Bosch AutoChef NETP666SUC User manual

For help and assistance with Bosch accessories please visit: www.bosch-eshop.com/eshop/bosch/us or call 1-800-944-2904 Mon-Fri 5am to 6pm PST Sat 6am to 3pm PST
Notes: All height, width and depth dimensions are shown in inches. Please refer to installation instructions prior to making cutout. BSH reserves the absolute and unrestricted right
to change product materials and specifications, at any time, without notice. Consult the product’s installation instructions for final dimensional data and other details. Applicable product
warranty can be found in accompanying product literature or you may contact your account manager for further details.
Warranties: Bosch warrants that the Product is free from defects in materials and workmanship for a period of three hundred and sixty-five (365) days from the date of purchase. The foregoing
timeline begins to run upon the date of purchase, and shall not be stalled, tolled, extended, or suspended, for any reason whatsoever. This Product is also warranted to be free from cosmetic
defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the finish of the Product, for a period of thirty (30) days
from the date of purchase or closing date for new construction. This cosmetic warranty excludes slight color variations due to inherent differences in painted and porcelain parts, as well as
differences caused by kitchen lighting, product location, or other similar factors. This cosmetic warranty specifically excludes any display, floor, “As Is”, or “B” stock appliances.
For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904
© BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH.
Benchmark™ Series – Black with Stainless Steel Frame NETP666SUC
36" Electric Cooktop
Element Performance
Power of Front Left
heating element
1,800 W
Power of Back Left
heating element
1,800 W
Power of Center heating
element
3,080 / 2,200 /
1,050 W
Power of Back Right
heating element
1,200 W
Power of Front Right
heating element
1,900 / 800 W
Element Size
Dimension of Front Left
heating element
7"
Dimension of Back Left
heating element
7"
Dimension of Center
heating element
11", 8", 6"
Dimension of Back Right
heating element
6"
Dimension of Front Right
heating element
8", 5"
Technical Details
Watts 9,700 W
Circuit breaker 40 A
Volts 208-240 V
Frequency 60 Hz
Plug type No plug
Energy source Electric
NETP666SUC
Black with Stainless
Steel Frame
Dimensions & Weight
Overall appliance
dimensions (HxWxD)
1/4" +4" x 37"
x 21 1/4"
Required cutout size
(HxWxD) 4" x 34 7/8" x 20"
Minimum distance from
counter front 2 1/4"
Minimum distance from
rear wall 2"
Net weight 33 lbs
Accessories—Optional
The Benchmark™ Series
electric cooktop is sleek
in design, and features
AutoChef® technology to
maintain precise cooking
temperatures.
Features & Benefits
AutoChef® maintains exact
cooking temperatures for
consistent results.
3-zone 11" heating
element features 3000W
of power for fast heating.
Each zone’s timer
automatically shuts off
when cooking is done.
PreciseSelect® offers 17
different direct cooking
level settings.
Bosch-recommended
AutoChef® pan included
via mail-in redemption
card.
HEZ390230
10" AutoChef® pan
HEZ390210
8" AutoChef® pan
HEZ390220
9" AutoChef® pan

For help and assistance with Bosch accessories please visit: www.bosch-eshop.com/eshop/bosch/us or call 1-800-944-2904 Mon-Fri 5am to 6pm PST Sat 6am to 3pm PST
Notes: All height, width and depth dimensions are shown in inches. Please refer to installation instructions prior to making cutout. BSH reserves the absolute and unrestricted right
to change product materials and specifications, at any time, without notice. Consult the product’s installation instructions for final dimensional data and other details. Applicable product
warranty can be found in accompanying product literature or you may contact your account manager for further details.
Warranties: Bosch warrants that the Product is free from defects in materials and workmanship for a period of three hundred and sixty-five (365) days from the date of purchase. The foregoing
timeline begins to run upon the date of purchase, and shall not be stalled, tolled, extended, or suspended, for any reason whatsoever. This Product is also warranted to be free from cosmetic
defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the finish of the Product, for a period of thirty (30) days
from the date of purchase or closing date for new construction. This cosmetic warranty excludes slight color variations due to inherent differences in painted and porcelain parts, as well as
differences caused by kitchen lighting, product location, or other similar factors. This cosmetic warranty specifically excludes any display, floor, “As Is”, or “B” stock appliances.
For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904
© BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH.
Installation Details
30" Built-in oven - under electric cooktop
Notes:
Dimensions based on standard countertop height (36" with 4
3
/
4
" toe kick
including base plate).
The built-in oven can be installed below the electric cooktop as long as there is
no contact between the bottom of the cooktop and the top of the oven.
Measurements in inches (mm)
Cooktop
Built-in Oven
4
11
/
16
" (119)
Cooktop conduit fitting
13
/
16
"
(21)
see notes
24
5
/
8
"
(625)
4
3
/
4
" (121)
6
1
/
16
"
(169)
3"
(76)
3
13
/
16
"
(96)
26
9
/
16
"
(674)
29"
(737)
36"
(915)
28
1
/
4
"
(718)
Installation above Wall Ovens
Benchmark™ Series – Black with Stainless Steel Frame NETP666SUC
36" Electric Cooktop
