BonSayOn S302 User manual

BonSayOn
BonSayOn
Product Manual
Bluetooth Sunglasses
S302
BonSayOn

Introduction
Completely different from the conventional
microphone which picks up sound or voice through
air, BonSayOn utilizes a newly developed nasal
bone conduction microphone by picking up the
sound through bone or solid material, instead of
air.
The speaker’s voice, which is received through
vibrations of the nasal bone, is clear. Reducing the
background noise , especially for the wind sound, is
the most outstanding feature for our product. The
clear conversation through the BonSayOn never
fails in any noisy environment. Please enjoy
BonSayOn; satisfied communication in style.
BonSayOn
Adjustable Nose Pad
Button
Indicator(Blue)
/Charge(Red)
Battery
Earphone Jack
/ Charge Jack
BonSayOn 1

Specification
Microphone Type NeoV Nasal bone conduction
microphone Version 3.0
Bluetooth Version Bluetooth V2.1,Class 2
Bluetooth Profile HSP / HFP / A2DP / AVRCP
Operating Distance 10 meters (open space)
Charge Time About 2 hours
Music Play Time About 5 hours
Talk Time About 6 hours
Standby Time About 100 hours
Size 172mmX155mmX45mm
Weight 53g
Operation Condition -30℃~50℃，humidity 0~90%
Battery Li-polymer Battery
(180mA/3.7V)
Standard accessories
Hard case
Replacement yellow lens
Glasses bag
USB cable
2.5mm standard earphone set
Product Manual
Adjust the Nose Pads
For getting good communication
quality, please adjust nose pads
to fit your nasal shape before
using the product.
BonSayOn
BonSayOn
2

BonSayOn
Instruction of Button Operation
Pairing
Press button until the blue and red LED
flashes quickly to turn BonSayOn into pairing
mode.
Search for BonSayOn device using your
phone/music device. For more information on
how to search for Bluetooth device, please
refer to the user guide that accompanies your
phone/music device.
Select BonSayOn S302 from the list of
discovered devices from your phone/music
device. Follow the onscreen prompts to
confirm the selection.
When prompted, enter the passkey “0000”(four
zeros). When pairing is successful, the blue
LED flashes slowly.
Do not need to pair again for a paired device,
just turn it on.(Blue LED flashes slowly)
Dual Pairing
BonSayOn supports dual pairing. It can be
connected with two cell phones at the same
time and answer a call in turn.
( Depends on the cell phone)
Auto-answer
BonSayOn supports auto-answer for incoming
call. The incoming call will be answered
automatically after 2 rings.
Press button for 2 seconds to reject incoming
call.
BonSayOn 3

BonSayOn
Button Function Illustration
StatusFunctionOperaton
Turn onPress for 3 secondsbutton
Turn on and search device Press for 5 seconds
button
Reject a callPress
button for 2 seconds
RedialPress button for 2 seconds
Battery power display Press twice
button forward
Voice dialingPress twicebutton backward
Answer/End a callPress oncebutton
Volume increasePress once
button backward
Volume decrease Press oncebutton forward
Switch a call Press
buttonfor 2 seconds
Volume increasePress once
button backward
Volume decreasePress oncebutton forward
Last TracePress twice
button backward
Next TracePress twice
button forward
Pause/Resume/Answer a call
Press oncebutton
ON Turn offPress for 5 secondsbutton
OFF
Standby
Talk
Music
Table of Operation Function
(Press Forward)
(Press)
(Press Backward)
BonSayOn
4

Indicator
Earphone Jack
/ Charge Jack
Battery
BonSayOn
Battery Charging Instruction
The warning sound indicates 10% of battery
power remaining.
Battery power level: press button forward
twice. Two seconds later a beep tone appears :
3 beeps mean high level, 2 beeps mean medium
level,1 beep means low level ( 10-15% power
remaining). Don't charge the battery if not
necessary to avoid shortening battery lifetime.
Charge as soon as possible when the warning
sound appears on phone call or while playing
music.
Red LED lights during charging . When charging
is complete, red LED will be turned off.
Battery breakdown or lifetime ends：Red LED
flashes.
BonSayOn 5

BonSayOn
6
Q & A
Q：Why is BonSayOn unable to link Bluetooth?
A：First, make sure the Bluetooth existing in the
device (mobile phone or computer) linked to
BonSayOn, and activate its Bluetooth to search
BonSayOn. The search time is not definite, so
please be patient to wait until BonSayOn S302 is
shown on the screen of the device. Finally, key in
identification code “0000” to start using
BonSayOn.
Q：Why is the Bluetooth unable to switch on
or disconnect soon after online?
A：It would be power shortage, please charge
immediately so as to maintain battery quality. A
new battery must be charged first until the red
light goes out. If the problem is still unsolved,
please contact with authorized maintenance
service station.
Q: Why is Bluetooth auto-disconnected or
unable to use after linking successfully?
A: Check the Bluetooth “on line list” in the device
(Pleas read your Bluetooth operation instructions.)
linked to BonSayOn. Delete most of the names on
the online list except BonSayOn to avoid linking
other products.
BonSayOn

BonSayOn 7
BonSayOn
BonSayOn 7
Q: Why cannot BonSayOn connect to the
device with Bluetooth protocols?
A: BonSayOn is equipped with Bluetooth chip
made by the world first brand CSR company. It
can connect to most of the Bluetooth devices but
not all the Bluetooth devices due to the variety of
Bluetooth protocols made by different
companies.
Q: Why cannot play the music again by using
the buttons on BonSayOn after picking up a
call or pause the music playing?
A: The cell phone manufacturers usually
implement somewhat different button operation
software, resulting in partial operation
malfunction. Please touch the play button on
your cell phone to continue playing the music on
BonSayOn.
REMOTE CONTROL
Model No: BonSayOn S302
FCC ID：X5HS302
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmul interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Made in Taiwan
FCC ID: X5HS302
BonSayOn / S302

BonSayOn
Caution
1. This product is humidity-proof, but not water-proof
or dust-proof. Do not use it in water or dust
environment to avoid the damage as well as
shortening the lifetime of the product.
2. Temperature range：-30℃~50℃
3. For the sake of product surface and accessories
intact, please avoid rubbing the product with hard
objects.
4. Please only use qualified accessories which have
been authenticated by the NeoVictory
Company. This will ensure smooth and normal
operation of this product.
5. All accessories have been officially certified. In
order to guarantee the product functioning
normally, please do not use the accessories not
officially certified.
6. When using the earphone, your can not access
outside sound very well. Do not use the
earphone where it may endanger your safety.
The transmitter output power is
below the thresholds established
by the FCC that would require a
formal RF exposure evaluation.
BonSayOn
8

Product Warranty
(Please keep this warranty for free maintenance in one year after purchase.)
Name： Phone：
Product Name： Mobile phone：
Serial Number： Purchase Date：
Address： e-mail： @
Exclusivity:
1.Disassembling, hitting, and soaking in water, or abnormal use.
2.Physical or electronic disturbance, the misuse of power source,
unstable power source, very close to magnetic material or other
artificial factors.
3.The breakage of serial number, date code, product tag, warranty
lost, etc.
4.Irresistible external factors：Earthquake, seaquake, war, etc.
5.Without NeoVictory stamp or the incorrect purchase date, warranty
is invalid automatically.
