Bobot MOP OPT User manual

MOP OPT
Wireless Electric Mop
Instruction
Manual
Table Of Contents
Please read the instructions carefully before using the appliance
MAKE THE WORLD CLEAN Table Of Contents
1.Product Description
2.Power Charging Attentions
3.Application Attentions
4.Item Installation Methods
5.Application Instruction
6.Relevant Safety Attentions
7.Cloth Pads Installation
8.Washing Attentions Of Cleaning Pads
9.Problem Solving
10.Product Specification
11.Sterilizing UV Lamp
...............................................................................1
.....................................................................2
...........................................................................4
.......................................................................7
...........................................................................7
.....................................................................9
............................................................................9
...................................................10
..................................................................................10
........................................................................11
............................................................................12

Start/Stop Button
Liquid Spray Button
Handle Remote Control
Lock Button
Stretchable Aluminum Tubes
Power Switch ON/OFF
Spray Nozzle
Major Fixed Pin Connectable
LED Light
Water Filling Hole
Removable Battery Pack
1
1.Product Description
2
Product Description Power Charging Attentions
2.Power Charging Attentions
Please check whether
the power cord and plug
was damaged or burnt-in.
(may cause the electric
shock or fire)
When plug in or out,
please don`t pull the
power cord.Catch the
and pull it out.
(may cause the electric
shock or fire)
Don`t touch the plug
or switch with wet
hands.
(may cause electric shock)
The loosing socket will
generate the heat,which
may cause the electric
leakage because the plug
or power cord was melted.
(May cause the electric
shock or fire)
It`s not allow to press
or touch the power cord
by the heavy objects
(may cause the electric
shock or fire)
Please don`t use the
socket with other
items.(may cause the
abnormality or fire)
When charging,don`t start
the product.
-when using,please ensure that the
charging has been finished.
When all three lights are on
red into green,which means that
the charging has been finished.
-In order to ensure the product
Cleaning Pads Adaptor Measuring Cup Funnel Instrution Manual
In order to avoid the danger and injury, please follow the matters as below:
1 )Please use the product according to the instruction manual.
2)This product is only for the inside cleaning, not for other application.
Warning ! The wrong application will cause the injury and death, please follow!
Power cord, in order to avoid the adanger, please don t use the product is the power
cord is damaged, and please contact.
power cord

Power Charging Attentions
3 4
Application Attentions
Warning !The wrong application will cause the injury and death, please follow! 3.Application Attentions
Warning ! The wrong application will cause the injury and death, please follow!
Don`t place the
equipment of open
fire around the mop,
such as stove,candles,
or power cord is easily
melted,which may
cause electric shock or
fire)
If there is the gas leakage,
please don`t touch the
plug or socket,please
change the gas first.
(May cause bombing or
fire)
Don`t allow the children
to climb the mop or make
it as toys.(The falling of
steam mop may hurt the
children)
When charging,don`t start
the product.
(may cause barrier)
When storing the product,
please keep clean and dry,
don`t allow the liquid into
the product.
(May cause the fire or
barrier)
Don`t uninstall the products
except for our technicians
(may cause barrier)
Don`t place the unit into
the canister with water
(may cause the fire or
electric shock)
The temperature for
storing the product
should be 0℃to 40℃
Once the product or cord
was damaged,please
contact with the a
immediately
allow the aged or chidren
to operae the product.
Before using the product,
please confirm that the
are correct.
When moving the product,
please switch off,and hold
the handle to move.
When using the product,
please don`t jam on the
product or shock with
heavy objects.
(may cause barrier)
the safety protector
will start,the machine
2 hours,the product can
restart working.
When moving the
product,please switch
off,and hold the handle
to move.
When cleaning,please
don`t force the mop
head into the gaps
of furniture,sofa,bed,
etc.
Don`t drop the product
or shock the product
with heavy objects .
(may cause barrier)
When changing the cloth pads,
please switch off first.When
the cloth pads become cold,
please change the pad.

5 6
Application Attentions Application Attentions
When found that there is
foreign noise, burned smell
or smoke,please plug out
and contact with the
(may cause electric shock
or fire,and may reduce
the product performance)
When using the product,
please don`t use the nail
or needle to touch the
connectors(may cause
electric shock or fire)
When installing,please
install the cloth pads
correctly according the
(may cause the abnormal
When filling into water,
please use the matched
measuring cup to avoid
more water leased.
Please use the product on
the smooth floor inside of
home. If the floor is not
smooth or there is the
foreign objects,please clean
first and then use.(may
cause the barrier of reduce
the product performance)
Please don`t use the
product without
installing cleaning pads.
The product is only used
for cleaning inside,
please don`t use for
When using,please don`t
or against the people.
When using,the pets
should be far away.
When using,the product
should not be close to
magnet or metallic
products.(may cause the
bad performance)
Please don`t use under
the wet circumstance.
(may cause electric
shock)
Please use the qualified
cloth pads
(may cause the poor
cleaning efficiency).
●The instructions for appliances with a ilquid dispensing system shall specify the amount
and type of the liquid to be used.
●The instructions for appliances with rotating brushes shall state that a hazard may occur
if the appliance runs over the supply cord.
●The instructions shall state that the plug must be removed from the socket-outlet before
cleaning or maintaining the appliance.
●If the supply cord is damaged, it must be replaced by the manufacturer, its service
agentor similarly qualified persons in order to avoid a hazard.
●This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision orinstruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children withoutsupervision.
The instructions for appliances incorporating batteries that are intended to be replaced
by theuser shall include the following:
●The type reference of the battery;
●The orientation of the battery with regard to polarity;
●The method of replacing batteries;
●Details regarding safe disposal of used batteries;
●Warning against using non-rechargeable batteries;
●How to deal with leaking batteries.
The instructions for appliances incorporating a battery that contains materials that are
hazardous to the environment shall give details on how to remove the battery and shall
state that:
●The battery must be removed from the appliance before it is scrapped.
●The appliance must be disconnected from the supply mains when removing the
battery.
●The battery is to be disposed of safely.

7 8
Item Installation Methods Application Instruction
1.Please take the handle and the major body
from the packing box.
4.Item Installation Methods
Please follow the below instruction
1)When cleaning,please absorb the water
completely, and then twist all water out.
5.Application Instruction
2)Fix the cloth pads on rotating plates.
A er matching the center of
pad A and rota ng place B,
presspads slightly to fix.(as fig)
As fig.,the two
sides of pads
are twisted to
move water out
When installing,please connect with power ,may cause the product barrier or electric
shock.
3)When the center of pads and rotating
plate match well, fix the pads.
5)Connecting power, step the button on
the main body, LED will be bright.
7)When using, press the water spray
button for water spraying.(with full water
inside)
8)When there is no water spraying out,
please power off and ref1ll into water.
6)Hold the handle, press the button.The
battery must be inserted into the handle.
4)Before cleaning, please confirm there
is no foreign objects on the floor(the
foreign objects may cause the barrier or
accidents of product.
2.Slide the bottom end of Telescopic pipe
onto the polisher head until pipe button clicks
into place. When fixing well, you will hear
“clicking”sound,After connecting, please
pull tightly to ensure. Whether the installation
is good.
3.Open the battery cover in the back part of
handle，put in 2*3AAA, 1.5v battery，close the
battery cover .Connect handle with telescopic
pipe，Insert handle into pipe until pipe button
clicks into place.When fixing well, you will hear
“clicking”sound. After connecting，please pull
tightly to ensure. Whether the installation is good.

9
Relevant safety attentions
Once the batter has the visible bulging problem that is very dangerous, please contact
.
●Please don`t use or store at the places of high temperature,such as Sauna room.
●Please don`t touch the connector of battery with coin,necklace,keys,etc.
●Please use the NI-MH Battery that is pointed by the manufacturer.
●Please don`t uninstall, press, beat, etc.
6.Relevant Safety Attentions
●The cloth pads and the rotating plate should be pasted well.
●The center of pads and rotating plate should match well.
with the manufacturer or distributor immediately.
●Please use the correct and pointed adaptor for charging.
●Please don`t be close to fire or flammable objects(Don`t put into microwave oven)
●Please don`t put into the cars in summer.
For your safety,please follow the attentions as below.
8.Washing Attentions Of Cleaning Pads
Washing Attentions Of Cleaning Pads
Can`t start
Much water left on floor ●Please ensure whether the pads are wet.
The machine body shocks seriously ●Please ensure whether the pads are installed well.
There is the foreign noise when cleaning ●There is the light “buzz” noise, which is normal.
●Please ensure whether the is foreign objects.
Barriers’ Appearances Confirmed subjects
10
7.Cloth Pads Installation
9.Problem Solving
and dry
When machine washing ,please
absorb some detergent for
washing
Detergent
℃water,
put in moderate detergent
and washing
9)Please use the adaptor of this product for charging(The charging time is around 3
hours, When the three LED blue charging indicator is always light and no longer flashes,
the power is full.
●When using the products, there is the after-sale claims without any problems. Please
confirm the below subjects.
●Which can solve the simple problems and comfirm whether these is the real problems,
also can reduce the unnecessary troubles.
●Please ensure whether the product has been
charged.
●please ensure whether the switch has been started.
●Please ensure whether the hand of product has the
battery and the battery capacity enough.
●The normal running time us 20 minutes, there will be
the difference for different environment.
●Please ensure whether the product is overtime
used,after 2 hours, please restart.
●Please don't do the unnormal colliding action, such as falling down from the high
places.
●Please don t put into the high temperature above 60℃. (avoid the direct sunshine)
●should be far from the wet.
●If the battery has leakage, don t touch the skin with liquid. If touched carelessly, please
clean with water and see the doctor.
●Please recognize the correct using of two electric poles(+)(-).
oPlease keep the battery far from the places that the children can reach.
●lf swallowed the battery, please see the doctor immediately.
●If stored the battery separately, please put it at the dry and clean place.
●Please clean the dirty on the battery with clean and dry cloth.
●Please follow the correct instruction of manufacturer for charging.
●After long time storage,in order to achieve at the best performance, please charge
and discharge repeatedly for several times.
●When using the battery under the normal temperature (20+5℃) ,the performance is the
best.
●Please use the battery correctly according to its application.
●Please handle the scrapped battery correctly.

Sterilizing UV Lamp Product Specification
ENVIRONMENT-FRIENDL
DESIGNED BY BOBOT ROBOTICS INC.(USA)
Y DIPOSAL
11 12
You can help protect the environment!
Please remember to respect the local regulations:
Hand in the non-working electrical equipments to an appropriate waste
disposal centre.
10.Product Specification
Model No: MOP OPT
Rated Voltage: DC 14.4V
Rated Power: 85W
Noise Level: about 60dB
Battery Capacity: 2600mAh
Net Weight: 4.4kg
Giftbox Size: 510*376*155mm
Charging Time: 4-5h
Working Time: >45min(Dry)
> 25min(Wet)
Water Tank: 240ml
Product Size: 405*220*1200mm
Net Weight: 3.2kg
Package Size: 530* 393*173mm
For continuous product improvement, we reseve the right to any technical and
design change
Parts Introduction
The role of the UV lamp is mainly used for indoor sterilization and disinfection in the
home, killing ground bacteria and viruses while mopping the floor.One machine for
multiple uses.
Eect
Instructions
After starting the machine, you can see the two LEDs on the left and right of the UV
module are on, you can use it, enjoy the clean floor and sterilize at the same time
Convenience.
UV lamp module
Indicator light
Precautions
1, it is strictly forbidden to directly touch the UV lamp tube with hands, so as not to
cause scratches or damage, thereby affecting the service life of the UV lamp tube.
2, the use of UV lamps in flammable and explosive materials is prohibited to prevent
explosion.
3, do not look directly at the lit UV with naked eyes, so as not to irritate the eyes or
cause vision loss.
4. Do not touch the UV lamp that is lit or just turned off with your hands, otherwise
the surface temperature will be too high and burns.
5. When using, please pay attention not to let the UV lamp shine on the skin, so as
not to damage the skin by ultraviolet radiation.
Twenty-six, try not to switch on and off the UV lamp frequently, because the lamp
tube will be lost and the service life of the UV lamp will be reduced every time you
switch on and off.
7. When installing or replacing the UV lamp tube or cleaning the lamp cover, the
power must be turned off to avoid electric shock.

MAKE THE WORLD CLEAN
MOP OPT
无线电动拖地机
使用产品前请仔细阅读本使用说明书，并妥善保管本使用说明书
使用说明书
目录 BOBOT ROBOTICS INC.
产品简介
一、电源使用注意事项
二、安装及保管注意事项
三、产品安装方法
四、产品使用方法
五、正确安装清洁布
六、清洁布清洗注意事项
七、安全相关注意事项
八、报修前请先确认
九、产品参数
十、UV杀菌灯················································10
····················································1
··········································2
········································3
·············································6
·············································7
···········································8
········································8
··········································8
············································9
·················································9

无线遥控手柄
铝合金管
前置指示灯
电源脚踏开关
喷水口
喷水按钮
开关按钮
伸缩按钮
转轴连接件
注水口
可拆卸电池包
1 2
产品简介
拖布 漏斗适配器 量杯 说明书
●本产品仅作为室内清洁用途，请勿用作其他用途。
一、电源使用注意事项
请务必遵守使用说明，使用不当可能会造成触电危险！
●电源线、插头破损情况下为避免危险，请勿使用产品，并立即联系售后服务中心进行处理。
请确认产品电源线、
插头是否有破损或
老化现象。
（可能导致触电或火灾）
请勿用潮湿的手操作
插头和开关。
（可能导致触电）
拔插电源插头时，
请勿拉扯电线，
请捏紧插头两侧
正常拔出。
（可能导致触电或火灾）
插座松动会产生热量将
插头或电源线融化而导
致漏电。
（可能导致触电或火灾）
请避免电源线被重物
挤压或接触尖锐的部位。
（可能导致触电或火灾）
请勿与其他产品共用插座。
（可能导致异常或火灾）
请务必使用本产品专用适配器
进行充电。
（防止故障或火灾）
充电过程中，请勿启动产品。
-使用时，请确认充电完成。
当三颗灯全亮
表示充电完成。
-为确保机器使用性能，
请及时充电。
产品简介 电源使用注意事项
BOBOT ROBOTICS INC. BOBOT ROBOTICS INC.

安装及保管注意事项
3 4
二、 安装及保管注意事项
警告 ！使用不当可能会导致重伤或死亡。请务必遵守！
暖炉,蜡烛,等明火器具，
请勿放置在拖把周围。
（塑料件或电源线融化，
可能导致火灾或触电）
煤气漏气的情况下请勿
碰触插座或插头，请先
换气。
（可能导致爆炸或火灾）
请不要让儿童攀爬或将
拖把当玩具。
（可能导致从清洁器摔
下受伤）
产品保管时请保持干燥，
避免水等液体流入产品。
（可能导致火灾或故障）
充电时请勿使用机器清洁。
（可能导致故障）
除本公司技术人员，请
勿随意拆卸产品。
（可能导致产品故障）
请勿将产品浸泡到装水
的容器内。
（可能导致火灾或触电）
产品保管温度为0℃~40℃。
产品或电源线等破损时，
请及时联系售后中心，
咨询、维修。
请注意不要让儿童，老人
或不懂使用方法的人使用。
产品使用前，请务必正确
安装布擦。
挪动产品时，请先关闭电源
开关，握住手柄再进行移动。
产品使用中，请勿踩踏或
重力冲击产品。
（可能导致产品故障）
清洁时，请勿将产品
清洁拖头强行塞入家
具，沙发，床等缝隙处。
请不要摔打或重力冲击产品。
（可能产生故障）
产品移动时，正确握住手柄
移动，请勿反握。
请勿用力撞击或踩踏机器，
可能导致机器运作暂停。
请关闭电源开关约2秒后
重新开启。若开启后机器
未运作，请充电后再次操作
（电池过载保护现象）
产品使用中需更换清洁布
时，请先关闭开关，待旋
转盘完全停止转动后再取
下拖布。
安装及保管注意事项
BOBOT ROBOTICS INC. BOBOT ROBOTICS INC.

5 6
安装产品时，请勿接通电源，可能导致产品故障或触电。
三、产品安装方法
1. 首先从包装箱中取出各部分进行连接
2.将伸缩连接管插入转轴连接件内,出现“咔哒”
“咔哒”
声响确认伸缩
连接管的弹珠与转轴连接件的孔装配到位,连接后,提拉伸缩连
接管,确保已牢固连接
3. 打开手柄后方的电池盒盖,按所标识的正负极装入两颗 7
号干电池,再盖上电池盒盖将。手柄按方向与伸缩连接管连杆
出现 声响,确认伸缩连接管的弹珠与手柄的孔装配到
位连 。接后请上下稍微用力拉拽,确认是否已安装好
产品有异响或焦味，烟
雾产生时请立即关闭开
关拔出电池并联系售后
服务中心。
（可能导致触电或火灾
及产品性能降低）
请勿用针或钉子等导
电物体接触产品连接部位。
（可能导致触电或产品
损伤）
请依照擦布安装说明
正确安装清洁布。
（可能导致底盘运作不一）
加水时，请使用产品配
套计量杯，防止加水过溢。
请在平坦的室内地面使用。
地面石子或异物较多时，
请清扫后再使用。
（可能导致清洁性能降低
或机器故障）
请勿在产品未安装清洁
擦布的情况下使用。
产品仅作室内清洁用，
请勿做他用。
产品使用过程中，请
勿用手接触底盘或对
向人使用。
（可能导致事故或产品
故障）
产品使用中，请远离宠物。， 产品使用中请勿接近
磁铁或金属类制品。
（可能导致运作不良）
电 池
使用环境不同，机器
使用时间及电池寿命会
有所区别。
机器使用过程中，请勿
让电源线或其他物品
缠入底盘。
（可能导致机器故障或
事故）
安装及保管注意事项 产品安装方法
BOBOT ROBOTICS INC. BOBOT ROBOTICS INC.

四、 产品使用方法
请务必依照下列说明操作
五、正确安装清洁布
擦布需与底座旋转盘的中心尽量一致
7 8
如图,擦布两侧
卷曲后拧去水分
底座转盘
1.清洗时，擦布充分湿
润后，适当用力拧去
水分。
2.底座旋转盘向上固定擦布。
对准中心点安装！
4.清洁前，请先确保地面无异物。
（异物存在可能导致产品故障或
事故）
5.连接电源，按下主机上
的电源开关，主机前部LED
灯会亮起。
6.握住把手，按下电源开关
7. 运作时，按住喷水控制
按钮，即可喷水。
（已注满水）
8. 使用本产品配套
的充电器进行充电
产品使用方法 正确安装清洁布
BOBOT ROBOTICS INC. BOBOT ROBOTICS INC.
请使用原装配套充电适配器对电池进行充电，如使用替代产品可能会出现充不进电或短路。
擦布
擦布
擦布擦布
擦布
擦布
擦布
擦布中心点与底座转盘
中心点对齐后，固定擦布。
擦布轻微折叠，十字折线与底盘
靠近，中心点对准，布擦A部分
与B部分先进行固定。(如图)

9 10
10.请正确分辨干电池正负两极使用。
11.将电池保管于儿童无法触及的地方。
12.请将电池和产品置于阴凉干燥处存放。
13.请参考厂商指示事项，正确充电。
14.需要长期存放时，为保证最佳性能，需每月将将电池充放电一次。
15.电池在常温下启动，表现性能最佳。
16.请勿将电池另作其他用途，电池报废后请入有害垃圾。
17.长期存放不使用本产品时，最少每一个月给产品充满电1次。
八、报修前请先确认
请先确认以下项目，解决简单问题及确认是否故障来减少不必要的麻烦。
故障现象
无法启动 1）请确认是否已充电
2）请确认电源开关已启动
3）充电完成正常使用时间约 20 分钟,使用条件不会
稍有偏差
4）请确认是否过度使用导致电机暂停工作
地面水渍较多 请确认擦布是否潮湿
清洁时机身晃动严重 请确认擦布是否正确安装
清洁时发出异响 1）产品动作过程会有轻微的“嗡嗡”声,属于正常
确认事项
2）请确认底座旋转盘是否有异物
九、产品参数
min
3.2kg4.4kg
DC
510*376*155mm
产品尺寸
毛 重
彩盒尺寸 530* 393*173 mm
单个外箱
净 重
MOP OPT
约
405*220*1200mm
85W
2600mAh
45min(干拖)
4-5h
25
240ml
BOBOT ROBOTICS INC.
报修前请先确认 BOBOT ROBOTICS INC. 带杀菌UV灯
ENVIRONMENT-FRIENDL
DESIGNED BY BOBOT ROBOTICS INC.(USA)
Y DIPOSAL
You can help protect the environment!
Please remember to respect the local regulations:
Hand in the non-working electrical equipments to an appropriate waste
disposal centre.
For continuous product improvement, we reseve the right to any technical and
design change
UV灯部件简介
如何使用
当启动机器后，看到UV模块左右两个指示灯点亮，
即可使用，享受清洁地面同时杀菌的便捷。
注意事项
一、严禁用手直接接触uv灯管，以免造成刮擦或破损，从而影响uv灯管的使用寿命。
二、禁止在易燃易爆物品之处使用uv灯，以免发生爆炸。
三、不要用肉眼直视点亮的uv等，以免刺痛眼睛或导致视力下降。
四、不要用手触摸点亮着或者刚熄灭的uv灯，以免表面温度过高而烫伤。
五、使用时要注意别让uv灯照射到皮肤，以免皮肤受到紫外线的照射而造成损伤。
六、尽量不要频繁开闭uv灯，因为每次开闭都会损耗灯管并减少uv灯的使用寿命。
七、安装或更换uv灯管或者清洁灯罩时，必须关闭电源，以免触电。
UV灯模块
指示灯
