Professional Material Mixers
from BN Products, U.S.A.
Product Manual
BNR6400 Material Mixer

BNR6400 Tech Manual.indd • 07242013
Page | 2
PRODUCT DESCRIPTION
From low-viscosity paints to high-viscosity mortars these
electric mixers will get your job done quicker, safer and eas-
ier than a conventional ½” drill motor. e ergonomically
designed handles and the variable 2-speed motor with soft-
start make the job quicker, safer and easier. e heavy-duty
gearbox and high-torque motor will outlast a standard ½”
drill motor by 3-4 times.
e machines have been designed to mix liquid and powder
building materials such as paint, mortar, adhesive, plaster,
epoxy and similar substances.
e relevant mixing action depends on the consistency of
the materials and the quantity that has to be mixed. is
must be set up for the appropriate mixing paddles.
You must abide by certain safety precautions when
using the equipment, in order to prevent injuries
and damages from occurring. Therefore you must
always read through this operating manual care-
fully.
PLEASE NOTE - This manual must be kept in a safe
place so that the information that it contains is al-
ways available. This operating manual must accom-
pany the equipment if it is transferred to someone
else.
We do not accept any liability for accidents or damage
arising from ignoring this manual and the safety
instructions.
SAFETY INSTRUCTIONS
Read through these operating instructions carefully be-
foreusingthesetools.Becomefamiliarwiththefunctions
and method of operation. To ensure proper operation,
always maintain the tools according to the instructions.
The operating instructions and associated documents
should always be kept close to the appliance.
When using power tools, you· must observe the follow-
ing basic safety precautions in order to ensure protec-
tion from electric shocks, injury and re. Read and follow
all the instructions before using these power tools. Fol-
low the notes on safety.
Always check ito see if voltage corresponds with the
manufacturer’s requirements
Our mixers are double-insulated.in accordance with
EN60745; therefore, an ground wire is not required.
USE CORRECT SUPPLY VOLTAGE
e power supply voltage must match the information
quoted on the tools identification plate.
USE PROPER EXTENSION CORD: Only use an approved
extension cable that is suitable..for the machine’s power.
SWITCH OFF THE MACHINE
IMMEDIATELY IN CASE OF:
1. Malfunction in the plug or power cable.
2. Broken switch.
3. Smoke or smell of scorched insulation.
GENERAL SAFETY RULES
WARNING! Read all safety warnings and all Instructions.
Failure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
e term “power tool” in the warnings refers to your elec-
tric power tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark ar-
eas invite accidents.
• Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.

BNR6400 Tech Manual.indd • 07242013
Page | 3
ELECTRIC SAFETY
• Power tool plugs must match the outlet: Never mod-
ify the plug in any way. Do not use any adapter plugs
grounded power tools. Unmodified plugs and match-
ing outlets will reduce risk of electric shock.
• Avoid body contact with grounded surfaces, such as
pipes, radiators, ranges and refrigerators. ere is an
increased risk of electric shock if your body is ground-
ed.
• Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
• Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an exten-
sion cord suitable for outdoor use. Use of a cord suit-
able for outdoor use reduces the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not, use a power
tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal
injury.
• Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat. and/or hearing protec-
tion used for appropriate conditions will reduce per-
sonal injuries. .
• Prevent unintentional starting. Make sure the switch is
in the off-position before connecting to power source.
• Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
• Remove any adjusting key or wrench before starting
the power tool. on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
• Do not overreach. Keep proper footing and balance at
all times. is enables better control of the power tool
in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from mov-
ing parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
• If devices are provided for the connection of dust ex-
traction and collection facilities, ensure these are con-
nected and properly used. Use of dust collection can
reduce dust-related hazards.
POWER TOOL USE AND CARE
• Use the correct power tool for your application. e
correct power tool will do the job better and safer at the
rate for which it was designed.
• Do not use the power tool if the switch does not turn
it on and off properly. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
• Disconnect the plug from the power source and/or the
battery pack before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power
tool accidentally.
• Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
BNR6400 Hand Held Power Mixer
Power 1800W / 15 Amps
Voltage 120V/60Hz
Number of Gears 2
No Load Speed I 150 - 300 rpm
No Load Speed II 300 - 700 rpm
Motor Protective Type Double Insulated
Mixing Paddles ( ø Max.) 6-1/2” (160mm)
Shipping Weight 21 lbs (8.5 Kg)

BNR6400 Tech Manual.indd • 07242013
Page | 4
• Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s opera-
tion. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
• Use the power tool, accessories and tool bits etc. in ac-
cordance with these Instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
SERVICE
Have your power tool serviced by a qualified repair person
using only Identical replacement parts. is will ensure that
the safety of the power tool is maintained.
PRECAUTION ON USING MIXERS
Attention! - You must abide by the following basic safety
measures to prevent electrical shocks, injuries and the dan-
ger of fire when using electric tools. Read and abide by these
instructions before you start to use any tools.
ese Instructions must be kept in a safe place.
• e equipment must never be used in areas where an
explosive atmosphere exists.
• Never mix in solvents or substances containing solvent
that have flash points below 21°C.
• Do not let the cable touch any parts of your body,
• Only use the extension cord approved for use in the
working area.
• e unit must only be started and stopped when it is
inside a mixing vessel. Ensure that the mixing vessel is
placed on a solid, secure base,
• Never reach into the mixing vessel with your hands or
any other object during the mixing process.
• We recommend that you always wear industrial safety
gloves and safety goggles when working with the mix-
er.
• Wearing close-fitting clothes is mandatory.
• Always allow for reaction torque
• Always wear a dust mask
Before Initial Operation
Check to see that the rated voltage on the tool nameplate
corresponds to the tool requirement. Before using the tool,
read the instruction book carefully.
Mixer Assembly (Fig. 2):
First screw mixer shaft (6a) together with mixer paddle (6b).
Screw the mixer paddle (6) into the mixer (5). Use the two
wrenches to tighten. Use one of the wrenches (a) to hold
the mixer (5) in place and then use the second wrench (b)
to tighten up the mixer (6). Proceed in the reverse sequence
to undo the paddle from the mixer.
STARTING THE MIXER
Ensure that the data listed on the nameplate matches the
voltage before connecting the unit up to power.
On / Off switch
• Switching on: Press the switch (1)
• Continuous running: Press the locking knob on the
switch (1) (2) to lock it in place.
• Switching off: Press the switch (1) briefly
• Speed control: Use the speed control (3) to select the
speed.
• Switching between 1st· 2nd gear (4)

BNR6400 Tech Manual.indd • 07242013
Page | 5
e switch position enables you to work at high or low
speeds. e gear switch position should only be changed
when the unit is stopped in order to prevent the gearing
from being damaged.
1st gear - Upper position
2nd gear- Lower position
CARE AND MAINTENANCE
• Remove the plug from the socket before making any
adjustment, servicing or maintenance.
• Your power tool requires no additional lubrication or
maintenance. Always store your power tool in a dry-
place.
• If the electric cord is damaged, it must be replaced by
the manufacturer, service agent or similarly qualified
persons in order to avoid a hazard.
CLEANING
• Keep the safety devices, ventilation slots and motor
housing as free of dirt and dust as possible.
• Clean the unit by rubbing it with a clean cloth or blow
it clean using low-pressure compressed air.
• We recommend that you always clean the unit imme-
diately after using it.
• Clean the unit regularly by rubbing it with a damp cloth
and a little soft soap. Do not use cleaners or solvents
--these will attack the plastic parts in the unit. You
must also ensure that water cannot get into the inside
of the unit.
•
CARBON BRUSHES
If excessive sparking occurs you must have the carbon
brushes checked by a qualified electrician.
Attention! Changing the brushes should be done by a quali-
fied electrician. MAINTENANCE
ere are no parts fitted inside the unit that require main-
tenance.
CORRECTIVE ACTION IN CASE OF FAILURE
e operating switch is switched on, but the motor is
not working.
• Wires in the electric plug or in the socket are loose.
Have socket and plug checked or repaired or replaced.
• e switch is faulty. Have the switch replaced.
e operating switch is switched on, but unusual nois-
es can be heard, the motor is not working or only very
slowly.
• Switch contact has failed. Have the switch replaced.
• Component jammed. Have the electric tool checked or
repaired.
• Too much thrust, as a result the motor is dragging. Use
less thrust during the task.
Motor gets hot.
• Foreign substances have got inside the motor. Have the
foreign substances removed.
• Lack of or contaminated lubrication grease. Have lu-
bricating grease applied or replaced.
• Pressure too high. Use less thrust during the task
Frequent or strong sparks on the commutator.
• Short circuit on the armature. Have the armature re-
placed.
• Carbon brushes worn out or jammed. Have the carbon
brushes checked.
• Rough running of the commutator. Have the surface of
the commutator cleaned or ground.
For your own safety, never remove parts or accessories of
the electric tool during operation, In case of fault or
damage have the electric tool repaired only by a specialist
workshop or by the manufacturer.
• Variable speed adjustment with a lock-on
feature.
• Two-speed gear box.
• Powerful high torque motor.
• Soft-start and constant speed control.
• Ergonomically designed handle with soft
grip design.
• Double insulated.
• 12’ power cord.
• Standard M14 paddle
connection.
• BNRA0315 1/2” Chuck
• Includes general purpose mixing paddle
(2’x 6-1/2”).
The BNR6400
Hand Held Power Mixer

BNR6400 Tech Manual.indd • 07242013
Page | 6
BNR6400 Material Mixer
Part No. Description
BNR6400-01 Handle set
BNR6400-02 Switch
BNR6400-03 Screw ST4X20
BNR6400-04 Tube
BNR6400-05 Tube
BNR6400-06 Clamp
BNR6400-07 Screw ST3.SX16
BNR6400-07A Connection Cover
BNR6400-08 Speed controller
BNR6400-09 Wire Harness
BNR6400-10 Screw M8X12
BNR6400-15 Screw MSX20
BNR6400-16 Bottom gear cover
BNR6400-17 Spindle
BNR6400-18 Hemicycle key 4XSX12
BNR6400-19 Safety ring
BNR6400-20 Dust cover
BNR6400-22 Bearing 6204DDU
BNR6400-23 Safety ring
BNR6400-24 Spindle gear
BNR6400-25 Safety ring
BNR6400-26 Bearing 6000ZZ
BNR6400-27 Gear case
BNR6400-28 Sealring
BNR6400-29 Bearing 6001ZZ
BNR6400-30 Armature Assembly
BNR6400-31 Bearing 608ZZ
BNR6400-32 Pin
BNR6400-33 Needle bearing HK0810
BNR6400-34 Countershaft
Part No. Description
BNR6400-35 Hemicycle key2.5X3.7Xl0
BNR6400-36 Motor gear
BNR6400-37 Flat washer
BNR6400-38 Bearing 698ZZ
BNR6400-39 Bearing 608ZZ
BNR6400-40 Pinion
BNR6400-41 Parallel key
BNR6400-42 Spindle double gear
BNR6400-43 Needle bearing HK0810
BNR6400-44 Pivot
BNR6400-45 Glide
BNR6400-46 Pivot
BNR6400-47 NutM8
BNR6400-48 Bail<l>4
BNR6400-49 Spring
BNR6400-50 Lever
BNR6400-51 Screw ST3X16
BNR6400-52 Airguide shim
BNR6400-53 Screw STSX6S
BNR6400-54 Spring washer
BNR6400-55 Stator
BNR6400-56 Motor housing
BNR6400-57 ScrewMSX25
BNR6400-58 Brush holder
BNR6400-59 Carbon brush
BNR6400-60 Brush cap
BNR6400-61 Controller
BNR6400-62 Protective cover
BNR6400-63 Top Cover
BNR6400-64 Screw ST3.5X16
BNR6400-65 Cord
BNR6400-66 Sleeve

BNR6400 Tech Manual.indd • 07242013
Page | 7
Parts Drawing
BNR6400 Material Mixer

BNR6400 Tech Manual.indd • 07242013
Page | 8
