Borum CH18FT User manual

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Specifications:
Motor: 240V 1HP
Number of Speeds: 16
Spindle Speeds: 162-3160rpm
Maximum Drilling Capacity: 20mm
Spindle Taper: MT2
Chuck: 16mm
Maximum Spindle Stroke: 82mm
Swing: 430mm
Maximum Distance from Spindle to Table: 775mm
Maximum Distance from Spindle to Base: 1270mm
Diameter of Column: 80mm
Diameter of Table: 350mm
Size of Base: 460 x 270mm
Overall Height: 1625mm
Weight: 85kg
About the Borum brand
Our “heavy duty commercial” range of Borum Industrial equipment has been manufactured to exacting standards for the past 34
years. We specify industrial quality components and design to ensure a long and durable working life in commercial transport,
mining, earthmoving and railway environments. Our Borum Industrial range of equipment is focused on achieving superior
professional standards, reliability, quality, and are covered by a 12 month trade use warranty.
PEDESTAL DRILL PRESS

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 1
Visit us at www.tqbbrands.com.au
WARNING INFORMATION
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before using or
operating this equipment. Do not allow anyone to use or operate this equipment until they have read
this manual and have developed a thorough understanding of how this equipment works. Failure to
observe any of the instructions contained in the manual could result in severe personal injury to the user
or bystanders, or cause damage to the equipment and property. Keep this manual in a convenient and
safe place for future reference.
The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the Borum
policy of continuous improvement determines the right to make modifications without prior warning.
CONTENTS
WARNING INFORMATION................................................................................................................................................. 1
CONTENTS.........................................................................................................................................................................1
STANDARD OPERATING PROCEDURE ............................................................................................................................... 2
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE.................................................................................................. 3
PARTS LIST.........................................................................................................................................................................9
PARTS DIAGRAM .............................................................................................................................................................10
TROUBLESHOOTING........................................................................................................................................................11
WARRANTY......................................................................................................................................................................12

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 2
Visit us at www.tqbbrands.com.au
STANDARD OPERATING PROCEDURE
DO NOT use this machine unless you have been trained and assessed to a competent level in its safe use and operation, and
have been given permission to use this
PRE-OPERATIONAL SAFETY CHECKS
1. Keep guards in place and in good working order
2. Keep drill press in good working order, follow lubricating and changing accessories instructions
3. Use recommended accessories only, failure to do so may damage the drill press and/or may risk
injury
4. Remove adjusting keys & wrenches from the drill press before operating
5. Ensure the switch is in the OFF position before starting the drill press
6. Disconnect drill press before performing any maintenance
7. Keep work area clean, free from hazards and well lit.
8. Only use the drill press for its intended purpose.
9. Wear the correct PPE clothing.
10. Secure work using claims or vice where practical.
11. Do not overreach, keep proper footing and balance at all times while operating the drill press
12. Never leave drill press running unattended, always lock the “on – off” switch when not in use
13. Use only on hard level surfaces capable of sustaining the load.
14. Ensure that risk assessment has been read.
15. Check workspace and walkways to ensure no slip-hazards are present.
16. Faulty equipment must not be used. Immediately report suspect equipment.
OPERATIONAL SAFETY CHECKS
1. Never leave the machine running unattended.
2. Before making adjustments or before cleaning sward accumulations switch off and bring the
machine to a complete standstill.
3. Ensure that the work piece is securely held in a clamped work vice or clamped directly to the
table.
4. Feed downwards at a sufficient rate to keep the drill cutting.
5. Feed with care as the drill breaks through the underside of the work.
6. Use a safe working posture (beware of hair catching).
HOUSEKEEPING
1. Switch off the machine.
2. Return all tooling and fixtures to the correct storage location.
3. Display a completed “Equipment in Use” notice if the machine is set up and/or in use but
unattended.
4. Leave the machine and work are in a safe, clean and tidy state after job is completed.
5. Return surplus material to stock and dispose of waste material in an appropriate recycling or
waste bin.
POTENTIAL HAZARDS
Hair/clothing entanglement –rotating spindle/drill
Flying swarf/chips
Eye injuries
Sharp edges and burrs
High noise levels when drilling some materials
Distracting operator
Removal or modification of safety devices
Using equipment with lapsed test tag
Safety glasses must be worn when
operating this equipment
Long loose hair must be contained when
operating this equipment
Safety footwear must be worn when
operating this equipment
Close fitting/protective clothing must be
worn when operating this equipment
Rings and jewellery must not be worn
when operating this equipment
Hearing protection must be worn where
noise levels are in excess of 85 dB(A)
occupational exposure limit
Gloves must not be worn when
machine is operating. Machine to be at
standstill if gloves required for manual
operations.

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 3
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES & MODELS
This "Borum Industrial Drill Press" delivers precision and power... and is designed to handle the
demands of a professional workshop environment. With a powerful long-life industrial quality 3/4 HP
motor (that's fully enclosed in a durable metal hood) double-wide spindle bearings and a precision
spindle, this is one very reliable drilling machine.
Equipped with 16 drilling speeds from 162 to 3,000rpm and a 16mm drilling capacity this robust and
user-friendly drill press is ideal for a busy maintenance workshop or small production factory.
Perfect for fabricators looking for a drill press that's rugged enough to handle the demands of light
and medium duty production work and accurate enough to consistently deliver precise results.
2. ASSEMBLY
Fig 1. Column Assembly
1. Place column assembly on base and align holes on column
support with holes on base.
2. Secure the column with 4 bolts and washers (provided)
Fig 2. Table Bracket Installation
1. Remove collar and rack
2. Install table bracket and rack
Fig 3. Collar Installation
1. Install collar and tighten firmly
Fig 4. Bracket Installation
1. Install bracket, handle and clamp bolt
2. Tighten handle with attached set screw
Fig 5.
1. Install clamp bolt to tighten

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 4
Visit us at www.tqbbrands.com.au
Fig 6.
1. Install table and clamp with bolt (provided)
Fig 7. Head Assembly
1. Position the head assembly over the column and slide into
position. Align head frame with table base
2. Fix set screws on right side of head to lock head into
position, tighten screws with allen key
Fig 8. Feeding Handle Installation
1. Screw knob on each feeding handle, install onto hub of
pinion shaft
Fig 9. Arbor & Chuck Installation
1. Insert Arbor onto spindle. Pull feed handle down to press
arbor into position
2. Open chuck jaws completely by turning attached chuck key
counter-clockwise to the end.
3. Place a piece of wood on the table to protect chuck nose
Fig 10.
1. Install the chuck to the arbor
and tighten
Fig 11.
1. Install the knob and screw of
upper pulley cover
Ensure the drill press is firmly fixed in place to table or floor following assembly

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 5
Visit us at www.tqbbrands.com.au
Table Adjustment
Fig 12. Height Adjustment
1. To adjust up or down, loosen the clamp bolt to
adjust the table the preferred position by turning
the table bracket handle
Fig 13. Tilting Adjustment
1. Loosen the table bevel lock bolt with an adjustable
wrench
2. Tilt the table to the preferred angle and re-tighten
the bolt
Fig 14. Swing 360°
1. Loosen the clamp bolt and swing table to preferred
position, re-tighten clamp bolt
Fig 15 Feed Depth Adjustment
1. Depth control scale sleeve type
2. Loosen the clamp bolt and move to the preferred
depth, re-tighten the clamp bolt

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 6
Visit us at www.tqbbrands.com.au
Speed Adjustment
Fig 16-1 Speed Adjustment
1. Open the pulley case and loosen the belt tension lock
handle
2. Choose speed for drilling operation and move belt to
correct position for preferred speed
3. Push motor backward until moderate belt tension as
required.
4. Re-tighten the lock handle. 16-1 & 16-2
Drilling Speed (Approximately)
Belt Tension Adjustment
Correct belt tension: Use 4.5kg’s of hand pressure on the belt as shown below. The distance is 1/2” (13mm) + 10%
Size
Diameter
Cast Steel
Tool Steel
Cast Iron
Mild Steel
Alum. & Copper
Cutting Speed
m/min
ft/min
m/min
ft/min
m/min
ft/min
m/min
ft/min
m/min
ft/min
12
40
18
60
24
80
30
100
60
200
mm
Inch
Cutting Speed Revolution Per Minute
2
1/16
1910
2445
2865
3665
3820
4890
4775
6110
9550
12225
3
1/8
1275
1220
1910
1835
2545
2445
3185
3055
6365
6110
5
3/16
765
815
1145
1220
1530
1630
1910
2035
3820
4075
6
¼
610
610
955
915
1275
1220
1590
1530
3180
3055
8
5/16
480
490
715
735
955
980
1195
1220
2390
2445
10
3/8
380
405
570
610
765
815
955
1020
1910
2035
11
7/16
350
350
520
525
700
700
870
870
1740
1745
13
1/2
300
305
440
460
590
610
735
765
1470
1530
16
5/8
240
245
360
365
480
490
600
610
1200
1220
19
3/4
190
205
285
305
380
405
480
510
955
1020

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 7
Visit us at www.tqbbrands.com.au
Quill Spring Adjustment
Fig 17 Speed Adjustment
1. Move the stop nuts to the lowest position and lock
into place with a wrench to prevent quill dropping
while tensioning spring
2. Place screwdriver in lower front notch (A) of spring
cap (B) and hold it in place while loosening and
removing nuts.
3. Carefully turn screwdriver counter clockwise and
engage next notch
4. Tighten inner nut (C) with wrench. DO NOT
overtighten as this will restrict quill removal.
5. Move stop nuts to highest position and check
tension while turning feed handle. It there isn’t
enough tension on spring, repeat steps 2 –4.
6. Check quill while feeding for: Smooth and
unrestricted movement. If movement is too tight
slightly loosen nuts until unrestricted.
3. BEFORE USE
Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds,
leaks, and damaged, loose, or missing parts.
Caution: This drill press is intended for use only with drill bits. The use of other accessories
may be hazardous.
Drill Speed: Factors that determine the best speed to use in any drill press operation are:
Type of material being worked on, size of hole, type of drill or cutter and quality of cut
desired. The smaller the drill bit, the greater the required RPM. For softer materials,
the speed should be higher than firmer material.
Drill Metal: Use clamps to hold work in place when drilling metal. DO NOT hold with hand. The
flutes of the drill may seize the work at any time, especially when breaking through
stock, causing the work piece to spin.
Clamp: The work must be clamped firmly while drilling: Any tilting, twisting, or shifting results
not only in a rough hole, but also increases drill bit breakage. For flat work, lay the
piece on a wooden base and clamp firmly down against the table to prevent the work
piece from turning. If the piece is of irregular shape and cannot be laid flat on the
table, is should be securely blocked and clamped.
Chuck: The chuck should be securely fastened to the spindle. Remove the chuck after
adjustment. Only use the chuck key provided by the manufacturer. This chuck key
is spring loaded to prevent the chuck key from remaining in the chuck during operation
of the drill.
Fixing: Fasten base of drill press to the floor before using to ensure no tipping, sliding of drill
press. The set screws of the head frame should be secured tightly before using this
machine.
Power: When mounting the motor, ensure the power is disconnected. Connect to power
supply protected by a circuit breaker.
Transportation: Lifting by Forklift;
1. If lifting equipment isn’t available, use 1ton capacity forklift under the machine
base to locate to position
2. To move the drill press safely, place the forks of the forklift at the rear of the drill
press –the drill press must only be moved while on a pallet.
3. Keep balance of drill press on pallet while moving with forklift.

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 8
Visit us at www.tqbbrands.com.au
4. OPERATION
Fig 18 Installing Drills
1. Insert drill into chuck jaws approx. 1” (25.4mm) long.
When using a small drill do not insert too far for the
jaws to tough the flutes of the drill. Make sure that the
drill is centred in the chuck before tightening the chuck
with the key.
Fig 19 Workpiece Positioning
1. Always place a piece of wood (or plywood) on the table
to prevent “splintering” and/or burrs on the underside
of the workpiece as the drill breaks through. Position
the wood so that it is in contact with the left side of the
column
Vice Positioning
1. For small workpieces that cannot be clamped to the table, use a drill press vice. The vice
must be clamped or bolted to the table.
5. INSPECTION
Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked
welds, leaks, and damaged, loose, or missing parts.
The drill press shall always be maintained in accordance with the maintenance instructions. No
alterations or modifications shall be made to this drill press.
Inspections shall be performed in accordance with this owner’s manual.
The drill press must be inspected immediately if it is believed to have been subjected to abnormal
load or shock.
Owners and /or operators should be aware that repair of this product may require specialised
equipment and knowledge (refer to maintenance section).
6. STORAGE
This drill press should always be stored in a dry location on a level surface with the power switched
off.
7. MAINTENANCE
1. DISCONNECT Drill Press before performing any maintenance
2. FREQUENTLY blow out any dust that may accumulate inside the motor
3. APPLY a coat of automobile type wax or similar to the table and column to keep surface clean
4. LUBRICATION; all the ball bearings are packed with grease at the factory. They require no further
lubrication
5. PERIODICALLY lubricate the gear and rack table elevation mechanism, the splines (grooves) in
the spindle and the rack (teeth on the quill)
6. Only use replacement parts that are approved by the manufacturer.
7. Regularly clean all surfaces and maintain all labels and warnings.

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 9
Visit us at www.tqbbrands.com.au
8. SERVICE & REPAIR
Any Borum Industrial Drill Press found damaged in any way, or found to be worn or operates
abnormally should be removed from service until repaired by an authorised service agent. Owners
and / or operators should be aware that repair of this product may require specialised equipment
and knowledge. Only authorised parts, labels, decals shall be used on this equipment. Annual
inspection of the drill press is recommended and can be made by an authorised repair facility to
ensure that your equipment is in optimum condition and that the equipment has the correct decals
and safety labels specified by the manufacturer.
PARTS LIST
Part
Description
QTY
Part
Description
QTY
Part
Description
QTY
1
Pulley cover
1
30
Tension adj. block
1
62
Knob
1
1-1
Label
1
31
Machine head
1
63
Handle bar
1
2
Spindle pulley
1
31-1
Label
2
64
Rack collar
1
2-1
Nut
1
32
Set screw
1
65
Screw
1
3
V-Belt
1
33
Snap ring
1
66B
Column
1
4
Knob
1
34
Motor tension adj lever
2
66BF
Column
1
4-1
Screw
1
35
Screw
1
67B
Rack
1
5
Centre pulley
1
36
Snap ring
1
67BF
Rack
1
6
Bearing
1
37
Motor bracket
1
68
Clamp bolt
1
7
Bearing
1
38
Motor bracket
4
69
Table bracket
1
8
Snap ring
1
39
Cable bushing
4
69-1
Angle scale
1
9
Set screw
1
40
Spring washer
4
70
Gear
1
10
V-Belt
1
41
Hex nut
1
71
Worm gear
1
11
Motor pulley
1
42
Hex screw
1
72
Shaft
1
12
Centre pulley bracket
1
43
Motor mounting plate
4
73
Table bracket screw
1
13
Screw
4
44
Motor
73-1
Screw
1
14
Cable bushing
2
45
Nut / Face washer
74
Table arm
1
15
Cable clip
1
46
Wiring box
1
74-1
Zero mark
1
16
Cable & plug
1
47
Rubber pad
1
75
Screw
1
16-1
Motor cable
1
48
Snap ring
1
76
Clamp bolt
1
17
Driving taper sleeve
1
49
Ball bearing
1
77
Spring washer
1
18
Circlip
2
50
Rubber spacer
1
78
Hex screw
1
19
Ball bearing
2
51
Quill
1
79
Table
1
20
Switch
1
52
Ball bearing
1
80B
Flange
1
20-1
Screw
3
53
Chuck guard
1
80BF
Flange
1
22
Switch box
1
54
Spindle
1
81
Hex screw
4
23
Screw
3
55
Wedge
1
82
Spring washer
4
24
Cable bushing
1
56
Arbor
1
83B
Base
1
25
Set screw
1
57
Chuck
1
83BF
Base
1
26
Nut
1
58
Chuck key
1
27
Nut
1
59
Set screw
1
28
Spring & cap
1
60
Scale sleeve
1
29
Set screw
1
61
Pinion shaft
1

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 10
Visit us at www.tqbbrands.com.au
PARTS DIAGRAM

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 11
Visit us at www.tqbbrands.com.au
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
REMEDY
Noisy Operation
Incorrect belt tension
Dry spindle
Loose pulley
Loose belt
Bad bearing
Adjust tension
Remove spindle/quill assembly &
lubricate
Tighten pulley
Adjust belt tension
Replace bearing
Excessive drill
wobble
Loose chuck
Worn spindle shaft or bearing
Bad chuck
Tighten by pressing chuck down against
table
Replace spindle shaft or bearing
Replace chuck
Motor won’t start
Power supply
Motor connection
Switch connections
Motor windings burnt
Bad switch
Check power cord
Check motor connections
Check switch connections
Replace motor
Replace switch
Drill binds in
workpiece
Excessive pressure on feed
handle
Loose belt
Loose drill
Speed too fast
Apply less pressure
Check belt tension
Tighten drill with key
Change speed
Drill burns or
smokes
Incorrect speed –reduce RPM
Fillings caught in drill bit
Poor drilling
Incorrect feed pressure
Refer to RPM sheet
Clean drill bit
Sharpen drill bit or replace drill bit
Apply less pressure
Table difficult to
raise
Needs lubrication
Bent rack
Table lock too tight
Lubricate with a light oil
Straighten rack
Loosen clamp

10/19 CH18FT
Made in China to TQB Brands Pty Ltd specifications P a g e | 12
Visit us at www.tqbbrands.com.au
WARRANTY
BORUM Industrial products have been carefully tested and inspected before shipment and are guaranteed
to be free from defective materials and workmanship for a period of 12 months from the date of purchase
except where tools are hired out when the guarantee period is ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your nearest
authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[e-mail].
If upon inspection it is found that the fault occurring is due to defective materials or workmanship, repairs
will be carried out free of charge. This guarantee does not apply to normal wear and tear, nor does it
cover any damage caused by misuse, careless or unsafe handling, alterations, accident, or repairs
attempted or made by any personnel other than the authorised TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms
are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a dated receipt
or invoice to verify your proof of purchase within the 12month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not amount to a major failure.
All images and illustrations shown are for reference purposes only. All information, specifications and
illustrations in this manual are based on the latest information available at the time of publication and
are subject to change without notice. The information in this manual is periodically revised to ensure the
latest information is included. Download the latest version of this manual and other related technical
documentation from www.tqbbrands.com.au
