Operating and installation instructions PKI3
BORA Pro induction cooktop
1.
2.
2.
1044842 - 32

EN
2
www.bora.com
5.8 Establishing communication and power connection..18
5.8.1 Connecting the control knobs........................................ 18
5.8.2 Establishing contact between the cooktop extractor
and cooktops.................................................................. 19
5.8.3 Connecting the power supply ........................................ 19
5.9 Basic configuration ......................................................20
5.10 Initial operation .............................................................20
5.11 Function test..................................................................20
5.12 Sealing the appliances..................................................20
5.13 Handover to user...........................................................20
6 Functions and operation 21
6.1 Knob operation ..............................................................21
6.1.1 Operating the knob ring ................................................. 21
6.1.2 Operating the touch surface .......................................... 21
6.2 Switching the system on and off .................................21
6.3 Operating the cooktops ................................................ 22
6.3.1 General operating instructions for cooktops ................. 22
6.3.2 Setting cooking zone power levels................................. 22
6.3.3 Cooktop power setting................................................... 22
6.3.4 Pan size recognition ....................................................... 22
6.4 Function menu...............................................................23
6.4.1 Variable heat retention function..................................... 23
6.4.2 Timer function/automatic cut-off .................................. 24
6.4.3 Automatic heat up function............................................ 25
7 Cleaning and maintenance 26
7.1 Cleaning agents .............................................................26
7.1.1 Cleaning products for glass ceramic cooktops.............. 26
7.2 Cleaning the cooktops ..................................................26
7.2.1 Cleaning glass ceramic cooktops .................................. 26
7.3 Looking after your cooktops ........................................ 26
7.4 Cleaning the control knobs ..........................................27
7.4.1 Cleaning the knob ring................................................... 27
7.4.2 Cleaning the touch surface and the knob housing ........ 27
8 Troubleshooting 28
9 Decommissioning, disassembly and
disposal 29
9.1 Decommissioning ..........................................................29
9.2 Disassembly...................................................................29
9.3 Environmentally-friendly disposal ................................29
10 Warranty, technical service, spare
parts, accessories 30
10.1 BORA manufacturer’s warranty....................................30
10.2 Service............................................................................30
10.3 Spare parts .................................................................... 30
10.4 Accessories.................................................................... 30
11 Notes 31
1 General information 3
1.1 Liability............................................................................. 3
1.2 Validity of the operating and installation instructions . 3
1.3 Product conformity ......................................................... 3
1.4 Data protection................................................................ 3
1.5 Presentation of information............................................ 3
2 Safety 4
2.1 Use as intended............................................................... 4
2.2 People with limited abilities ........................................... 4
2.3 General safety instructions ............................................ 4
2.4 Safety instructions for installation................................. 5
2.5 Safety instructions – operation...................................... 6
2.6 Safety instructions – cleaning and maintenance ......... 7
2.7 Safety instructions – repairs, servicing and spare
parts ................................................................................. 8
2.8 Safety instructions – disassembly and disposal .......... 8
3 Technical data 9
3.1 BORA Pro induction cooktop PKI3................................. 9
3.2 BORA Professional 3.0 control knob dimensions......... 9
4 Appliance description 10
4.1 Control knob ..................................................................10
4.2 Cooktop appliance description.....................................10
4.2.1 Display and symbols ...................................................... 10
4.2.2 How induction cooktops work (PKFI3, PKI3, PKIW3)..... 11
4.3 Safety devices................................................................12
4.3.1 Safety shut-down ........................................................... 12
4.3.2 Residual heat indicator................................................... 12
4.3.3 Overheating protection .................................................. 12
4.3.4 Childproofing feature ..................................................... 12
5 Installation 13
5.1 General installation instructions .................................13
5.2 Checking the scope of delivery....................................13
5.3 Tools and aids ................................................................ 13
5.4 Assembly instructions...................................................13
5.4.1 Safety clearances........................................................... 13
5.4.2 Minimum installation dimensions (standard set-up)...... 14
5.4.3 Worktop and kitchen units ............................................. 14
5.5 Cut-out dimensions .......................................................14
5.5.1 Flush installation ............................................................ 15
5.5.2 Surface mounting........................................................... 15
5.6 Installing the control knob in the floor unit front
panel............................................................................... 16
5.6.1 Cooktop bore holes........................................................ 16
5.6.2 Example bore holes........................................................ 16
5.6.3 Fitting the control knob.................................................. 16
5.7 Installing the cooktops ................................................. 17
5.7.1 Installing the cooktop..................................................... 17
5.7.2 Installation rotated by 180°
(alternative installation variation)................................... 18
Table of Contents

EN
3
General information
www.bora.com
1 General information
Data can only be read out manually via your cooktop extractor.
This decision is therefore your responsibility.
These saved data then enable a rapid error search and
troubleshooting in the event of servicing.
1.5 Presentation of information
We use standard formatting, numbering, symbols, safety
instructions, terms and abbreviations so that you can work
quickly and safely when using this manual.
The term “appliance” is used to refer to cooktops, cooktop
extractors or cooktops with integrated cooktop extractor.
Instructions are indicated with an arrow.
XAlways follow all instructions in the prescribed order.
Enumerations are indicated with a bullet point at the start of
the line:
O Enumeration 1
O Enumeration 2
i Information notes point to special features that must be
taken into account.
Safety and warning instructions
The safety and warning instructions in this manual are
emphasised with symbols and signal words.
Safety and warning instructions are structured as follows:
ÿ
WARNING SYMBOL AND SIGNAL WORD!
Type and source of danger
Results of non-compliance
X Measures to minimise risk
Please note:
O warning symbols draw attention to a high risk of injury.
O The signal word indicates the severity of that risk.
Warning
symbol
Signal word Risk
üDanger Indicates an immediate, hazardous
situation which causes death or
serious injury if not respected.
üWarning Indicates a potentially hazardous
situation which can cause death or
serious injury if not respected.
Caution Indicates a potentially hazardous
situation which can cause minor
injury or damage to property if not
respected.
Tab. 1.1 Meaning of the warning symbols and signal words
These instructions contain important information to protect you
from injury and prevent damage to the appliance.
Please read these instructions carefully before installing or using
the appliance for the first time.
Other documents apply alongside these instructions.
Please by all means adhere to all documents that form part of
the scope of delivery.
Assembly, installation and commissioning must always occur
in line with national laws, regulations and standards. The work
must be performed by qualified specialists who are familiar with
and comply with the supplementary regulations of the local
utility companies.
All safety and warning information as well as the handling
instructions in the accompanying documents must be observed.
1.1 Liability
BORA Holding GmbH, BORA Vertriebs GmbH & Co KG, BORA
APAC Pty Ltd and BORA Lüftungstechnik GmbH – hereinafter
referred to as BORA – does not assume any liability for damage
arising from disregard for or non-adherence to the documents
included in the scope of delivery!
Furthermore, BORA shall not be held liable for damage caused
by improper installation or failure to observe the safety and
warning instructions!
1.2 Validity of the operating and
installation instructions
These instructions apply to several appliance versions. It is
therefore possible that some of the features described do not
apply to your appliance. The details of the figures contained
herein may differ from some appliance versions and are to be
understood as schematic diagrams.
1.3 Product conformity
Directives
The appliances meet the following EU/EC directives:
2014/30/EU EMC Directive
2014/35/EU Low Voltage Directive
2009/125/EC Ecodesign Directive
2011/65/EU RoHS Directive
1.4 Data protection
During operation your cooktop extractor saves pseudonymised
data such as menu settings entered by you, operating hours
of the individual technical units and the number of functions
selected. Furthermore, your cooktop extractor documents errors
in combination with the number of operating hours.

EN
4
Safety
www.bora.com
2 Safety
The appliance complies with the stipulated safety
requirements. The user is responsible for the safe
use of the appliance, cleaning and maintenance.
Improper use can lead to personal injury and damage
to property.
2.1 Use as intended
The appliance is solely intended for preparing food in
private households.
This appliance is not intended for:
O
outdoor use
O
heating rooms
O
cooling, ventilating or dehumidifying rooms
O
use in mobile installation sites such as motor
vehicles, ships or aeroplanes
O
use with an external timer or a separate remote
control system (except for emergency shutdown)
O
use at altitudes of over 2,000m (metres above sea
level)
Any other use or any use that goes beyond that which
is described here is classed as unintended.
i BORA does not assume any liability for
damages caused by improper use or incorrect
operation.
All misuse is prohibited!
2.2 People with limited abilities
Children
The appliance can be used by children aged 8 and
over if they are supervised or have been instructed
how to use the appliance safely and understand
the resultant risks. Children must not play with the
appliance.
X Use the childproofing feature in order to prevent
children from switching on the appliance or
changing the settings when they are unattended.
X Supervise children in the vicinity of the appliance.
X Do not store any items that could be of interest to
children in storage spaces above or behind the
appliance.Otherwise, they will be tempted to
climb onto the appliance.
i Any work involving cleaning and maintenance
must not be carried out by children unless they
are supervised at all times while doing so.
People with reduced physical, sensory or
mental capacities
The appliance can be used by people with reduced
physical, sensory or mental capacities or a lack of
experience and/or knowledge if they are supervised
or have been instructed how to use the appliance
safely and understand the resultant risks.
Operation can be restricted using the childproofing
feature.
ÿDANGER!
Risk of burns from hot cookware and food
Handles projecting over the edge of the worktop
are asking to be grabbed.
X Keep children away from hot cooking zones or
ensure they are supervised at all times.
X Do not turn pot and pan handles so they stick
out beyond the worktop.
X Make sure that hot pots and pans cannot be
pulled down.
X If necessary, use suitable stove guards or
covers.
X Only use stove guards and covers that are
approved by the appliance manufacturer;
otherwise, there is a risk of accidents.
X To choose a suitable stove guard, contact your
specialist supplier or the BORA Service Team.
2.3 General safety instructions
ÿDANGER!
Packaging components are a choking hazard
Packaging components (e.g. lm, polystyrene) can
be life-threatening for children.
X Store all packaging components out of reach of
children.
X Dispose of the packaging properly and
immediately.

EN
5
Safety
www.bora.com
CAUTION!
Risk of injury from heavy lifting
If not handled correctly, carrying and installing
appliances can cause injury to the limbs or torso.
X If necessary, carry and install the appliance with
another person.
X Use appropriate aids to prevent damage or
injury.
CAUTION!
Damage from improper use
The appliance surfaces must not be used as
work or storage surfaces. This can damage the
appliances (particularly in the case of hard and
sharp objects). Never use the appliances as work
or storage surfaces.
X Keep hard or sharp objects away from the
appliance surfaces.
Faults and errors
X In the case of faults and errors, follow the
instructions in the “Troubleshooting” chapter.
X In the event of any faults or errors that are not
mentioned, switch the appliance off and contact
BORA Service.
Pets
X Keep pets away from the appliance.
2.4 Safety instructions for
installation
i The appliance must only be installed and
assembled by trained specialists who are
familiar with and comply with the standard
national regulations and supplementary
regulations of the local utility companies.
i During installation maintain the minimum
clearance stated in the “Installation” (“Safety
clearances”) chapter.
i Work on electrical components must only be
conducted by trained electrical personnel.
i The appliance may only be installed with the
power disconnected.
The electrical safety of the appliance is only
guaranteed if it is connected to a protective
conductor system that has been installed in line with
regulations. Ensure that this basic safety precaution
is met.
ÿDANGER!
Risk of electric shock or injury from damaged
surfaces
The underlying electronics can be exposed or
damaged due to ssures, fractures or cracks
in appliance surfaces (e.g. damaged glass),
particularly in the vicinity of the operating unit.
This can cause an electric shock. Furthermore, a
damaged surface can cause injuries.
X Do not touch the damaged surface.
X If there are any cracks, fissures or fractures,
switch the appliance off immediately.
X Safely disconnect the appliance from the mains
using the LS switch, fuses, automatic circuit
breakers or contactor.
X Contact BORA Service.
ÿWARNING!
Risk of injury from damaged components
Damaged components that cannot be removed
without tools can cause injuries.
X Try not to repair or replace damaged
components yourself.
X Contact BORA Service.
ÿWARNING!
Risk of injury or damage due to incorrect
components or unauthorised modifications
Incorrect components can lead to personal
injury or damage to the appliance. Modications,
additions or alterations to the appliance can lead to
safety risks.
X Only use original components.
X Do not make any modifications, additions or
alterations to the appliance.
CAUTION!
Appliance components can cause injury if
dropped
Appliance components (e.g. pan supports,
operating controls, covers, grease lters, etc.) can
cause injury if dropped.
X Place any appliance components that have been
removed in a safe place near the appliances.
X Ensure that no components removed from the
appliances can fall on the floor.

EN
6
Safety
www.bora.com
The appliance must be suitable for the regional
voltage and frequency.
X Check the information on the identification plate
and in the event of deviations, do not connect the
appliance.
X Conduct all work extremely attentively and
conscientiously.
X Do not connect the appliance to the mains until
the duct system has been installed or the
recirculation filter has been fitted.
X Only use the connection cables supplied. Where
necessary these are included in the scope of
delivery.
X Do not use the appliance until installation is
complete. This is the only way to ensure safe
operation.
ÿDANGER!
Risk of electric shock from damaged appliance
A damaged appliance can cause an electric shock.
X Check the appliance for visible damage prior to
installation.
X Do not install or connect any damaged
appliances.
X Do not operate any damaged appliances.
CAUTION!
Risk of burning from control knobs that are
not positioned optimally.
If the control knobs are not installed in a suitable
place, during operation there is a risk of sustaining
burns from the cooktop surface.
X Only install the control knobs in a suitable place,
which is practical and safe.
2.4.1 Safety instructions for cooktop
installation
ÿDANGER!
Risk of electric shock from incorrect mains
connection
Connecting the appliance to the mains incorrectly
poses a risk of electric shock.
X Make sure that the appliance has a fixed
connection to the mains voltage.
X Make sure that the appliance is connected to a
properly installed protective conductor system.
X Make sure that technical equipment is provided
to enable all of the appliance’s poles to be
disconnected from the mains with a contact
opening width of at least 3mm (LS switch and
automatic circuit breakers, fuses, contactor).
ÿDANGER!
Risk of electric shock from damaged power
supply cable
If the power supply cable is damaged (e.g. during
installation or by coming into contact with hot
cooking surfaces), this can cause an (lethal)
electric shock.
X Make sure that the power supply cable does not
become trapped or damaged.
X Make sure that the power supply cable does not
come into contact with hot cooking surfaces.
2.5 Safety instructions – operation
X Make sure that the base of the cookware as well
as the appliance surfaces are clean and dry.
X Always lift (do not drag) cookware to prevent
scratching and abrasion on the appliance surface.
X Do not use the appliance as a storage surface.
X Switch off the appliance after use. WARNING!
Risk of burning from hot appliances
Certain appliances and their exposed parts become
hot during use. They should be left to cool down
completely after switching off. Touching hot
surfaces can cause serious burns.
X Do not touch hot appliances.
X Pay attention to the residual heat indicator.
ÿWARNING!
Risk of burns due to power cut
During or after a power cut a cooktop that was
previously in operation may still be hot.
X Do not touch the appliance while it is still hot.
X Keep children away from the hot appliance.
ÿDANGER!
Risk of fire from overheated oil or fat
Oil or fat in the pot can quickly heat up and ignite.
X Never leave the appliance unattended when
cooking with oil or fat
X Never extinguish oil and fat fires with water.
X Switch off the appliance.
X Extinguish the fire using a pan lid or a fire
blanket, for example.

EN
7
Safety
www.bora.com
ÿWARNING!
Risk of burning and fire from hot objects
The appliance and its exposed parts are hot
during operation and the cooling phase. Objects
in contact with hot appliance components heat
up very quickly and can cause severe burns (this
particularly applies to metal objects such as knives,
forks, spoons, lids or appliance components) or
catch re.
X Do not place any items on the appliance.
X Please use suitable accessories (pot holders,
oven gloves).
CAUTION!
Damage caused by hot cookware
Hot cookware can damage certain components in
the appliance.
X Do not put hot cookware down in the area of the
cooktop display.
2.5.1 Safety instructions – cooktop
operation
X Do not simply rely on the pan size recognition
function on induction cooktops; always switch the
appliance off after use.
ÿDANGER!
Danger of fire caused by leaving the cooktop
unattended
Oil or fat in the pot can quickly heat up and ignite.
X Never leave oil or fat to heat up unattended.
X Never extinguish oil and fat fires with water.
X Switch off the cooktop.
X Extinguish the fire using a pan lid or a fire
blanket, for example.
ÿDANGER!
Danger of explosion caused by flammable
liquids
Flammable liquids in the vicinity of a cooktop can
explode and cause serious injury.
X Do not spray aerosols near the appliance when
it is in use.
X Do not place any flammable liquids in the
vicinity of a cooktop.
ÿWARNING!
Risk of burns from hot liquids boiling over
Unattended pans can boil over allowing hot liquids
to escape.
X Keep an eye on pans when cooking.
X Try not to let them boil over.
ÿWARNING!
Risk of burns from hot steam
Liquid between the cooking zone and the pan base
can evaporate and cause burns.
X Make sure that the cooking zone and the pan
base are always dry.
CAUTION!
Damage caused by sugary and salty foods
Sugary and salty foods and juices can damage the
hot cooking zone.
X Make sure sugary and salty foods or juices do
not get onto the cooking zone while it is hot.
X Remove sugary and salty foods and juices from
the hot cooking zone immediately.
Special safety instructions for the operation of
induction cooktops
Effect on pace makers, hearing aids and metal
implants:
induction cooktops generate a high-frequency
electromagnetic field in the area of the cooking
zones. The cooking zones may affect pacemakers,
hearing aids or metal implants negatively or disturb
their function when in close proximity. A reduced
function of the pacemaker is unlikely.
X If in doubt, contact the manufacturer of your
medical device, or your doctor.
2.6 Safety instructions – cleaning
and maintenance
The appliance must be cleaned at regular intervals.
Dirt can lead to damage, restriction of functions, or
bothersome odours. In the worst case scenario, this
can become a hazard.
X Remove dirt immediately.
X When cleaning, only use non-abrasive detergents
to prevent scratching and abrasion on the surface.
X When cleaning, ensure that no water penetrates
the appliance. Use only a slightly damp cloth.
Never spray the device with water. Water
penetration can cause damage!
X Do not use a steam cleaner for cleaning. Steam
can cause a short circuit on live parts and thus
lead to property damage.
X Please follow all instructions in the “Cleaning and
Maintenance” chapter.
Special safety instructions for cooktop cleaning
and maintenance
X Whenever possible, clean the cooktops after every
use.
X Only clean the cooktops when they have cooled down.

EN
8
Safety
www.bora.com
2.7 Safety instructions – repairs,
servicing and spare parts
i The appliance must only be repaired and
serviced by trained specialists who are familiar
with and comply with the standard national
regulations and supplementary regulations of
the local utility companies.
i Work on electrical components must only be
conducted by trained electrical personnel.
X Before any repair work, safely disconnect the
appliance from the mains supply.
ÿWARNING!
Risk of injury or damage from improper repairs
Incorrect components can lead to personal
injury or damage to the appliance. Modications,
additions or alterations to the appliance can lead to
safety risks.
X Only use original spare parts for repairs.
X Do not make any modifications, additions or
alterations to the appliance.
i A damaged power supply cable must be
replaced by a suitable power supply cable. This
may only be done by an authorised member of
the After Sales Service team.
2.8 Safety instructions –
disassembly and disposal
i The appliance must only be disassembled by
trained specialists who are familiar with and
comply with the standard national regulations
and supplementary regulations of the local
utility companies.
i Work on electrical components must only be
conducted by trained electrical personnel.
X Before disassembly, safely disconnect the
appliance from the mains supply.
ÿDANGER!
Risk of electric shock from incorrect
disconnection
Incorrectly disconnecting the appliance from the
mains results in a risk of electric shock.
X Safely disconnect the appliance from the mains
using LS switches, fuses, automatic circuit
breakers or contactors.
X Use an authorised measuring device to ensure
that there is no power to the appliance.
X Do not touch exposed contacts on the electronic
unit as they may contain residual charge.

EN
9
Technical data
www.bora.com
3 Technical data
509 15,5
410 32
Fig. 3.3 PKI3 appliance dimensions side view
3.2 BORA Professional 3.0 control
knob dimensions
Fig. 3.4 Control knob
Ø49
Ø58
Ø76
90
22 10-40 18
Fig. 3.5 Control knob dimensions
3.1 BORA Pro induction cooktop PKI3
Parameter Value
Supply voltage 220–240V
Frequency 50/60Hz
Power consumption 3.68kW
Fuse protection 1 x 16A
Dimensions (width x depth x height) 370 x 540 x 52mm
Weight (incl. accessories/packaging) 8.0kg
Cooktop Value
Power levels 1–9, P
Heat retention levels 3
Front cooking zone
power setting
Ø 230mm 2300W
3680W
Rear cooking zone
power setting
Ø 165mm 1400W
2200W
Energy consumption
(calculated with standard pot sizes)
Front cooking zone (240 mm) 162,7 Wh/kg
Rear cooking zone (180 mm) 169,3 Wh/kg
Total (average) 166,0 Wh/kg
Tab. 3.1 Technical data for PKI3
PKI3 appliance dimensions
370
255
540
133,5
Ø165
Ø230
R3
Fig. 3.1 PKI3 appliance dimensions from above
341 14,5
31228
52
40
7
Fig. 3.2 PKI3 appliance dimensions front view

EN
10
Appliance description
www.bora.com
4 Appliance description
Control knob display
3
1
2
4
Fig. 4.3 Control knob display elements
[1] Timer/egg timer indicator
[2] Rear cooking zone indicator
[3] Multi-function display
[4] Front cooking zone indicator
Control knob assignment
54321
Fig. 4.4 Control knob assignment
[1] Control knob for left cooktop, front cooking zone
[2] Control knob for left cooktop, rear cooking zone
[3] Control knob for cooktop extractor
[4] Control knob for right cooktop, front cooking zone
[5] Control knob for right cooktop, rear cooking zone
4.2 Cooktop appliance description
4.2.1 Display and symbols
i The power levels and cooking functions of each cooking
zone are shown in the control knob display on the
corresponding control knob.
i The cooktops PKFI3 and PKI3 also have a 7-segment
cooktop display for each cooking zone. Power levels and
operating functions respectively are shown directly on
the cooktop.
XObserve all safety and warning information during operation
(see „2 Safety“).
4.1 Control knob
How it works
The cooktop extractor and cooktops are operated with a control
knob. The power levels and functions are controlled by turning
the knob ring and pressing the touch surface.
i How it works and its functions are described in more
detail in the Operation chapter.
Structure
4
3
5
2
1
Fig. 4.1 Control knob structure
[1] Knob housing
[2] Universal nut
[3] Control knob display
[4] Knob ring
[5] Wave spring
Operating elements
2
1
Fig. 4.2 Control knob operating elements
[1] Knob ring
[2] Touch surface
