BoLiving Java 1 519791 User manual

2020-07-03Rev 1 -
Java 1 Drawer Lamp Table
519791

! Read instructions carefully. Check no parts are missing.
! Assemble the furniture on a soft level surface to avoid damaging the furniture or your floor.
! Carefully identify each component, especially those that are similar.
! The most common mistake is getting things back to front.
! Separate and identify each component from the hardware pack and rest each one in it's
proper location before fastening.
! We recommend furniture be assembled near where they will be placed, to avoid moving the
product unnecessarily once assembled.
! If there is a need to move the furniture, please remove all loose items and have extra hands
to help lift the furniture to the desired location. Dragging the furniture will damage both the
furniture and the floor.
! Regularly check and re-tighten (if necessary) all bolts on furniture that you have assembled
yourself.
WARNING
Keep these instructions for future reference
ALLOW 60 MIN
Page 2
Unit 1, Ubique Business Park, March Way, Battlefield, Shrewsbury, SY1 3JE
2 Persons Required
Tools Required
DO NOT USE ON PRODUCT
Rattan
Rattan is a natural material that will expand and contract with changes in the surrounding humidity
and temperature. Each rattan piece in the furniture may also respond to these changes to a different
degree. Once humidity and temperature return to normal, each rattan piece would also return to its
original shape. This is a natural phenomenon and not a defect.
Warning: Ensure the wall strap is attached to
avoid serious injury
To avoid any serious of fatal injury, a wall strap has been provided with this product to prevent
toppling. We strongly recommend that this product is permanently fixed to the wall or other suitable
surface. Fixing devices are not included since different surface materials require
different attachment. Please seek professional advice if you are in doubt of what fixing device to use.

Parts list
1 x Top Panel (P1)
1 x Bottom Panel (P2)
2 x Side Panels (P3)
1 x Back Panel (P4)
1 x Drawer Front (P5)
1 x Drawer Left Side (P6)
1 x Drawer Right Side (P7)
1 x Drawer Back (P8)
1 x Drawer Base (P9)
4 x Legs (P10)
Top Panel (P1)
Page 3
Bottom Panel (P2)
Side Panel
(P3)
Side Panel
(P3)
Back Panel
(P4)
Drawer Front
(P5)
Drawer Back
(P8)
Drawer Base
(P9)
Leg (P10)
Leg (P10)
Leg (P10)
Drawer Left
Side (P6)
Drawer Right
Side (P7)

Page 4
Hardware Pack
12 x Cam Bolts
(H1)
8 x Big Cam
Nuts (H2)
8 x Dowels ø8mm
(H3)
1 x Handle
(H4)
4 x Screws 16mm
(H6)
10 x Flat Washers
(H9)
8 x Spring
Washers (H10)
2 x Screws 28mm
(H11)
1 x Allen Key
(H12)
4 x Felt Feet
(H5)
8 x Bolts 55mm
(H8)
4 x Back Panel
Connectors (H7)
1 x Screw 25mm
(H14)
4 x Small Cam
Nuts (H15)
1 x Wall Strap
(H13)
2 x Dowels ø6mm
(H16)
4 x Screws 38mm
(H17)
2 x Slides
(H19)
12 x Screws 12mm
(H18)

Step 1
Page 5
You will need
Attach 1 x felt foot (H5) onto each leg (P10) as shown.
Step 2
You will need
8 x Bolts
55mm (H8)
Attach leg (P10) onto bottom panel (P2),
using 2 x bolts (H8), 2 x flat washers (H9)
and 2 x spring washers (H10).
Tighten the bolts with allen key (H12).
Repeat three times for all legs (P10).
Turn the assembled unit over.
(P10)
4 x Felt Feet
(H5)
X4
H5
8 x Flat
Washers (H9)
8 x Spring
Washers (H10)
1 x Allen Key
(H12)
Step 3
You will need
(P2)
H1
H1
H1
H1
Screw 4 x cam bolts (H1)
into bottom panel (P2),
using a phillips head screwdriver.
4 x Cam Bolts
(H1)
Phillips Head
Screwdriver
(P10)
H12
H8
H9
H10
(P2)
(P10)
(P10)
(P10)
(P2)
(P10)

Step 4
Page 6
You will need
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
2 x Slides
(H19)
Mallet
H19
Separate the 2 sets of slide runners (H19-2) and
slide tracks (H19-1) from slides (H19) by following the steps below:
Extend the slide runner all the way forward.
Press the plastic release lever of the slide down and
pull the slide runner (H19-2) completely out.
H19
Slide runner H19-2 Slide track H19-1
H19-1
H19-1
Note the position
of the rubber stopper
Attach 2 x separated slide tracks (H19-1) onto side panels (P3) with 6 x screws (H18),
using a phillips head screwdriver as shown.
Pay attention to ensure the slides are in correct direction as shown.
Insert 4 x dowels (H3) into each panel (P3) as shown.
Use a mallet to gently tap the dowels into place if needed.
Adjust runner to access the screw holes.
H19-1
8 x Dowels
ø8mm (H3)
H18
(P3)
H3
H3
H3
H3
X2
H18
H18 H19-1

Step 5
Page 7
You will need
Position side panel (P3) onto bottom panel (P2), making sure the grooves on side panels
and bottom panel are on the same side.
Insert 4 x big cam nuts (H2) into side panels (P3), using a flat head screwdriver
turn clockwise to lock.
Flat Head
Screwdriver
4 x Big Cam
Nuts (H2)
(P2)
(P3)
H2
H2
H2
H2
(P2)
(P3)
(P3)
This is how a cam nut works........
The head of the cam
bolt goes into the open
mouth of the cam nut.
You then turn the cam
nut so it tightens over
the bolt.
Step 6
Slide back panel (P4) into
the grooves of panel of
assembled unit as shown.
(P4)
(P3)
(P2)
(P3)

Step 7
Page 8
You will need
Flat Head
Screwdriver
4 x Big Cam
Nuts (H2)
(P1)
Phillips Head
Screwdriver
4 x Cam Bolts
(H1)
Step 8
You will need
Screw 4 x cam bolts (H1) into top panel (P1), using a phillips head screwdriver.
Position top panel (P1) to assembled unit as shown.
Insert 4 x cam nuts (H2) into panels (P3), turn clockwise to lock using a flat head screwdriver.
H1
H2
H1
H1
H1
(P1)
(P3)
(P3)
H2
H2
H2

Step 9
Page 9
You will need
Step 10
You will need
H1 (P5)
H1
H1
H1
Screw 4 x cam bolts (H1) into drawer front (P5), using a phillips head screwdriver as shown.
Phillips Head
Screwdriver
4 x Cam Bolts
(H1)
If necessary, gently adjust the top panel (P1) sideways
in either direction until XX and YY are equal.
Holding it in place, fix 4 x back panel connectors (H7)
to assembled unit with 4 x screws (H6) as shown, using a phillips head screwdriver.
Phillips Head
Screwdriver
(P4)
4 x Screws
16mm (H6)
4 x Back Panel
Connectors (H7)
H7
H7
H7
H7 H7
H6 (P4)
H7
XX
YY
XX=YY
XX
YY
(P1)
(P1)
(P4)
(P1)
(P1)

Page 10
Step 11
You will need
Insert 2 x dowels (H16) into drawer side panels (P6) & (P7) as shown.
Use a mallet to gently tap the dowels into place if needed.
Step 12
You will need
Mallet
2 x Dowels
ø6mm (H16)
(P6) (P7)
H16 H16
Position drawer sides (P6) & (P7)
onto drawer front (P5).
Insert 4 x small cam nuts (H15)
into drawer sides (P6) & (P7).
Turn small cam nuts (H15) clockwise to lock
using a flat head screwdriver.
(P5)
(P7)
(P6)
H15
H15
Flat Head
Screwdriver
4 x Small Cam
Nuts (H15)
Step 13
(P7)
(P6)
(P9)
Slide drawer base (P9) into
the grooves of panels (P5), (P6) & (P7).
(P5)

Step 14
Page 11
You will need
Step 16
You will need
Attach 1 x slide runner (H19-2)
to each drawer side (P6) and (P7)
with 3 x screws (H18), using a phillips head screwdriver as shown.
2 x Screws
28mm (H11)
Phillips Head
Screwdriver
1 x Handle
(H4)
Attach 1 x handle (H4) onto drawer front (P5) with 2 x screws (H11),
using a phillips head screwdriver as shown.
2 x Slide
Runners (H19-2)
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
H11
(P5) H4
H19-2
H19-2
H19-2
H18
H18
H18
H18
H18
H18
(P6)
(P7)
H19-2
H19-2
Step 15
You will need
4 x Screws
38mm (H17)
Phillips Head
Screwdriver
Attach drawer back (P8) to drawer assembly
with 4 x screws (H17),
using a phillips head screwdriver as shown.
(P6)
(P7)
(P8)
H17
H17
Ensure screw holes
in (P6) & (P7) align with
pilot holes in (P8).

Step 17
Page 12
Move inner ball bearing track
to front of slide track (H19-1).
H19-2
H19-1
Gently insert drawer slide runner
into ball bearing Track.
Position drawer so that slide runners (H19-2) align with slide tracks (H19-1) as shown.
Gently push drawer into the closed position.

Step 18
Page 13
You will need
Step 19
You will need
Fix 1 x wall strap (H13) to top panel (P1) with 1 x screw (H14) and 1 x flat washer (H9) as shown,
using a phillips head screwdriver.
1 x Flat
Washer (H9)
1 x Screw
25mm (H14)
1 x Wall Strap
(H13)
Phillips Head
Screwdriver
(P1)
H13
H9
H14
1 x Flat
Washer (H9)
Phillips Head
Screwdriver
Seek advice from a qualified
trades person on how to
attach this wall strap to
your specific wall.
Screw and wall plug are not included.
Please use appropriate fixtures for your wall.
Move the lamp table to the final position.
Attach the wall strap to the wall.
Make sure they are firmly attached and fit snugly .
H9
Wall
Screw

Step 20
Page 14
Job complete!
In the interest of our environment please dispose
of all packaging thoughtfully.
