CEILING GRID
CEILING GRID
SUPPORT RAIL
CROSSBAR INCLUDED
(2 ft. X 4 ft. CEILING GRID ONLY)
CEILING TILE
(CUT IN HALF, OR NO MORE
THAN 23-3/4")
2 ft. X 2 ft.
TILE SPACE
2 ft. X 4 ft.
TILE SPACE
Low-Impedance Drop-In
Ceiling Speaker
with Back Can
CSD2X2L(U)
Bogen’s CSD2X2L(U) Drop-In Ceiling Speakers are 8-ohm,
full-range speakers that allow for fast and easy installa-
tion, which saves installation time, effort, and cost.
The CSD2X2L(U) is a 2' x 2' speaker that fits perfectly
into place in 2' x 2' ceiling grids – without needing to
cut ceiling tiles or requiring the use of tile support rails.
The CSD2X2L(U) can also be easily installed in 2' x 4'
ceiling grids – just make one cut to the ceiling tile, posi-
tion the support rail (included), and drop the speaker
into place.
•Finely perforated grille over the entire front of speaker
•Fully enclosed, industrial grade steel construction
•Enclosed Back Can
•8'' main cone with secondary high-frequency cone
•Low-Impedance: 8-ohm speaker, 15W max. power
•Seismic attachment points
•Complies with Requirements of UL-2043
•Support Rail Crossbar (included)
•Available in Off-white and Bright White ("U" versions)
grille finish
CSD2X2L(U)CSD2X2L(U)

Frequency Response . . . . . . . . . . 85 Hz - 20 kHz
SPL @ 1W / 1m . . . . . . . . . . . . . . . 94 dB
Maximum Power . . . . . . . . . . . . . . 15 watts @ 8-ohm
Dispersion @ 2 kHz
(6 dB down) . . . . . . . . . . . . . . . . . .100°
Cone Material & Surround . . . . . . Treated paper
Cones . . . . . . . . . . . . . . . . . . . . . . .
8" main cone with secondary
high frequency cone
Magnet Weight . . . . . . . . . . . . . . . .10 oz.
Connection . . . . . . . . . . . . . . . . . . . Via wire nuts (included in electrical box)
Dimensions . . . . . . . . . . . . . . . . . .23-13/16" W x 5" H x 23 -13/16" D
Product Weight . . . . . . . . . . . . . . .12 lb.
Plenum-Rated, complies with Requirements of Standard UL-2043.
The speaker shall be a Bogen Model CSD2X2L(U) Low-Impedance
Drop-In Ceiling Speaker, which shall be fully enclosed and
constructed of industrial grade steel. It shall be comprised of a
damped high-compliance factory-mounted 8" loudspeaker that shall
consist of an 8" treated paper main cone, a secondary high frequency
cone, and a 10 ounce magnet. The unit shall have an 8-ohm nominal
impedance with maximum power of 15 watts. Output shall be 94 dB
@ 1 watt / 1 meter (min.). Frequency response shall be 85 Hz - 20
kHz (min.). The speaker shall include 4 seismic attachment points.
The speaker shall have a non-reflective, Off-white or Bright White
("U" versions) metal finish grille.
The speaker assembly will fit into 2' x 2' and 2' x 4' ceiling tiles.
For 2' x 2' installations, a support rail shall not be needed and no
cuts to the ceiling shall be necessary. For 2' x 4' installations, a single
cut to the ceiling tile and an included support rail shall be needed.
The speaker shall measure 23-13/16" W x 5" H x 23-13/16" D and
weigh 12 lb.
SPECIFICATIONS
Architect and Engineer Specifications
50 Spring Street, Ramsey, NJ 07446, U.S.A.
Tel: [phone] • Fax: [phone]
www.bogen.com
Specifications subject to change without notice.
© 2008 Bogen Communications, Inc.
54-9283-01B 0902
SUPPORT RAIL
CROSSBAR INCLUDED
(FOR USE WITHIN 2' X 4' TILE SPACE ONLY)
SEISMIC
ATTACHMENT
POINTS (4X) COVER
COVER
WIRE
NUTS
WIRE
NUTS
Lead Color
+Red
—
—
Black
FINELY PERFORATED
METAL FINISH GRILLE
Low-Impedance Drop-In Ceiling Speaker CSD2X2L(U)
