BonSayOn W301 User manual

BonSayOn
BonSayOn
Product Manual
Bluetooth Goggle
W301
BonSayOn

Introduction
Completely different from the conventional
microphone which picks up sound or voice through
air, BonSayOn utilizes a newly developed nasal
bone conduction microphone by picking up the
sound through bone or solid material, instead of
air.
The speaker’s voice, which is received through
vibrations of the nasal bone, is clear. Reducing the
background noise , especially for the wind sound, is
the most outstanding feature for our product. The
clear conversation through the BonSayOn never
fails in any noisy environment. Please enjoy
BonSayOn; satisfied communication in style.
BonSayOn
BonSayOn 1
Nasal bone conduction microphone
ButtonIndicator
Earphone jack
Charge jack
Battery

BonSayOn
BonSayOn
2
Specification
Microphone Type NeoV Nasal bone conduction
microphone Version 3.0
Bluetooth Version Bluetooth V2.1,Class 2
Bluetooth Profile HSP / HFP / A2DP / AVRCP
Operating Distance 10 meters (open space)
Charge Time About 4 hours
Music Play Time About 10 hours
Talk Time About 12 hours
Standby Time About 200 hours
Size 208mmX88mmX80mm
Weight 170g
Operation Condition -30℃~50℃，humidity 0~90%
Battery Li-polymer Battery
(350mA/3.7V)
Standard Accessories
Hard case
Replacement orange lens
Cleaning cloth
USB cable
3.5mm standard earphone set
Inside the helmet earphone set
Product Manual

BonSayOn 3
Instruction of Button Operation
Pairing
Press button until the blue and red LED
flashes quickly to turn BonSayOn into pairing
mode.
Search for BonSayOn device using your
phone/music device. For more information on
how to search for Bluetooth device, please
refer to the user guide that accompanies your
phone/music device.
Select BonSayOn W301 from the list of
discovered devices from your phone/music
device. Follow the onscreen prompts to
confirm the selection.
When prompted, enter the passkey “0000”(four
zeros). When pairing is successful, the blue
LED flashes slowly.
Do not need to pair again for a paired device,
just turn it on.(Blue LED flashes slowly)
Dual Pairing
BonSayOn supports dual pairing. It can be
connected with two cell phones at the same
time and answer a call in turn.
( Depends on the cell phone)
Auto-answer
BonSayOn supports auto-answer for incoming
call. The incoming call will be answered
automatically after 2 rings.
Press for 2 seconds to reject incoming call.

Button Function Illustration
Button
Button
Button
BonSayOn
StatusFunctionOperaton
Turn onPress botton for 3 secondsM
Turn on and search device Press for 5 seconds
M botton
Reject a callPress M bottonfor 2 seconds
RedialPress
M botton for 2 seconds
Battery power display Press twice
U botton
Voice dialingPress twiceD botton
Answer/End a callPress onceM botton
Volume increasePress once
U botton
Volume decrease Press once
D botton
Switch a call Press M bottonfor 2 seconds
Volume increasePress once
U botton
Volume decreasePress onceD botton
Last TracePress twice
U botton
Next TracePress twiceD botton
Pause/Resume/Answer a call
Press onceM botton
ON Turn offPress for 5 secondsM botton
OFF
Standby
Talk
Music
Table of Operation Function
BonSayOn
4

Battery Charging Instruction
The warning sound indicates 10% of battery
power remaining.
Battery power level: press button twice. Two
seconds later a beep tone appears : 3 beeps
mean high level, 2 beeps mean medium
level,1 beep means low level (10-15% power
remaining). Don't charge the battery if not
necessary to avoid shortening battery lifetime.
Charge as soon as possible when the warning
sound appears on phone call or while playing
music.
Red LED lights during charging . When charging
is complete, red LED will be turned off.
Battery breakdown or lifetime ends：Red LED
flashes.
BonSayOn
BonSayOn 5
indicator
Earphone jack
Charger jack

Q & A
Q：Why is BonSayOn product unable to link
Bluetooth?
A：First, make sure the Bluetooth existing in the
device (mobile phone or computer) linked to
BonSayOn product, and activate its Bluetooth to
search BonSayOn W301. The search time is not
definite, so please be patient to wait until
BonSayOn product is shown on the screen of the
device. Finally, key in identification code
“0000” to start using BonSayOn product.
Q：Why is the Bluetooth unable to switch on
or disconnect soon after online?
A：It would be power shortage, please charge
immediately so as to maintain battery quality. A
new battery must be charged first until the red
light goes out. If the problem is still unsolved,
please contact with authorized maintenance
service station.
Q：Why is Bluetooth auto-disconnected or
unable to use after linking successfully?
A：Check the Bluetooth“on line list” in the
device (Pleas read your Bluetooth operation
instructions.) linked to BonSayOn product. Delete
most of the names on the online list except
BonSayOn's to avoid linking other products.
BonSayOn
BonSayOn
6

Q：Why cannot BonSayOn goggles connect to
the device with Bluetooth protocols?
A：BonSayOn goggles is equipped with
Bluetooth chip made by the world first brand CSR
company. It can connect to most of the Bluetooth
devices but not all the Bluetooth devices due to
the variety of Bluetooth protocols made by
different companies.
Q：Why cannot play the music again by using
the buttons on BonSayOn after picking up a
call or pause the music playing?
A：The cell phone manufacturers usually
implement somewhat different button operation
software, resulting in partial operation
malfunction. Please touch the play button on
your cell phone to continue playing the music on
BonSayOn.
BonSayOn
BonSayOn 7
REMOTE CONTROL
Model No: BonSayOn W301
FCC ID：X5HW301
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmul interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Made in Taiwan
FCC ID: X5HW301
BonSayOn / W301

Caution
1. This product is humidity-proof, but not water-proof
or dust-proof. Do not use it in water or dust
environment to avoid the damage as well as
shortening the lifetime of the product.
2. Temperature range：-30℃~50℃
3. For the sake of product surface and accessories
intact, please avoid rubbing the product with hard
objects.
4. Please only use qualified accessories which have
been authenticated by the NeoVictory Company.
This will ensure smooth and normal operation of
this product.
5. All accessories have been officially certified. In
order to guarantee the product functioning
normally, please do not use the accessories not
officially certified.
6. When using the earphone, your can not access
outside sound very well. Do not use the earphone
where it may endanger your safety.
The transmitter output power is
below the thresholds established
by the FCC that would require a
formal RF exposure evaluation.
BonSayOn
BonSayOn
8

Product Warranty
(Please keep this warranty for free maintenance in one year after purchase.)
Name： Phone：
Product Name： Mobile phone：
Serial Number： Purchase Date：
Address： e-mail： @
Exclusivity:
1.Disassembling, hitting, and soaking in water, or abnormal use.
2.Physical or electronic disturbance, the misuse of power source,
unstable power source, very close to magnetic material or other
artificial factors.
3.The breakage of serial number, date code, product tag, warranty
lost, etc.
4.Irresistible external factors：Earthquake, seaquake, war, etc.
5.Without Company stamp or the incorrect purchase date, warranty
is invalid automatically.
