Bogen NYQUIST NQ-GA10P Quick start guide

NQ-GA10P, NQ-GA10PV VoIP
Intercom Module Installation
and Use
The NQ-GA10P
is a plenum rated
Voice over Internet
Protocol (VoIP)
intercom module
that is designed
for exible installation and mounting options.
The module features an integrated 10 watt power
amplier, an 8-ohm analog speaker connection, a
dry-contact analog call switch input, a CAN Bus port
interface, and a Form C SPST type 2-amp dry contact
relay.
The NQ-GA10PV
model also features
an HDMI video
output. Designed
to run on a 10/100
Ethernet network,
the NQ-GA10P and
the NQ-GA10PV are IEEE 802.3af compliant and
can be powered using Power-Over-Ethernet (PoE),
or if that is not available, it can be powered via an
optional 48VDC 15W power adapter.
Publication Number 740-00053A
1807

Notice
Every effort was made to ensure that the information
in this manual was complete and accurate at the
time of printing, however, all information is subject to
change.
WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
Avertissement: pour réduire le risque d’incendie ou
de choc électrique, ne pas exposer cet appareil sous
la pluie et l’humidité.
The apparatus shall not be exposed to dripping or
splashing and that no objects lled with liquids, such
as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux écoulements
ou aux éclaboussures et aucun objet ne contenant
de liquide, tel qu’un vase, ne doit être placé sur
l’objet.
This equipment is not suitable for use in locations
where children are likely to be present.
Equipment is intended for use
only in a restricted access area.
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
2

Important Safety Information
WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
Always comply with the following basic safety
precautions when installing and using the unit:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry cloth.
6. DO NOT install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce
heat.
7. Only use attachments/accessories that are
specied by the manufacturer.
8. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
3

cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
Installation
To install the VoIP Intercom Module:
1. Attach the desired speakers and their associated
call switches to the module using the pluggable
connectors provided, where the 1 and 2 terminals
connect to the +/- speaker wires and the “G” and
“A” terminals connect to the asociated wires from
the analog call switch. (See Fig. 1.)
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
4

2. If using the NQ-GA10P/PV in an intercom
talkback application, connect the speaker to the
power amplier’s 1 and 2 output and use either
the NQ-E7020 or the CA-15C. (See Fig. 1.)
3. If the CAN Bus is to be used, ensure CAN_H and
CAN_L use (Cat5 10/100) twisted pair cable.
4. Connect a Cat5 type cable into the module’s
Ethernet port and ensure the other end of the
cable is correctly connected to your network.
5. If PoE is not available and your are using a 48V
power supply, connect the Bogen PS48 15W
power supply to the module.
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
5

6. If using the Bogen ANS500M ambient sound
microphone, connect (-) on the ANS500M to Pin
1 and (+) on the ANS500M to Pin 2. (See Fig. 2.)
Further conguration is done through the Nyquist
Admin web-based user interface (UI). See the
Nyquist System Administrator Manual.
7. If using the Bogen DDRU250 desktop microphone
as a Push-to-Talk device, connect the microphone
as shown in Fig. 3.
Further conguration is done through the Nyquist
Admin web-based user interface (UI). See the
Nyquist System Administrator Manual.
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
6

Viewing and Understanding LEDs
Two LEDs appear on the
front of the module. One
is labeled POWER and
appears as solid red during
initial power up, ashes
green during a boot se-
quence, and appears solid
green when fully booted.
The STATUS LED uses the following indicators to
provide information about the module:
• Flashing red – No network connection found.
• Solid blue – The module is in an uninitialized
state and is not associated to a Nyquist server.
(The server may be in a discovery mode.)
• Solid red – The module needs to be rebooted or
reset so that the Nyquist application can resume.
• Flashing blue – The module is updating.
• Solid green – The module is registered to a Ny-
quist server and is in normal operation.
• Flashing green – The module has an IP address
but is not registered with the Nyquist server.
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
7

Using the Reset Button
The Reset button allows
you to restart the module
or to reset the module’s
conguration settings
to the factory default
settings.
For more information
about resetting
conguration settings,
refer to the Nyquist NQ-GA10P, NQ-GA10PV
Conguration Manual.
Temperature Indicator
In addition to the LEDs that appear on the actual
appliance, a separate temperature status indicator
appears on the module’s web-based user interface.
For more information, refer to the Nyquist NQ-GA10P,
NQ-GA10PV Conguration Manual.
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
8

Compliance
NOTE: This equipment has been tested and found
to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These lim-
its are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case
the user will be required to correct the interference
at his own expense.
1200 MacArthur Blvd. Suite 304,
Mahwah, NJ 07430
1-800-999-2809
© Copyright 2018, Bogen Communications, Inc.
9

Limited Warranty, Exclusion of
Certain Damages
The NQ-GA10P and NQ-GA10PV are warranted to
be free from defects in materials and workmanship
for ve (5) years from the date of sale to the origi-
nal purchaser. Any part of the product covered by
this warranty that, with normal installation and use,
becomes defective (as conrmed by Bogen upon in-
spection) during the warranty period will be repaired
or replaced by Bogen, at Bogen’s option, with new or
refurbished product, provided the product is shipped
insured and prepaid to: Bogen Factory Service De-
partment: 4570 Shelby Air Drive, Suite 11, Memphis,
TN 38118, USA. Repaired or replacement product(s)
will be returned to you freight prepaid. This warranty
does not extend to any of our products that have
been subjected to abuse, misuse, improper storage,
neglect, accident, improper installation or have been
modied or repaired or altered in any manner what-
soever, or where the serial number or date code has
been removed or defaced.
THE FOREGOING LIMITED WARRANTY IS BOGEN’S
SOLE AND EXCLUSIVE WARRANTY AND THE PUR-
CHASER’S SOLE AND EXCLUSIVE REMEDY. BOGEN
