Bosch Climate 5000 Series User manual

Service Manual
Ducted Type (Medium & High Static)
Air Conditioner / Heat Pump
Climate 5000 Series
BTC 769102303 A / 11.2022
WARNING:
Installation must be performed by a licensed
contractor, and per the instructions in the
installation manual. Improper installation can
cause water leakage, electrical shock, or fire.
In North America, installation must
be performed in accordance with the
requirement of NEC (National Electric Code)
and CEC (Canadian Electric Code) by licensed
and qualified personnel only.
Only contact a licensed contractor for repair
or maintenance of this unit.

2|
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)

| 3
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
Table of Contents
1 Key to Symbols and Safety Instructions 4
1.1 Key to Symbols 4
1.2 Safety 4
2 Part Names and Model Numbers 6
2.1 Model Numbers 6
3 Dimensions & Clearances 7
3.1 Ducted Indoor Unit 7
3.2 Outdoor Unit 9
4 Refrigerant Cycle Diagrams 10
4.1 115V 12K System, Regular 9K, 12K Systems,
Max Performance 9K, 12K Systems 10
4.2 Regular and Max Performance 18K Systems 10
4.3 Regular 24K, 30KSystems,Max Performance24KSystem 11
4.4 Regular 36K System 11
4.5 Light Commercial 36K, 48K, 60K Systems 12
5 Installation Details 13
5.1 Torque Requirements 13
5.2 Connecting the Cables 13
5.3 Pipe Length and Elevation 13
5.4 First Time Installation 14
5.5 Adding the Refrigerant to an Existing System 14
5.6 Re-Installation / Indoor Unit Needs to be Repaired 15
5.7 Re-Installation Whilethe OutdoorUnit Needstobe Repaired 15
5.8 Operation Characteristics 16
6 Electronic Functions 17
6.1 Abbreviation 17
6.2 Display Function 17
6.3 Main Protection 18
6.4 Operation Modes and Functions 18
7 Troubleshooting 26
7.1 Error Codes - Ducted Indoor Unit 27
7.2 Quick Check by Error Codes 28
7.3 ODU PCB & IPM 29
7.4 Indoor Wiring Diagram 37
7.5 Outdoor Wiring Diagram 46
7.6 Wall Mounted Unit (IDU & ODU) Error Code Diagnosis
and Solution 52
8 Disassembly Guide 80
8.1 Indoor Unit - Medium & High Static Ducted Unit 80
8.2 Outdoor Unit 84

4|
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
1 Key to Symbols and Safety Instructions
1.1 Key to Symbols
Warnings
Warnings in this document are identified by a warning triangle
printed against a grey background.
Keywords at the start of a warning indicate the type and seriousness
of the ensuing risk if measures to prevent the risk are not taken.
The following keywords are defined and can be used in this document:
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor to moderate injury.
NOTICE is used to address practices not related to personal injury.
Important information
This symbol indicates important information where there is no risk to
people or property.
1.2 Safety
Please read safety precautions before installation
Incorrect installation due to ignoring instructions can cause serious damage or
injury.
WARNING: ELECTRICAL HAZARD
Do not modify the length of the power supply cord or use an
extension cord to power the unit.
Do not share the electrical outlet with other appliances.
Improper or insufficient power supply can cause fire or
electrical shock.
WARNING: INSTALLATION REQUIREMENTS
Installation must be performed by a licensed contractor,
and per the instructions in the installation manual. Improper
installation can cause water leakage, electrical shock, or fire.
In North America, installation must be performed in
accordance with the requirement of NEC (National Electric
Code) and CEC (Canadian Electric Code) by licensed and
qualified personnel only.
Only contact a licensed contractor for repair or maintenance
of this unit.
Only use the included accessories, parts, and specified
parts for installation. Using non-standard parts can cause
water leakage, electrical shock, fire, and can cause the unit
to fail.
Install the unit in a solid location that can support the unit’s
weight. If the chosen location cannot support the unit’s
weight, or the installation is not done properly, the unit may
drop and cause serious injury and/or damage.
WARNING:
This product can expose you to chemicals including Lead
and Lead components, which are known to the State
of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.
P65Warnings.ca.gov.

| 5
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
WARNING: ELECTRICAL HAZARD
For all electrical work, follow all local and national wiring
standards, regulations, and the Installation Manual.
The power supply to the outdoor unit requires a service
disconnect at the unit. Only use a dedicated circuit. Never
share a power source connected to this system. Insufficient
electrical capacity or defects in electrical work can cause
electrical shock or fire.
For all electrical work, use the specified cables. Connect
cables tightly, and clamp them securely to prevent external
forces from damaging the terminal. Improper electrical
connections can overheat and cause fire, and may also
cause shock.
All wiring must be properly arranged to ensure that the
control board cover can close properly. If the control board
cover is not closed properly, it can lead to corrosion and
cause the connection points on the terminal to heat up,
catch fire, or cause electrical shock.
In certain functional environments, such as kitchens, server
rooms, etc., the use of specially designed air-conditioning
units is highly recommended.
If the power supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons such as a licensed electrician in order to avoid a
hazard.
The product must be properly grounded at the time of
installation, or electrical shock may occur.
CAUTION: BURN HAZARD
For units that have an auxiliary electric heater, do not
install the unit within 1 meter (3 feet) of any combustible
materials.
Do not install the unit in a location that may be exposed
to combustible gas leaks. If combustible gas accumulates
around the unit, it may cause fire.
Do not operate your air conditioner in a wet room such as a
bathroom or laundry room. Too much exposure to water can
cause electrical components to short circuit.
NOTICE: PROPERTY DAMAGE
Install condensate drainage piping according to the
instructions in this manual. Improper condensate drainage
may cause water damage to your home and property.
CAUTION: CONTAINS REFRIGERANT
This air-conditioning unit contains fluorinated gases. For
specific information on the type of gas and the amount,
please refer to the relevant label on the outdoor unit itself.
Installation, service, maintenance and repair of this unit
must be performed by a certified technician.
Product removal and recycling must be performed by a
certified technician.
If the system has a leak-detection system installed, it must
be checked for leaks at least every 12 months.
When the unit is checked for leaks, proper record-keeping of
all checks is strongly recommended.

6|
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
2 Part Names and Model Numbers
2.1 Model Numbers
Voltage IndoorType Capacity IndoorUnits Regular Outdoor Units Max Performance
OutdoorUnits LightCommercial OutdoorUnits
208-230V Ducted
9k BMS500-AAU009-1AHDXB BMS500-AAS009-1CSXRC BMS500-AAS009-1CSXHC
12k BMS500-AAU012-1AHDXB BMS500-AAS012-1CSXRC BMS500-AAS012-1CSXHC
18k BMS500-AAU018-1AHDXB BMS500-AAS018-1CSXRC BMS500-AAS018-1CSXHC
24k BMS500-AAU024-1AHDXB BMS500-AAS024-1CSXRC BMS500-AAS024-1CSXHC
36k BMS500-AAU036-1AHDXB BMS500-AAS036-1CSXLC
48k BMS500-AAU048-1AHDXB BMS500-AAS048-1CSXLC
60k BMS500-AAU060-1AHDXB BMS500-AAS060-1CSXLC
Table 1

| 7
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
3 Dimensions & Clearances
3.1 Ducted Indoor Unit
3.1.1 Medium Static Pressure (9K, 12K, 18K, 24K, 36K & 48K)
Figure 1
Air filter
Air filter
Air inlet from bottom side
Air inlet from rear side
Fresh air intake
Test mouth & test cover
Ø 0.98 Drain connecting
pipe (for pump)
Ø 0.98 Drain pipe
Gas side
Liquid side
Electric control box
4-install hanger
Capacity unit A B C D E F G H I J K L M H1 H2 W1 W2
9k / 12k inch 27.6 7.9 19.9 17.7 5.4 21.1 1.2 6.0 23.6 7.3 2.0 29.2 14.2 3.3 5.5 3.3 3.3
18k inch 34.6 8.3 26.5 23.6 5.5 27.8 2.0 5.4 30.8 7.5 1.6 36.2 20.0 3.1 5.8 3.5 4.4
24k inch 43.3 9.8 30.5 27.6 5.5 36.5 2.0 6.9 39.4 9.0 0.2 44.9 23.5 3.1 5.9 5.1 6.1
36k inch 53.5 9.8 30.5 27.6 5.5 46.7 2.0 6.9 49.6 9.0 0.2 55.1 23.5 3.1 5.9 5.1 6.1
48k inch 47.2 11.8 34.4 31.5 4.8 41.1 2.0 8.9 43.3 11.0 0.2 48.8 27.4 3.1 5.9 7.3 8.3
Table 2

8|
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
3.1.2 High Static Pressure (60K)
Figure 2
NOTE:16 groups all around
0.2
2 -0.13
11.0
39.4
19.7
39.4
19.7
15.2 (air inlet
duct flange)
(air outlet
duct flange)
46.8 (air inlet duct flange)
56.5 (suspension position)
27.6 (suspension position)
30.3
55.1
440
1.7
0.8
1.7
33.8
1.7
1.7
0.8
0.8
46.8 (air outlet duct flange)
0.8
11.0
15.2
0.4
0.4
Dimensions in inches.

| 9
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
3.2 Outdoor Unit
Figure 3
H
W
A
B
D
A
B
D
A
W
H
Outdoor Model OutdoorUnit Dimensions mm (in.) Mounting Dimensions
W x H x D A mm (in.) B mm (in.)
BMS500-AAS012-0CSXRC, BMS500-AAS009-1CSXRC, BMS500-AAS012-1CSXRC 765x555x303 (30.1”x 21.8”x 11.9”) 454 (17.8”) 286(11.3”)
BMS500-AAS009-1CSXHC, BMS500-AAS012-1CSXHC 805x554x330 (31.7”x 21.8”x 13.0”) 511 (20.1”) 317(12.5”)
BMS500-AAS018-1CSXRC, BMS500-AAS018-1CSXHC, BMS500-AAM018-1CSXRC 890x673x342 (35.0”x 26.5”x 13.5”) 663 (26.1”) 348 (13.7”)
BMS500-AAS030-1CSXRC, BMS500-AAS036-1CSXLC, BMS500-AAS036-1CSXRC,
BMS500-AAS024-1CSXRC, BMS500-AAS024-1CSXHC, BMS500-AAM027-1CSXRC,
BMS500-AAM036-1CSXRC, BMS500-AAM018-1CSXHC, BMS500-AAM027-1CSXHC
946x810x410 (37.2”x 31.9”x 16.1”) 673 (26.5”) 403 (15.9”)
BMS500-AAS060-1CSXLC, BMS500-AAS048-1CSXLC, BMS500-AAM048-1CSXRC,
BMS500-AAM036-1CSXHC, BMS500-AAM048-1CSXHC 952x1333x415 (37.5”x 52.5”x 16.34”) 634 (25.0“) 404 (15.9”)
Table 3
Figure 4
More than 60cm (23.6in)
More than 200cm (79in)
More than 30cm (11.8in)
More than 60cm (23.6in)
(Service space)
Fence or
obstacles
More than 30cm (11.8in)
Outdoor Unit Clearances

10 |
Service Manual
Bosch Climate 5000 Series Ducted Type (Medium & High Static) Air Conditioner / Heat Pump (11.2022)
4 Refrigerant Cycle Diagrams
4.1 115V 12K System, Regular 9K, 12K Systems, Max Performance 9K,
12K Systems
Figure 5
4.2 Regular and Max Performance 18K Systems
Figure 6
For Max Performance 9K, 12K, 18K System, there is no Accumulator.
