BoLiving Java 519788 User manual

2020-07-03Rev 1 -
Java Coffee Table
519788

! Read instructions carefully. Check no parts are missing.
! Assemble the furniture on a soft level surface to avoid damaging the furniture or your floor.
! Carefully identify each component, especially those that are similar.
! The most common mistake is getting things back to front.
! Separate and identify each component from the hardware pack and rest each one in it's
proper location before fastening.
! We recommend furniture be assembled near where they will be placed, to avoid moving the
product unnecessarily once assembled.
! If there is a need to move the furniture, please remove all loose items and have extra hands
to help lift the furniture to the desired location. Dragging the furniture will damage both the
furniture and the floor.
! Regularly check and re-tighten (if necessary) all bolts on furniture that you have assembled
yourself.
WARNING
Keep these instructions for future reference
ALLOW 60 MIN
Page 2
Unit 1, Ubique Business Park, March Way, Battlefield, Shrewsbury, SY1 3JE
2 Persons Required
Tools Required
DO NOT USE ON PRODUCT
Rattan
Rattan is a natural material that will expand and contract with changes in the surrounding humidity
and temperature. Each rattan piece in the furniture may also respond to these changes to a different
degree. Once humidity and temperature return to normal, each rattan piece would also return to its
original shape. This is a natural phenomenon and not a defect.

Parts list
1 x Top Panel (P1)
1x Bottom Panel (P2)
2 x Side Panels (P3)
1 x Right Side Panel (P4)
1 x Back Frame (P5)
1 x Drawer Front (P6)
1 x Drawer Left Side (P7)
Page 3
Top Panel (P1)
Bottom Panel (P2)
Side Panel
(P3)
(P3)
Right Side
Panel (P4)
Back Frame
(P5)
Drawer Front
(P6)
Drawer Back
(P9)
Drawer Base
(P10)
Drawer Left
Side (P7)
Drawer Right
Side (P8)
Drawer Support
(P11)
Leg (P12)
Leg (P12)
Big Middle
Leg (P13)
Small Middle
Leg (P14)
1 x Drawer Right Side (P8)
1 x Drawer Back (P9)
1 x Drawer Base (P10)
1 x Drawer Support (P11)
4 x Legs (P12)
1 x Large Middle Leg (P13)
1 x Small Middle Leg (P14)

Page 4
Hardware pack
23 x Cam Bolts
(H1)
17 x Large Cam
Nuts (H2)
22 x Dowels ø8mm
(H3)
1 x Handle
(H4)
8 x Flat Washers
(H7)
8 x Spring
Washers (H8)
2 x Screws 28mm
(H9)
1 x Allen Key
(H10)
4 x Felt Feet
(H5)
8 x Bolts
(H6)
6 x Small Cam
Nuts (H11)
2 x Dowels ø6mm
(H12)
9 x Screws 38mm
(H13)
2 x Slides
(H15)
12 x Screws 12mm
(H14)
1 x Adjustable
Foot (H16)

Step 1
Page 5
You will need
Attach 1 x felt foot (H5) onto each leg (P12) as shown.
Step 2
You will need
8 x Bolts
(H6)
Attach each leg (P12) onto bottom panel (P2), using 2 x bolts (H6), 2 x spring washers (H8)
and 2 x flat washers (H7). Tighten the bolts with allen key (H10).
Screw 3 x cam bolts (H1) into bottom panel (P2), using a phillips head screwdriver.
4 x Felt Feet
(H5)
X4
H5
8 x Flat
Washers (H7)
8 x Spring
Washers (H8)
1 x Allen Key
(H10)
(P12)
H10
H6
H8
H7
(P2)
(P12)
(P2)
(P12)
(P12)
(P12)
(P12)
3 x Cam Bolts
(H1)
Phillips Head
Screwdriver
H1
H1
H1

Step 3
Page 6
You will need
Screw 1 x adjustable foot (H16) into the large middle leg (P13).
Insert 2 x dowels (H3) into middle legs (P13, P14).
Use a mallet to gently tap the dowels into place if needed.
Attach small middle leg (P14) to large middle leg (P13)
with 1 x screw (H13), using a phillips head screwdriver.
1 x Screw
38mm (H13)
Phillips Head
Screwdriver
H3
Mallet
2 x Dowels
Ø8mm (H3)
H3
H16
H13
(P13)
(P13)
(P14) (P14)
1 x Adjustable
Foot (H16)
Flat Head
Screwdriver
3 x Large Cam
Nuts (H2)
Step 4
You will need
Attach middle legs (P13, P14) to bottom panel (P2).
Insert 3 x large cam nuts (H2) into middle legs (P13, P14).
Rotate the cam nuts so the arrows point towards the incoming cam bolts
and turn clockwise to lock with a flat head screwdriver.
With assistance, turn the assembled unit over.
(P2)
H2 H2
H2
(P13)
(P14)

Step 5
Page 7
You will need
Screw 5 x cam bolts (H1)
into bottom panel (P2),
using a phillips head screwdriver.
5 x Cam Bolts
(H1)
Phillips Head
Screwdriver
H1
Step 6
You will need
Step 7
You will need
Insert 8 x dowels (H3) into
back frame (P5) as shown.
Insert 4 x dowels (H3)
into right side panel (P4) as shown.
Use a mallet to gently tap the dowels into place if needed.
(P2)
H1
H1
H1
H1
7 x Cam Bolts
(H1)
Phillips Head
Screwdriver
Screw 7 x cam bolts (H1) into top panel (P1),
using a phillips head screwdriver.
(P1)
H1
H1
H1
H1
H1
H1
H1
(P5)
(P4)
12 x Dowels
Ø8mm (H3) Mallet
H3
H3
H3
H3
H3
H3
H3
H3
H3
H3
H3

Step 8
Page 8
You will need
Phillips Head
Screwdriver
6 x Screws
12mm (H14)
2 x Slides
(H15)
Mallet
H15
Separate the slide runners (H15-2) and slide tracks (H15-1)
from the 2 x slides (H15) by following the steps below:
Extend the slide runner all the way out.
Press down the plastic release lever on the slide and pull out
the slide runner (H15-2) completely.
H15
Slide runner H15-2 Slide track H15-1
H15-1
H15-1
Note the position
of the rubber stopper
Attach 2 x separated slide tracks (H15-1) onto 2 x side panels (P3) with 6 x screws (H14),
using a phillips head screwdriver as shown.
Ensure the slide tracks (H15-1) are attached so the rubber stopper is positioned as shown.
Screw 1 x cam bolt (H1) into each side panel (P3), using a phillips head screwdriver as shown.
Insert 4 x dowels (H3) into 2 x side panels (P3) as shown.
Use a mallet to gently tap the dowels into place if needed.
Adjust runner to access the screw holes.
H15-1
8 x Dowels
Φ8mm (H3)
2 x Cam Bolts
(H1)
X2
H1
H3
H3
H3
H3
H15-1
H14
H14
H14
(P3)

Step 9
Page 9
You will need
Attach side panel (P3) to back frame (P5) as shown.
Insert 1 x Large cam nut (H2) into back frame (P5).
Rotate the cam nut so the arrow points towards the incoming cam bolt .
Using a flat head screwdriver, turn clockwise to lock.
H2
Flat Head
Screwdriver
1 x Large Cam
Nut (H2)
Step 10
You will need
Attach side panel (P3) to back frame (P5) as shown.
Insert 1 x large cam nut (H2) into back frame (P5).
Rotate the cam nut so the arrow points towards the incoming cam bolt . Using
a flat head screwdriver, turn clockwise to lock.
Flat Head
Screwdriver
1 x Large Cam
Nut (H2)
(P3) (P5)
(P3)
(P3)
H2
(P5)

Step 11
Page 10
You will need
Attach side panels (P3) and back frame (P5) to bottom panel (P2) as shown.
Insert 5 x large cam nuts (H2) into side panels (P3) and back frame (P5),
Rotate the cam nuts so the arrows point towards the incoming cam bolts .
Using a flat head screwdriver, turn clockwise to lock.
Step 12
You will need
Attach right side panel (P4) to bottom panel (P2) as shown.
Screw 2 x screws (H13) into right side panel (P4), tighten with a phillips head screwdriver.
Flat Head
Screwdriver
5 x Large Cam
Nuts (H2)
(P3)
(P3)
(P2)
(P5)
(P2)
(P4)
H2
H2
H2
H2
H13
Phillips Head
Screwdriver
2 x Screws
38mm (H13)
H13

Step 13
Page 11
You will need
With assistance, position top panel (P1) to assembled unit as shown.
Insert 7 x cam nuts (H2) into panels (P3, P4) and back frame (P5).
Rotate the cam nuts so the arrows point towards the incoming cam bolts .
Using a flat head screwdriver, turn clockwise to lock.
Step 14
You will need
Flat Head
Screwdriver
7 x Large Cam
Nuts (H2)
Phillips Head
Screwdriver
6 x Cam Bolts
(H1)
Step 15
You will need
H12
Mallet
2 x Dowels
Ø6mm (H12)
Insert 2 x dowels (H12)
into drawer side panels (P8, P7) as shown.
Use a mallet to gently tap the dowels into place if needed.
(P7)
(P8)
H12
Screw 6 x cam bolts (H1)
into drawer front (P6) as shown,
using a phillips head screwdriver.
(P6)
H1
H1
H1
H1 H1
(P1)
(P3)
(P4)
(P3)
H2
H2
H2
H2
H2
H2 H2

Step 16
Page 12
You will need
Position drawer sides (P7, P8)
and drawer support (P11) onto drawer front (P6).
Insert 6 x small cam nuts (H11)
into drawer sides (P7, P8) and drawer support (P11).
Rotate the cam nuts so the arrows point towards
the incoming cam bolts.
Using a flat head screwdriver, turn clockwise to lock..
Step 17
Flat Head
Screwdriver
6 x Small Cam
Nuts (H11)
(P10)
Slide drawer base (P10)
into the grooves on panels of (P6, P7, P8).
Step 18
You will need
Attach drawer back (P9) to assembled drawer
with 6 x screws (H13),
using a phillips head screwdriver as shown.
Phillips Head
Screwdriver
6 x Screws
38mm (H13)
Ensure the pre-drilled holes
on drawer side panels (P7, P8)
align with holes on back panel (P9),
and the holes on back panel (P9)
align with the holes on
drawer support (P11).
(P8)
(P7)
(P9)
(P11)
H13
H13
H13
(P8)
(P7)
(P11)
(P6)
H11
H11
H11
H11
(P6)
(P7)
(P8)

Step 19
Page 13
You will need
Step 20
You will need
Attach 1 x slide runner (H15-2) to each drawer side (P7, P8) with 3 x screws (H14),
using a phillips head screwdriver as shown.
2 x Screws
28mm (H9)
Phillips Head
Screwdriver
1 x Handle
(H4)
Attach 1 x handle (H4) onto drawer front (P6) with 2 x screws (H9),
using a phillips head screwdriver as shown.
2 x Slide
Runners (H15-2)
Phillips Head
Screwdriver
6 x Screws
12mm (H14)
H15-2
(P7)
H15-2
H15-2
(P8)
H4
H15-2
H15-2
H14
H14
H14
H14
H14
H14
H9 (P6)

Step 21
Page 14
Move inner ball bearing track
to front of slide track (H15-1).
H15-2
H15-1
Gently insert drawer slide runner (H15-2)
between the ball bearing track.
Position drawer so that slide runners (H15-2) align with slide tracks (H15-1) as shown.
Gently push drawer into the closed position.

Step 22
Page 15
Job complete!
In the interest of our environment please dispose
of all packaging thoughtfully.
