan battery to the BatteryPlus35.
After fitting a new battery to the BatteryPlus35, make sure that it is configured in your
battery monitor.
Correctly configuring the battery capacity and profile will ensure that the
BatteryPlus35 will select the best charging parameters for the caravan battery in use,
and the software accurately estimates battery usage.
INSTALLATION INSTRUCTIONS
REPLACING BATTERIES
Before using a battery other than that which was installed at the caravan dealership,
consult with the battery manufacturer for a detailed description of the installation, uses and
maintenance of the battery. Verify that the type and capacity of the battery or batteries used
are compatible for use with the BatteryPlus35.
Sparks have the potential to cause an explosion should combustible gases be present. The
following procedures are designed to minimise the risk of spark generation when connecting
or disconnecting the battery. The positive terminal of the battery must not be connected to
the chassis.
Do not install battery in the same compartment where flammable material, such as petrol, is
stored.
Figure 2: Wiring the caravan house battery to the
BatteryPlus35, compatible for all BatteryPlus35 Models
To protect against short-circuits and reversed battery
connections, install a 40A fuse, as close as possible to
the battery’s positive terminal.

10
DISCONNECTING A BATTERY FROM THE BATTERYPLUS35
To disconnect a battery from the BatteryPlus35:
1. Power off all loads connected to the BatteryPlus35, the easiest way is with
the switch connected to the BatteryPlus35 RSW input
2. Turn off and remove all power sources (mains/solar/AUX) to the
BatteryPlus35
3. Disconnect the battery’s negative (black) terminal from the BatteryPlus35
Batt- connection point
4. Disconnect the battery’s positive (red) terminal from the BatteryPlus35 Batt+
connection point
CONNECTING A BATTERY TO THE BATTERYPLUS35
To connect a battery to the BatteryPlus35:
1. Power off all loads connected to the BatteryPlus35, the easiest way is with
the switch connected to the BatteryPlus35 RSW input
2. Turn off and remove all power sources (mains/solar/AUX) to the
BatteryPlus35
3. Connect the battery’s positive (red) terminal to the BatteryPlus35 Batt+
connection point
4. Connect the battery’s negative (black) terminal to the BatteryPlus35 Batt-
connection point
Figure 3: Recommended wiring
for connecting batteries in
parallel.
CONNECTING MULTIPLE BATTERIES
Before connecting multiple batteries in parallel to the BatteryPlus35, check that
all batteries are:
1. Of the same type, for example, deep cycle AGM battery
2. Of the same capacity, for example, 100Ah
3. By the same manufacturer
4. Fully charged
5. Of the same age-never use batteries that differ in age
The recommended wiring for connecting multiple
batteries in parallel to the mis given in Figure 3.
Depending on system requirements, a qualified auto-
electrician may wire the batteries differently.

11
USING YOUR BATTERYPLUS35
INPUT POWER SOURCES
The BatteryPlus35 may be powered from auxiliary, mains and solar input sources.
When multiple inputs are available to the BatteryPlus35, the BatteryPlus35 uses
power as specified in the tables below to provide the current to simultaneously
power caravan loads and charge the caravan battery.
Table 4: Input Power Sources to the BP35-PM
INPUT SOURCE TO BatteryPlus35 POWER SOURCE
AUX + Mains Mains
AUX + Solar AUX/Solar Blending
AUX + Mains + Solar Mains/Solar Blending
Mains + Solar Mains/Solar Blending
Table 5: Input Power Sources to the BP35-HA and BP35-SR
INPUT SOURCE to BatteryPlus35 POWER SOURCE
AUX + Mains Mains
AUX + Solar AUX/Solar Blending
AUX + Mains + Solar Mains
Mains + Solar Mains
Auxiliary
The auxiliary input is designed for use with 12V DC power sources. The voltage of
the DC power source connected to the auxiliary input must not exceed 14.8V.
Fuse protection is required at the auxiliary positive input. The rating on this
protective fuse must not exceed 30A
Mains
The BatteryPlus35 mains power cord can accept power from either a 110V or 240V
voltage outlet.
To prevent your car battery from discharging when the vehicle’s ignition is off, please
disconnect the auxiliary input to the BatteryPlus35 whenever the car is not running.

12
Solar Input on the BP35-PM
Connection of solar panels to the BP35-PM must always be through an external
regulator. The external regulator may either be a Maximum Power Point Tracker
(MPPT) regulator or Pulse Width Modulator controller.
Always consult with manufacturer’s specifications before choosing an external
regulator to fit between your solar panels and the BP35-PM, ensuring that:
1. The solar regulator output does not exceed 30A, and
2. The charging profile of the solar regulator is suitable for the battery in use
Solar Input on the BP35-HA and the BP5-SR
The BP35-HA and the BP35-SR both feature an in-built MPPT charger. This
enables solar panels to be connected directly to the BP35-HA or BP35-SR without
the need for an external regulator.
The MPPT charger supports the use of standard 12V solar panels up to a total of
450W.
DO NOT connect solar panels directly to the BP35-PM solar input terminals.
BATTERY CHARGING AND MANAGEMENT WITH THE BATTERYPLUS35
The BatteryPlus35 can deliver up to 35A to simultaneously power loads and
charge the caravan battery, with a maximum charging current of 20A for the
BP35-PM and BP35-SR and 30A for the BP35-HA.
The maximum charging current will be reduced if the loads present are drawing
significant current and as the battery approaches full charge. To ensure that the
caravan battery is charged by the maximum charging current, switch off non-
essential loads.
Auxiliary Charging
When charging from auxiliary, the BatteryPlus35 monitors the battery voltage
level and charges as needed. Auxiliary charging is enabled only when the auxiliary
voltage exceeds the battery voltage by at least 0.5V.
Mains Charging
When charging the battery from mains, the BatteryPlus35 applies a multi-stage
charging algorithm. Further details can be found in the Appendices.
Solar Charging with the BP35-PM
Battery charging depends on the solar regulator used to connect the solar panels
to the BP35-PM.

13
Solar Charging with the BP35-HA and BP35-SR
When charging the battery from solar, the BP35-HA and BP35-SR applies a multi-
stage charging algorithm.
The BatteryPlus35 (HA and SR) will use solar as a charging source is the voltage
generated by the solar panel is greater than 17.5V for at least two minutes.
Battery Health Preservation
The BatteryPlus35 preserves battery health by preventing the battery from
excessive discharge. The BatteryPlus35 will start a two-stage shutdown or Low
Voltage Disconnect (LVD), powering down the BatteryPlus35 outputs. This is to
conserve remaining battery capacity until the battery can be charged.
LVD MODE LEAD ACID LiFePO4 (BP35-HA ONLY)
ECO Mode 10.5V 12.0V
Storage Mode 9.8V 11.5V
Recovery 12.8V 13.8V
Table 5: LVD Mode voltage thresholds
The BatteryPlus35 will enter the two stages of LVD, ECO Mode and Storage Mode,
when the caravan’s battery voltage falls below the LVD thresholds.
ECO MODE
The BatteryPlus35 will provide power to the CAN bus. This allows you to continue
to monitor battery consumption from your battery monitor. However, power to the
load terminal block will be turned off (except for terminal 1) and you will not be
able to use your battery monitor to power caravan loads.
To exit ECO Mode, start battery charging. The BatteryPlus35 will exit ECO Mode
when the battery charges to the Recovery voltage. Upon exit of ECO Mode, the
BatteryPlus35 will automatically return to its previous state of operation.
When in ECO Mode you may temporarily turn on caravan loads for a short time by
cycling the switch connected the BatteryPlus35’s RSW input. This feature allows
you to retract slide-outs or electric steps should you need to pack your caravan.
If a battery monitor is connected, this may also be done by pressing the Battery
button.

14
STORAGE MODE
Power to load output terminal 1 and the CAN bus will now be turned off; meaning
no communication or power to the accessories connected to the BatteryPlus35
CAN bus.
To exit Storage Mode, start battery charging. The BatteryPlus35 will exit Storage
Mode when the battery charges to the Recovery voltage.
When in Storage Mode you may temporarily turn on caravan loads for a short time
by cycling the switch connected the BatteryPlus35’s RSW input.
Heavily Discharged Batteries (Lead Acid)
The BatteryPlus35 will not charge heavily discharged lead acid batteries.
In normal use, and with the BatteryPlus35 battery health preservation, batteries
should never become heavily discharged.
If your battery is heavily discharged, disconnect it from the BatteryPlus35 and
charge with a stand-alone charger. Reconnect the battery once the battery
voltage has recovered to normal levels.
Heavily Discharged Batteries (LiFePO4) (BP35 Model HA only)
The BP35-HA can recover and charge a heavily discharged LiFePO4 battery. The
internal Battery Management System (BMS) of a LiFePO4 battery will turn off
if it detects that the battery is heavily discharged. The BP35-HA will provide the
voltage to restart the LiFePO4 battery’s BMS and then commence charging of the
LiFePO4 battery.

15
USING THE BATTERYPLUS35 AS A POWER SUPPLY (BATTERY-LESS
OPERATION)
The BatteryPlus35 will act as a power supply if the following conditions are met:
1. A battery is not connected to the BatteryPlus35, and
2. The BatteryPlus35 is configured to charge Lead Acid batteries, and
3. The BatteryPlus35 is connected and powered from mains, or
4. The BatteryPlus35 is connected and powered from AUX input
Power Supply mode allows you to control and power your caravan’s loads directly
from mains or AUX without the need to connect the caravan battery. When
powered from the mains, the BatteryPlus35 provides an output voltage of 12.8V.
When powered from an AUX input, the output voltage will vary depending on the
AUX input voltage.
This mode of operation is unavailable with a solar power source.
FAULT PROTECTION
Electronic Load Fuse Protection
Each load output is protected by an internal electronic fuse. Electronic fuses are
auto-recoverable and eliminate the need for the user to replace a blown fuse.
The electronic fuse will act if the BatteryPlus35 detects a current greater than
the current rating of the terminal and the corresponding LED in the Load Output
Status Indicator on the BatteryPlus35 will flash red.
The LED indicators have a narrow viewing window. To view the LED colour
clearly, one must be directly above the LED indicators.
The BatteryPlus35 will power off the faulty load and resume normal operation
once the fault has been rectified.
Over-Temperature, Over-Voltage and Short Circuit Overload Protection
The BatteryPlus35 provides automatic protection for over-temperature, over-
voltage and short circuit overload situations.
If any of these situations are detected, the BatteryPlus35 will shut down and
automatically attempt a restart every 30 seconds until the fault is removed.

16
SERVICING
The BatteryPlus35 contains hazardous voltages and energy hazards that
may cause death or injury. Only qualified service personnel may service the
BatteryPlus35. Do not attempt to service the BatteryPlus35 yourself, OR
dismantle, modify or repair the BatteryPlus35 yourself; this will void your
warranty.
If your BatteryPlus35 requires servicing other than what is stated in this Owner’s
Manual, please consult your BMPRO dealer.
MAINTENANCE
Use a dry or moist cotton cloth to lightly remove dust or dirt from the
BatteryPlus35. Do not use alcohol, thinners, benzene or any other chemical
cleaner as these products may degrade the housing surface. Do not allow any
liquids to enter the housing.
Be sure to turn off all power sources to the BatteryPlus35 and disconnect the
battery before cleaning.
STORAGE
Once your adventure is over be sure to charge the caravan’s battery and power off
loads. Use the switch connected to the BatteryPlus35 RSW input to enter Storage
Mode and power off all loads.
When not in use, it is recommended that you recharge the caravan’s battery,
ideally monthly, or every three to six months. Regular recharge prevents the
battery from becoming heavily discharged-a condition which can significantly
shorten the battery’s lifespan.
SERVICING, MAINTENANCE AND STORAGE

17
FAQS AND TROUBLESHOOTING
Need more help troubleshooting your BatteryPlus35? Contact our customer
service team online at teambmpro.com/technical-support or give us
a call on [phone].
BATTERY
I’ve fitted a battery to the BatteryPlus35, but it’s not detected by my BMPRO
battery monitor?
Check the following:
1. Battery connections are tight and not loose or corroded
2. Battery polarity, red lead-positive, black lead-negative
3. The dealership fitted in-line fuse with the caravan battery is fitted and not
blown. Correct value is 40A.
CARAVAN LOADS
I think one of my loads is not receiving power?
The load may be faulty, activating the protective electronic fuse and turning the
load off. If this is the case, the Load Status Indicator LED for that load will be red.
Should you encounter any faulty loads, please contact your caravan dealership.
None of my loads appear to be powered but I can still use my battery monitor?
All loads will power down, but the battery monitor will still be in use if the
BatteryPlus35 was put into ECO Mode. The BatteryPlus35 will be put into ECO
Mode if:
1. The user pressed the Battery icon on their battery monitor.
Check to see that Battery icon on your monitor has been pressed, thus turning
power off to the caravan loads.
2. The BatteryPlus35 has entered ECO Mode and to conserve remaining battery
voltage will disable power to caravan loads.
Connect the BatteryPlus35 to a power source and begin battery charging.

18
None of my loads appear to be powered and the screen on my battery monitor
has turned off?
All loads, including any battery monitor in use with the BatteryPlus35 will power
down if the BatteryPlus35 was put into Storage Mode. The BatteryPlus35 will be
put into Storage Mode if:
1. The user activated the switch connected to the BatteryPlus35 RSW input.
This turns off power to all caravan loads and accessories connected to the
BatteryPlus35 CAN bus such as your battery monitor.
Check that the switch has not been activated.
2. The BatteryPlus35 has entered Storage Mode and to conserve remaining
battery voltage will disable power to all caravan loads and accessories
connected to the BatteryPlus35 CAN bus.
Connect the BatteryPlus35 to a power source and begin battery charging.
SOLAR
Solar Output Appears to be Lower than Expected
If the battery is close to fully charged, the BatteryPlus35 will periodically turn
off solar to protect the batteries from overcharging. As a result, you may see less
output on your solar display.
The following tips will also make sure you are getting the most of your solar set-
up:
1. Make sure your solar panels are clean
For optimal performance of your solar panels, regularly clean them (when
cool) with warm, soapy water.
2. Consider the location of your caravan/RV
A shadow (for example from trees, buildings and even other accessories on
the roof of your caravan) across any part of the solar panel can reduce the
panel performance by up to 80%.
3. The time of day and time of year is important as well.
In some parts of the year (especially is southern parts of Australia) the sun will
never be directly overhead, so your solar output will be reduced-sometimes by
up to 50%.

19
BATTERYPLUS35 OPERATIONAL STATUS INDICATOR
The following details the operational status of the BatteryPlus35, as shown by the
coloured flash of the LED Status Indicator on the BatteryPlus35.
APPENDICES
Colour Code Flashing Status
Orange: Charging
AC Charging On, Solid
Low Battery Voltage Flashes, 1 Time
BP35-PM
Solar Charging
BP35-SR & BP35-HA
Solar or Aux/Solar Charging
Flashes, 2 Times Quickly
Aux Charging
BP35-PM
Solar/Aux Charging
Flashes, 3 Times Quickly
Green: OK
Battery OK, AC available On, Solid
Battery OK, no sources
available Flashes, 1 Time
BP35-PM
Battery OK, solar available
BP35-SR & BP35-HA
Battery OK, solar or Aux/
Solar available
Flashes, 2 Times Quickly
Battery OK, Aux available Flashes, 3 Times Quickly
Red: Error
High Temperature Fault Flashes, 1 Time
Battery Fault Flashes, 2 Times Quickly
Solar Fault Flashes, 3 Times Quickly
Other Fault Flashes, 4 Times Quickly
OFF BatteryPlus35 Powered Off Off

20
BATTERY CHARGING MANAGEMENT ALGORITHM
The following describes the Battery Charging Management Algorithm used by the
BatteryPlus35 when charging the caravan battery from a mains power source and
by the BP35-HA and BP35-SR with solar charging. The BatteryPlus35 will operate
as described when the caravan loads are connected directly to the BatteryPlus35
and not the caravan battery.
Figure 4: BatteryPlus35 Battery Charging Management Algorithm
Battery Capacity Soft Start Bulk-Absorption Float
≤100AH 6 Hours 5 Hours 6 Hours
150AH 6 Hours 7.5 Hours 6 Hours
200AH 6 Hours 10 Hours 6 Hours
250AH 6 Hours 12.5 Hours 6 Hours
≥ 300AH 6 Hours 15 Hours 6 Hours
Table 6: Timeout for each charging mode, based on battery capacity
