Bonart ART Marquee ART-M3II User manual

ART Marquee
ART-M3II Magnetostrictive Ultrasonic Scaler
Instruction Manual
Bonart Co., Ltd.
Jorgen Kruuse A/S
4F-11, No.3 Wuquan 1st Rd., Xinzhuang
Dist., New Taipei 24892, Taiwan, R.O.C.
Tel: [phone]
Fax:[phone]
Email: [email protected]
Havretoften 4, DK-5550 Langeskov,
Denmark
0434
COPYRIGHT© 2014 BONART CO., LTD.

- 1 -
BONART Co., Ltd. owns all rights to this publication. This publication shall be used solely as a
reference for operation, maintenance, and repair on BONART equipment. No part of this document
may be reproduced or distributed in any form for any other purpose.
In the event of inadvertent or deliberate publication, BONART intends to enforce its rights to this
manual under the copyright law. Reproduction of the materials presented in this manual without the
express written permission of BONART Co., Ltd. is prohibited.
The contents of this manual are subject to change without prior notice.
PROPERTY OF BONART CO., LTD.
ALL RIGHTS RESERVED
ART is a registered trademark of BONART Co., Ltd. & its affiliates.
Document No. RD-02-04-02 Rev.1.1 (10/14)
Printed in Taiwan, R.O.C.

- 2 -
Operator Safety
Please read this manual before operating unit.
The ART Marquee (ART-M3II) magnetostrictive ultrasonic scaler should be operated, maintained
and repaired by qualified and properly trained personnel.
NOTE, CAUTION, AND WARNING STATEMENTS
NOTE：Provides tips and advice
CAUTION：Provides correct operating or maintenance procedures
WARNING：Alerts users of danger that may cause severe injury when proper procedures
are not followed
SYMBOLS
Compliance with MDD 93/42/EEC
BF equipment
Grounding terminal
Attention! Please read instructions

- 3 -
Warnings
Important!
Only trained and qualified doctors, dentist, and hygienists should operate the ART
Marquee.
Patients with pacemakers cannot be treated with the ART Marquee
Do not immerse the ART Marquee in water!
If patient or operator is pregnant, consult a physician prior to performing dental
scaling for safety purposes.
The ART Marquee requires a shielded AC power cord.
Plug the power cord into a well-grounded outlet.
Attention to users with cardiac pacemakers!
Patients with pacemakers should avoid treatment with the ART Marquee. Electronic
appliances including razors, hair dryers, microwave ovens, TV receptors, and other medical
equipment, such as the ART Marquee, may interfere with the performance of pacemakers.
For more information on this subject, please refer to the following articles:
"Advances in Cardiac Pacemaker", The New York Academy of Sciences, Vol. 167,
Article 2, pp. 515-1075
"Electromagnetic Radiation Interference with Cardiac Pacemaker", U. S. Department of
Health, Education and Welfare
"The Individual with a Pacemaker in the Dental Environment", Journal of the American
Dental Association, Vol. 91, No. 6, pp. 1224-1229

- 4 -
Please Read Before Operating:
Make sure the device is connected to a grounded outlet.
Failure to meet this requirement may severely damage the
user and equipment.
Place the device on a flat and stable surface. Placing the
device on a tilted or unstable surface may degrade
performance and also cause damage to the device.
Do not modify this device. Modifications to the device will
invalidate the safety codes and warranty while endangering
the patient and operator.
Do not place heavy objects on top of the power cord and keep
the power cord away from intense heat.
Unplug the device and call Bonart for service and instructions
if you observe any abnormalities while operating the device.

- 5 -
Preface
About the ART Marquee Magnetostrictive Ultrasonic Scaler
The ART Marquee Magnetic Ultrasonic Scaler is manufactured by Bonart Co., Ltd., an ISO
13485:2003 company. The ART Marquee is also CE 0434 certified in compliance with the
applicable requirements of the Council Directive 93/42/EEC. The reviewing council also
classifies the ART Marquee in accordance with EN60601-1 and EN60601-1-2 safety
requirements.
How it works
The ART Marquee consists of two parts: The main electronic system and the scaling hand piece.
The main electronic system utilizes two closed loops. One loop provides automatic tuning to
match the resonance of the insert. The other loop will control the tip stroke based on various
working conditions.
The scaling hand piece utilizes a pulsing magnetic field. This magnetic field is applied to a metal
“stack” which flexes and moves an installed scaling tip (insert) approximately 25,000-30,000+
cycles per second in an elliptical pattern based on the amount of power used. Thus, more power
results in greater tip displacement, which allows for more robust scaling. However, the
vibrating metal stack generates heat and requires adequate amounts of fluid to cool the hand
piece and tissues during treatment.
When the two parts of the ART Marquee are placed together, the properties of the main unit and
scaling hand piece enable the ART Marquee to “power away” the heaviest calculus deposits. In
addition, tips may be rotated 360 degrees within the hand piece to relieve cord tension and
alignment. As a result, the ART Marquee provides maximum comfort to the patient and ease of
use to the operator.

- 6 -
Technical Support
For technical support and repairs in the U.S., call 1-888-526-6278 or 626-600-5330, Monday
through Friday, 9:00 AM to 5:00 PM (Pacific Time). For other areas, contact your local Bonart
representative.
Supplies & Replacement Parts
To order supplies or replacement parts in the U.S., contact your Bonart Distributor or Dealer. A
list of Bonart dealers can be found on our website at www.bonartmed.com.
CAUTION：Since the scaling tip (insert) is made of stainless steel, avoid direct contact with
teeth. Direct contact will cause damage to teeth enamel. For optimum performance, we suggest
practicing on a model or aluminum plates to become more familiar with the scaling tips before
performing on patients.

- 7 -
Table of Contents
Copyrights ……………………………...
1
Operator Safety ..........……………………….
2
Warnings ......………………………….
3
Preface ……..……………………….
5
Contents ..…………………………….
7
Section I. Indications for Use ..…………………………….
8
Section II. Contraindications and Warnings ……………………..
8
Section III. Precautions .……………………………..
8
Section IV. Infection Control ……………………………...
9
Section V. Installation …..………………………………………….
11
Section VI. General Description and Information of Parts…………….
14
Section VII. Techniques ……………………………….
17
Section VIII. System Maintenance …………………………..…
19
Section IX. Troubleshooting ……………………………….
20
Section X. Specifications ……………………………….
21
Section XI. Disposal ..……………………………..
21

- 8 -
Section I: Indications for Use
Ultrasonic procedures:
Removal of calculus and plaque during dental prophylaxis.
General supra and sub-gingival scaling applications.
Periodontal debridement for all types of periodontal diseases.
Endodontic procedures.
Section II: Contraindications and Warnings
Do not use the ART Marquee for amalgam restorative dental procedures.
Do not use the ART Marquee if the patient or operator is wearing a pacemaker.
Do not immerse the ART Marquee in water or liquid. If the ART Marquee has water damage,
return the machine to Bonart for servicing.
Do not modify the ART Marquee. Modifications will invalidate the warranty on the machine
as well as invalidate safety codes and endanger the patient and operator.
Section III: Precautions
3-A: Precautions for all Ultrasonic Scaler Units and Systems
Ensure sufficient water flow to the scaler tip during use to cool the hand piece and insert.
Take precaution as all ultrasonic scalers produce aerosols that may transmit contagious
diseases.
Use inserts manufactured by Bonart for optimal performance and results.
Keep the unit away from intense heat. Excessive heat may damage the electronic
components.
Switch the water valve off when the ART Marquee is not in use.
Avoid treating patients with pacemakers due to the magnetic field produced by the ART
Marquee. The magnetic field may cause monitoring devices to malfunction and provide
inaccurate readings.

- 9 -
3-B: Precautions for Ultrasonic Prophylaxis Procedures
Scaling tips (inserts) will wear with use. Inserts with 2mm of wear will lose approximately
50% of their scaling efficiency. In general, it is recommended that inserts be discarded and
replaced after 2mm of wear to maintain optimal efficiency and avoid breakage.
Avoid direct contact of inserts with the patient’s lips, cheeks and tongue.
Do not reuse scaling tips (inserts) that are damaged, bent, or reshaped. Discard immediately.
Use the long axis of the scaling tip (insert) to wipe accretions from the tooth. Do not gouge
the tooth with the tip.
3-C: Precautions for the hand-piece
In order for the system’s hand-piece to function consistently and effectively, accumulated
air pressure from the handle (or hand-piece) must be released every 10 to 15 minutes on
every procedure by doing the following steps:
1. Push the insert into the hand-piece and ensure that is securely seated. Make sure to use
inserts that designed for the working frequency of the Marquee unit. If you have a 30kHz
Marquee unit, use only 30kHz inserts. If you have a 25kHz Marquee unit, use only 25kHz
inserts.
2. Hold the hand-piece vertically with the insert tip on top; press the foot switch (control).
3. Let the water spray for about 1 minute. Then start the scaling procedure.
Section IV: Infection Control
4-A: General Infection Control Recommendations:
As with all dental procedures, use standard protective equipment such as face masks, eyewear, face
shields, gloves and protective gowns.
To ensure safety to the operator and patient, carefully follow the Infection Control Procedures
detailed in Section XII.
4-B: Water Supply Recommendations
All dental water supply systems should conform to applicable Centers for Disease Control and
Prevention (CDC) and the American Dental Association (ADA) standards. These standards should
apply to flushing, chemical flushing and general infection control procedures.

- 10 -
4-C: Cleaning and Sterilization:
Hand piece
To clean the hand piece:
1. Remove the insert from the hand piece.
2. Drain any water left in the hand piece to clear accumulated debris and residue.
3. Clean the surface of the hand piece with antiseptic soap or solution. Rinse thoroughly
with water.
4. Wipe or spray the hand piece with a chemical disinfectant. Try to use a disinfectant that
has a 1:6 dilute solution (ie Sporicidin Disinfectant) to avoid damaging the materials of the
hand piece.
5. Repeat steps 1 through 4 after each use.
6. Scrub the hand piece and cable at the end of the day with antiseptic soap and rinse
thoroughly with water.
After disinfecting the hand piece, a sterile insert may be re-inserted into the hand piece in
preparation for the next patient.
NOTE：Cleaning the hand piece after every patient is strongly advised.
WARNING：Do not dip the hand piece and extension cable directly into the sterilized
fluid. Doing so will cause the ART Marquee to malfunction.
WARNING：Do not leave the disinfectant on the surface of the hand piece and extension
cable any longer than instructed by the manufacturer of the disinfectant.
Insert
Saliva, blood, and other debris will leave a residue on the insert after each use. Therefore, it is
necessary to clean inserts after each use.
To clean the insert:
1. Remove the insert from the hand piece
2. Scrub the insert with a brush, water, and detergent. Rinse thoroughly with water after
scrubbing.
3. Let the insert dry.
4. Put the insert in a sterilization pouch and autoclave at 275ºF (135ºC) for 15 minutes or as
recommended by the manufacturer of your autoclave machine.

- 11 -
NOTE: Bio-indicators or chemical indicators for ensuring the efficiency of the
sterilization cycle are recommended
NOTE：Routine spore testing will determine the sterile conditions of your office.
NOTE：The Sterilization Assurance Level (SAL) of steam autoclave should be 10-6
(According to ISO 13683:Sterilization of health Care products)
WARNING：High room temperature conditions, improper dilutions, or extended
immersion time in chemical sterilizers can result in damage to the plastic
and other materials of the insert/Tips.
CAUTION：The use of a dry heat oven, incompatible chemical vapor type sterilizers or
quaternary ammonium compounds must be avoided as damage can result
to the plastic and elastomeric materials.
Main Unit
To clean the main unit, carefully wipe the surface with alcohol. Dust regularly and try to
keep the main unit away from dust.
Section V: Installation
5-A: General Information
If the installation of your ART Marquee system is performed by unauthorized Bonart dealer or
non-Bonart personnel, check to see that the requirements below are followed.
5-B: Water Line Requirements
Incoming water supply line pressure to the Scaler must be 25 psi (172 kPa minimum) to 60
psi (414Kpa maximum). If your dental water supply line pressure is above 60 psi, install a
water regulator on the water supply line to your ART Marquee unit.
After the above installation requirement is fulfilled, thoroughly flush the water prior to
connecting to the scaler.
Please manually close the valve on the dental water system supply line to shut-off water
when the office is unoccupied.

- 12 -
5-C: Electrical Requirements
Refer to Section X: Specifications
5-D: Unpacking the Unit
Carefully unpack your ART Marquee unit and verify that all components and accessories are
included:
(Figure 1) All components and accessories
Item
Quantity
Item
Quantity
(1) Main Unit
1
(2) Foot Control / Foot Switch
1
(3) AC Power Cord Set.
1
(4) PU Water Tubing
1
(5) User Manual & Literature Packet
1
(6)
ART IF-50 Streamline Universal Plastic Handle Internal Flow Insert.
ART P-10 Straight Angle Universal Metal Handle External Flow Insert.
Optional
Optional
(7) Water Hose/ Quick Disconnect Assembly.
Optional
NOTE：
While unpacking, check your ART Marquee unit for any damages. If any damages are
found, please contact your dealer immediately. Enter the unit serial number on your
warranty card and mail it within 14 days from the date of purchase.
5-E: Power Cord / Power Connection
Always make sure that the power switch is set to the OFF position before performing the
following tasks:
oPlug the detachable AC cord into the back of the unit.
oPlug the 3-prong plug into a grounded outlet.

- 13 -
Safety Instructions
A. Grounding:
Prior to connecting accessories to the unit, check that the main unit is plugged into a
grounded wall outlet.
B. Main voltage range and fuse:
Prior to plugging the AC adapter into the power outlet, check that the voltage is supported.
5-F: Foot Control Cable Assembly Connection
Align the pins of the foot control plug with the receptacle on the back of the device and push in
until the plug is firmly seated.
5-G: Water Supply Line Connection
Push the blue water tube (hose) into the stainless steel receptacle until the hose cannot be pushed
any further. Then tighten the screw.
Connect the quick connect to the water supply line. The ART Marquee should be prepackaged
with a male quick connect. If a female quick connect is necessary, please contact a Bonart
distributor to purchase the part.
Inspect all connections for leaks.
To remove the water line from the ART Marquee scaler, first, turn off the water supply or
disconnect the water supply line. Then loosen the screw on the water tube from the receptacle of the
unit and gently pull the water hose out.
5-H: Hand piece Cable Assembly Connection
The ART Marquee hand piece and cable are one piece. Do not detach the hand piece from the
cable.

- 14 -
5-I: Assembling the Scaler Unit
1.Switch the power of the ART Marquee off. The power indicator should not be lit if the
machine is off.
2.Plug the power cord of the main unit into a grounded AC power outlet.
3.Install an insert by pushing the insert into the hand piece. Make sure that the insert is securely
seated in the hand piece. To remove the insert, pull the insert out.
4.Check the water tube connection to the water supply source and main unit.
Section VI: General Description and Information of Parts
Figure 2. ART Marquee Outlook diagram
1. Main Unit
The main unit generates power and produces a signal that is passed to the hand piece.
The hand piece is then powered up and vibrates the installed insert.

- 15 -
2. Hand piece
The hand piece is a housing for scaling inserts. Inserts are interchangeable and can be
installed by pushing into the hand piece. To remove the insert, pull the insert out. Aside
from Bonart inserts, Dentsply/Cavitron and Hu-Friedy inserts are also compatible with the
ART Marquee.
When the hand piece is activated, the hand piece will begin to heat due to the power
generated by the main unit. To cool the temperature of the hand piece, a stream of water
is released into the hand piece and through the tip. This stream of water is also used to
wash away tooth calculus and tartar.
CAUTION：Make sure that new insert is firmly seated.
CAUTION: Do not press the footswitch when there is no insert installed. Doing so
will cause the hand piece to melt!
NOTE：The ART Marquee is a stand-alone unit and is now only available in 25Khz.
Please do not use 30Khz inserts with the hand piece.
3. Footswitch
The footswitch is designed to allow the operator to use two hands while scaling.
4. LCD Display Screen
The user-friendly built-in LCD display screen allows user to monitor power settings and
operation modes. The figure and scale correspond to the power setting for each operation
mode. Thus, different operation modes will be available based on the power setting.
For example, if you turned the power setting to certain level, and all 3 icons appear on
screen, the user has the option to use any of the 3 modes alternately with the matching
insert. If however only 2 of the 3 icons for a particular mode are showing, the user can
only utilize the shown modes. Similarly, the operation mode indicator is another way of
telling user which appropriate insert should be used.

- 16 -
Figure 2. ART Marquee Front panel
Caution: To prevent any damages, INSERT something should go here operation has to be
chosen according to the operation mode shown on the LCD display panel.
5. Power control
The power control adjusts the power intensity to the desired level based on the cleaning
procedure. When turned clockwise, power output increases. When turned
counter-clockwise, power output decreases.
6. Water-in Connector
The water-in connector is the contact point for the water tube and the main water supply
line. Use either a male or female quick connect to connect the water tube to the water
supply. The ART Marquee comes with a male quick connect attached to the water tube.
7. AC Line Socket Seat
The AC line socket seat is the connection point between the power cord and the main unit.
8. Main power switch (ON/OFF)
The main power switch turns the ART Marquee unit on and off. When the power is
switched on, the LED power indicator on the main unit should be lit. When the power is
switched off, the LED power indicator should be unlit.
Make sure the footswitch is in the OFF position before turning
on the ART Marquee.

- 17 -
9. Water control
The water control knob adjusts the amount of water flowing through the hand piece. To
increase the water flow, turn the knob counter-clockwise. To decrease the water flow, turn
the knob clockwise. Keep in the mind that the water level should be adjusted not only for
cleaning tartar but also for cooling the hand piece during use. Increasing the water level
will cool the hand piece faster.
WARNING：Do not turn the water knob counter-clockwise more than three full turns.
Doing so will damage the internal water line needle.
WARNING：If needed, gently adjust the water control knob to prevent any serious
damages to the water valve.
When used for the first time, turn the knob clockwise to allow water to
flow through. The knob is set to the off position when assembled by
the manufacturer.
Section VII: Techniques
7-A: Performing Ultrasonic Scaling Procedures
1. Use purified or distilled water to prevent infection when patients experience tissue
laceration during treatment
2. Keep the power cord tidy to avoid tripping and other accidents.
3. Position the footswitch in an easily accessible spot for the user. Keep the footswitch cord
tidy to avoid tripping and other accidents.
4. Hold the empty hand piece in an up right position when testing to see if the scaler is
working properly. Tap the footswitch until water appears. Do not repeatedly tap or hold
the footswitch down. The empty hand piece will melt!
5. Lubricate the rubber O-ring on the insert with water before placing it into the hand piece.
Install the insert by gently pushing the insert into the hand piece. Do not force the
insert in!
6. Hold the hand piece over a sink or drain with an insert installed. Verify that the water is
reaching the tip.

- 18 -
7. Check your Bonart scaling inserts for wear and replace as needed.
8. Use the foot switch to control the water flow to the hand piece. Hold the foot switch down
to allow water to flow through. Release the foot switch to shut-off the water flow.
9. Adjust the water flow using the water control knob to the desired level of water flow and
hand piece temperature. Increase the water flow by turning the water control knob
counter-clockwise. Decrease the water flow by turning the water control knob clockwise.
NOTE：Increased water flow results in a cooler hand piece temperature and vice versa.
CAUTION：During operation, a continuous flow of water is required to keep the hand
piece cool.
7-B: Patient Comfort Considerations
1. Position the patient comfortably on the patient chair. Adjust the chair angle and position to
access the patient's oral cavity with ease and comfort.
2. Put the saliva ejector into the patient's mouth to remove excess saliva and debris.
3. Rotate the patient's head gently so that the oral cavity can be easily accessed without causing
discomfort to the patient (see figure below).
4. During treatment, try to keep the angle between the surface of the tooth and scaling insert at 15
degrees. If the patient experiences any discomfort during treatment, follow the suggestions
below:
Increase the hand piece movement speed on the surface when treating sensitive areas.
Treat less sensitive area first, and then return to sensitive areas.
If the problem persists, reduce the power output intensity of the hand piece.

- 19 -
Section VIII: System Maintenance
Daily start-up
1.Open the water supply shut-off valve.
2.Turn the ART Marquee on using the main power switch. Verify that the LED power indicator
(LED) is lit.
3.Set the power control knob to full power.
4.Turn the water control knob to the maximum setting.
5.Hold the empty hand piece upright over a sink or drain.
6.Press the footswitch and flush the water line for at least 2 minutes.
7.Place a Bonart scaling insert (or a compatible insert) into the hand piece and adjust the water
level as desired.
NOTE：If no water is detected, check the water supply
NOTE：If the power LED is not lit, contact a local authorized agent.
Preparations for treating each patient
1. Remove, clean, and sterilize all used ultrasonic inserts.
2. Make sure the scaling insert/tip has been sterilized before treating the next patient.
3. Clean and disinfect the surface of the power cord, hand piece, and cable assembly.
Daily shutdown
1. Use the power switch to turn the ART Marquee off.
2. Close the water supply shut-off valve.
Daily Maintenance
The suggestions below will help maximize the lifespan of the scaler.
A. The ART Marquee should be used in a well-ventilated room
B. Handle the ART Marquee with care when moving it.
C. Before leaving the operation room, make sure that the ART Marquee is turned off and the water
faucet is tightly closed.
D. If you find that the power output to the hand piece is insufficient, the insert is probably worn
out. Inserts should typically be replaced after six months or when worn out.
E. If service is needed, please contact a local authorized agent for technical support.
