Bosch Climate 5000 L User manual

6721841492 (2022/03) div
bg Голям климатичен уред сплит система Ръководство за монтаж за специалисти. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
de Large-Split-Klimagerät Installationsanleitung für die Fachkraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
el Κλιματιστικό τύπου Split Large Οδηγίες εγκατάστασης για τον εξειδικευμένο τεχνικό. . . . . . . . . . . . . . . . . . . . . . . . . . . 32
en Large split air conditioner Installation instructions for the qualified person . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
es Climatizador Large Split Manual de instalación para el técnico . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
fr Climatiseur large split Notice d’installation pour le spécialiste. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
it Condizionatore Large Split Istruzioni per l'installazione per il tecnico specializzato . . . . . . . . . . . . . . . . . . . . . . . . 93
nl Large-Split-airconditioning Installatie-instructie voor de vakman. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
pl Urządzenie klimatyzacyjne large split Instrukcja montażu dla instalatora. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
pt Ar condicionado split Manual de instalação para técnico especializado . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
ro Aparat de aer condiționat de tip split Large Instrucțiuni de instalare pentru personalul specializat. . . . . . . . . . . . . . . . . . . . . . . . 153
sq Kondicioner Large Split Udhëzimet e instalimit për specialistin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
tr 4 Yöne Üflemeli Kaset Tipi Split Klima Yetkili servis personeli için montaj kılavuzu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
uk Спліт кондиціонер для застосування у
приміщеннях великих площ Інструкція з монтажу та технічного обслуговування для фахівців . . . . . . . . . . . . 198
Climate 5000L • Climate 5000i U/L
0010040318-003
CL5000L 35 E • CL5000iU 4CC 35 E | CL5000L 53 E • CL5000iU 4CC 53 E |
CL5000L 70 E • CL5000iU 4C 70 E | CL5000L 88 E • CL5000iL 4C 88 E |
CL5000L 105 E • CL5000iL 4C 105 E | CL5000L 105 E-3 • CL5000iL 4C 105 E |
CL5000L 125 E • CL5000iL 4C 125 E | CL5000L 140 E-3 • CL5000iL 4C 140 E |
CL5000L 160 E-3 • CL5000iL 4C 160 E

Table of contents
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
48
Table of contents 1 Explanation of symbols and safety instructions
1.1 Explanation of symbols
Warnings
In warnings, signal words at the beginning of a warning are used to
indicate the type and seriousness of the ensuing risk if measures for
minimizing danger are not taken.
Thefollowingsignal wordsaredefined andcan be used inthisdocument:
DANGER
DANGER indicates that severe or life-threatening personal injury will
occur.
WARNING
WARNING indicates that severe to life-threatening personal injury may
occur.
CAUTION
CAUTION indicates that minor to medium personal injury may occur.
NOTICE
NOTICE indicates that material damage may occur.
Important information
Theinfosymbol indicatesimportantinformationwherethereis noriskto
people or property.
Table 1
1 Explanation of symbols and safety instructions . . . . . . . . . . 48
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . 48
1.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . 49
1.3 Notices regarding these instructions . . . . . . . . . . . . . . 49
2 Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.1 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . 49
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.3 Twin combination. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.4 Product dimensions and minimum clearances. . . . . . . 50
2.4.1 Indoor unit and outdoor unit . . . . . . . . . . . . . . . . . . . . . 50
2.4.2 Refrigerant lines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.5 Information on refrigerant . . . . . . . . . . . . . . . . . . . . . . . 50
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3.1 Before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3.2 Requirements for installation site . . . . . . . . . . . . . . . . . 51
3.3 Unit installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
3.3.1 Installing the indoor unit in the ceiling . . . . . . . . . . . . . 51
3.3.2 Assembly of cover CL5000iU 4CC .... . . . . . . . . . . . . . 51
3.3.3 Assembly of cover CL5000iL 4C ... . . . . . . . . . . . . . . . 52
3.3.4 Installing the outdoor unit . . . . . . . . . . . . . . . . . . . . . . . 52
3.4 Installing the outside air duct . . . . . . . . . . . . . . . . . . . . 52
3.5 Pipework connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
3.5.1 Connecting refrigerant lines to the indoor and
outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
3.5.2 Connecting condensate pipe to the indoor unit. . . . . . 53
3.5.3 Testing the condensate pipe . . . . . . . . . . . . . . . . . . . . . 53
3.5.4 Checking tightness and filling the system. . . . . . . . . . . 53
3.6 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
3.6.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
3.6.2 Connecting the indoor unit . . . . . . . . . . . . . . . . . . . . . . 54
3.6.3 Connecting the outdoor unit . . . . . . . . . . . . . . . . . . . . . 54
3.6.4 Connection as twin combination. . . . . . . . . . . . . . . . . . 54
3.6.5 Connecting external accessories . . . . . . . . . . . . . . . . . 54
4 On-site configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.1 DIP switch setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5.1 Commissioning checklist. . . . . . . . . . . . . . . . . . . . . . . . 56
5.2 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5.3 Handover to the user . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.1 Faults with indication (Self diagnosis function) . . . . . . 56
6.2 Faults not indicated . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7 Environmental protection and disposal . . . . . . . . . . . . . . . . . 59
8 Data Protection Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Symbol Meaning
Warning regarding flammable substances: the
refrigerant R32 used in this product is a gas with low
combustibility and low toxicity (A2L or A2).
Wear protective gloves during installation and
maintenance work.
Maintenance by a qualified person should be done
while following the instructions of the service manual.
For operation follow the instructions of the user
manual.

Product Information
49
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
1.2 General safety instructions
HNotices for the target group
These installation instructions are intended for
qualified persons who are skilled in dealing with
refrigeration engineering and HVAC technology and
also electrical systems. All system-relevant
instructions must be observed. Failure tocomply with
instructions may result in material damage and
personal injury, including danger to life.
▶ Before carrying out the installation, read the
installation instructions of all system components.
▶ Observe the safety instructions and warnings.
▶ Follow national and regional regulations, technical
regulations and guidelines.
▶ Record all work carried out.
HGeneral dangers posed by the refrigerant
▶ This appliance is filled with refrigerant R32. If the
refrigerant gas gets into contact with fire, it may
generate toxic gas.
▶ Thoroughly ventilate the room if refrigerant leaks
during the installation.
▶ Check the tightness of the system following the
installation.
▶ Do not to let any other substance than the specified
refrigerant (R32) into the refrigerant cycle.
HSafety of electrical devices for domestic use
and similar purposes
The following requirements apply in accordance with
EN 60335-1 in order to prevent hazards from
occurring when using electrical appliances:
“This appliance can be used by children of 8 years and
older, as well as by people with reduced physical,
sensoryormentalcapabilitiesorlackingin experience
and knowledge, if they are supervised and have been
given instruction in the safe use of the appliance and
understand the resulting dangers. Children shall not
play with the appliance. Cleaning and user
maintenance must not be performed by children
without supervision.”
“If the power cable is damaged, it must be replaced by
the manufacturer, its customer service department or
a similarly qualified person, so that risks are avoided.”
HHandover to the user
When handing over the air conditioning system,
explain the operation and operating conditions to the
user.
▶ Explain operation – with particular emphasis on all
safety-related actions.
▶ Highlight the following points in particular:
– Point out that modifications or repairs may be
carried out only by an approved contractor.
– To ensure safe and environmentally compatible
operation, an annual inspection, and also
cleaning and maintenance if required, must be
carried out.
▶ Point out the possible consequences (personal
injury and possible danger to life or material
damage) of not carrying out inspection, cleaning
and maintenance correctly, or omitting it
altogether.
▶ Hand over the installation and operating
instructions to the user for safekeeping.
1.3 Notices regarding these instructions
The figures are shown together at the end of these instructions. The text
contains references to the figures.
Depending on the model, the products may be different to those shown
in these instructions.
2ProductInformation
2.1 Declaration of conformity
Thedesignandoperating characteristicsof this productcomplywith the
European and national requirements.
The CE marking declares that the product complies with all the
applicable EU legislation, which is stipulated by attaching this
marking.
The complete text of the Declaration of Conformity is available on the
Internet: worcester-bosch.co.uk.
2.2 Scope of delivery
The appliances are shown as an example and deviations are possible.
The scope of delivery is shown in Figs.:
Scope of delivery, Fig. 1 and 2:
[1] Outdoor unit (filled with refrigerant)
[2] Indoor unit (filled with nitrogen)
[3] Copper nut (2x)
[4] Drainage elbow with gasket
[5] Remote controller
[6] Remote control Holder with fixing screw
[7] 4 anti-vibration couplings for the outdoor unit
[8] Magnetic ring (number depends on appliance type)
[9] Ceiling hook and supporting bolt (4 in each case)
[10] Set of printed documents for product documentation
[11] Only CL5000iL 4C ...: mounting template
[12] Only CL5000iL 4C ...: connecting cable and holder
(used for the optional accessory IP-Gateway)
[13] Only CL5000iL 4C ...: heat insulation for pipe
[14] Only CL5000iL 4C ...: cable clip

Installation
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
50
2.3 Twin combination
The appliances can be installed as so-called twin combination. In doing
so, an outdoor unit is combined with two indoor units of the same type.
The indoor units must be installed at the same height.
▶ Observe the possible combinations in table 2.
▶ Observe the dimensions in Fig. 30.
▶ Arrange the branch joints horizontally.
Table 2 Possible twin combinations
2.4 Product dimensions and minimum clearances
2.4.1 Indoor unit and outdoor unit
Indoor unit CL5000iU 4CC ...
Figs. 4 and 6.
[1] Refrigerant lines
[2] Condensate pipe
Indoor unit CL5000iL 4C ...
Figs 5 and 6.
[1] Refrigerant lines
[2] Condensate pipe
[3] Connection for outside air duct (round)
[4] Connection for air conduit (rectangular; exemplary position)
Outdoor Unit
Figs. 7 to 8.
2.4.2 Refrigerant lines
Key to figure 9:
[1] Pipe on gas side
[2] Pipe on liquid side
[3] Siphon-shaped elbow as oil separator
If the indoor units are positioned lower than the outdoor unit, install a
siphon-shaped elbow on the gas side after no more than 6 m and every
6 m thereafter (figure 9, [1]).
▶ Observe maximum pipe length and maximum difference in height
between indoor unit and outdoor unit.
Table 3 Piping lengths
▶ Observe pipe diameter and further specifications.
Table 4 Alternative pipe diameter
Table 5
2.5 Information on refrigerant
This device contains fluorinated greenhouse gases as refrigerant. The
device is hermetically sealed. You will find the information on the
refrigerant according to the Regulation (EU) No 517/2014 on
fluorinated greenhouse gases in the operating instructions of the device.
Information for the installer: If you refill refrigerant, enter the additional
charge size and the total charge size of the refrigerant in the table
“information on refrigerant” of the operating instructions.
3 Installation
3.1 Before installation
CAUTION
Risk of injury from sharp edges!
▶ Wear protective gloves during installation.
CAUTION
Danger of burns!
During operation the pipes become hot.
▶ Make sure, that the pipes cooled down before touching them.
▶ Check the scope of delivery for damage.
▶ Check whether a hissing sound due to negative pressure can be
detected when opening the pipes of the indoor unit.
Outdoor unit Indoor Unit
CL5000L 140 E-3 2 × CL5000iU 4C 70 E
CL5000L 160 E-3 2 × CL5000iL 4C 88 E
Appliance type Maximum pipe
length [m]
Maximum height
difference [m]
CL5000L 35 E ≤ 25 ≤ 10
CL5000L 53 E ≤ 30 ≤ 20
CL5000L 70 E ≤ 50 ≤ 25
CL5000L 88 E
CL5000L 105 E ≤ 75 ≤ 30
CL5000L 105 E-3
CL5000L 125 E
CL5000L 140 E-3
CL5000L 160 E-3
Pipe diameter [mm] Alternative pipe diameter [mm]
6.35 (1/4") 6
9.53 (3/8") 10
12.7 (1/2") 12
15.9 (5/8") 16
Specification of the pipes
Min. piping length 3 m
Additionalrefrigeranttobeaddedifthepipe
length exceeds 5 m (liquid side)
With Ø 6.35 mm (1/4"):
12 g/m
With Ø 9.53 mm (3/8"):
24 g/m
Pipe thickness with pipe diameter from
Ø 6.35 mm to 12.7 mm
≥ 0.8 mm
Pipe thickness with 15.9 mm pipe diameter ≥ 1.0 mm
Thickness of insulation against heat ≥ 6 mm
Material of insulation against heat Polyethylene foam

Installation
51
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
3.2 Requirements for installation site
▶ Observe minimum clearances (Chapter 2.4 on page 50).
▶ Observe minimum room area.
Table 6 Minimum room area
Notices regarding the indoor unit
▶ Do not install the indoor unit in a room in which open ignition sources
(for example: open flames, an operating wall mounted gas boiler or
an operating electric heating system) are in operation.
▶ The installation location must not be higher than 2000 m above sea
level.
▶ Keep the air inlet and air outlet clear of any obstacles to allow the air
to circulate freely. Otherwise poor performance and higher noise
levels may occur.
▶ Keep TV, radio and and similar appliances at least 1 m away from the
unit and the remote control.
▶ Do not install the indoor unit in rooms with a high humidity
(e.g. bathrooms or utility rooms).
▶ Indoorunits with a cooling capacity of 2.0 to 5.3 kW are designed for
a single room.
▶ The ceiling construction and suspension system (on site) must be
able to support the weight of the appliance.
Notices regarding the outdoor unit
▶ The outdoor unit must not be exposed to machine oil vapour, hot
spring vapour, sulphur gas, etc.
▶ Do not install the outdoor unit directly next to water or where it is
exposed to sea air.
▶ The outdoor unit must always be kept free of snow.
▶ There must be no disruption caused by extract air or operating noise.
▶ Air should be able to circulate freely around the outdoor unit, but the
appliance must not be exposed to strong wind.
▶ Condensate that forms during operation must be able to drain off
easily. Lay a drain hose if required. In cold regions, installation of the
drain pipe is not advisable as freezing could result.
▶ Place the outdoor unit on a stable base.
3.3 Unit installation
NOTICE
Incorrect assembly can cause material damage.
If the appliance is mounted incorrectly, it may drop off the ceiling
▶ Only mount the appliance on a solid flat ceiling. The ceiling must be
able to carry the weight of the appliance.
▶ Only use screws and wall plugs that are suitable for the ceiling type
and appliance weight.
3.3.1 Installing the indoor unit in the ceiling
We recommend preparing the pipes before hanging the indoor unit so
that only the pipes need to be connected.
▶ Open the box at the top and lift the indoor unit out and up.
▶ Determine the installation location, taking the minimum clearances
and orientation of the pipes into consideration: Figs. 4 to 6.
Make sure that the appliance fits between the structural ceiling and
suspended ceiling.
▶ The fascia must be flush with the suspended ceiling.
▶ Define and mark the position of the suspension bolts on the ceiling.
DANGER
Risk of injury!
The ceiling attachment must be suitable for carrying the weight of the
indoor unit. We recommend using threaded rods in order to be able to
adjusttheheightprecisely.Suitablenutsandwashersareincludedinthe
scope of delivery of the indoor unit.
DANGER
Risk of injury!
At least two persons are required to hang the appliance and fasten it
securely.
▶ Do not install the appliance on your own.
▶ Hang the appliance on the suspension bolts with the washers and
nuts included in the scope of delivery.
▶ Positiontheindoorunit at the correctheight and alignhorizontallyby
turning the nuts on the threaded rods.
NOTICE
If the appliance is not level condensate may leak out.
▶ Use a spirit level to align the appliance horizontally.
▶ Secure the appliance at the correct installation position with lock
nuts.
▶ Establish pipe connections as described in chapter 3.5.1.
3.3.2 Assembly of cover CL5000iU 4CC ...
▶ Remove the air inlet grille from the cover (Fig. 20).
▶ Attach cover to the indoor unit with screws provided, paying
attention to orientation(Fig. 21). The display [2]must be located
opposite the "shorter" side of the L-shaped electronics [1].
▶ The cover must rest evenly and tightly against the indoor unit.
Only reinstall the air inlet grille when establishing the electrical
connection.
Device type Installation height
[m]
Minimum room area
[m2]
CL5000iU 4CC 35 E ≥ 2.2 ≥ 4
CL5000iU 4CC 53 E ≥ 2.2 ≥ 4
CL5000iU 4C 70 E ≥ 2.2 ≥ 6
CL5000iL 4C 88 E ≥ 2.2 ≥ 7
CL5000iL 4C 105 E ≥ 2.2 ≥ 10
CL5000iL 4C 125 E ≥ 2.2 ≥ 12
CL5000iL 4C 140 E ≥ 2.2
CL5000iL 4C 160 E ≥ 2.2

Installation
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
52
3.3.3 Assembly of cover CL5000iL 4C ...
▶ Remove the air inlet grille from the cover (Fig. 22).
▶ Remove the cover at the 4 corners (Fig. 23).
NOTICE
Damage to the cover and display
The display is fixed at one of the removable corner covers and can be
damaged when removing the corner.
▶ Carefully lever the corner clamps with a screwdriver and lift off the
corners.
▶ Attach the 4 corner hooks of the cover in the tabs of the indoor unit,
paying attention to the orientation (Fig. 24). If required, bring the
cover into the correct position by turning it The corner with the
display [2] must be orientated on the electronics [3] and be located
above the refrigerant lines [1].
▶ Evenly tighten the screw hooks until the thickness of the foam
betweenthe casing and the air outlet on the cover is roughly 4-6 mm.
The edge of the cover should be tight against the ceiling.
▶ Remove the foam parts from the inside of the unit.
Only reinstall the air inlet grille when establishing the electrical
connection.
3.3.4 Installing the outdoor unit
▶ Place the box so it is facing upwards.
▶ Cut and remove the packing straps.
▶ Pull the box up and off and remove the packaging.
▶ Prepareandinstalla floororwallmountingbracket,dependingonthe
type of installation.
▶ Set up or hang the outdoor unit.
▶ When installing on the floor or wall mounting bracket, attach the
supplied drainage elbow and gasket (Fig. 10).
▶ Remove the cover for the pipe connections (Fig. 14 and 15).
▶ Establish pipe connections as described in chapter 3.5.1.
3.4 Installing the outside air duct
There is an outside air intake opening on side the appliance, which can
be used if required (Fig. 4 and Fig. 5, [3]).
Nomorethan5% of theair volumetric flowratecan be introduced via the
outside air intake opening.
3.5 Pipework connection
3.5.1 Connecting refrigerant lines to the indoor and outdoor unit
CAUTION
Discharge of refrigerant due to leaky connections
Refrigerant may be discharged if pipe connections are incorrectly
installed. Reusable mechanical connections and flared connections are
not permitted indoors.
▶ Tighten flared connections only once.
▶ After releasing, always fabricate the flared connection again.
Copper pipes are available in metric and imperial sizes, the flare nut
threadishoweverthesame. Theflaredfittingsonthe indoorand outdoor
unit are intended for imperial sizes.
▶ When using metric copper pipes, replace the flare nuts with nuts of a
suitable diameter (Tab. 7).
▶ Determine pipe diameter and length (Page 50).
▶ Cut the pipe to length using a pipe cutter (Fig. 11).
▶ Deburr the inside of the pipe at both ends and tap to remove swarf.
▶ Insert the nut onto the pipe.
▶ Widen the pipe using a flaring tool to the size indicated in the tab. 7.
It must be possible to slide the nut up to the edge but not beyond it.
▶ Connectthepipe and tightenthescrewfitting to the torque specified
in the tab. 7.
▶ Repeat the above steps for the other pipes.
NOTICE
Reduced efficiency due to heat transfer between refrigerant pipes
▶ Thermally insulate the refrigerant lines separately.
▶ Fit the insulation on the pipes and secure.
Table 7 Key data of pipe connections
External diameter of pipe
Ø [mm]
Tightening torque [Nm] Flared opening diameter
(A) [mm]
Flared pipe end Pre-assembled flare nut
thread
6.35 (1/4") 18-20 8.4-8.7 3/8"
9.53 (3/8") 32-39 13.2-13.5 3/8"
12.7 (1/2") 49-59 16.2-16.5 5/8"
15.9 (5/8") 57-71 19.2-19.7 3/4"
R0.4~0.8
A
45°± 2
90°± 4

Installation
53
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
3.5.2 Connecting condensate pipe to the indoor unit
Depending on the type of installation, the condensate pipe must either
be connected to the integrated condensate pump or the condensation
catch pan.
▶ Use PVC pipes with 32 mm inside diameter and 5-7 mm wall
thickness.
▶ Insulate drain pipe to prevent condensate formation.
▶ Connect drain pipe to indoor unit and secure connection with a hose
clip.
▶ Install drain pipe on slope (Fig. 25). With a condensate pump
installed, the outlet of the drain pipe may be higher than the indoor
unit if the dimensions and wiring diagram are observed.
NOTICE
Danger due towater damage!
If the pipes are routed incorrectly, water may be discharged, or may flow
backinto the indoorunitand cause the waterlevelswitchtomalfunction.
▶ To prevent the pipes from sagging, install a support every 1–1.5 m.
▶ Route a drain pipe to the sewer via a siphon.
3.5.3 Testing the condensate pipe
Testing the condensate pipe ensures that all connections are tight.
▶ Test the condensate pipe before closing the cover.
ifthecondensatepumpcanonlybetestedoncetheelectricalconnection
has been established.
▶ Fill the condensation catch pan or water injection pipe with roughly
2lofwater.
▶ Switch on cooling mode. The drainage pump can be heard.
▶ Make sure that the condensate drains away properly.
▶ Check tightness of all connections.
3.5.4 Checking tightness and filling the system
Checking tightness
Observe the national and local regulations when carrying out the
tightness test.
▶ Remove the caps of the valves of a connection pair
(Fig. 14 and 15, [1], [2] and [3]).
▶ Connect the Schrader opener [6] and pressure gauge [4] to the
service socket [1].
▶ Open Schrader valve [1].
▶ Leave valves [2] and [3] closed and fill the pipes with nitrogen until
the pressure is 10% above the maximum operating pressure
(Page 60).
▶ Check whether the pressure is still the same after 10 minutes.
▶ Discharge the nitrogen until the maximum operating pressure is
reached.
▶ Check whether the pressure is still the same after at least 1 hour.
▶ Discharge nitrogen.
Filling the system
NOTICE
Malfunction due to incorrect refrigerant
The outdoor unit is filled with refrigerant R32 at the factory.
▶ If refrigerant needs to be topped up, only use the same refrigerant.
Do not mix refrigerant types.
▶ Evacuate and dry the pipes with a vacuum pump (Fig. 14 and 15,
[5])foratleast 30minutesat roughly−1 bar(approx.500 microns).
▶ Open valve [3] on liquid side.
▶ Use a pressure gaugeto [4] check whether the flow is unobstructed.
▶ Open valve [2] on gas side.
The refrigerant is distributed round the connected pipes.
▶ Afterwards, check the pressure ratios.
▶ Close Schrader valve [1] on the service socket side.
▶ Remove the vacuum pump, pressure gauge and Schrader opener.
▶ Reattach the valve caps.
▶ Reattach the cover for pipe connections to the outdoor unit.
3.6 Electrical connection
3.6.1 General notes
WARNING
Risk to life from electric shock!
Touching live electrical parts can cause an electric shock.
▶ Before working on electrical parts, disconnect all phases of the
power supply (fuse/circuit breaker) and lock the isolator switch to
prevent unintentional reconnection.
▶ Work on the electrical system must only be carried out by an
authorised electrician.
▶ An authorised electrician must determine the correct conductor
cross-section and circuit breaker. The maximum current
consumption of the technical data (see chapter 9, page 60) is
decisive for this purpose.
▶ Observe safety measures according to national and international
regulations.
▶ If you identify a safetyrisk in the mains voltage, or if a short circuit
occurs during installation, inform the operator in writing and do not
install the appliances, until the problem has been resolved.
▶ All electrical connections must be made in accordance with the
electrical connection diagram.
▶ Only use a special tool to cut cable insulation.
▶ Connect the cable to the existing mounting clips / cable glands using
suitable cable ties (scope of delivery).
▶ Do not connect any additional consumers to the mains power supply
of the device.
▶ Do not mix up live and PEN conductor. This can lead to malfunctions.
▶ If the mains power supply is fixed, install an overvoltage protector
and isolator which is designed for 1.5 times the maximum power
input of the appliance.
▶ For devices with a fixed mains power supply in which the leakage
current is potentially higher than 10 mA, we recommend installing a
residual current device (RCD) with a maximum rated residual
operating current of 30 mA.

Installation
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
54
3.6.2 Connecting the indoor unit
Connect CL5000iU 4CC ...
The indoor unit is connected via a 4-wire communication cable. Use
cables of the type H07RN-F with sufficient conductor cross-section.
NOTICE
Material damage can be caused by connecting the indoor unit
incorrectly
Voltage is supplied to every indoor unit via the outdoor unit.
▶ Only connect the indoor unit to the outdoor unit.
▶ Remove the cover of the indoor unit electronics.
▶ Connect the cable of the cover and the communication cable to the
indoor unit (Fig. 26) and secure to the strain relief.
– Plug the cables of the cover into the connections provided.
– With several product types, connect the communication cable to
the terminals L, N, S and 1).
– If necessary, connect other accessories.
▶ Note assignment of communication cable wires to the terminals.
▶ Hook in air inlet grille on one side (Fig. 28).
▶ Reattach the cover of the electronics and close the air inlet grille
(Fig. 29).
▶ Route the cable to the outdoor unit.
Connect CL5000iL 4C ...
The indoor unit is connected via a 4-wire communication cable. Use
cables of the type H07RN-F with sufficient conductor cross-section.
NOTICE
Material damage can be caused by connecting the indoor unit
incorrectly
Voltage is supplied to the indoor unit via the outdoor unit.
▶ Only connect the indoor unit to the outdoor unit.
▶ Remove the cover of the indoor unit electronics.
▶ Connect the cable of the cover to the control unit, (Fig. 27) and
secure to the strain relief.
– Plug the cables of the cover into the connections provided.
– With several product types, connect the communication cable to
the terminals 1(L), 2(N), S and .
– If necessary, connect other accessories.
▶ Hook in air inlet grille on one side (Fig. 28).
▶ Close and secure the air inlet grille with the screw.
▶ Attach the cover of the corners again.
▶ Route the cable to the outdoor unit.
3.6.3 Connecting the outdoor unit
A power supply cable (3-wire) and the communication cable of the
indoor unit (4-wire) are connected to the outdoor unit. Use cables of the
type H07RN-F with sufficient conductor cross-section and protect the
mains power supply with a fuse.
▶ Secure the communication cable to the strain relief and connect to
theterminals1(L), 2(N), S and (assignment of wires to terminals
same as indoor unit) (Fig. 18 and 19).
▶ Attach 1 magnetic ring to the communication cable, as close as
possible to the outdoor unit.
▶ Secure power cable to the strain relief and connect.
– CL5000L ... E: terminals L, N and
– CL5000L ... E-3: terminals L1, L2, L3, N and
▶ Fasten cover for connections.
3.6.4 Connection as twin combination
With the twin combination, two indoor units are connected in series.
Withtheslaveunit,terminalSis omitted.Insteadofthat,communication
takes place between he indoor units via terminals X, Y and E.
Key to Fig. 31 and 32:
IDU-M Master unit (indoor unit 1)
IDU-S Slave unit (indoor unit 2)
▶ Connect master unit as described in chapter 3.6.2.
▶ Connect save unit to the master unit via terminals L, N and 2).
▶ Connect master unit and slave unit additionally to terminals X, Y and
E via a communication cable. In doing so, earth the shield.
Thecentral controllerandtwin combinationbothuse the X/Y/Eterminal.
For this reason, a decision must be made in advance if a twin
combination or central controller is installed.
3.6.5 Connecting external accessories
Table 8
1) L=1(L) and N=2(N). 2) L=1(L) and N=2(N).
Connection Description
CN8 External fan for supply of fresh air
• Integrated power supply for maximum 200 W
or 1 A (relay recommended).
• External fan switches on / off simultaneously
with the fan of the indoor unit.
• In test mode or manual operation, the external
fan remains off.
CN23 On / Off contact switch
• Volt free terminal
• When using jumper connector, remove J6 next
to the connection.
• Open contact:
– Indoor unit off
– Remote control / room controller inactive
(CP in the display)
•Closedcontact:
– Indoor unit on
– Remote control / room controller active
CN33 Alarm signal output
• Volt free terminal
• Connection, maximum 24 V DC, 500 mA
• Open contact: Alarm off
•Closedcontact:Alarmon
CN381)
1) Only CL5000iL 4C ...
For connection of the gateway (WLAN) without
connection accessories
CN40 Connection for room controller

On-site configuration
55
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
4 On-site configuration
4.1 DIP switch setting
WARNING
Risk to life from electric shock!
Touching live electrical parts can cause an electric shock.
▶ Before working on electrical parts, disconnect all phases of the
power supply (fuse/circuit breaker) and lock the isolator switch to
prevent unintentional reconnection.
All DIP switches have been configured before delivery. The default
setting is highlighted bold.
▶ Only professional maintenance personnel should change these
settings.
▶ Improper DIP switch settings may cause condensation, noise, or
unexpected system malfunction.
CL5000iU 4CC ...
CL5000iL 4C ...
Definition of DIP switch 0/1:
Definition 0
Definition 1
ENC1 Code Capacity setting1)
1) Default depending on the model
020
1 26
2 32 - 35
436 - 53
5 54 - 71
772 - 90
8 91 - 105
9109 - 140
A 141 - 160
B161 - 200
S1 S1 Setting S2 Network address
0 - F 0 - 151)
1) Default
0 - F 16 - 31
0 - F 32 - 47
0 - F 48 - 63
DIP switch Definition of DIP Switches1)
1) Default highlighted in bold
Fan OFF temperature when heating (anti-cold air function)
SW1 • [00]: 24°
• [01]: 8 °C
• [10]: 15 °C
• [11]: Reserved
Behaviour of the fan once the room target temperature has been
reached
SW2 • [0]: Fan off
• [1]: Fan on (anti-cold air function deactivated)
Auto restart
SW3 • [0]: Note setting
• [1]: Do no note setting
Set master and slave unit
SW5 • [00]: Master unit only, no slave unit
• [01]: Master unit (heating)
• [10]: Master unit (cooling)
• [11]: Slave unit
Temperature compensation (heating)
SW6 • [00]: 6°C
• [01]: 2 °C
• [10]: 4 °C
• [11]: Reserved
DIP switch Definition of DIP Switches1)
1) Default highlighted in bold
Fan OFF temperature when heating (anti-cold air function)
SW1 • [00]: 24 °C
• [01]: 15 °C
• [10]: 8 °C
• [11]: Reserved
Behaviour of the fan once the room target temperature has been
reached
SW2 • [0]: Fan off
• [1]: Fan on (anti-cold air function deactivated)
Auto restart
SW3 • [0]: Automatic restart on
• [1]: Automatic restart off
Set master and slave unit
SW5 • [00]: Master unit only, no slave unit
• [01]: Master unit (heating)
• [10]: Master unit (cooling)
• [11]: Slave unit
Temperature compensation (heating)
SW6 • [00]: 6°C
• [01]: 2 °C
• [10]: 4 °C
• [11]: Reserved
Default cooling and heating or only cooling
SW7 • [0]: Cooling and heating
• [1]: Cooling only

Commissioning
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
56
5 Commissioning
5.1 Commissioning checklist
Table 9
5.2 Function check
The system can be tested once the installation including tightness test
has been carried out and the electrical connectionhas been established:
▶Connectthepowersupply.
▶ Switch on indoor unit with the remote control.
▶ Switch on cooling mode and set the lowest temperature.
▶ Test cooling mode for 5 minutes.
▶ Switch on heating mode and set the highest temperature.
▶ Test heating mode for 5 minutes.
Observe the operating instructions provided for operation of the indoor
units.
5.3 Handover to the user
▶ When the system has been set up, hand over the installation manual
to the customer.
▶ Explain to the customer how to use the system, referring to the
operation manual.
▶ Advise the customer to carefully read the operation manual.
6Troubleshooting
6.1 Faults with indication (Self diagnosis function)
WARNING
Risk to life from electric shock!
Touching live electrical parts can cause an electric shock.
▶ Before working on electrical parts, disconnect all phases of the
power supply (fuse/circuit breaker) and lock the isolator switch to
prevent unintentional reconnection.
If a fault occurs during operation, the LEDs flash for an extended period
or an error code is displayed (e.g. EH 02).
If a fault is present for more than 10 minutes:
▶ Brieflyinterruptthe powersupplyandswitchtheindoor unit back on.
If a fault persists:
▶ Call customer service and provide the fault code and details of the
appliance.
1 Outdoor unit and indoor units are correctly
installed.
2 Pipes are correctly
•connected,
• thermally insulated,
• and checked for tightness.
3 Electrical connection has been correctly
established.
• Power supply is in the normal range.
• Protective conductor is properly attached.
• Connection cable is securely attached to the
terminal strip.
• Optional external accessories properly
connected and DIP switch correctly set.
• WLAN-Gateway (optional accessories)
Connectioniscorrectandestablishedaccording
to the Gateway installation instructions.
4 Condensate pump and condensate pipe is properly
installed and tested.
5 All covers are fitted and secured.

Troubleshooting
57
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
4C Indoor Unit
Table 10 Fault codes of type 4C indoor unit
4CC Indoor Unit
Table 11 Fault codes of type 4CC indoor unit
Fault code Content
EH 00/EH 0A Indoor unit EEPROM fault
EL 01 Communication fault between outdoor and indoor unit
EH 03 Indoor unit fan outside the normal range (with some units)
EH 60 Temperature sensor T1 (room temperature sensor) switched off or short-circuited
EH 61 Temperature sensor T2 (pipe temperature sensor) switched off or short-circuited
EL 0C Refrigerant leakage detector (with some units)
EH 0b Communication fault of the indoor unit main board
EH 0E Malfunction of the water level alarm
EC 53 Temperature sensor T4 (outside temperature) switched off or short-circuited
EC 52 Temperature sensor T3 (pipe temperature sensor) switched off or short-circuited
EC 54 Temperature sensor TP (compressor discharge temperature protection) switched off or short-circuited
EC 56 Temperature sensor T2B (pipe temperature) switched off or short-circuited
EC 51 Outdoor unit EEPROM fault
EC 07 Outdoor unit fan outside the normal range (with some units)
PC 00 IPM malfunction or IGBT overvoltage protector
PC 01 Overvoltage or low-voltage protection
PC 02 Maximum temperature protection of compressor or high temperature protection of IPM module
PC 04 Compressor control system failure of inverter
PC 03 High or low-pressure protection (with some units)
EC 0d Malfunction of outdoor unit
Content Timer lamp Operation lamp (flashes)
Indoor unit EEPROM fault OFF 1
Communication fault between outdoor and
indoor unit
OFF 2
Indoor unit fan outside the normal range
(with some units)
OFF 4
Temperature sensor T3 (pipe temperature
sensor) switched off or short-circuited
OFF 5
Temperature sensor T4 (outside temperature)
switched off or short-circuited
OFF 5
Temperature sensor TP (compressor discharge
temperature protection) switched off or short-
circuited
OFF 5
Temperature sensor T1 (room temperature
sensor) switched off or short-circuited
OFF 6
Temperature sensor T2 (pipe temperature
sensor) switched off or short-circuited
OFF 6
Refrigerant leakage detector (with some units) OFF 7
Malfunction of the water level alarm OFF 9
Outdoor unit fan outside the normal range
(with some units)
OFF 12
Outdoor unit is faulty
(for old communication protocol)
OFF 14
Outdoor unit EEPROM fault (with some units) ON 5
IPM malfunction FLASH (at 2Hz) 7
Overvoltage or low-voltage protection FLASH (at 2Hz) 2
Maximumtemperature protection of compressor
or high temperature protection of IPM module
FLASH (at 2Hz) 3
High or low-pressure protection
(with some units)
FLASH (at 2Hz) 7
Compressor control system failure of inverter FLASH (at 2Hz) 5

Troubleshooting
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
58
Outdoor Unit
Table 12 Outdoor unit fault codes
6.2 Faults not indicated
Table 13
Fault code Content
EC 51 Outdoor unit EEPROM fault
EL 01 Communication fault between outdoor and indoor unit
PC 40 Communication fault between PCI and printed circuit board of outdoor unit
PC 08 Overcurrent protection of outdoor unit
PC 10 Low-voltage protection of outdoor unit AC voltage
PC 11 Overvoltage protector of DC-bus for outdoor unit PCB
PC 12 Overvoltage protector of DC-bus for outdoor unit PCB/341/MCE fault
PC 00 IPM module protection
PC 0F PFC module protection
EC 71 Overvoltage defect in fan motor (DC current) of outdoor unit
EC 72 Missing phase detection of outdoor unit fan motor (direct current)
EC 07 Fan speed of outdoor unit out of control
PC 43 Phase detection protection of outdoor unit compressor
PC 44 Zero speed protection of outdoor unit
PC 45 IR control failure (outdoor unit)
PC 46 Compressor speed out of control
PC 49 Overvoltage defect in compressor
PC 30 High-pressure protection
PC 31 Low-pressure protection
PC 0A Condenser high-temperature protection
PC 06 Compressor discharge temperature protection
PC 02 Maximum temperature protection of compressor
EC 52 Temperature sensor T3 (pipe temperature sensor) switched off or short-circuited
EC 53 Temperature sensor T4 (outside temperature) switched off or short-circuited
EC 54 Temperature sensor TP (compressor discharge temperature protection) switched off or short-circuited
Fault Possible cause Remedy
The output of the indoor unit is too low. Heat exchanger of the outdoor or indoor unit
contaminated or partially blocked.
▶ Clean heat exchanger of outdoor or indoor
unit.
Shortage of refrigerant ▶ Check tightness of pipes, reseal if required.
▶ Refill refrigerant.
Outdoor unit or indoor unit is not working. No current ▶ Check power connection.
▶ Power on the IDU.
Leakage protector or fuse installed in the
device1) has blown.
1) A fuse for the overcurrent protection is located on the main PCB. The specification is printed on the main PCB and can also be found in the technical data on page 60. Use
only ex-protected ceramic fuses.
▶ Check power connection.
▶ Check the leckage protection and fuse.
Outdoor unit or indoor unit starts and stops
continuously.
Insufficient refrigerant in the system. ▶ Check tightness of pipes, reseal if required.
▶ Refill refrigerant.
Too much refrigerant in the system. Remove refrigerant with refrigerant recovery
unit.
Moisture or impurities in the refrigerant circuit. ▶ Evacuate refrigerant circuit.
▶ Fill with new refrigerant.
Voltage fluctuations too high. ▶ Install voltage regulator.
Defective compressor. ▶ Replace compressor.

Environmental protection and disposal
59
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
7 Environmental protection and disposal
Environmental protection is a fundamental corporate strategy of the
Bosch Group.
The quality of our products, their economy and environmental safetyare
all of equal importance to us and all environmental protection legislation
and regulations are strictly observed.
We use the best possible technology and materials for protecting the
environment taking account of economic considerations.
Packaging
Where packaging is concerned, we participate in country-specific
recycling processes that ensure optimum recycling.
Allofourpackagingmaterialsareenvironmentallycompatibleandcanbe
recycled.
Used appliances
Used appliances contain valuable materials that can be recycled.
Thevarious assemblies canbeeasilydismantled.Syntheticmaterialsare
markedaccordingly.Assembliescanthereforebesortedbycomposition
and passed on for recycling or disposal.
Old electrical and electronic appliances
This symbol means that the product must not be disposed
of with other waste, and instead must be taken to the waste
collection points for treatment, collection, recycling and
disposal.
The symbol is valid in countries where waste electrical and
electronic equipment regulations apply, e.g. "European Directive 2012/
19/EC on old electronic and electrical appliances". These regulations
define the framework for the return and recycling of old electronic
appliances that apply in each country.
As electronic devicesmay contain hazardous substances, it needs to be
recycled responsibly in order to minimize any potential harm to the
environment and human health. Furthermore, recycling of electronic
scrap helps preserve natural resources.
For additional information on the environmentally compatible disposal
of old electrical and electronic appliances, please contact the relevant
local authorities, your household waste disposal service or the retailer
where you purchased the product.
You can find more information here:
www.weee.bosch-thermotechnology.com/
Batteries
Batteries must not be disposed together with your household waste.
Used batteries must be disposed of in local collection systems.
Refrigerant R32
TheappliancecontainsfluorinatedgasR32(globalwarming
potential 6751)) mild combustibility and low toxicity
(A2L or A2).
Contained quantity is indicated on the equipment outdoor
unit name label.
Refrigerant is hazardous to the environment and must be collected and
disposed of separately.
8 Data Protection Notice
We, Bosch Thermotechnology Ltd., Cotswold Way,
Warndon, Worcester WR4 9SW, United Kingdom
process product and installation information,
technical and connection data, communication data,
product registration and client history data to provide
product functionality (art. 6 (1) sentence 1 (b)
GDPR), to fulfil our duty of product surveillance and for product safety
and security reasons (art. 6 (1) sentence 1 (f) GDPR), to safeguard our
rights in connection with warranty and product registration questions
(art. 6 (1) sentence 1 (f) GDPR) and to analyze the distribution of our
products and to provide individualized information and offers related to
theproduct(art.6(1) sentence1 (f)GDPR).To provideservicessuchas
salesand marketingservices,contract management,paymenthandling,
programming, data hostingand hotlineservices we can commission and
transfer data to external service providers and/or Bosch affiliated
enterprises. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located
outside of the European Economic Area. Further information are
provided on request. You can contact our Data Protection Officer under:
Data Protection Officer, Information Security and Privacy (C/ISP),
Robert Bosch GmbH, Postfach 30 02 20, 70442 Stuttgart, GERMANY.
You have the right to object, on grounds relating to your particular
situation or where personal data are processed for direct marketing
purposes, at anytime to processing of your personal data whichis based
onart. 6(1)sentence 1(f) GDPR.Toexerciseyourrights, pleasecontact
us via privacy[email protected] To find further information, please
follow the QR-Code.
1) Based on ANNEX I of REGULATION (EU) No 517/2014 of the European
Parliament and of the Council of 16 April 2014.

Technical data
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
60
9Technicaldata
Table 14 Technical data
Set CL5000iL-Set35 4CCE CL5000iL-Set534CCE CL5000iL-Set 70 4CE
Indoor Unit CL5000iU 4CC 35 E CL5000iU 4CC 53 E CL5000iU 4C 70 E
Outdoor Unit CL5000L 35 E CL5000L 53 E CL5000L 70 E
General
Refrigerant – R32 R32 R32
Design pressure (max./min.) MPa 4.3/1.7 4.3/1.7 4.3/1.7
Cooling
Rated output kW 3.52 5.28 7.03
Rated output kBtu/h 12 18 24
Power input at rated output W 1010 1633 2320
Cooling load (Pdesignc) kW 3.5 5.3 7
Output (min. - max.) kW 0.85-4.11 2.90-5.59 3.30-7.91
Power input (min. - max.) W 168-1434 720-2088 780-2748
Max. current consumption A 4.45 7.2 10.2
Energy efficiency class A++ A++ A++
Coefficient of Performance in cooling mode (SEER) W/W 6.6 6.3 6.2
Heating
Rated output kW 3.81 5.57 7.62
Rated output kBtu/h 13 19 26
Power input at rated output W 1019 1540 1900
Heating load (Pdesignh) kW 2.7 4.2 6
Output (min. - max.) kW 0.47-4.31 2.37-6.10 2.81-8.94
Power input (min. - max.) W 124-1376 700-1930 610-2700
Max. current consumption A 4.73 6.8 8.5
Energy efficiency class A+ A+ A+
Coefficient of Performance in heating mode (SCOP) W/W 4.1 4.0 4.0
Indoor unit
Ex-protected ceramic fuse on main board – T 20A/250V T 20A/250V T 20A/250V
Power infeed V/Hz 220-240 / 50
single phase
220-240 / 50
single phase
220-240 / 50
single phase
Volumetric flow rate (high/medium/low) m3/h 569/485/389 680/584/479 1247/1118/992
Sound pressure level (high/medium/low/noise reduction) dB(A) 42/37.5/34.5/28.5 45.4/44/39/31.6 50/47.5/42/38
Sound power level (high) dB(A) 57 59 59
Permissible ambient temperature (cooling/heating) °C 16...32/0...30 16...32/0...30 16...32/0...30
Total net weight kg 18.8 18.5 27.6
Net weight (casing/cover) kg 16.3/2.5 16.0/2.5 21.6/6.0
Outdoor unit
Maximum power consumption W 1850 2950 3700
Maximum power consumption A 9 13.5 19
Ex-protected ceramic fuse on main board – T 20A/250V T 20A/250V T 20A/250V
Power infeed V/Hz 220-240 / 50
single phase
220-240 / 50
single phase
220-240 / 50
single phase
Vol. flow rate m3/h 2200 2100 3500
Sound pressure level dB(A) 53.6 56 60
Sound power level dB(A) 62 65 69
Permissible ambient temperature (cooling/heating) °C -15...50/-15...24 -15...50/-15...24 -15...50/-15...24
Net weight kg 26.6 32.5 43.9

Technical data
61
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
Table 15 Technical data
Set CL5000iL-Set 88 4CE CL5000iL-Set 105 4CE CL5000iL-Set 105 4CE-3
Indoor Unit CL5000iL 4C 88 E CL5000iL 4C 105 E CL5000iL 4C 105 E
Outdoor Unit CL5000L 88 E CL5000L 105 E CL5000L 105 E-3
General
Refrigerant – R32 R32 R32
Design pressure (max./min.) MPa 4.3/1.7 4.3/1.7 4.3/1.7
Cooling
Rated output kW 8.8 10.5 10.5
Rated output kBtu/h 30 36 36
Power input at rated output W 2750 3950 4000
Cooling load (Pdesignc) kW 8.79 10.55 10.55
Output (min. - max.) kW 2.23-9.38 2.70-11.43 2.70-11.43
Power input (min. - max.) W 190~3000 900-4200 890-4150
Max. current consumption A 12.0 17.5 6.5
Energy efficiency class – A++ A++ A++
Coefficient of Performance in cooling mode (SEER) W/W 6.6 6.7 6.3
Heating
Rated output kW 9.38 11.14 11.14
Rated output kBtu/h 32 38 38
Power input at rated output W 2450 3000 3000
Heating load (Pdesignh) kW 7.8 8.5 8.0
Output (min. - max.) kW 2.70-9.73 2.78-12.30 2.78-12.66
Power input (min. - max.) W 430-2550 800~3950 780~4000
Max. current consumption A 11.0 13.5 5.0
Energy efficiency class – A+ A+ A
Coefficient of Performance in heating mode (SCOP) W/W 4.2 4.0 3.9
Indoor unit
Ex-protected ceramic fuse on main board – T 30A/250V T 30A/250V T 30A/250V
Power infeed V / Hz 220-240 / 50
single phase
220-240 / 50
single phase
220-240 / 50
single phase
Volumetric flow rate (high/medium/low) m3/h 1700/1530/1300 1700/1530/1300 1700/1530/1300
Sound pressure level (high/medium/low/noise reduction) dB(A) 50.5/48/46/40 51/48/46/40.5 510/49/46/40
Sound power level (high) dB(A) 63 64 64
Permissible ambient temperature (cooling/heating) °C 16...32/0...30 16...32/0...30 16...32/0...30
Total net weight kg 30.6 33.2 33.2
Net weight (casing/cover) kg 24.6/6.0 27.2/6.0 27.2/6.0
Outdoor unit
Maximum power consumption W 4500 5000 5000
Maximum power consumption A 20 22.5 10
Ex-protected ceramic fuse on main board – T 30A/250V T 30A/250V T 30A/250V
Power infeed V / Hz 220-240 / 50
single phase
220-240 / 50
single phase
380-415 / 50
three phase
Vol. flow rate m3/h 3800 4000 4000
Sound pressure level dB(A) 62 63 63
Sound power level dB(A) 70 70 70
Permissible ambient temperature (cooling/heating) °C -15...50/-15...24 -15...50/-15...24 -15...50/-15...24
Net weight kg 52.8 66.9 80.5

Technical data
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
62
Table 16 Technical data
Set CL5000iL-Set 125 4CE CL5000iL-Set1404CE-3 CL5000iL-Set1604CE-3
Indoor Unit CL5000iL 4C 125 E CL5000iL 4C 140 E CL5000iL 4C 160 E
Outdoor Unit CL5000L 125 E CL5000L 140 E-3 CL5000L 160 E-3
General
Refrigerant – R32 R32 R32
Design pressure (max./min.) MPa 4.3/1.7 4.3/1.7 4.3/1.7
Cooling
Rated output kW 12.1 14.0 15.3
Rated output kBtu/h 41 48 52
Power input at rated output W 4200 4650 5000
Cooling load (Pdesignc) kW 12.02 14.07 15.24
Output (min. - max.) kW 2.93-12.31 3.52-15.83 4.10-16.71
Power input (min. - max.) W 680-4350 800-5900 980-6200
Max. current consumption A 18.8 8.1 8.6
Energy efficiency class – A++ A++ A++
Coefficient of Performance in cooling mode (SEER) W/W 6.1 6.1 6.3
Heating
Rated output kW 13.48 16.12 18.17
Rated output kBtu/h 46 55 62
Power input at rated output W 3700 4580 5550
Heating load (Pdesignh) kW 9.5 11.0 11.9
Output (min. - max.) kW 3.37-14.07 4.10-17.29 4.40-19.9
Power input (min. - max.) W 750~4250 900 – 5500 1020 – 6700
Max. current consumption A 16.3 8.0 9.6
Energy efficiency class – A+ A+ A+
Coefficient of Performance in heating mode (SCOP) W/W 4.0 4.0 4.0
Indoor unit
Ex-protected ceramic fuse on main board – T 30A/250V T 30A/250V T 30A/250V
Power infeed V / Hz 220-240 / 50
single phase
220-240 / 50
single phase
220-240 / 50
single phase
Volumetric flow rate (high/medium/low) m3/h 1900/1750/1600 1900/1750/1600 2000/1850/1650
Sound pressure level (high/medium/low/noise
reduction)
dB(A) 52.5/50/47.5/40 52.5/50.5/48/41.5 54.5/52/49.5/44
Sound power level (high) dB(A) 66 66 66
Permissible ambient temperature (cooling/heating) °C 16...32/0...30 16...32/0...30 16...32/0...30
Total net weight kg 35.3 35.3 35.3
Net weight (casing/cover) kg 29.3/6.0 29.3/6.0 29.3/6.0
Outdoor unit
Maximum power consumption W 5000 6900 7500
Maximum power consumption A 22.5 13 14
Ex-protected ceramic fuse on main board – T 30A/250V T 30A/250V T 30A/250V
Power infeed V / Hz 220-240 / 50
single phase
380-415 / 50
three phase
380-415 / 50
three phase
Vol. flow rate m3/h 4000 7500 7500
Sound pressure level dB(A) 63 63.5 64
Sound power level dB(A) 72 74 75
Permissible ambient temperature (cooling/heating) °C -15...50/-15...24 -15...50/-15...24 -15...50/-15...24
Net weight kg 71 103.7 107

Технічні характеристики
213
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
1 CL5000L 35~125... 2 CL5000L 140~160...
3 [mm]
ii
1
13
14
2
3
4
5
6
7
812
9
11
10
0010042043-001
ii
1
11
10
13
14
2
3
4
5
6
7
8
12
9
0010042044-001
>1000
>1000
>1000
>1000
0010040090-002

Технічні характеристики
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
214
4 CL5000iU 4CC ...
5 CL5000iL 4C ...
17
6 [mm]
18
A [mm] B [mm] C [mm] D [mm]
CL5000iU 4CC 35 E 647 570 545 523
CL5000iU 4CC 53 E 647 570 545 523
CL5000iU 4C 70 E 950 830 770 670
CL5000iL 4C 88 E 950 830 770 670
CL5000iL 4C 105 E 950 830 770 670
CL5000iL 4C 125 E 950 830 770 670
CL5000iL 4C 140 E 950 830 770 670
CL5000iL 4C 160 E 950 830 770 670
2
1
3
0010040089-002
A
B
C
A
B
D
C
D
B
A
A
B
2
3
1
00100042045-001
A [mm] B [mm] C [mm]
CL5000iU 4CC 35 E 260 600 >290
CL5000iU 4CC 53 E 260 600 >290
CL5000iU 4C 70 E 205 880 >235
CL5000iL 4C 88 E 245 880 >275
CL5000iL 4C 105 E 245 880 >275
CL5000iL 4C 125 E 287 880 >317
CL5000iL 4C 140 E 287 880 >317
CL5000iL 4C 160 E 287 880 >317
0010040091-001
>2500 C
B
A

Технічні характеристики
215
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
7[mm]
19
8
9
10
11
A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
[mm]
CL5000L 35 E 835 765 452 303 555 286
CL5000L 53 E 874 805 511 330 554 317
CL5000L 70 E 955 890 663 342 673 354
CL5000L 88 E 1030 946 673 410 810 403
CL5000L 105 E 1030 946 673 410 810 403
CL5000L 105 E-3 1030 946 673 410 810 403
CL5000L 125 E 1030 946 673 410 810 403
CL5000L 140 E-3 1045 952 634 415 1333 404
CL5000L 160 E-3 1045 952 634 415 1333 404
≥300
C
D
E
≥600
≥300
≥2000
B
A
≥600
0010032599-003
F
≥ 250
H
≥ 3000
A
L≤ ½H →
→
L≤ H
A≥ 250
A≥ 300
L>H
≥ 600
≥ 1500
L
0010033858-002
3
1 2
≤ 6 m
≤ 6 m
0010034026-001
0010032880-001
1.
?
2.
90°
> 50
0010032754-001
1. 2.
3. 4.

Технічні характеристики
Climate 5000L • Climate 5000i U/L – 6721841492 (2022/03)
216
12 CL5000L 35~125...
13 CL5000L 140~160...
14 CL5000L 35~125...
15 CL5000L 140~160...
16 CL5000L 35~125...
17 CL5000L 140~160...
1.
2.
0010032911-001
1.
1.
2.
00100042053-001
0010032916-001
1.
2.
3.
1.
2.
3.
00100042052-001
Lo Hi
2
1
6
4
5
3
0010041912-001
Lo Hi
1
23
4
65
0010042054-001
