Steamfast SteamMax SF-475 User manual

SteamMax
TM
Garment Plus
Model SF-475
by Top Innovations, Inc.
Please read instructions before use.
Mail in your warranty registration card.

Dear Valued Customer,
Thank you for purchasing the SteamMax
TM
Garment Plus steamer.
This revolutionary new product uses a high-pressure system to create a
powerful flow of steam. This versatile unit is equipped with two unique
modes of steaming: a Spot Cleaner and a Fabric Steamer.
Turn your steamer on, and in minutes, you are ready to eliminate dirt,
grease, and other stains from your fabrics and linens. Or, with the twist of
a
knob, you can remove wrinkles from your garments with Tailor-Quality
Results, eliminating time-consuming and expensive trips to a professional
dry cleaner. In addition to removing stains and wrinkles, you will receive
the many benefits that steam provides. Hot steam refreshes fabric and
eliminates smoke and other unpleasant odors, as well as dust mites and
other allergens. Use it on curtains, upholstery, and more to make your
home fresher and cleaner than ever before. And when you’re finished
steaming, the SteamMax
TM
Garment Plus’ compact size and convenient
telescopic pole make cleaning and storage quick and simple.
Top Innovations, Inc. would like to invite you to take advantage of our
Customer Support web site at:
www.topinnovations.com
On this website you will find additional information about many other
exciting Steam Fast products that are available, helpful tips on ways in
which you can utilize your SteamMax
TM
Garment Plus, and other useful
information to assist you in maximizing the power of steam!
Enjoy your new SteamMax
TM
Garment Plus!
Benny Lee
Chairman and CEO
Top Innovations, Inc.
L ETTER FROM THE CEO
2

Water Tank Capacity 44 oz.
Steam Duration – Full Water Tank 36 min.
Input Voltage 120 volts
Input Frequency 60 hertz
Output Power 1500 watts
CUSTOMER SUPPORT
For problems with your steamer, please refer to the Troubleshooting
Guide Located on page 13 of this manual. Additional inquiries should be
directed to our Customer Support services at 1-800-711-6617 ext. 102 /
130 or e-mailed to:
[email protected]
Should there be any missing or defective parts or accessories, contact
Customer Support. In most cases, it is not necessary to return the entire
unit. We can ship most parts directly to your door.
To ensure prompt and accurate service, call for a Return
Authorization number before returnin
g
an
y
unit to Top Innovations.
Failure to obtain a Return Authorization number will cause a delay
in warranty or out-of-warranty service requests.
S UPPORT AND S PECIFICATIONS
PRODUCT SPECIFICATIONS
3

1. DO NOT leave your SF-475 SteamMax
TM
Garment Plus unattended when
plugged in or not in use.
2. This unit is not a toy. Close supervision is required when using
unit near children, pets, and plants. Steam produced by it is hot and
pressurized. Care must be taken to avoid burns or other injuries. Never
point nozzle at pets or people.
3. Always unplug electrical cord when unit is not in use. DO NOT use this
unit if electrical cord or outlet is damaged. DO NOT use unit if it is not
working properly or has been dropped, damaged, or left outdoors. If such
damage occurs, return unit to an approved service technician for repair.
4. This unit is an electrical appliance. DO NOT submerge it in water. DO
N
OT use steam hose or electrical cord as a handle. DO NOT allow cord to
be crimped by closing it in doors or allowing the unit to roll over it. DO
N
OT pull or stretch cord around sharp corners or edges. Be sure to keep
electrical cord away from all heated surfaces.
5. DO NOT use this unit with electrical cords or outlets that have inadequate
current capacity. A three-prong outlet or a properly grounded adapter is
necessary when using SF-475 SteamMax
TM
Garment Plus.
6. In order to unplug SF-475 SteamMax
TM
Garment Plus, grasp plug and pull
smoothly and firmly from outlet. DO NOT attempt to unplug unit by pulling
or tugging on cord.
7. Always keep Steam Nozzle elevated above Water Reservoir. DO NOT
lay hose on floor.
SAVE THESE INSTRUCTIONS!
F OR HOUSEHOLD USE ONLY
4
I MPORTANT S AFEGUARDS
WARNING: To reduce the risk of fire, electrical shock, or
injury, the following basic safety precautions should always
be followed when using an electrical appliance.
READ ALL INSTRUCTIONS BEFORE USING YOU
R
STEAME
R

8. DO NOT handle or use this unit while hands are wet or when not wearing
shoes. To avoid falls and other injuries, be sure to dry any wet areas on
floors and to stand away from damp surfaces while using steam cleaner.
9. SF-475 SteamMax
TM
Garment Plus is only meant to be used with
recommended SF-475 accessories. Other types of attachments such as those
used with vacuum cleaners are not to be used with SteamMax
TM
Garment
Plus. Doing so may cause injuries or damage to unit.
10. Nozzles and attachments become hot during use. To avoid injuries, DO
N
OT touch nozzles while using this appliance. DO NOT attempt to change
attachments while unit is emitting steam.
11. DO NOT turn unit on its side when in use.
12. When filling your SteamMax
TM
Garment Plus with water, DO NOT
overfill Water Reservoir.
13. Before filling unit with water, always take the following steps:
(1) Turn appliance off
(2) Unplug electrical cord
Failure to follow these steps may result in electric shock and injury.
14. Only water should be used in unit. Other cleaning agents will damage
unit and can cause injuries.
15. DO NOT operate unit if steam opening is blocked. Should this occur,
shut unit off and unplug.
16. Store your SF-475 SteamMax
TM
Garment Plus in a cool, dry place. Allow
unit to cool completely, and drain Water Reservoir before storage.
SAVE THESE INSTRUCTIONS!
F OR HOUSEHOLD USE ONLY
5
I MPORTANT S AFEGUARDS
WARNING: To reduce the risk of electric shock, this appliance
has a three-pronged plug. This plug will fit in a polarized wall
outlet only one way. If the plug does not fit fully in the outlet,
contact a qualified electrician to install a proper outlet. DO NOT
attempt to modify the plug or defeat this safety feature in any way.

SF-475 S TEAM M AX
TM
G ARMENT P LUS
P RODUCT I NFORMATION
The following features and accessories come with your steamer. Carefully
inspect packaging material as some parts are shipped inside Styrofoam
packaging. To obtain possible missing parts, refer to the Customer Support
section on page 3 of this manual.
6
UNIT FEATURES
1.) Pole Top
1a.) Steam Nozzle Holder
1b.) Clothes Hanger Hook
2.) Telescopic Pole
3.) Hose
4.) Pole Base
5.) Steam Ready Light
6.) Hose Base
7.) Lighted On/Off Switch
8.) Compartment Lid
8a.) Water Reservoir Cap
8b.) Accessory Compartment
9.) Water Reservoir
10.) Handle
11.) Mode Select Knob
12.) Steam Nozzle
13.) Fabric Steamer
14.) Fabric Brush
15.) Spot Cleaner
16.) Spot Cleaner Brush
17.) Measuring Cup
18.)
Water Funnel

·The Pole Top (1) is comprised of the Steam Nozzle Holder (1a) and the
Clothes Hanger Hook (1b). The Steam Nozzle Holder
p
rovides a safe and
convenient place to hang the Steam Nozzle. The Clothes Hanger Hook
allows you to steam garments that are hanging from a clean, rust-free
hanger.
·The Telescopic Pole (2) connects the Pole Top to the steamer and
provides quick, compact storage of the unit.
·The Hose (3) directs steam from boiler to the Handle and Steam Nozzle.
·The Pole Base (4) ensures a stable mount for the Telescopic Pole.
·The Steam Ready Light (5) indicates when the unit is ready to steam.
·The Hose Base (6) is a threaded metal pipe for attachment of the Hose.
·The Lighted On/Off Switch (7) provides a clear visual indication that the
steamer is in use.
·The Compartment Lid (8) covers the compartment which houses the
Water Reservoir Cap (8a) and the Accessory Compartment (8b). The
Water Reservoir Cap covers the opening through which water is poured
into the Water Reservoir. The Accessory Compartment provides a safe
and convenient place to store small accessories.
·The Water Reservoir (9) is where water is stored for use by the unit.
There must be a sufficient amount of water in the Water Reservoir in
order for the unit to function.
·The Handle (10) is permanently attached to the Steam Nozzle. It is
designed to stay relatively cool and is safe to grasp. Use the Handle to
safely direct steam onto desired surface or fabric.
·The Steam Nozzle (12) spreads steam over a wide area providing hot,
penetrating steam.
·The Mode Select Knob (11) is used to switch between the units two main
modes of function. When set to “Iron”, the Fabric Steamer (13) will be
the active component of the Steam Nozzle. Attach the Fabric Brush (14)
to the Fabric Steamer for tough wrinkles. When the Mode Select Knob is
set to “Clean”, the Spot Cleaner (15) becomes active. Attach the Spot
Cleaner Brush (16) for tough stains.
·The Measuring Cup (17) and Water Funnel (18) provide a precise and
easy way to fill the Water Reservoir with the proper amount of water.
SF-475 S TEAM M AX
TM
G ARMENT P LUS
P RODUCT I NFORMATION
7

Assembling and Mounting Telescopic Pole
1. Screw top section of Telescopic Pole (A) onto middle section (B)
(FIGURE 1).
2. Place Pole Top on top of Telescopic Pole, and rotate it clockwise until
snug (FIGURE 2).
3. Loosen Top Ridged Knob (C) by turning it counter-clockwise. Pull pole
to extend top section (E) of Telescopic Pole. Tighten Top Ridged Knob
(FIGURE 3).
4. Repeat step 3 for Bottom Ridged Knob (D) to extend middle section (F)
of Telescopic Pole (FIGURE 3).
NOTE: Telescopic Pole must be fully extended during steamer
operation to insure a free flow of steam through Hose.
NOTE: Figures 1, 2, and 3 show Telescopic Pole in collapsed position.
5. Slide ridged base knob onto bottom of Telescopic Pole (FIGURE 4).
6. Insert bottom of Telescopic Pole into Pole Base (FIGURE 5) in such a
way so that Steam Nozzle Holder faces rear of steamer (see illustration
on page 6). Pointing Steam Nozzle Holder towards rear will ensure
stability of steamer when garments are hanging from Clothes Hanger
Hook.
7. Push Telescopic Pole down as far as possible.
8. Turn ridged base knob clockwise to secure Telescopic Pole to Pole Base.
Attaching Hose
1. Screw Hose onto the threaded Hose Base by turning fitting on end of
Hose clockwise (FIGURE 6).
2. Hand-tighten only. Do not over-tighten.
3. Hang Steam Nozzle on specially designed Steam Nozzle Holder as shown
(FIGURE 7).
CAUTION: To prevent steam from causing bodily injury or damage to
surfaces, always hang Steam Nozzle on Steam Nozzle Holder when not
in use. Do not la
y
Hose on the floor as condensation ma
y
occur, causin
g
unwanted water droplets in steam.
CAUTION: Pulling on Hose with excessive force will damage it,
resulting in a steam leak.
A SSEMBLY I NSTRUCTIONS
8

IMPORTANT
- FILLING THE WATER RESERVOIR -
Before filling Water Reservoir, make sure Lighted On/Off Switch is set to
“Off” position and unplug power cord. Fill Water Reservoir with 44 oz.
of water. DO NOT overfill Water Reservoir. Drain Water Reservoir after
every use to avoid overfilling later. DO NOT add detergents or any other
type of chemicals or cleaning compounds to Water Reservoir.
FIGURE
5
FIGURE
4
FIGURE
6
FIGURE
7
FIGURE
2
FIGURE
1
FIGURE
3
9

U SING THE S TEAM M AX
TM
G ARMENT P LUS
STEAM MODE SELECTION
The SteamMax
TM
Garment Plus offers two modes of cleaning: a Spot Cleaner for
steaming dirt, grease, and other stains off of linens and fabrics, and a Fabric Steamer for
pressing your clothing and linens with steam. To switch between modes, turn Mode
Select Knob on Handle to the corresponding mode.
CAUTION: When switching between steam modes the Steam Nozzle may spray
small amounts of heated water. Use care when using the Mode Select Knob to
avoid injury. Do not point Steam Nozzle towards face when switching modes, and
make sure arms and all other body parts are not in a position to be sprayed with
hot water. Do no point Steam Nozzle at people, pets, or plants.
SPOT CLEANING WITH STEAM
- Set Mode Select Knob to “CLEAN” -
1. Connect Spot Cleaner Brush attachment to Spot Cleaner by inserting circular tab
on back of attachment into circular hole on top of Steam Nozzle face. Twist
counter-clockwise until snug to secure in place.
2. Open Compartment Lid and remove Water Reservoir Cap by turning it counter-
clockwise.
3. Fill SteamMax
TM
measuring cup (provided) with 44 oz. of water. We recommend
using distilled or de-mineralized water if possible, to help prevent mineral build-up
in unit.
4. Using SteamMax
TM
water funnel (provided), pour contents of measuring cup into
Water Reservoir fill hole. Do not overfill Water Reservoir. Do not use any
detergent, chemical, or other cleaning agent in your SteamMax
TM
Garment
Plus.
5. Replace Water Reservoir Cap and tighten securely.
WARNING: Failure to properly close Water Reservoir Cap may allow hot,
pressurized steam to escape from Water Reservoir, causing bodily injury.
6. Plug power cord into a properly grounded 3-prong electrical outlet. Turn Lighted
On/Off Switch to “On” position to activate unit.
7. SteamMax
TM
Garment Plus will be ready for use in 6 minutes (based on Water
Reservoir filled with 44 oz. of water). Steam Ready Light on top of unit will
illuminate while unit is heating. When light deactivates, the unit is ready for use
and will begin emitting steam.
8. To use, direct Steam Nozzle at fabric or garment you wish to spot clean. Using a
slight back-and-forth motion will enhance the cleaning process when dealing with
tough dirt, grease, and pet stains.
9. To stop the flow of steam, turn Lighted On/Off Switch to “Off” position. Steam
will cease once unit has cooled down and all remaining steam has escaped from
Hose.
10

U SING THE S TEAM M AX
TM
G ARMENT P LUS
FABRIC STEAMING
- Set Mode Select Knob to “IRON” -
1. Connect Fabric Brush attachment to Fabric Steamer by inserting two pegs on
back of attachment into two holes on either side of Steam Nozzle face (note that
semi-circular indention on top of Fabric Brush fits around Spot Cleaner).
2. Follow steps 2-7 of Spot Cleaning with Steam section on page 10 of this manual
to finish preparing unit to steam.
3. To steam a garment, place it on a clean, rust-free clothes hangar and place hangar
on Clothes Hangar Hook.
4. Grasp Handle, and direct Steam Nozzle at bottom of garment. Steam will rise
along inside and outside of fabric, removing wrinkles. Slowly slide Steam Nozzle
vertically, from bottom to top of garment.
NOTE: Do not allow kinks to form in Hose at any time.
5. Direct Steam Nozzle away from garment and smooth fabric with your free hand.
6. Repeat steps 4 and 5 as necessary until fabric is wrinkle-free.
7. Once steaming tasks are complete, turn Lighted On/Off Switch to “Off” position to
stop the flow of steam. Steam will cease once unit has cooled down and all
remaining steam has escaped from Hose.
TIPS FOR FABRIC STEAMING
·Curtains and draperies can be steamed while still hanging.
·To remove wrinkles from towels, handkerchiefs, and napkins, drape them over a
rod or towel rack and gently steam.
·Heavier fabrics may require repeated steaming to achieve desired results.
·To remove exceptionally stubborn wrinkles, steam both sides of fabric.
11
IMPORTANT
- CONDENSATION IN HOSE -
When steamer is first activated it is natural for it to spray small amounts of
water. This is due to condensation forming in Hose, and will dissipate
within 30 seconds of use. To help clear condensation out of Hose faster, try
the following:
- Point Steam Nozzle towards ground and shake it to force water out
of Hose
- Extend Hose vertically as far as possible to allow water to drain bac
k
into Water Reservoir

PROPER STORAGE
1. Preparing your SteamMax
TM
Garment Plus for storage is quick and simple.
When you have finished your steaming tasks, turn power switch to “Off”
position. Unplug power cord, and allow unit to cool completely. After unit has
cooled, dump any remaining water in Water Reservoir into a sink or tub to
prevent overfilling during your next use. This also serves to minimize potential
mineral buildup in Water Reservoir.
2. Store any small accessories neatly into Accessory Compartment.
3. Loosen two ridged knobs on Telescopic Pole by turning them counter-
clockwise, and push down on the Pole Top; pole will collapse to a compact
height.
4. Wrap Hose around Telescopic Pole one time, and hang Steam Nozzle from
Steam Nozzle Holder.
5. Store unit indoors in a cool, dry area.
C ARE AND S TORAGE G UIDELINES
REMOVING MINERAL BUILD-UP
One common problem with steam appliances is mineral build-up caused by high
mineral content in many municipal water supplies.
The best way to avoid this is to use de-mineralized or distilled water in unit.
If you are unable to use de-mineralized or distilled water, we recommend you use
this procedure monthly to help avoid mineral build-up:
1. Turn unit off, and unplug power cord.
2. Remove Water Reservoir Cap and drain Water Reservoir into sink or tub.
3. Remove Hose and Telescopic Pole from unit.
4. Using SteamMax
TM
measuring cup (provided), make a mixture of 8oz. vinegar
and 8oz. water.
5. Slowly pour water-vinegar solution into Water Reservoir, using SteamMax
TM
water funnel (provided).
6. Allow to stand for 40 minutes.
7. Drain water-vinegar solution from Water Reservoir.
8. Rinse Water Reservoir with fresh water and drain until vinegar odor dissipates.
9. Replace Water Reservoir Cap.
12

T ROUBLESHOOTING G UIDE
PROBLEM POSSIBLE CAUSE SOLUTION
Unit fails to steam. Light
on the On/Off Switch
does not illuminate.
Steamer is not plugged in Plug into electrical outlet
Household Circuit
Breaker / Ground Fault
Interrupter has tripped or
blown a fuse.
Reset Circuit Breaker /
Ground Fault Interrupter,
or replace fuse. If you
need assistance, contact a
qualified electrician.
Unit fails to steam. Light
on the On/Off Switch
does illuminate.
Mineral buildup in unit.
Water Tank is empty.
Follow Removing
Mineral Buildup
procedure on page 12 of
this manual.
Refill Water Tank using
p
rocedures on page 10 of
this manual.
Water drips from nozzle. Condensation has built
up in Hose.
Extend Hose vertically to
allow water to drain back
into Water Reservoir.
Excessive gurgling of
Hose and Steam Nozzle.
Condensation has built
up in Hose.
Some gurgling is a
natural effect of the
steaming process. For
excessive gurgling,
extend Hose vertically to
allow water to drain back
into Water Reservoir.
Steam output is
intermittent.
Mineral buildup in unit. It is normal for unit to
periodically stop
steaming for a few
seconds. If steam stays
off for longer periods,
follow Removing
Mineral Buildup
procedure on page 12 of
this manual.
13
Steam mode not properly
selected.
Turn Mode Select Knob
completely to one of the
two steaming modes.

14
PART PART DESCRIPTION PRICE QTY. TOTAL
(+ $3.99 S&H)
Method of Payment (no C.O.D. orders)
Check or Money Order (payable to Top Innovations
Charge to my VISA MASTERCARD
ACCOUNT NUMBER
EXPIRATION DATE
SIGNATURE: ____________________________________________
N
AME: __________________________________________________
MAILING ADDRESS: _____________________________________
_
________________________________________________________
TELEPHONE: ____________________________________________
(Full name as shown on account)
TO ORDER:
B
Y M AIL
Fill out this form
and return to
address on back of
this manual
B Y P HONE
[phone]
EXT. # 102/130
B Y F AX
[phone]
M ODEL SF-475
A475-001 SF-475 Fabric Brush $5.99
A475-002 SF-475 Spot Cleaner Brush $3.99
A475-003 SF-475 SteamMax
TM
Measuring Cup $5.99
A475-004 SF-475 SteamMax
TM
Water Funnel $5.99
ACCESSORY ORDER FORM
S TEAM M A
X
TM
G ARMENT P LUS

W ARRANTY I NFORMATION
ONE YEAR LIMITED WARRANTY
(If outside USA, additional shipping charges may apply)
Top Innovations, Inc. warrants this product to be free from defects in material
and workmanship for a period of one (1) year from the date of purchase. This
warranty does not cover damage caused by misuse, negligence, use by
improper current or voltage, use contrary to operating instructions or
disassembly, repair or alteration by any person other than Top Innovations,
Inc. Warranty Service Department.
Top Innovations, Inc. will repair or replace, at its option. This warranty gives
you specific legal rights and may have other rights, which may vary from
state to state.
Performance of any obligation under this warranty may be obtained by:
1. Call [phone] for Return Authorization Number before returning
for repair
2. Include copy of purchase receipt
3. Include your name, address, telephone number, and Return Authorization
Number on returned package
Please send product postage prepaid to:
TOP INNOVATIONS, INC.
WARRANTY SERVICE DEPARTMENT
400 NW PLATTE VALLEY DR.
RIVERSIDE, MO 64150
After 1 year limited warranty has expired, you will be advised of the cost of
repair before any servicing is done unless you enclose a note indicating that
you would like us to proceed with repairs.
If you have any questions about coverage under this warranty, you may
contact warranty service department by telephone at [phone] ext. 102
/
130 or e-mail custom[email protected]
15

Printed In China
Top Innovations, Inc.
400 NW Platte Valley Dr.
Riverside, MO 64150
Tel: [phone]
www.topinnovations.com
[email protected]
V0307
14
